Teac CD-P1260 User manual

ENGLISH
3D0787910A
Z
CD-P1260
Compact Disc Player
OWNER’S MANUAL
MODE D’EMPLOI
MANUAL DEL USUARIO
FRANÇAIS ESPAÑOL

2
IMPORTANT SAFETY INSTRUCTIONS
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with
the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider than
the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided
for your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by
the manufacturer, or sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning
storms or when unused for long periods of
time.
14) Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled or objects have
fallen into the apparatus, the apparatus has been exposed to rain
or moisture, does not operate normally, or has been dropped.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.

3
ENGLISH
<Do not expose this apparatus to drips or splashes.
<Do not place any objects filled with liquids, such as vases, on the
apparatus.
<Do not install this apparatus in a confined space such as a book
case or similar unit.
<The apparatus draws nominal non-operating power from the
AC outlet with its POWER or STANDBY/ON switch not in the ON
position.
<The apparatus should be located close enough to the AC outlet so
that you can easily grasp the power cord plug at any time.
<The mains plug is used as the disconnect device, the disconnect
device shall remain readily operable.
<If the product uses batteries (including a battery pack or installed
batteries), they should not be exposed to sunshine, fire or excessive
heat.
<CAUTION for products that use replaceable lithium batteries: there
is danger of explosion if a battery is replaced with an incorrect type
of battery. Replace only with the same or equivalent type.
<Caution should be taken when using earphones or headphones
with the product because excessive sound pressure (volume) from
earphones or headphones can cause hearing loss.
CAUTION
<DO NOT REMOVE THE EXTERNAL CASES OR CABINETS TO EXPOSE
THE ELECTRONICS. NO USER SERVICEABLE PARTS ARE WITHIN.
<IF YOU ARE EXPERIENCING PROBLEMS WITH THIS PRODUCT,
CONTACT TEAC FOR A SERVICE REFERRAL. DO NOT USE THE
PRODUCT UNTIL IT HAS BEEN REPAIRED.
<USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT
IN HAZARDOUS RADIATION EXPOSURE.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
CAUTION Regarding Placement
To maintain proper ventilation, be sure to leave a space around
the unit (from the largest outer dimensions including projections)
equal to, or greater than, shown below.
Left and Right Panels: 20 cm (8”)
Rear Panel: 10 cm (4”)
Top Panel: 5 cm (2”)
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the equipment and/or the receiving
antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
CAUTION
Changes or modifications to this equipment not expressly
approved by TEAC CORPORATION for compliance will void the
user’s warranty.
For U.S.A.
This product has been designed and manufactured according to
FDA regulations “title 21, CFR, chapter 1, subchapter J, based on the
Radiation Control for Health and Safety Act of 1968“, and is classified
as class 1 laser product. There is not hazardous invisible laser radiation
during operation because invisible laser radiation emitted inside of
this product is completely confined in the protective housings.
The label required in this regulation is as follows:
For U.S.A.
Optical pickup
Type : SF-P101VZ
Manufacturer : Sanyo Electric Co., Ltd
Laser output : Less than 1 mW on the objective lens
Wavelength : 790 ±30 nm
MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS
and Thomson.

4
Before UseContents
Read this before attempting any operations.
<Since the unit may become warm during operation, always leave
sufficient space around the unit for ventilation.
Make sure there is at least 8” (20 cm) of space above and at least 2”
(5 cm) of space on each side of the unit. Do not place anything on
top of the unit.
<When this unit is on, turning on a TV nearby might cause lines to
appear on the TV screen, depending on the frequency of the TV
broadcast. This is not a malfunction of the unit or the TV. If you see
such lines, place this unit farther away from the TV set.
<During playback, since the disc is revolving at high speed, do not
lift or move this unit. Doing so could damage the disc.
<Always remove the disc before relocating or moving this unit.
Moving the unit with a disc inside it could cause malfunction.
<The voltage supplied to the unit should match the voltage that is
printed on the rear panel. If you are in any doubt regarding this
matter, consult an electrician.
<Choose the installation location of your unit carefully. Avoid placing
it in direct sunlight or close to a source of heat. Also avoid locations
that are subject to vibrations or excessive dust, heat, cold or
moisture.
<Do not place the unit on an amplifier or receiver or any other
device that generates heat.
<Do not open the cabinet as this might result in damage to the
circuitry or cause electrical shock. If a foreign object should get
into the unit, contact your dealer or service company.
<When removing the power plug from the wall outlet, always pull
directly on the plug. Never yank on the cord.
<To keep the laser pickup clean, do not touch it and always close the
disc tray.
<Do not attempt to clean the unit with chemical solvents as they
might damage the finish. Use a clean, dry or slightly damp cloth.
<Keep this manual in a safe place for future reference.
Thank you for choosing this TEAC product. Read this manual
carefully to get the best performance from this unit.
BeforeUse .......................................................4
RemoteControlUnit .............................................5
Connections .....................................................5
Discs .............................................................6
IdentifyingtheParts(MainUnit)..................................8
Identifying the Parts (Remote Control Unit) .......................9
BasicOperation................................................ 10
Repeat Playback.................................................13
Shuffle Playback.................................................14
Intro Check......................................................14
ProgramPlayback...............................................15
Search Mode (MP3 Disc Only)....................................18
Troubleshooting................................................20
Specifications .................................................. 21
MP3DiscPlaybackOrder....................................... 21

5
ENGLISH
Caution:
<Turn off the power of all the equipment before making
connections.
<Read the instructions of each component that you intend to use
with this unit.
<Be sure to insert each plug securely. To prevent hum and noise, do
not bundle connection cords with power cords.
A
LINE OUT jacks
An analog 2-channel audio signal is output from these jacks.
Connect it to the CD input jacks of an amplifier with RCA cables.
Be sure to connect:
White plug qWhite jack (L: left channel)
Red plug qRed jack (R: right channel)
B
AC Power Cord
After all other connections are complete, connect the plug to an
AC wall outlet.
Be sure to connect the power cord to an AC outlet that supplies
the correct voltage.
Hold the power plug when plugging or unplugging the power
cord. Never pull or yank on the power cord.
Voltage Selection
Be sure to remove the power cord from the AC outlet before changing
the position of the voltage selector switch.
1. Locate the VOLTAGE SELECTOR switch on the rear panel.
2. Using a flat-bladed screwdriver, set to the appropriate position
(230 V or 120 V) for the power supply used in your area.
IN NORTH AMERICA USE ONLY ON 120 V SUPPLY.
Amplifier
ConnectionsRemote Control Unit
The included remote control allows this unit to be operated from a
distance.
When using the remote control, point it towards the remote sensor on
the front panel of the main unit.
<Even if the remote control unit is used within its effective range,
operation by remote control might be impossible if there are any
obstacles between the unit and the remote control.
<If the remote control unit is operated near other devices that
generate infrared rays, or if other remote controls that use infrared
rays are operated near the unit, this unit might operate incorrectly.
The other devices might also operate incorrectly.
Battery Installation
1. Remove the battery compartment cover.
2. Insert two AA (R6 or SUM-3) dry batteries. Make sure that they are
inserted with their positive (+) and negative (_) poles oriented
correctly.
3. Close the cover.
Battery Replacement
If the distance from the main unit that the remote control works
effectively decreases, the batteries are probably exhausted. Replace
the batteries with new ones when this happens.
For more information about the collection of batteries, please contact
your local municipality, your waste disposal service or the place where
you purchased them.
Precautions concerning batteries
<Be sure to insert the batteries with correct positive (+) and
negative (_) orientations.
<Use batteries of the same type. Never use different types of
batteries together.
<Both rechargeable and non-rechargeable batteries can be used.
Refer to the precautions on their labels.
<If the remote control will not be used for a long time (more than a
month), remove the batteries to prevent them from leaking.
<If the batteries leak, wipe away the leakage inside the battery
compartment and replace the batteries with new ones.
<Do not use batteries of types other than those specified. Do not
mix new batteries with old ones or use different types of batteries
together.
<Do not heat or disassemble batteries. Never throw batteries into
fire or water.
<Do not carry or store batteries with other metallic objects. The
batteries could short circuit, leak or explode.
<Never recharge a battery unless it is confirmed to be a rechargeable
type.

6
Discs that can be played on this unit:
Caution:
Playback of any other type of disc could cause loud noise and
damage to speakers as well as harm hearing. Never play back any
other type of disc.
<Depending on the quality of the disc and/or the condition of the
recording, some discs might not be playable.
<Video CDs, CD-ROMs and similar types of discs can be read by the
unit, but they will make no sound when played back.
<Video and audio DVDs, DVD-ROMs and other types of DVDs
cannot be read and played back by this unit.
Caution:
If you put a video or audio DVD, DVD-ROM or other DVD into
the disc tray, the unit will attempt to read the disc and rotate at
high speed. If you accidentally insert such a disc, wait until the
unit stops spinning before ejecting it in order to avoid possibly
damaging the disc. (Do not attempt to remove the disc when
“” appears on the screen.)
<Copy-protected discs and other discs that do not conform to the
CD standard might not play correctly in this player. If you use such
discs in this unit, TEAC Corporation and its subsidiaries will not
be responsible for any consequences or guarantee the quality of
reproduction. If you experience problems with such non-standard
discs, you should contact their issuers.
About CD-R/CD-RW discs
This unit can play back CD-R and CD-RW discs that have been
recorded in the audio CD format (CD-DA).
<Discs created by a CD recorder must be finalized before use with
this unit.
<Depending on disc quality and recording conditions, playback of
some discs might not be possible. Please see the manual for the
device that you used to create the disc.
<If you are uncertain about the handling of a CD-R or CD-RW disc,
please contact the seller of the disc directly.
CDs that bear the (12cm/8cm) “COMPACT disc DIGITAL AUDIO”
logo.
CD-R and CD-RW discs that have been correctly recorded in
the audio CD format and finalized.
Finalized CD-R and CD-RW discs that contain MP3 files.
Caution:
<Do not play any disc that is warped, deformed or damaged.
Playing such discs could cause irreparable harm to the playing
mechanisms.
<Printable CD-R and CD-RW discs are not recommended because
their label sides could be sticky and damage the unit.
<Do not stick papers or protective sheets on the discs and do not
use any protective coating sprays.
<Use a soft oil-based felt-tipped pen to write information on the
label side. Never use a ball-point or hard-tipped pen, as this could
cause damage to the recorded side.
<Never use a stabilizer. Using commercially available CD stabilizers
with this unit will damage the mechanisms and cause them to
malfunction.
<Do not use irregularly-shaped discs (octagonal, heart-shaped,
business card size, etc.). CDs with these shapes could damage the
unit.
Handling precautions
<Always place the disc on the disc tray with the label side up. Only
one side of a Compact Disc can be played or used for recording.
<To remove a disc from its storage case, press down on the center of
the case and lift the disc out, holding it carefully by the edges.
How to remove the disc How to hold the disc
Storage precautions
<Discs should be returned to their cases after use to avoid dust and
scratches that could cause the laser pickup to “skip.”
<Do not expose discs to direct sunlight or high-temperature
and humidity for extended periods. Long exposure to high
temperatures will warp discs.
<CD-R and CD-RW discs are more sensitive to the effects of heat
and ultraviolet rays than ordinary CDs. It is important that they
are not stored in locations where they will be exposed to direct
sunlight. They should also be kept away from sources of heat, such
as radiators and heat-generating electrical devices.
Discs

7
ENGLISH
Maintenance
<If a disc becomes dirty, wipe its surface radially from the center
hole outward towards the outer edge with a soft, dry cloth.
<Never clean discs using chemicals such as record sprays, antistatic
sprays and fluids, benzene and thinner. Such chemicals will do
irreparable damage to the disc’s plastic surface.
If you are in any doubt as to the care and handling of a CD-R or
CD-RW disc, read the precautions supplied with the disc or contact
the disc manufacturer.
About MP3 files
This unit can play MP3 files that are on CD-R/CD-RW discs.
< This unit can play back monaural and stereo MP3 files that are in
the MPEG-1 Audio Layer 3 format with a sampling rate of 44.1 or 48
kHz and a bit rate of 320 kbps or less.
< This unit is not compatible with discs that have been recorded
using multiple sessions. Only the first session can be played back.
File information display
The display of this unit can only show single-byte letters and
numbers.
< If a file information uses Japanese, Chinese or other double-byte
characters, playback is possible but the name will not be shown
correctly. In such cases, “ ” is displayed.
Cautions when preparing MP3 files using a computer or other
device
<Always include the extension in the file name. This unit recognizes
MP3 files by their “.mp3” file extensions.
<Always close the session (complete disc creation). This unit cannot
play discs if the session has not been closed.
<Carefully read the manual for the software that you are using when
you create an MP3 disc.
Discs that are unplayable or only partially playable
<Files without extensions cannot be played. Files that are not in the
MP3 format cannot be played even if they have extensions.
<Variable bit rate files might not play back correctly.
<If the disc has more than 500 files or 200 folders, this unit can only
play back the first 500 files and files in the first 200 folders.
<Depending on disc conditions, this unit might not be able to play a
disc or skipping might occur.

8
APOWER
Press this button to turn the unit on and off.
BDisc tray
COPEN/CLOSE
Press this button to open and close the disc tray.
DPlay/Pause (y/J)
Press this button to start or pause CD/MP3 playback.
EStop (H)
Press this button to stop CD/MP3 playback.
FSkip (.//)/Search (m/,)
Press these buttons to skip through tracks/files.
Hold down these buttons to search for a part of a track/file.
GMP3 FOLDER (
‡/°)
During playback of an MP3 disc, use these buttons to select
folders on the disc.
HPROGRAM
Use this button to program tracks/files.
IREPEAT
Use this button to enable repeat playback.
JSHUFFLE
Use this button to enable shuffle playback.
KDisplay
LRemote Sensor
When operating the remote control, point it towards here.
MPHONES jack/LEVEL knob
To listen with headphones, turn the LEVEL knob to minimize the
volume level before connecting the headphones plug to the
PHONES jack. Then, adjust the volume after connecting the plug.
Connected speakers will make no sound when headphones are
plugged in.
Caution:
Do not connect headphones with the PHONES jack while
wearing them. Moreover, do not disconnect headphones
or turn the unit on or off while wearing them. Very loud
sound could be output from the headphones.
AVOID DAMAGING YOUR HEARING
- Do not put on
headphones until after plugging them in.
Identifying the Parts (Main Unit)
ABCDE F
G
H
I
J
K
L
M

9
ENGLISH
Identifying the Parts (Remote Control Unit)
A
F
G
H
I
J
B
C
D
E
ANumber buttons
Use these buttons to select tracks/files.
BESP/MP3
During CD playback, use this button to turn the ESP function on
or off.
When playing an MP3 disc, use this to change the display of file
information.
This button is also used in MP3 search mode.
CINTRO CHECK
Use this button to start using the Intro Check function.
DMP3 FOLDER (
‡/°)
During playback of an MP3 disc, use these buttons to select a
folder on the disc.
ESKIP (.//)/SEARCH (m/,)
Press these buttons to skip through tracks/files.
Hold down these buttons to search for a part of a track/file.
FPROGRAM
Use this button to program tracks/files.
GSHUFFLE
Use this button to enable shuffle playback.
HREPEAT
Use this button to enable repeat playback.
ISTOP (H)
Use this button to stop CD/MP3 playback.
JPLAY/PAUSE (y/J)
Use this button to start or pause CD/MP3 playback.
Note:
To simplify explanations, instructions in this manual might refer to the
main unit or remote control only. In such cases, the same controls on
the remote control and main unit will operate similarly.

10
Basic Operation (1)
1Press the POWER switch to turn the unit on.
< Playback begins automatically if a disc is already inserted.
2Press the OPEN/CLOSE button (L) to open the tray.
3Place a disc on the tray with the label side up.
< Never place more than one disc on the tray.
< The disc must be centred on the disc tray. If the disc is not
correctly loaded, it might not be possible to open the tray again
after it has been closed. Confirm that the disc is always centered
on the tray before closing it.
< Do not force the tray by hand when opening and closing it.
4Press the OPEN/CLOSE button (L) to close the tray.
< After closing the tray, loading the disc takes a few seconds. No
buttons will work while loading. Wait until the total number of
tracks/files is displayed.
< When no disc is loaded in the CD player, “ ” is
displayed.
When an audio CD is loaded
When an MP3 disc is loaded
5Press the Play/Pause button (y/J) to start playback.
Playback starts from the first track/file on the disc.
< MP3 files that are not in folders are automatically put in the
“ROOT” folder. Playback starts from the first file in the ROOT
folder.
< When playback of all the tracks/files has finished, the unit stops
automatically.
< See page 21 for information about the playback order of MP3
discs.
Total tracks Total playing time
Total number of folders
Total number of files

11
ENGLISH
Suspending playback temporarily
(Pause mode)
Press the Play/Pause button (G/J) during playback to stop
playback at the current position. To resume playback, press the
Play/Pause button (G/J) again.
Stopping playback
Press the Stop button (H) to stop playback.
Search for a part of a track/file
Hold down
During playback, hold down a Search button (mor ,) to
search a part of a track/file. Release it when you find the beginning
of the part you want to hear.
Skipping to an earlier or later track/file
During playback
Press a Skip button (.//) repeatedly until the desired track/
file is selected. The selected track/file will be played from the
beginning.
When playback is stopped
Press a Skip button (.//) repeatedly to select the track/file
you want to hear. Then, press the Play/Pause button (G/J) to start
playback of the selected track/file.
<If the .button is pressed once during playback, the track/file
being played will be played again from the beginning. To return
to the beginning of the previous track/file, press the .button
twice.
<During program playback, tracks/files in the program are selected
and played.
Direct Playback
When stopped or playing back, you can use the Number buttons on
the remote control to select tracks/files.
Select a track/file using the Number buttons, and press the PLAY/
PAUSE (G/J) button within 10 seconds to start playback of the
selected track/file.
Examples:
To playback track/file 7
To playback track/file 23
<Direct playback is not possible during shuffle playback and
program playback.

12
Listening with headphones
To listen with headphones, turn the LEVEL knob to minimize the
volume level before connecting the headphones plug to the
PHONES jack. Then, adjust the volume after connecting the plug.
Connected speakers will make no sound when headphones are
plugged in.
Caution:
Do not connect headphones with the PHONES jack while
wearing them. Moreover, do not disconnect headphones or
turn the unit on or off while wearing them. Very loud sound
could be output from the headphones.
AVOID DAMAGING YOUR HEARING
- Do not put on
headphones until after plugging them in.
ESP (Electronic Shock Protection)
The ESP function stores music in a buffer to prevent sound from
skipping.
This function can be turned on or off when playing an audio
CD. During playback of MP3 files, this function is always on.
During CD playback, press the ESP button to turn this function on
and off. When you turn ESP on, “ “ (20 seconds) briefly
appears, and the ESP indicator is shown on the display.
<The ESP indicator blinks while the unit is filling the buffer.
<We recommend that you place this unit in a stable location that is
free from vibration and turn the ESP function off when playing an
audio CD.
Displaying MP3 information
Hold down
more than 1sec.
During playback of an MP3 disc, press the MP3 button for more
than 1 second to show information about the current file as
follows:
File name wTitle wArtist wAlbum
Press the MP3 button for more than 1 second again to cancel the
MP3 information mode.
<“
” appears when there is no information.
<“
” appears when the unit cannot read the
information.
<The display of this unit can only show single-byte letters and
numbers. If a file name uses Japanese, Chinese or other double-
byte characters, playback is possible but the name will not be
shown correctly. In such cases, “ ” is displayed.
Skip to the next folder (MP3)
Press the MP3 FOLDER buttons (‡/°)to skip folders.
Basic Operation (2)

13
ENGLISH
Press the REPEAT button to cycle through the following playback
modes:
When an audio CD is loaded.
REPEAT REPEAT ALL
(off)
When an MP3 disc is loaded.
REPEAT REPEAT ALL
(off)
REPEAT ALBUM
<If one of the following buttons is pressed, the repeat mode will be
canceled:
Main unit
POWER, OPEN/CLOSE (L), Stop (H), SHUFFLE
Remote control unit
STOP (H), SHUFFLE, INTRO CHECK
Repeat one track/file (REPEAT)
The track/file being played will be played repeatedly.
Press the REPEAT button once during ordinary playback. “REPEAT”
appears on the display.
<If you press the Skip button (.or /) to select another track/
file, the selected track/file will be played repeatedly.
<You can select a track/file to be repeated when playback is
stopped. Press the REPEAT button, select a track/file using a Skip
button (.or /), and then press the Play/Pause button
(G/J) to start playback.
Repeat all tracks/files (REPEAT ALL)
All the tracks/files on the disc will be played repeatedly.
Press the REPEAT button twice during ordinary playback. “REPEAT
ALL” appears on the display.
<During program playback, the programmed tracks/files will be
played repeatedly.
Repeat all the files in the folder (REPEAT ALBUM) (MP3 only)
All the files in the selected folder will be played repeatedly.
Press the REPEAT button three times during ordinary playback.
“REPEAT ALBUM” appears on the display.
Repeat Playback

14
The tracks/files on a disc can be played in random order.
Press the SHUFFLE button in the stop mode. “SHUFFLE” appears on
the display.
<If you press the /button during shuffle playback, the next
track/file will be randomly selected and played. If you press the
.button, the currently played track/file will be played from the
beginning. During shuffle playback, a track/file that has completed
playback will not be played again.
<During shuffle playback, tracks/files cannot be selected using the
Number buttons.
<Repeat playback is not possible during shuffle playback.
<After all tracks/files have been played once, playback ends and
shuffle mode is cancelled.
<If one of the following buttons is pressed, shuffle mode will be
cancelled:
Main unit
POWER, OPEN/CLOSE (L), Stop (H), SHUFFLE
Remote control unit
STOP (H), SHUFFLE, INTRO CHECK
Shuffle Playback
Ten seconds of the beginning of each track/file can be played back in
succession.
Press the INTRO CHECK button during playback or when stopped.
The INTRO indicator appears on the display, and 10 seconds of the
beginning of each tracks/files is played.
When you find the track/file that you want to hear, press the INTRO
CHECK button again to resume normal playback.
<To skip to an earlier or later track/file, press a SKIP button (. or
/).
<Press the INTRO CHECK button during ordinary playback to start
checking the beginnings of tracks/files from the currently playing
track/file.
<Repeat playback and shuffle playback cannot be used with the
intro check function. (The first 10 seconds of each track/file cannot
be played back repeatedly or shuffled.)
<After the beginning of every track/file has been checked, playback
stops and the intro check mode is canceled.
<If one of the following buttons is pressed, intro check mode will be
cancelled:
Main unit
POWER, OPEN/CLOSE (L), Stop (H), SHUFFLE
Remote control unit
STOP (H), SHUFFLE, INTRO CHECK
Intro Check

15
ENGLISH
Up to 64 tracks/files can be programmed in the desired order.
1Press the PROGRAM button when playback is stopped.
CD
MP3
The MEMORY indicator appears, showing that program mode is
enabled.
< To stop programming, press the STOP button (H).
2(When programming with an MP3 disc)
Press the Number buttons to select a folder, then press
the PROGRAM button.
< You can also use the SKIP buttons (.//) to select folders.
< MP3 files not located in a specific folder are in the “01” (ROOT)
folder.
3Press the Number buttons to select a track/file, then
press the PROGRAM button.
The track/file is programmed, and “P-02” is displayed.
< You can also use the SKIP buttons (.//) to select tracks/
files.
< Repeat steps 2and 3to program more tracks/files.
< You can program up to 64 tracks/files.
< To stop programming, press the STOP button (H). Programming
is cancelled, but the program contents are retained in memory.
To restart program playback, press the PROGRAM button, and
then press the PLAY/PAUSE button (G/J).
4When the selection of track/file numbers is completed,
press the PLAY/PAUSE button (G/J) to start program
playback.
< After program playback finishes, press the PLAY/PAUSE button
(y/J) to play the program again.
< Pressing the POWER button or the OPEN/CLOSE button (L)
causes the program content to be discarded.
< The shuffle function does not work during program playback.
< During program playback, tracks/files cannot be selected using
the Number buttons.
Program Playback (1)

16
Adding tracks/files to the end of the program
In the stop mode, press the PROGRAM button repeatedly until
“00” appears on the display.
Press repeatedly
Select a track/file number using the Number buttons, and then
press the PROGRAM button.
<You can also use the SKIP buttons (.//) to select track/file
numbers.
The track/file is added to the end of the program.
Overwriting part of the program
When playback is stopped, press the PROGRAM button repeatedly
until the program number to be changed appears on the
display.
Press repeatedly
Program number
to be changed
Select a track/file number using the Number buttons, and then
press the PROGRAM button.
<You can also use the SKIP buttons (.//) to select track/file
numbers.
The newly selected track/file is added to the program.
Program Playback (2)

17
ENGLISH
Checking the program order
Press repeatedly
When playback is stopped, press the PROGRAM button repeatedly.
The numbers of the programmed tracks/files and their program
numbers will be shown in order.
Exiting program mode
Hold down
more than 1sec.
When playback is stopped, press and hold the PROGRAM button
more than 1 second. The MEMORY indicator will disappear.
<The contents of the program are not cleared. Press the PROGRAM
button again and then press the Play/Pause button (y/J) to
restart program playback.
Clearing the program
Hold down
more than 1sec.
When playback is stopped, press and hold the STOP button (H)
more than 1 second. The MEMORY indicator will disappear.
<If the MEMORY indicator is not shown, press the PROGRAM button
to activate program mode before clearing the program.
The contents of the program are also cleared if the POWER or
OPEN/CLOSE button (L) is pressed.

18
You can search for, select and play files by name.
<If a file name uses Japanese, Chinese or other double-byte
characters, “ ” is displayed and the search function will
not work accurately.
Search for the name of a file
1Press the MP3 button during playback or when stopped.
The SEARCH indicator blinks, and the first letter of the file name,
the file name and the file number are shown.
File name File number
First letter of le name
< Press the Stop button (H) to exit search mode. (This also stops
playback when playing.)
Pressing the MP3 button twice also exits search mode (and stops
playback when playing).
< “” appears when there is no information.
2Select the first letter of the file you want to hear by
pressing the SKIP buttons (.//).
< Press /to search forward from A to Z and then 0 to 9, and
press .to search backward from 9 to 0 and then Z to A.
Search Mode (MP3 Disc Only)
3When you reach the letter that is the first letter of the file
that you want to hear, press and hold a SKIP button
(.//) until the first letter blinks.
Hold down
4Press the SKIP buttons (.//) to search through the
files that start with the selected letter until you find the
file that you want to play.
< To return to selection of the first letter (as shown in the
illustration in step 1), press and hold a SKIP (.or /)
button.
5Press the PLAY/PAUSE button (G/J).
Playback starts from the selected file.

19
ENGLISH
Search for a file in a folder
1Press the MP3 button twice during playback or when
stopped.
Press twice
The SEARCH and ALBUM indicators light and the folder name
and folder number are shown.
Folder name
Folder number
< Press the Stop button (H) to exit search mode. (This also stops
playback when playing.)
Pressing the MP3 button twice also exits search mode (and stops
playback when playing).
< “” appears when there is no information.
2Press the SKIP buttons (.//) to find the folder that
contains the file that you want to hear.
< Press /to search forward from A to Z and then 0 to 9, and
press .to search backward from 9 to 0 and then Z to A.
< MP3 files not located in a specific folder are in the “01” (ROOT)
folder.
3When you find the folder that contains the file that you
want to play, press and hold a SKIP button (.or /)
until the ALBUM indicator disappears.
Hold down
File name
< To return to selection of the folder (as shown in the illustration in
step 1), press and hold a SKIP button (. or /).
4Select the file in the folder by pressing the SKIP buttons
(.//).
< If you press the PLAY/PAUSE button (y/J) before selecting a
file, playback will start from the first file in the selected folder.
5Press the PLAY/PAUSE button (G/J).
Playback starts from the selected file.

20
If you experience any problems with the unit, please take a moment
to read through this page and try to solve the problem yourself before
you call your dealer or a TEAC service center.
No power
eCheck the connection to the AC power source. Confirm that the
AC source is not a switched outlet, and, if it is, that the switch
is turned on. Confirm that there is power to the AC outlet by
plugging another item such as a lamp or a fan into the outlet.
Remote control does not work
ePress the POWER switch of the main unit to turn it on.
eIf the batteries are exhausted, change the batteries.
eUse the remote control within the effective range (16 ft/5 m) and
point it toward the remote sensor on the front panel.
eMake sure that there are no obstacles between the remote
control and the main unit.
eTurn off any fluorescent lights near the unit.
No sound
eCheck the connection to the amplifier.
eCheck the operation of the amplifier.
Will not play
eLoad a disc with the label side up.
eIf the disc is dirty, clean its surface.
eIf a blank disc has been loaded, load a prerecorded disc.
eDepending on the disc and other factors, playback of some
CD-R/RW discs might not be possible. Try again with another
disc.
eYou cannot play unfinalized CD-R/RW discs. Finalize such a disc in
a CD recorder and try again.
Sound skips
ePlace the unit in a stable place to avoid vibrations and shocks.
eWhen using the unit in a place where vibration is unavoidable,
turn the ESP anti-skipping function on (see page 12).
eIf the disc is dirty, clean its surface.
eDo not use scratched, damaged or warped discs.
Since this device uses a microcontroller, external noise and
other interference can cause the unit to malfunction. If this
occurs, turn the power off and restart the operation after
waiting about a minute.
Beware of condensation
Condensation could occur when the unit (or a disc) is moved from
a cold to a warm place, or used after a sudden temperature change.
Vapor in the air could condense on the internal mechanisms, making
correct operation erratic or impossible. To prevent this, or if this
occurs, leave the unit for one or two hours with its power turned on.
The unit will stabilize at the temperature of its surroundings.
Maintenance
If the surface of the unit gets dirty, wipe it with a soft cloth or use
diluted mild liquid soap. Never spray liquid directly on this unit. Apply
cleaner to the cleaning cloth and wipe gently. Be certain to remove
any excess completely. Do not use thinner, benzene or alcohol as they
could damage the surface of the unit. Allow the surface of the unit to
dry completely before using.
Troubleshooting
