Teac AG-H350 User manual

AAGG--HH335500
SERVICE MANUAL
AV Digital Home Theater Receiver
Effective : March, 2002 S-0053A
NOTES
●PC boards shown are viewed from parts side.
●The parts with no reference number or no parts number in the
exploded views are not supplied.
●As regards the resistors and capacitors, refer to the circuit diagrams
contained in this manual.
●£Parts marked with this sign are safety critical components. They
must be replaced with identical components - refer to the appropriate
parts list and ensure exact replacement.
●Parts of [ ] mark can be used only with the version designated.
[J]:JAPAN[US]:U.S.A.[C]:CANADA[E]:EUROPE[UK]:U.K.
注 意
●プリント基板図は部品面を示しています。
●分解図に部番のない部品および品番のない部品は供給できま
せん。
●標準の抵抗、コンデンサーは省略してあります。
回路図を参照してください。
●£印は安全重要部品です。
交換する時は必ず指定の部品を使用してください。
●仕向先
[J]:JAPAN[US]:U.S.A.[C]:CANADA[E]:EUROPE[UK]:U.K.
CONTENTS
1 SPECIFICATIONS ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・2
2 EXPLODED VIEWS AND PARTS LIST ・・・・・・・・・・・・・・・・・4
3 PC BOARDS AND PARTS LIST ・・・・・・・・・・・・・・・・・・・・・・・・6
4 INCLUDED ACCESSORIES ・・・・・・・・・・・・・・・・・・・・・・・・・・・12
目次
1仕 様 ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・2
2分解図とパーツリスト ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・4
3基板図とパーツリスト ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・6
4付属品 ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・12

1 SPECIFICATIONS
−2−
仕 様
Amplifier Section
Output Power (Stereo)
50 watts RMS per channel minimum, both channels
driven into 8 ohms from 20 Hz to 20kHz with no more than
0.9% total harmonic distortion
Surround Output Power (0.9 % THD, 1 kHz, 8 ohms):
30 + 30 watts (Front)
30 watts (Center)
30 + 30 watts (Rear)
Total Harmonic Distortion (Stereo):
0.02% (at 50 watts, 1 kHz)
Delay Time:
DOLBY DIGITAL: REAR 0 – 15 ms
CENTER 0 – 5 ms
DOLBY PRO LOGIC: REAR 15 – 30 ms
Audio Input Sensitivity/Impedance:
*LINE: 250 mV/47 k ohms
Output Level/Impedance:
VCR/TAPE, CDR/MD: 230 mV / 2.2 k ohms
Frequency Response:
*LINE: 20 Hz – 65 kHz, +1 / –3 dB
Signal-to-Noise Ratio:
*LINE: 85 dB (IHF-A)
Tone Control:
BASS: ± 10 dB at 100 Hz
TREBLE: ± 10 dB at 10 kHz
Digital Audio Section
Sampling Frequency:
32 kHz, 44.1 kHz, 48 kHzz
DIGITAL Input Level/Impedance:
COAXIAL: 0.5 Vp-p / 75 ohms
OPTICAL: –15 dBm to –21 dBm
Video Section
Input Sensitivity/Impedance:
1.0 Vp-p / 75 ohms
Output Level/Impedance:
1.0 Vp-p / 75 ohms
FM Tuner Section
(Without notes 100.1 MHz, 65 dBf)
Tuning Range:
87.5 MHz – 108.0 MHz (100 kHz steps) [U.S.A./Canada model]
87.5 MHz – 108.0 MHz (50 kHz steps) [Europe/U.K. model]
AM Suppression Ratio: 45 dB
Total Harmonic Distortion (1 kHz):
Mono: 0.4%
Stereo: 0.5%
Frequency Response:
30 Hz – 15 kHz, +1/ –1.5 dB
Stereo Separation (1 kHz): 40 dB
Signal-to-Noise Ratio:
Mono: 75 dB
Stereo: 70 dB
AM Tuner Section
Tuning Range:
530 kHz – 1,720 kHz (10 kHz steps) [U.S.A./Canada model]
522 kHz – 1,620 kHz (9 kHz steps) [Europe/U.K. model]
Usable Sensitivity: 55 dB/m
Total Harmonic Distortion:
0.8% at 85 dB/m
Signal-to-Noise Ratio:
45 dB at 85 dB/m
General
Power Requirements:
120 V AC, 60 Hz [U.S.A./Canada model]
230 V AC, 50 Hz [Europe/U.K. model]
Power Consumption:
2.2A [U.S.A./Canada model]
260 W [Europe/U.K. model]
Dimensions (W x H x D)
215 x 143 x 388 mm (8-7/16" x 5-5/8" x 15-1/4")
Weight (net): 7.6 kg (16-3/4 lbs)
Standard Accessories:
AM Loop Antenna x 1
FM T-type Antenna x 1 [U.S.A./Canada model]
FM Matching Transformer x 1 [U.S.A./Canada model]
FM Lead-type Antenna x 1 [Europe/U.K. model]
Remote Control Unit (RC-821) x 1
*LINE means VCR/TAPE, DVD, SAT/AUX, CD-R/MD and CD.
<Improvements may result in specifications and features
changing without notice.

−3−
■アンプ部
ステレオ出力(0.9%THD,1kHz,8Ω)......................80W+80W
サラウンド出力(0.9%THD,1kHz,8Ω)
フロント ..............................................................30W+30W
センター............................................................................30W
リア ......................................................................30W+30W
ディレイタイム
ドルビーデジタル........................................リア：0〜15ms
センター：0〜5ms
ドルビープロロジック ............................リア：15〜30ms
周波数特性 ........................*ライン :20Hz〜65kHz,+1/−3dB
SN比............................................................*ライン :85dB(IHF-A)
全高調波歪率(80W、1kHz、ステレオ)..............................0.02%
入力感度/インピーダンス .................. *ライン :200mV/47kΩ
出力レベル/インピーダンス ................................................................
VCR/TAPEOUT:185mV/2.2kΩ
CD-R/MDREC:185mV/2.2kΩ
トーンコントロール ............................BASS:±10dB(100Hz)
TREBLE:±10dB(10kHz)
■デジタルオーディオ部
サンプリング周波数 ..........................32kHz、44.1kHz、48kHz
デジタル入力レベル/インピーダンス
OPTICAL1,2(光) ........................−15dBm〜−21dBm
COAXIAL(同軸) ..........................................0.5Vp-p/75Ω
■FMチューナー部
受信周波数..................76.0MHz〜90.0MHz(100kHzステップ)
AM抑圧比 ..................................................................................45dB
高調波歪み率(1kHz)
モノ ..................................................................................0.4%
ステレオ ..........................................................................0.5%
周波数特性 ......................................30Hz〜15kHz,+1/−1.5dB
ステレオセパレーション(1kHz)..............................................40dB
S/N比(1kHz)
モノ..................................................................................75dB
ステレオ ..........................................................................70dB
■AMチューナー部
受信周波数 ........................522kHz〜1,620kHz(9kHzステップ)
実用感度 ................................................................................55dB/m
高調波歪み率 ..........................................................0.8%(85dB/m)
S/N比......................................................................45dB(85dB/m)
■ビデオ部
入力感度/インピーダンス ........................................1.0Vp-p/75Ω
出力レベル/インピーダンス ....................................1.0Vp-p/75Ω
■共通
電源................................................................ AC100V、50-60Hz
消費電力 ....................................................................................170W
外形寸法 (mm) .................................. 215(W)x143(H)x388(D)
質量............................................................................................ 7.6kg
■付属品
リモコン(RC-821)
リモコン用乾電池（単4）x2本
AMループアンテナ
変換アダプター
FM室内アンテナ
取扱説明書
保証書
*ライン :VCR/TAPE、DVD、SAT/AUX、CD-R/MD、CD
仕様及び外観は改善のため予告なく変更することがあります。

−4−
1
2
3
4
5
6
7
9
10
12
14
15
11
16
17
18
19
20
21
22
24
25
26
27
28
29
30
29
30
31
32
34
35
36
37
38
40
41
39
44
45
23
13
42
33
2 EXPLODED VIEWS AND PARTS LIST
分解図とパーツリスト

−5−
EXPLODED VIEW LIST
REF.NO. PARTSNO. DESCRIPTION REMARKS
1 9A09277500 WINDOW,FIP KGU1A154W
2 9A09277200 VOLUMEKNOBASSY KGK1A068ZA
3 9A08738700 ORNAMENT,FUNCTION KGX1A290C11
4 9A07286800 KNOB,LEVEL KBN1A098M9K79
5 9A06697400 VOLUMECAPASSY(C) KGX2A218ZA
6 9A06677900 BADGE KGB1A047
7 9A09279900 PANEL,FRONT(AL) KKM2A113YC11
9 9A09277000 ORNAMENR,DOOR(AL) KGK1A066ZC11
10 9A09277400 DOOR,SUB KGR1A244M9K79
11 9A09276400 KNOB,ROTARY KBN1A146M9K79
12 9A09280400 HOLDER,DOOR(R) KMH1A138M9
13 9A09280500 HOLDER,DOOR(L) KMH1A139M9
14 9A09280300 LOCKER,DOOR KMH1A137M9
15 9A09277300 INDICATOR,FUNCTION KGL1A194
16 9A06863300 INDICATOR,STANDBY KGL1A133
17 9A09277700 PANEL,SUB KGW1A320M9YK79
18 9A07287200 CAP,STANBY KBT1A495M9K79
19 9A06862500 KNOB,STANDBY KBT1A483
20 9A07287000 KNOB,TACT KBT1A492M9K79
21 9A06863501 WINDOW,SENSOR KGU1A261
22 9A07290100 SUPPORT,LED KMD1A376
23 9A05326800 RUBBER KHG1A024
24 9A09276900 DAMPERGEARASSY KDG1A006W
25 9A09283000 SPRING,DOOR KUS1A127
26 9A09276300 KNOB,OPEN KBC1A136M9K79
27 9A09282900 SPRING,OPEN KUS1A126
28 9A09282400 CHASSIS,BOTTOM KUA1A205
29 9A06864400 FOOT KKL2A055M9K63
30 9A05837300 FOOTCUSHION KHG1A050Y
31 9A09280800 HEATSINK(B) KMY1A186
32 9A07290000 BRACKET,FLT KMD1A374
33 9A07434300 KNOB,POWER[E,UK] KBC1A098M9K79
34 9A09276600 KNOB,SELECTOR KBT1A773M9K79
35 9A09276500 KNOB,BAND KBT1A772M9K79
36 9A09280200 BRACKET,PCB KMD1A450
37 9A09279700 CABINET,TOP KKC1B121S21
38 9A09280700 HEATSINK(A) KMY1A183
39 9A09279800 REARPANEL[J] KKF1A227X
9A09279810 REARPANEL[US,C] KKF1A227Y
9A09279820 REARPANEL[E,UK] KKF1A227Z
40£9A09280100 TRANSFORMER,POWER[J] KLT5U017ZJ
£9A09280110 TRANSFORMER,POWER[US,C] KLT5U017ZU
£9A09280120 TRANSFORMER,POWER[E,UK] KLT5U017ZE
41 9A09275100 FAN,MOTOR BDMKD1206PTS3
42 9A05921700 RUBBER KHG1A113
44£9A06754900 BUSHING,ACCORD KHR1A028
45£9A08144000 POWERCORD[J] BJA2J049Z
£9A08043100 POWERCORD[US,C] BJA523FBY
£9A08152100 POWERCORD[E] BJA2B043Z
£9A09267600 POWERCORD[UK] BJA2E045Z
F601£9A06814200 FUSE[J] KBA2C5000TLJ
F601£9A09306400 FUSE,5A250V[US,C] KBA2C5000TLU
F601£9A09297300 FUSE,[E,UK] KBA2C5000TLE
9A09275300 TUNERMODULE[J] BNVTFCE1J101A
9A09306200 TUNERMODULE[US,C] BNVTFCE1U116A
9A09296900 TUNERMODULE[E,UK] BNVTFCE1E320A
9A08038100 RING,FERRITE[US,C,E,UK] KLZ9W001Z

−6−
3 PC BOARDS AND PARTS LIST
MAIN PCB
基板図とパーツリスト

−7−
SURROUND PCB

−8−
FRONT PCB

−9−
MAIN PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
9A09281200 MAINPCBASSY[J]
9A09281210 MAINPCBASSY[US,C]
9A09281220 MAINPCBASSY[E,UK]
9A09282500 PCB,MAIN
9A09275100 FAN,MOTOR
9A09280200 BRACKET,PCB
9A09280700 HEATSINK(A)
9A09280900 HEATSINK,DIODE
BD51‑BD55 9A07050600 BEAD,CORE
BR01 9A07308700 BRACKET,PCB
BR61 9A05333900 PLATE,EARTH
C589£9A05938300 C,ELECT470UF/25V
C593£9A08032200 C,LINEACROSS0.1UF/250V
C615,C616£9A08034300 C,ELECT2200UF/35V
C618,C619£9A05922400 C,ELECT6800UF/63V
CN23 9A07889700 WAFER,MOLEX35336‑0610
CN53,CN54 9A07330100 WAFER
CN55 9A05330300 WAFER,MOLEX53014‑0810
CN58 9A05329100 WAFER,MOLEX5267‑03A
CN59 9A09279300 WAFER
CN64 9A05328900 WAFER,MOLEX5267‑02A
CN68 9A06785000 WAFER,MOLEX35328‑02
CN69 9A06674400 WAFER
CN72 9A08036800 WAFER,MOLEX35336‑1410
CN76 9A05330400 WAFER,MOLEX53014‑0910
D501,D502 9A05193600 DIODE,ZENERMTZJ15BT
D503,D504 9A01390500 DIODE,1N4148MT
D505 9A05193600 DIODE,ZENERMTZJ15BT
D506 9A01390500 DIODE,1N4148MT
D507,D508 9A05193600 DIODE,ZENERMTZJ15BT
D509,D510 9A01390500 DIODE,1N4148MT
D512‑D516 9A01390500 DIODE,1N4148MT
D517£9A06759900 DIODE,KBU804F
D518£9A05194600 DIODE,1N4003SRT
D520 9A06236200 DIODE,ZENERMTZJ6.2BT
D521 9A05194600 DIODE,1N4003SRT
D522,D523 9A06236200 DIODE,ZENERMTZJ6.2BT
D524‑D532 9A01390500 DIODE,1N4148MT
D533‑D535£9A05194600 DIODE,1N4003SRT
D536,D537 9A01390500 DIODE,1N4148MT
ET01 9A05333900 PLATE,EARTH
F601 9A05328200 HOLDER,FUSE
IC51£9A09275800 IC,NJM7812FA
IC52£9A09275900 IC,NJM7912FA
IC53‑IC55 9A09275700 IC,NJM2279MTE1
IC56 9A07343300 IC,NJM2068MD‑TE1
JK51 9A09278700 TERMINAL,SP(RRRR/BBBB)
JK52 9A07426900 TERMINAL,SP(R/B)
JK58‑JK62 9A09278800 JACK,S‑VIDEO+VHS
L503‑L507 9A08037300 COIL,0.5UHK
Q501 9A05196800 TR,KSC2316‑Y‑SHTA
Q502 9A03745100 TR,KSA1175‑YTA
Q503,Q504 9A05341600 TR,KSA992‑FTA
Q505,Q506 9A03745000 TR,KSC2785‑YTA
Q507 9A05196700 TR,KSA916‑Y‑SHTA
MAIN PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
Q508 9A05196800 TR,KSC2316‑Y‑SHTA
Q509 9A03745100 TR,KSA1175‑YTA
Q510,Q511 9A05341600 TR,KSA992‑FTA
Q512,Q513 9A03745000 TR,KSC2785‑YTA
Q514 9A05196700 TR,KSA916‑Y‑SHTA
Q515 9A05196800 TR,KSC2316‑Y‑SHTA
Q516,Q517 9A05341600 TR,KSA992‑FTA
Q518 9A03745100 TR,KSA1175‑YTA
Q519,Q520 9A03745000 TR,KSC2785‑YTA
Q521 9A05196700 TR,KSA916‑Y‑SHTA
Q522,Q523 9A05196800 TR,KSC2316‑Y‑SHTA
Q524,Q525 9A03745100 TR,KSA1175‑YTA
Q526‑Q529 9A05341600 TR,KSA992‑FTA
Q530,Q531 9A03745000 TR,KSC2785‑YTA
Q532 9A05196700 TR,KSA916‑Y‑SHTA
Q533,Q534 9A03745000 TR,KSC2785‑YTA
Q535 9A05196700 TR,KSA916‑Y‑SHTA
Q536 9A08745700 TR,KTC2026Y
Q537£9A05359800 TR,KTD998O
Q538£9A05359700 TR,KTB778O
Q539 9A08745700 TR,KTC2026Y
Q540£9A05359800 TR,KTD998O
Q541£9A05359700 TR,KTB778O
Q542 9A08745700 TR,KTC2026Y
Q543£9A05359800 TR,KTD998O
Q544£9A05359700 TR,KTB778O
Q545 9A08745700 TR,KTC2026Y
Q546£9A05359800 TR,KTD998O
Q547£9A05359700 TR,KTB778O
Q548 9A08745700 TR,KTC2026Y
Q549£9A05359800 TR,KTD998O
Q550£9A05359700 TR,KTB778O
Q551 9A05197200 TR,KTA1271YT
Q552,Q553 9A03745000 TR,KSC2785‑YTA
Q554 9A08791100 TR,KRC107M
Q555 9A08791000 TR,KRA107M
Q556‑Q558 9A08791100 TR,KRC107M
Q559 9A09283100 TR,KRA102MT
Q560 9A08791000 TR,KRA107M
Q561£9A05196800 TR,KSC2316‑Y‑SHTA
Q562 9A08791100 TR,KRC107M
Q564£9A08745700 TR,KTC2026Y
Q565£9A09283400 TR,KTA1046Y
Q566,Q567 9A08791000 TR,KRA107M
Q568 9A08791000 TR,KRA107M
R591£9A05896300 R,0.22OHM5W
R592£9A06234600 R,METALOXIDEFILM
R593,R594£9A05896300 R,0.22OHM5W
R595£9A06234600 R,METALOXIDEFILM
R596£9A05896300 R,0.22OHM5W
R597£9A06234600 R,METALOXIDEFILM
R598,R599£9A05896300 R,0.22OHM5W
R600£9A06234600 R,METALOXIDEFILM
R601£9A05896300 R,0.22OHM5W
R602£9A06234600 R,METALOXIDEFILM

−10−
MAIN PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
R603‑R605£9A05896300 R,0.22OHM5W
R621‑R624£9A05338000 R,METAL10OHM1WJ
R625,R626£9A07892200 R,METAL330OHM1WJ
R627£9A05338000 R,METAL10OHM1WJ
R639£9A06761000 R,CARBON3.3MK1/2W[US,C]
RY51,RY52 9A07326100 RELAY
RY53 9A09275400 RELAY
RY54 9A07326100 RELAY
RY55£9A09275400 RELAY
SW61 9A09275600 SW,SLIDE
T501£9A09280000 TRANS,SUB[J]
T501£9A09280010 TRANS,SUB[US,C]
T501£9A09280020 TRANS,SUB[E,UK]
THR1 9A08039800 THERMALSENSOR,POSISTOR
WF51 9A09279000 HOUSING
WF52 9A09279200 HOUSING,ANGLE
WF53,WF54 9A07330200 HOUSING,ANGLE
WF73 9A05329700 WAFER,MOLEX53014‑0610
SURROUND PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
9A09281300 SURROUNDPCBASSY[J]
9A09281310 SURROUNDPCBASSY[US,C]
9A09281320 SURROUNDPCBASSY[E,UK]
9A09282600 PCB,SURROUND
BD11 9A07050600 BEAD,CORE
CN20 9A09279500 WAFER,CARDCABLE
CN22 9A07890800 WAFER,CARDCABLEGF120‑2
CN23 9A07889700 WAFER,MOLEX35336‑0610[E,UK]
CN25 9A05330300 WAFER,MOLEX53014‑0810
CN31 9A07890800 WAFER,CARDCABLEGF120‑2
CN32 9A08220000 WAFER,CARDCABLE
CN33 9A09279500 WAFER,CARDCABLE
CN34 9A07890800 WAFER,CARDCABLEGF120‑2
CN51 9A09278900 WAFER
CN52 9A09279100 WAFER
CN73 9A05330900 WAFER,MOLEX53014
D100 9A01390500 DIODE,1N4148MT
D300 9A06765300 DIODE,MTZJ5.6BT
D301 9A06236100 DIODE,ZENERMTZJ4.7BT
D302 9A01390500 DIODE,1N4148MT
IC10 9A08033700 IC,YSS912
IC11 9A08903900 IC,AK4527VQ
IC12 9A08032900 IC,256KSRAM
IC13 9A08948100 IC,AK4112VF
IC14 9A07044300 IC,TC74HCU04AFN
IC20‑IC23 9A07343300 IC,NJM2068MD‑TE1
IC25 9A09276100 IC,TC9215AF
IC26 9A08033500 IC,TC9482F
IC27 9A07424801 IC,TC9163AF
IC28‑IC31 9A07343300 IC,NJM2068MD‑TE1
SURROUND PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
JK10 9A06239100 MODULE,OPTICAL
JK11 9A09278500 JACK,BOARD
JK12,JK13 9A09275200 MODULE,OPTICAL(RX)
JK20 9A09278600 JACK,BOARD
JK21,JK22 9A07289400 JACK,BOARD
JK23 9A06230200 JACK,REMOTE(2P)
L100,L300 9A05356900 COIL,10UHK
L301 9A07330400 COIL
L302 9A08037600 COIL,PEAKING
L303,L304 9A05356900 COIL,10UHK
Q106 9A08791100 TR,KRC107M
Q107 9A08791000 TR,KRA107M
Q110‑Q115 9A05197500 TR,KTD1302T
Q300 9A05196700 TR,KSA916‑Y‑SHTA
Q301 9A08791000 TR,KRA107M
Q302 9A05196800 TR,KSC2316‑Y‑SHTA
Q303 9A08745700 TRKTC2026Y
Q401 9A06183000 TR,KSC945YT[E,UK]
Q402 9A09283200 TR,KRA111M
R360£9A05896400 R,4.7OHM1W
R361£9A05338000 R,METAL10OHM1WJ
S001 9A04882400 SW,TACT
WF10 9A08036900 WAFER,MOLEX35237‑1410
[J,US,C]
WF23 9A07889800 CONNECTOR,MOLEX35237‑0610
[J,US,C]
WF59 9A09279400 CONNECTOR
WN11 9A09279500 WAFER,CARDCABLE
X300 9A08039000 CRYSTAL
X400 9A07501700 CRYSTAL[E,UK]
FRONT PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
9A09281400 FRONTPCBASSY[J]
9A09281410 FRONTPCBASSY[US,C]
9A09281420 FRONTPCBASSY[E,UK]
9A09282700 PCB,FRONT
9A07290000 BRACKET,FLT
9A07290100 SUPPORT,LED
C768£9A06764800 C,ELECT100UF/50V
C772£9A06764800 C,ELECT100UF/50V
C773£9A08882700 C,CERAMIC(KHTYPE)[E,UK]
CN11 9A09279600 WAFER,CARDCABLE
CN22 9A07890900 WAFER,CARDCABLEGF120‑21S‑L
CN53 9A06785000 WAFER,MOLEX35328‑02[E,UK]
CN56 9A05892600 WAFER,9P
CN57 9A05329600 WAFER,MOLEX5267‑06A
CN66 9A05938500 WAFER,3P
CN71 9A05356300 WAFER,04GA19ZM
CN74 9A06676900 WAFER
CN77 9A06250600 WAFER,02GA19ZM
D701 9A01390500 DIODE,1N4148MT[J]
D701‑D703 9A01390500 DIODE,1N4148MT[US,C]

FRONT PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
D703,D704 9A01390500 DIODE,1N4148MT[E,UK]
D707‑D710 9A01390500 DIODE,1N4148MT
D712‑D717 9A08131100 LED,YELLOWSLR342YCTB7
D720 9A08131100 LED,YELLOWSLR342YCTB7
D721‑D724£9A05194700 DIODE,1N4003ST
D725 9A06236200 DIODE,ZENERMTZJ6.2BT
D726 9A05194700 DIODE,1N4003ST
D727 9A05193800 DIODE,ZENERMTZJ33BT
D728 9A05194700 DIODE,1N4003ST
D729‑D731 9A01390500 DIODE,1N4148MT
F701,F702£9A06760000 FUSE,LEADF6A250V
FIP1 9A08034600 FIP,SVA‑10MS11
IC72 9A08033200 IC,MC74HC14D
IC73 9A09276000 IC,NJU3713G
IC75 9A09276200 IC,TMP87PS71AF
IC76,IC77 9A07343300 IC,NJM2068MD‑TE1
JK01 9A06861800 JACK,HEADPHONE
L701 9A05356900 COIL,10UHK
Q702 9A03747300 TR,KSB811‑YTA
Q703 9A08791000 TR,KRA107M
Q704 9A08791100 TR,KRC107M
Q705 9A08791000 TR,KRA107M
R771,R772£9A06760900 R,FUSE0.47OHM1WJ
RC71 9A08563600 SENSOR,REMOCON
RY71 9A09275500 RELAY
S701 9A04882500 SW,TACTSKHV10910A
S704‑S715 9A04882500 SW,TACTSKHV10910A
SW71£9A06784700 SW,PUSH[E,UK]
VR01,VR02 9A09283600 R,VARIABLE
VR03 9A09283500 R,VARIABLE
VR04 9A06224700 VR,ENCODOR
VR05 9A08124200 VR,ENCODER
X702 9A05193000 CRYSTAL
−11−

4 INCLUDED ACCESSORIES
−12−
付属品
INCLUDED ACCESSORIES
REF.NO. PARTSNO. DESCRIPTION REMARKS
9A08901400 OWNER'SMNL,J[J] KQX1A722Z
9A08901200 OWNER'SMNL,E/F[US,C] KQX1A710Z
9A08901300 OWNER'SMNL,E/F/G/I/S[E,UK] KQX1A709Z
9A09148000 REMOTECONTROLASSY,RC‑821 KARTAGH550
9A08153900 BATTERY[J] KABAAM1.5V
9A01397000 ANTENNATERMINAL[J,US,C] KSA267
9A08046100 ADAPTOR,75‑300[J,US,C] KLR1T201
9A04883100 ANT,FMWIRE[E,UK] KSA1A007
9A09282200 ANT,AMLOOP KSA3A013Z
