Teal Handeman Xtra User manual

HMX 110v 2_2021
Handeman Xtra 110V
Installation and operating
instructions
Manufactured by:
Teal Patents Limited
Unit 2, Waterloo Avenue
Chelmsley Wood Industrial Estate
irmingham 37 6QQ
Telephone: [phone]
Email: [email protected]

IMPORTANT SAFETY INSTRUCTIONS
Before us ng th s appl ance, read all nstruct ons
and fam l ar se yourself w th the operat on of the
un t
1. This appliance can be used by children aged from
eight (8) years and above, persons with reduced
physical, sensory or mental capabilities, or persons
with lack of experience and knowledge only if they
have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the ha ards involved. Cleaning and user
maintenance shall not be made by children without
supervision.
2. Children should be supervised to ensure that they
do not play with the appliance.
3. The unit should only be used in accordance with
these instructions. Do not carry out any
maintenance other than is shown in these
instructions or as advised by Teal Patents service
support.
4. Do not handle the plug with wet hands.
5. Do not use with a damaged cable or plug. If the
supply cable is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualied
persons, in order to avoid a ha ard.
6. If the appliance is not working as it should, has been
dropped, damaged or submerged in water do not
use. Contact the seller or Teal Patents.
7. Do not dismantle the unit or attempt to repair the
unit.
8. This equipment is for heating water for
handwashing only. It is not designed for washing of
crockery or other items.
9. Water dispensed is not suitable for drinking.
10. Water is dispensed at a temperature of 38-40˚C.
11. The appliance must be connected to a 110V power
supply.
12. The unit must be protected by a fuse rated at 3
amps.
13. If used outdoors the equipment should be
protected by an RCD.
14. Cable should be placed in such a way to avoid trip
ha ards.
15. Do not stretch the cable and beware of sharp
corners which may damage the cable.
16. Unit may be wall mounted: if so, use the provided
ttings for a solid brick wall. If mounting on an
alternative type of wall, ensure that you use
appropriate ttings.
17. Unit should be positioned where it does not
obstruct walkways or access to services.
18. Unit must only be lled with clean cold water.
19. Do not overll, only ll to the level of the bae.
20. The unit should not be operated without water.
21. Waste water is discharged from the base of the unit.
A suitable container must be in place to collect this
water.
22. Any spillages should be cleaned-up as soon as
possible to avoid slipping ha ards.
23. Waste water should be disposed of to a foul drain.
24. Keep unit away from direct heat sources.
25. Unit should not be left switched on when the
building is unoccupied.
26. Do not alter the unit in any way this will invalidate
the warranty and may make it unsafe to operate.
Box contents
Before nstall ng the un t check that all parts are
present and undamaged.
In the event of any shortages or damaged items contact
the retailer.
Do not attempt to use substitute parts except as stated
in these instructions.
Contents consist of:
•1 Handeman Xtra unit with pre-tted mains cable
•Carrying strap tted to the unit
•1 ttings pack consisting of:
•4 rawlplugs and 4 mounting screws
•4 mounting spacers
•1 drilling template.

Parts dent cat on
Lid
Plug hole
Lid seal
Upper
mounting holes
D scla mer
Teal Patents has a policy of continual
improvement in product quality and
design.
The company
reserves the right to
change the
specication of its
models at any time.
Lower
mounting holes
Carrying
handle
Indicator light
Reset button
Bowl
Bae
Water drainage slot
Tap
Mains cable
Rear of bowl
Back of Handeman Xtra
Removable
rubber cover

Fill the unit with cold water until water can be seen
below the bae.
Do not use pre-heated water as this may damage the
unit.
Do not overll – if there is water above the bae use the
tap to reduce the water level before operating.
Close lid and ensure seal is fully engaged.
Connect to a mains power source to switch on the unit.
An orange LED indicates that the power is connected.
Allow to heat up for approximately 15 minutes.
The green LED will light to indicate water is at the
correct temperature.
Use tap to discharge water to wash hands.
If a continuous ow of water is required fully depress
the tap lever.
Waste water will drain into the hollow bowl.
To remove waste water, detach the bowl and lift it out.
Tip the water from the water drainage slot on the front
edge of the bowl into a foul water drain and replace.
Rinse with clean water.
When the water tank is empty of water the red LED will
light.
Disconnect the unit and allow to cool before relling.
LED d splay
The unit has an LED display to indicate the status.
ORANGE - this indicates the water is heating up.
GREEN - indicates the water is up to temperature and
ready to use.
SOLID RED – low water level.
FLASHING RED - fault – see Troubleshooting Guide
below.
Wall Mount ng Or Free Stand ng
This unit has been designed for wall mounting or to be
placed on any rm, at, level surface.
Before xing to a wall, check that you have all the parts
listed.
The rawlplugs provided are suitable for use in a solid
brick wall. If mounting on an alternative type of wall,
ensure that you use appropriate ttings.
Before commencing installation check that you have
appropriate tools and a suitable workspace.
Failure to follow these instructions may result in
personal injury, damage to the product or damage to
property.
Check that there are no hidden service pipes or cables in
the area where you intend to drill.
If you are unsure consult a suitable qualied installer.
Ensure that the position of the unit allows sucient
space for the opening of the lid and the safe opening of
the bowl.
Using the supplied template identify the locations for
the 4 mounting screws.
Drill holes using an 7mm diameter drill bit.
Fit rawlplugs in each hole.
Mount the unit using the 4 screws and mounting
spacers provided.
Note: the bowl must be removed to provide access to
the two lower mounting holes. Lift the lid to access the
upper mounting holes.
Do not overtighten xings as this may damage the unit.
Take care not to drop tools or xings into the unit.
Check that the unit is upright and level before lling.
Electr cal Connect on
This unit must be connected to a mains power supply
using the plug provided.
Do not attempt to replace the plug or hard wire the unit
unless you are competent electrician.
Waste Water
All Handeman models have removable bowl that retains
all the dirty water.
There is no need for a separate waste pipe or waste
water storage container.
FAILURE TO FOLLOW THESE INSTRUCTIONS MAY INVALIDATE YOUR WARRANTY.
Installat on
Operat ng nstruct ons

Empty the detachable bowl to a foul water drain and
rinse with clean water.
If unit is left unused for an extended period it is
recommended that it is emptied of water and
replenished with fresh water.
Clean all surfaces with an anti-bacterial wipe or
disinfectant paying particular attention to frequent
contact points. To clean the inside of the bowl, rst take
o the removable rubber cover.
Do not use abrasive cleaners which may scratch the
external surfaces.
It is recommended that the unit is cleaned with a
cleaning solution such as Milton according to the
instructions on a weekly basis.
Towel holder ref HM/TH
Soap bottle and bracket ref SS/SDB
Clean ng nstruct ons
All Teal Patents products are tested before leaving the
factory.
The unit is covered by a two year return to manufacturer
warranty from date of purchase – please ensure that you
retain proof of purchase.
Any faulty items will be repaired or replaced, and the
repairs guaranteed for the remainder of the original
warranty period.
Should a unit need repair, those repairs only will be
covered by a further 12 months warranty.
Exclus ons
Teal Patents will not be liable to repair or replace goods
where:
•The fault has been caused through misuse,
accidental damage, use contrary to the
manufacturers instructions, damage in transit or
power surges.
•The appliance has been used on a voltage supply
other than that specied on the product
•Repairs have been attempted by someone other
than Teal Patents or an authorised dealer
•The appliance is second hand
•The warranty does not cover any claims for
consequential loss or damage.
This guarantee does not eect your statutory rights as a
consumer.
Guarantee
No water d spensed. Check water level in tank
Water cold. Check Orange LED is on. If not, check power
supply. If LED is on leave unit for 15 minutes to fully heat
water. If water is still cold unplug unit and return to
supplier.
Red LED sol d. Unit cut-out activated.
•Low water.
•Check water level. Rell if required and press
and release reset button
•Unit tilted.
•Return unit to upright position. Rell if
required and press and release reset button.
Red LED ash ng. Hardware fault.
•Unplug unit. Check water level and rell if required.
Plug unit in. If fault persists contact Teal or the
retailer.
Water around un t. Clean up any spillage from lling
unit.
Check that the bowl is not full.
If further water is seen switch o unit and contact the
supplier for advice.
Troubleshoot ng gu de
Opt onal extras
At the end of its useful life, the
handwash unit should not be disposed
of in general household waste.
Units should be taken to a recycling
facility for electrical and electronic
items.
Please see WEEE regulations.
D sposal

Teal Patents Ltd
Unit 2, Waterloo Avenue
Chelmsley Wood Industrial Estate
Chelmsley Wood
Birmingham, B37 6QQ, UK
Tel: [phone]
Fax [phone]
Email: [email protected]
Product Spec cat on:
Height 370mm
Width 310mm
Depth (bowl open) 370mm
Depth (bowl closed) 220mm
Weight 3Kg empty
6.3Kg full
Electr cal Spec cat on:
Operating voltage 110V
Heater output 300W
Operating current 2A
Conforms to EN61000-6-1 &
EN61000-6-3.
Techn cal spec cat on
The Handeman Xtra 110V
