TEC TECDrive20-EU Series User manual

TECDrive20-EU Series Inverter Contents
-i-
Contents
Contents....................................................................................................................................i
Chapter 1 Safety precautions.................................................................................................1
1.1 Safety definition.............................................................................................................1
1.2 Warning symbols ...........................................................................................................1
1.3 Safety guide...................................................................................................................2
1.3.1 Delivery and installation........................................................................................2
1.3.2 Commissioning and running .................................................................................3
1.3.3 Maintenance and component replacement ..........................................................3
1.3.4 What to do after scrapping....................................................................................4
Chapter 2 Product overview...................................................................................................5
2.1 Quick startup..................................................................................................................5
2.1.1 Unpacking inspection............................................................................................5
2.1.2 Checking before applying.....................................................................................5
2.1.3 Environment confirmation.....................................................................................5
2.1.4 Installation confirmation........................................................................................6
2.1.5 Basic commissioning ............................................................................................7
2.2 Data related to safety standards....................................................................................7
2.3 Decommissioning ..........................................................................................................7
2.4 Product specification .....................................................................................................7
2.5 Product nameplate ........................................................................................................9
2.6 Model code..................................................................................................................10
2.7 Rated specifications ....................................................................................................10
2.8 Structure diagram ........................................................................................................12
Chapter 3 Installation guidelines .........................................................................................14
3.1 Mechanical installation ................................................................................................14
3.1.1 Installation environment......................................................................................14
3.1.2 Installation direction............................................................................................15
3.1.3 Installation mode.................................................................................................15
3.2 Standard wiring............................................................................................................17
3.2.1 Wiring of main circuit ..........................................................................................17
3.2.2 Main circuit terminals..........................................................................................18
3.2.3 Wiring of main circuit terminals...........................................................................19
3.2.4 Wiring of control circuit .......................................................................................19
3.2.5 Control circuit terminals ......................................................................................20
3.2.6 Input/output signal connection figure..................................................................22
3.3 Overview of STO function............................................................................................23
3.3.1 Logic table for STO function ...............................................................................24
3.3.2 Description of STO channel delay......................................................................24

TECDrive20-EU Series Inverter Contents
-ii-
3.3.3 STO function installation checklist......................................................................25
3.4 Layout protection.........................................................................................................25
3.4.1 Protecting the inverter and input power cable in short-circuit situations.............25
3.4.2 Protect the motor and motor cables....................................................................26
3.4.3 Implementing a bypass connection ....................................................................26
Chapter 4 Keypad operation.................................................................................................27
4.1 Keypad introduction.....................................................................................................27
4.2 Keypad display ............................................................................................................29
4.2.1 Displaying stopped-state parameters .................................................................30
4.2.2 Displaying running-state parameters..................................................................30
4.2.3 Displaying fault information.................................................................................30
4.2.4 Editing function codes.........................................................................................30
4.3 Operations on the keypad ...........................................................................................31
4.3.1 Modifying inverter function codes .......................................................................31
4.3.2 Setting a password for the inverter.....................................................................32
4.3.3 Viewing inverter status........................................................................................32
Chapter 5 Function parameters ...........................................................................................33
P00 group Basic functions.................................................................................................33
P01 group Start and stop control.......................................................................................40
P02 group Motor 1 parameters..........................................................................................46
P03 group Vector control...................................................................................................48
P04 group SVPWM control................................................................................................53
P05 group Input terminals .................................................................................................57
P06 group Output terminals...............................................................................................64
P07 group HMI...................................................................................................................67
P08 group Enhanced functions .........................................................................................73
P09 group PID control .......................................................................................................82
P10 group Simple PLC and multi-step speed control........................................................87
P11 group Protection parameters......................................................................................90
P13 group SM control........................................................................................................95
P14 group Serial communication.......................................................................................95
P17 group Status viewing..................................................................................................97
Chapter 6 Fault tracking .....................................................................................................101
6.1 Fault prevention.........................................................................................................101
6.1.1 Periodical maintenance ....................................................................................101
6.1.2 Cooling fan........................................................................................................104
6.1.3 Capacitor...........................................................................................................105
6.1.4 Power cable......................................................................................................106
6.2 Fault solution .............................................................................................................106
6.2.1 Indications of alarms and faults........................................................................106
6.2.2 Fault reset.........................................................................................................106

TECDrive20-EU Series Inverter Contents
-iii-
6.2.3 Inverter faults and solutions..............................................................................107
6.2.4 Other states ......................................................................................................113
Chapter 7 Communication protocol ..................................................................................114
7.1 Modbus protocol introduction ....................................................................................114
7.2 Application .................................................................................................................114
7.2.1 Two-wire RS485................................................................................................114
7.2.2 RTU mode.........................................................................................................117
7.2.3 ASCII mode.......................................................................................................120
7.3 RTU command code and communication data .........................................................121
7.3.1 RTU mode.........................................................................................................121
7.3.2 ASCII mode.......................................................................................................125
7.4 Data address definition..............................................................................................128
7.4.1 Function code address format rules .................................................................128
7.4.2 Description of other function addresses in Modbus..........................................129
7.4.3 Fieldbus scale...................................................................................................132
7.4.4 Error message response ..................................................................................133
7.5 Read/Write operation example..................................................................................135
7.5.1 Examples of reading command 03H.................................................................135
7.5.2 Examples of write command 06H.....................................................................136
7.5.3 Examples of continously writing command 10H...............................................138
7.6 Common communication faults .................................................................................140
Appendix A Technical data.................................................................................................141
A.1 Derated application...................................................................................................141
A.1.1 Capacity............................................................................................................141
A.1.2 Derating............................................................................................................141
A.2 CE .............................................................................................................................142
A.2.1 CE marking.......................................................................................................142
A.2.2 Compliance with the European EMC Directive ................................................142
A.3 EMC regulations........................................................................................................142
A.3.1 Inverters of category C2...................................................................................142
A.3.2 Inverters of category C3...................................................................................143
Appendix B Dimension drawings ......................................................................................144
B.1 External keypad structure .........................................................................................144
B.2 Inverter chart.............................................................................................................145
Appendix C Optional peripheral accessories...................................................................150
C.1 Wiring of peripheral accessories...............................................................................150
C.2 Power supply ............................................................................................................151
C.3 Cables.......................................................................................................................152
C.3.1 Power cables....................................................................................................152
C.3.2 Control cables ..................................................................................................152
C.4 Breaker and electromagnetic contactor....................................................................153

TECDrive20-EU Series Inverter Contents
-iv-
C.5 Reactors....................................................................................................................154
C.6 Filter..........................................................................................................................156
C.6.1 C3 Filter model instruction ...............................................................................156
C.6.2 C3 filter.............................................................................................................156
C.6.3 Installation instruction for C3 filter....................................................................158
C.6.4 C2 Filter type instruction ..................................................................................158
C.6.5 C2 filter model selection...................................................................................159
C.7 Braking resistors .......................................................................................................160
C.7.1 Selecting braking resistors...............................................................................160
C.7.2 Braking resistor installation..............................................................................161
Appendix D Energy efficiency data ...................................................................................163
Appendix E Further information ........................................................................................165
D.1 Product and service inquiries....................................................................................165
D.2 Feedback on TECDrive manuals ...........................................................................165
D.3 Documents on the Internet........................................................................................165

TECDrive20-EU Series Inverter Safety precautions
-1-
Chapter 1 Safety precautions
Please read this manual carefully and follow all safety precautions before moving, installing,
operating and servicing the inverter. If ignored, physical injury or death may occur, or damage
may occur to the devices.
If any physical injury or death or damage to the devices occurs for ignoring to the safety
precautions in the manual, our company will not be responsible for any damages and we are
not legally bound in any manner.
1.1 Safety definition
Danger:
Serious physical injury or even death may occur if not follow relevant
requirements.
Warning:
Physical injury or damage to the devices may occur if not follow relevant
requirements.
Note:
Physical hurt may occur if not follow relevant requirements.
Qualified
electricians:
People working on the device should take part in professional electrical
and safety training, receive the certification and be familiar with all steps
and requirements of installing, commissioning, operating and maintaining
the device to avoid any emergency.
1.2 Warning symbols
Warnings caution you about conditions which can result in serious injury or death and/or
damage to the equipment, and advice on how to avoid the danger. Following warning symbols
are used in this manual:
Symbols
Name
Instruction
Abbreviation
Danger
Danger
Serious physical injury or even death
may occur if not follow the relative
requirements
Warning
Warning
Physical injury or damage to the
devices may occur if not follow the
relative requirements
Do not
Electrostatic
discharge
Damage to the PCBA board may
occur if not follow the relative
requirements
Hot sides
Hot sides
Sides of the device may become hot.
Do not touch.
Note
Note
Physical hurt may occur if not follow
the relative requirements
Note

TECDrive20-EU Series Inverter Safety precautions
-2-
1.3 Safety guide
Only qualified electricians are allowed to operate on the inverter.
Do not carry out any wiring, inspection or component replacement when
the power supply is applied. Ensure all input power supply is disconnected
before wiring and checking and always wait for at least the time designated
on the inverter or until the DC bus voltage is less than 36V. The table below
describes the waiting time:
Inverter model
Minimum waiting time
1PH 230V
0.4kW–2.2kW
5 minutes
3PH 230V
0.4kW–7.5kW
5 minutes
3PH 400V
0.75kW–110kW
5 minutes
Do not refit the inverter unless authorized; otherwise, fire, electric shock or
other injury may occur.
The base of the radiator may become hot during running. Do not touch to
avoid hurt.
The electrical parts and components inside the inverter are electrostatic.
Take measurements to avoid electrostatic discharge during related
operation.
1.3.1 Delivery and installation
Please install the inverter on fire-retardant material and keep the inverter
away from combustible materials.
Connect the optional brake parts (braking resistors, braking units or
feedback units) according to the wiring diagram.
Do not operate on the inverter if there is any damage or components loss
to the inverter.
Do not touch the inverter with wet items or body; otherwise, electric shock
may occur.
Note:
Select appropriate moving and installing tools to ensure a safe and normal running of the
inverter and avoid physical injury or death. For physical safety, the erector should take
some mechanical protective measurements, such as wearing exposure shoes and working
uniforms.
Ensure to avoid physical shock or vibration during delivery and installation.
Do not carry the inverter by its cover. The cover may fall off.
Install away from children and other public places.

TECDrive20-EU Series Inverter Safety precautions
-3-
The leakage current of the inverter may be above 3.5mA during operation. Ground properly
and ensure the grounding resistor is less than 10Ω. The conductivity of PE grounding
conductor is the same as that of the phase conductor.
R, S and T are the input terminals of the power supply, while U, V and W are the motor
terminals. Please connect the input power cables and motor cables properly; otherwise, the
damage to the inverter may occur.
1.3.2 Commissioning and running
Disconnect all power supplies applied to the inverter before the terminal
wiring and wait for at least the designated time after disconnecting the
power supply.
High voltage is present inside the inverter during running. Do not carry out
any operation except for the keypad setting.
The inverter may start up by itself when P01.21=1. Do not get close to the
inverter and motor.
The inverter cannot be used as "Emergency-stop device".
The inverter cannot be used to brake the motor suddenly. A mechanical
brake device should be provided.
Note:
Do not switch on or off the input power supply of the inverter frequently.
For inverters that have been stored for a long time, set the capacitance and carry out
inspection and pilot run on the inverter before use.
Close the front cover before running; otherwise, electric shock may occur.
1.3.3 Maintenance and component replacement
Only well-trained and qualified professionals are allowed to carry out
maintenance, inspection, and component replacement on the inverter.
Disconnect all the power sources applied to the inverter before terminal
wiring, and wait for at least the time designated on the inverter after
disconnecting the power sources.
Take measures to prevent screws, cables and other conductive matters
from falling into the inverter during maintenance and component
replacement.
Note:
Select proper torque to tighten screws.
Keep the inverter and its parts and components away from combustible materials during
maintenance and component replacement.

TECDrive20-EU Series Inverter Safety precautions
-4-
Do not carry out insulation voltage-endurance test on the inverter, or measure the control
circuits of the inverter with megameters.
1.3.4 What to do after scrapping
The heavy metals inside the inverter should be treated as industrial
effluent.
When the life cycle ends, the product should enter the recycling system.
Dispose of it separately at an appropriate collection point instead of
placing it in the normal waste stream.

TECDrive20-EU Series Inverter Product overview
-5-
Chapter 2 Product overview
2.1 Quick startup
2.1.1 Unpacking inspection
Check the following items after receiving the product.
1. Whether the packing box is damaged or dampened.
2. Whether the model identifier on the exterior surface of the packing box is consistent
with the purchased model.
3. Whether the interior surface of the packing box is abnormal, for example, in wet
condition, or whether the enclosure of the product is damaged or cracked.
4. Whether the nameplate of the product is consistent with the model identifier on the
exterior surface of the packing box.
5. Whether the accessories (including the user manual and control keypad) inside the
packing box are complete.
If any of the problems described in the check items are found, contact the local dealer or our
company.
2.1.2 Checking before applying
Confirm the following items before using the inverter.
1. Mechanical type of the load to be driven by the inverter. Check whether the inverter will
be overloaded in actual operation and whether the power level needs to be raised.
2. Whether the actual running current of the to-be-loaded motor is lower than the rated
current of the inverter.
3. Whether control precision implemented by the inverter meets the requirement of the
actual load.
4. Whether the grid voltage is consistent with the rated voltage of the inverter.
2.1.3 Environment confirmation
Check the following items before you install and use the inverter.
1. Whether the ambient temperature in the application is higher than 40°C. If yes, derate
the machine by 1% for every increased 1°C. Do not use the inverter in environments
where the temperature is higher than 50°C.
Note: If the inverter is installed in a cabinet, the ambient temperature is the air
temperature inside the cabinet.
2. Whether the ambient temperature in application is lower than –10°C. If yes, configure a
heating device.

TECDrive20-EU Series Inverter Product overview
-6-
Note: If the inverter is installed in a cabinet, the ambient temperature is the air
temperature inside the cabinet.
3. When the altitude exceeds 3000m, consult our local dealer or office for details.
When the altitude exceeds 1000m, derate by 1% for every increase of 100m.
4. Whether the ambient humidity is higher than 90% or condensation occurs. If yes, take
extra protective measures.
5. Whether there is direct sunlight or biological invasion in the application environment. If
yes, take extra protective measures.
6. Whether there is dust or inflammable and explosive gas in the application environment.
If yes, take extra protective measures.
2.1.4 Installation confirmation
Check the following items after the installation of the inverter is complete.
1. Whether the input power cables and motor cables meet the current-carrying capacity
requirements of the actual load.
2. Whether the peripheral accessories are correctly selected and properly installed, and
whether the installation cables meet the current-carrying capacity requirements of the
accessories, including the input reactor, input filter, output reactor, output filter, DC
reactor, braking unit, and braking resistor.
3. Whether the inverter is installed on non-flammable materials, and whether its
heat-emitting accessories (such as reactor and braking resistor) are kept away from
inflammable materials.
4. Whether all the control cables are wired separately from power cables, and whether
electromagnetic compatibility (EMC) specification requirements are taken into full
account during the wiring.
5. Whether all the grounding systems are properly grounded according to the
requirements of the inverter.
6. Whether all the installation spacings of the inverter meet the requirements stated in the
manual.
7. Whether the installation of the inverter meets the requirements stated in the manual.
8. Check that the external connection terminals are tightly fastened and whether the
torque meets the requirements.
9. Whether screws, cables, or other conductive items drop into the inverter. If yes, take
them out.

TECDrive20-EU Series Inverter Product overview
-7-
2.1.5 Basic commissioning
Complete the basic commissioning as follows before using the inverter.
1. Perform autotuning if required. Remove the motor load, if possible, to perform dynamic
parameter autotuning; and if the load cannot be removed, you can perform static
autotuning.
2. Adjust the ACC/DEC time according to the actual operation conditions of the load.
3. Perform commissioning on the machine in jogging mode and check whether the
rotating direction of the motor meets the requirement. If no, exchange the wires of any
two phases of the motor to change the running direction of the motor.
4. Set all control parameters and then run the machine.
2.2 Data related to safety standards
IEC/EN 61508 (type A system)
ISO 13849**
SIL
PFH
HFT
SFF
λdu
λdd
PTI*
PL
CCF
DC
Category
2
8.73*10-10
1
71.23%
1.79*10-9
0
1 year
d
57
60%
3
3
8.53*10-10
1
99.38%
0.64*10-10
3.3*10-9
3 months
e
57
98.09%
3
* PTI: proof test interval.
** According to the categorization defined in EN ISO 13849-1.
2.3 Decommissioning
Before decommissioning any safety system from active service:
Evaluate the impact of decommissioning on adjacent operating units and facilities or other
field services.
Conduct a proper review and obtain required authorization.
Ensure that the safety functions remain appropriate during decommissioning activities.
Implement appropriate change management procedures for all decommissioning activities.
2.4 Product specification
Function
Specification
Power input
Input voltage (V)
AC 1PH 200V–240V, rated voltage: 230V
AC 3PH 200V–240V, rated voltage: 230V
AC 3PH 380V–480V, rated voltage: 400V
Allowable voltage
fluctuation
-15%–+10%
Input current (A)
Refer to section 2.7 "Rated specifications".
Input frequency (Hz)
50Hz or 60Hz; allowed range: 47–63Hz

TECDrive20-EU Series Inverter Product overview
-8-
Function
Specification
Power output
Output voltage (V)
0–input voltage
Output current (A)
Refer to section 2.7 "Rated specifications".
Output power (kW)
Refer to section 2.7 "Rated specifications".
Output frequency (Hz)
0–400Hz
Technical
control
feature
Control mode
SVPWM, SVC
Motor
Asynchronous motor
Adjustable-speed ratio
Asynchronous motor 1:100 (SVC)
Speed control accuracy
±0.2% (SVC)
Speed fluctuation
±0.3% (SVC)
Torque response
<20ms (SVC)
Torque control accuracy
10%
Starting torque
0. 5Hz/150% (SVC)
Overload capability
150% of rated current: 1 minute
180% of rated current: 10 seconds
200% of rated current: 1 second
Running
control
feature
Frequency setting
method
Digital setting, analog setting, pulse frequency
setting, multi-step speed running setting, simple
PLC setting, PID setting, Modbus communication
setting
Shift between the set combination and set channel.
Auto-adjustment of the
voltage
Keep a stable voltage automatically when the grid
voltage transients
Fault protection
Provide comprehensive fault protection functions:
overcurrent, overvoltage, undervoltage,
overheating, phase loss and overload, etc.
Start after speed tracking
Smoothing starting for running motor
Peripheral
interface
Analog input
1 (AI2) 0–10V/0–20mA and 1 (AI3) -10–10V
Analog output
2 (AO1, AO2) 0–10V/0–20mA.
* AO2 output only available on TDI20-EU >2.2kW
Digital input
4 common inputs, the max. frequency: 1kHz;
1 high speed input, the max. frequency: 50kHz
Digital output
1 Y1 terminal output
Relay output
2 programmable relay outputs
RO1A NO, RO1B NC, RO1C common terminal
RO2A NO, RO2B NC, RO2C common terminal
Contact capacity: 3A/AC250V, 1A/DC30V
*Relay 2 output only available onTDI20-EU > 2.2kW
Others
DC reactor
Standard embedded DC reactor for the inverters
(≥18.5kW)

TECDrive20-EU Series Inverter Product overview
-9-
Function
Specification
Installation mode
Wall and rail installation of the inverters (single
phase 230V/three phase 400V, ≤2.2KW and three
phase 230V, ≤0.75KW)
Wall and flange installation of the inverters (three
phase 400V, ≥4KW and three phase 230V, ≥1.5KW)
Braking unit
Standard for the inverters≤37kW and optional for
the inverters within 45–110kW
EMI filter
3PH 400V 4kW and above/3PH 230V 1.5kW and
above can comply with IEC 61800-3 class C3,
others can meet requirements of IEC 61800-3 class
C3 by installing external filter (optional). This series
of products can comply with IEC 61800-3 class C2
by installing external filter (optional).
Ambient temperature
-10 to 50°C , derate 1% for every increased 1°C
when the temperature is higher than 40°C
Altitude
Below 1000m. If the elevation is above 1000m,
derate 1% for every additional 100m.
Ingress protection (IP)
rating
IP20
Note: The inverter with plastic casing should be
installed in metal distribution cabinet which
conforms to IP20 and the top of which conforms to
IP3X.
Pollution level
Level 2
Safety regulation
Comply with CE requirements
Cooling mode
Forced air cooling
2.5 Product nameplate
Figure 2-1 Product nameplate

TECDrive20-EU Series Inverter Product overview
-10-
Note: These are product nameplate examples for the standard products. The mark such as
CE/TUV/IP20/UL will be applied according to the actual condition. The 1PH/3PH 220V models
of 2.2kW and lower and the 3PH 380V models of 11kW and lower have been UL certified.
2.6 Model code
The model code contains information on the inverter. Users can find the model code on the
nameplate attached to the inverter or the simple nameplate.
TDI20 –2R2G –4 –B –EU
①②③④⑤
Figure 2-2 Product model
Key
No.
Detailed
description
Detailed content
Abbreviation of
product series
①
Abbreviation of
product series
TDI20: TECDrive20 series inverter
Rated power
②
Power range +
load type
055: 55kW;
G: Constant torque load
Voltage class
③
Voltage class
S2: 1PH 200V–240V
2: 3PH 200V–240V
4. 3PH 380V–480V
Additional remark 1
④
Built-in braking
unit
Null: Built-in braking unit is included in standard
configuration for models ≤ 37kW
-B
Built-in braking unit is optional for models ≥
45kW, -B is its built-in braking unit model
Additional remark 2
⑤
EU: Built-in safe torque off function
2.7 Rated specifications
Model
Voltage
degree
Rated output
power (kW)
Rated input
current (A)
Rated output
current (A)
STO
function
TDI20-0R4G-S2-EU
Single
phase 230V
0.4
6.5
2.5
Class SIL2
PLd CAT.3
TDI20-0R7G-S2-EU
0.75
9.3
4.2
TDI20-1R5G-S2-EU
1.5
15.7
7.5
TDI20-2R2G-S2-EU
2.2
20
10
TDI20-0R4G-2-EU
Three phase
230V
0.4
3.7
2.5
TDI20-0R7G-2-EU
0.75
5
4.2
TDI20-1R5G-2-EU
1.5
7.7
7.5
Class SIL3
PLe CAT.3
TDI20-2R2G-2-EU
2.2
11
10

TECDrive20-EU Series Inverter Product overview
-11-
Model
Voltage
degree
Rated output
power (kW)
Rated input
current (A)
Rated output
current (A)
STO
function
TDI20-004G-2-EU
4
17
16
TDI20-5R5G-2-EU
5.5
21
20
TDI20-7R5G-2-EU
7.5
31
30
TDI20-0R7G-4-EU
Three phase
400V
0.75
3.4
2.5
Class SIL2
PLd CAT.3
TDI20-1R5G-4-EU
1.5
5.0
4.2
TDI20-2R2G-4-EU
2.2
5.8
5.5
TDI20-004G-4-EU
4
13.5
9.5
Class SIL3
PLe CAT.3
TDI20-5R5G-4-EU
5.5
19.5
14
TDI20-7R5G-4-EU
7.5
25
18.5
TDI20-011G-4-EU
11
32
25
TDI20-015G-4-EU
15
40
32
TDI20-018G-4-EU
18.5
47
38
TDI20-022G-4-EU
22
51
45
TDI20-030G-4-EU
30
70
60
TDI20-037G-4-EU
37
80
75
TDI20-045G-4-EU
45
98
92
TDI20-045G-4-B-EU
45
98
92
TDI20-055G-4-EU
55
128
115
TDI20-055G-4-B-EU
55
128
115
TDI20-075G-4-EU
75
139
150
TDI20-075G-4-B-EU
75
139
150
TDI20-090G-4-EU
90
168
180
TDI20-090G-4-B-EU
90
168
180
TDI20-110G-4-EU
110
201
215
TDI20-110G-4-B-EU
110
201
215

TECDrive20-EU Series Inverter Product overview
-12-
2.8 Structure diagram
The following figure shows the structure of the inverter (3PH 400V, ≤2.2kW) (using the 0.75kW
inverter model as the example).
1
2
3
1
53
4
7
9
8
211101
6
Figure 2-3 Product structure (3PH 400V, ≤2.2kW)
No.
Name
Description
1
External keypad port
Connect the external keypad
2
Port cover
Protect the external keypad port
3
Cover
Protect the internal parts and components
4
Hole for the sliding cover
Fix the sliding cover
5
Trunking board
Protect the inner components and fix the cables of the
main circuit
6
Name plate
See section 2.5 "Product nameplate" for details.
7
Potentiometer knob
Refer to Chapter 4 "Keypad operation".
8
Control terminals
See Chapter 3 "Installation guidelines" for details.
9
Main circuit terminals
See Chapter 3 "Installation guidelines" for details.
10
Screw hole
Fix the fan cover and fan.
11
Cooling fan
See Chapter 6 "Fault tracking" for details.
12
Fan cover
Protect the fan
13
Bar code
The same as the bar code on the name plate
Note: The bar code is on the middle shell which is under
the cover.
Note: In above figure, the screws at 4 and 10 are provided with packaging and specific
installation depends on the requirements of customers.

TECDrive20-EU Series Inverter Product overview
-13-
The following figure shows the structure of the inverter (3PH 400V, ≥4kW) (using the 4kW
inverter model as the example).
9
8
6
7
10
3
2
11
15
4
Figure 2-4 Product structure (Three phase 400V, ≥4kW)
No.
Name
Description
1
External keypad port
Connect the external keypad
2
Cover
Protect the internal parts and components
3
Keypad
Refer to Chapter 4 "Keypad operation"
4
Cooling fan
See Chapter 6 "Fault tracking" for details.
5
Name plate
See section 2.5 "Product nameplate" for details.
6
Cover for the heat
emission hole
Optional, enhancement of the protective degree. It
is necessary to derate the inverter because the
internal temperature is increasing
7
Control terminals
See Chapter 3 "Installation guidelines" for details.
8
Main circuit terminals
See Chapter 3 "Installation guidelines" for details.
9
The cable entry of the
main circuit
Fix the cables
10
Simple name plate
Refer to section 2.6 "Model code".
11
Bar code
The same as the bar code on the name plate
Note: The bar code is on the middle shell which is
under the cover.

TECDrive20-EU Series Inverter Installation guidelines
-14-
Chapter 3 Installation guidelines
The chapter describes the mechanical installation and electric installation of the inverter.
Only qualified electricians are allowed to carry out what described in this
chapter. Please operate as the instructions in Chapter 1 "Safety
precautions". Ignoring these may cause physical injury or death or
damage to the devices.
Ensure the power supply of the inverter is disconnected during the
operation. Wait for at least the time designated after the disconnection if
the power supply is applied.
The installation and design of the inverter should be complied with the
requirement of the local laws and regulations in the installation site. If the
installation infringes the requirement, our company will exempt from any
responsibility. Additionally, if users do not comply with the suggestion,
some damage beyond the assured maintenance range may occur.
3.1 Mechanical installation
3.1.1 Installation environment
The installation environment is the safeguard for a full performance and long-term stable
functions of the inverter. Check the installation environment as follows:
Environment
Conditions
Installation
site
Indoor
Environment
temperature
-10°C to +50°C, and the temperature changing rate is less than
0.5°C/minute.
If the ambient temperature of the inverter is above 40°C, derate 1% for
every additional 1°C.
It is not recommended to use the inverter if the ambient temperature is
above 50°C.
In order to improve the reliability of the device, do not use the inverter if the
ambient temperature changes frequently.
Please provide cooling fan or air conditioner to control the internal ambient
temperature below the required one if the inverter is used in a closed space
such as in the control cabinet.
When the temperature is too low, if the inverter needs to restart to run after
a long stop, it is necessary to provide an external heating device to
increase the internal temperature; otherwise, damage to the devices may
occur.

TECDrive20-EU Series Inverter Installation guidelines
-15-
Environment
Conditions
Humidity
RH ≤90%.
No condensation is allowed.
Storage
temperature
-40°C to +70°C, and the temperature changing rate is less than 1°C/minute.
Running
environment
condition
The installation site of the inverter should fulfill the following requirements.
Away from electromagnetic radiation sources.
Away from oil mist, corrosive gases and combustible gases.
Ensure foreign object like metal powder, dust, oil and water will not fall into
the inverter (do not install the inverter onto combustible object like wood).
Away from radioactive substance and combustible objects.
Away from harmful gases and liquids.
Low salt content.
No direct sunlight.
Altitude
Below 1000m.
When the altitude exceeds 3000m, consult the local TECDrive dealer or
office for details.
When the altitude exceeds 1000m, derate by 1% for every increase of
100m.
Vibration
Max. vibration acceleration: 5.8m/s2 (0.6g)
Installation
direction
The inverter should be installed on an upright position to ensure sufficient
cooling effect.
Note:
The inverters should be installed in a clean and ventilated environment according to
enclosure classification.
Cooling air must be clean, free from corrosive materials and electrically conductive dust.
3.1.2 Installation direction
The inverter may be installed in a cabinet.
The inverter needs be installed in the vertical position. Check the installation site according to
the requirements below. Refer to Appendix B "Dimension drawings" for details.
3.1.3 Installation mode
a) Wall and rail mounting for the inverters (single phase 230V/three phase 400V, ≤2.2KW and
three phase 230V, ≤0.75KW)
