Technaxx LED TouchFree 2.5W User manual

Technaxx® LED LED TouchFree 2.5W
User Manual
The Declaration of Conformity for this device is under: www.technaxx.de/ (in bottom bar “Konformitätserkärung”)
Features
 Dimming and On/Off function by hand movement  Touchfree sensor on lamp top
 Touchable sensor in lamp base  Frosted lamp case makes a gentle light, no harm to
eyes  Comparable with a conventional 20 watt halogen bulb  Built-in rechargeable battery
 USB charging cable & AC adaptor included  For interior lighting only  Easiest handling
Product View
Touchfree inductive area
Frosted lamp case
Touchable inductive icon
DC socket
Reset button
Sensor ON / OFF
Make sure the battery is fully charged before use the lamp the first time.
USB Charging
The USB charging cable is included in delivery. Connect it’s round end to the DC plug in
the lamp’s base, and the other side of the cable to a PC USB port or to an USB 5V adapter*
(* not included). Charging time takes ~6 hours.
If the lamp dims even at the maximum lightness or the touchfree function is not sensitive,
it means the power is low and you have to charge the lamp. Fully charged lamp can last
~5 hours (steady light) up to ~3 days (short periods of light).
Touchfree Function (sensor in the lamp’s top)
Note: In order to make the touchfree function work well, there should be nothing within min.
1m over the lamp’s top (e.g. shelf, ceiling, etc.).
Put the switch “Sensor ON/OFF” at the lamp’s base to the ON position. Pass with your
hand (without touching it) over the lamp’s top (max. 20cm distance) The lamp turns ON.
Do it again and the lamp turns OFF.

Put the switch “Sensor ON/OFF” at the lamp’s base to the ON position. Let your hand
stay (without touching it) over the lamp’s top (max. 20cm distance) The dimming function
is activated. The lamp dims light down. Do it again and the lamp dims light up. Move your
hand away and the lightness can be kept.
In case you do not want to have the touchfree function activated, put the switch “Sensor
ON/OFF” to the OFF position.
Touchable Function (sensor in lamp’s body, see icon )
This function always works when the lamp is charged. Touch the icon on the lamp’s body
once. The lamp turns ON. Do it again and the lamp turns OFF. Touch the icon on the
lamp’s body and let your finger stay there. The diming function is activated. The lamp
dims light down. Do it again and the lamp dims light up. Move your finger away and the
lightness can be kept.
Reset function:
If the battery is excessive discharged, the touchfree function may not run normally. 
Charge the battery; and possibly In this case reset the battery after charging. Insert a
slim object (e.g. needle or clip) into the RESET hole in the lamp’s base and press slightly
and carefully one time.
Technical Specifications
LED no./size/colour 14 / Ø 5 / white
Viewing angle 360°
Degree of protection IP20
Dimmable Yes
Voltage 110–220V AD/DC
Frequency 50 Hz / 60Hz
Power consumtion 2.5W
Lumen 60lm
Halogen equivalent 20W
Working temperature -10 up to +50°C
Life span ≥50,000 hours
Charging time ~ 5 hours
Working time ~ 6 hours steady light; ~3 days short periods of light
Outshell / Lamp ABS / ABS
Power adaptor* Input: AC 110V / 220V; Output: DC–5V 500mA
Dimensions / Weight Ø 10cm, Height 25cm / 322g
Accessories USB cable with Ø 3.5mm DC plug , User Manual
Security and Disposal Hints for Batteries: Hold children off batteries. When a child swallowed a battery go to a doctors place or bring
the child into a hospital promptly! Look for the right polarity (+) and (--) of batteries! Always change all batteries, never use old and new
batteries or batteries of different types together. Never short batteries. Do NOT open, deform or load up batteries! There is a risk of
injury by battery leakage fluid! NEVER throw batteries into fire! There is a risk of explosion!
Hints for Environment Protection: Packages materials are raw materials and can be recycled. Do not disposal old devices or
batteries into the domestic waste. Cleaning: Protect the device from contamination and pollution. Only clean the device with
soft cloth/drapery, avoid using rough or coarse-grained materials. Do NOT use solvents or other aggressive cleaner. Wipe the
device after cleaning accurately. Important Notice: Should battery fluid leak from a battery, wipe the battery-case with a soft
cloth dry.
