Silvair MESH-CEDRP User manual

PLEASE READ THESE INSTRUCTIONS BEFORE INSTALLING THE PRODUCT
NOTE: MESH-CEDRP is compatible with any qualified Bluetooth mesh components and commissioning tools.
We recommend Silvair Commissioning as a reliable solution.
MESH-CEDRP
Plug-in Directional Passive Infra Red
(PIR) Occupancy Detector & Photocell
Input: 100-240 Vac 50/60Hz
DANLERS Limited, Vincients Road, CHIPPENHAM, Wiltshire, SN14 6NQ, UK.
Telephone: [phone] Fax: [phone] E-mail: [email protected]
www.danlers.co.uk
Company Registered Number 2570169 VAT Registration Number 543 5491 38
11/10/19 INS374 MESH-CEDRP (Issue 03)
This directional MESH-CEDRP can plug into a
ceiling mounted socket (not included) - DANLERS
Product Code: MESH-CESO. The socket can
be mounted onto an appropriate BESA box
or pattress box. Configurable for any room
occupancy style, via the Silvair Platform (App
and Web).
INSTALLATION
To be installed by a competent person with
reference to BS 7671 or equivalent local standards.
If in doubt consult a qualified electrician.
• Plan where the MESH-CEDRP is to be located
(see diagram 1). Switch off supply and check
for hidden cables and pipes.
•
The MESH-CEDRP plugs into a ceiling mounted
socket (not included) - DANLERS Product Code:
MESH-CESO.
• The MESH-CEDRP should be connected as
shown in diagram 2:
L - Live in. N - Neutral in.
OPERATION
To check the operation of the MESH-CEDRP:
• Turn on the supply then after 20 seconds if the
sensor has recognised movement of a person
within its zone of detection the integral red LED
on MESH-CEDRP will stay illuminated for 4
seconds before the red LED turns off.
• Thereafter, every time movement is detected
by MESH-CEDRP the integral red LED will stay
illuminated for 4 seconds.
The control also features adjustable time out (time
lag) control and daylight threshold control which
are configured by the Silvair APP.
PRECAUTIONS
• Do not place the MESH-CEDRP near heat
sources, fans or in ventilated ceiling voids.
• MESH-CEDRP can be wired in parallel (sharing
the same Live and Neutral).
• Do not place close to, or positioned such
that, any light source points directly into the
MESH-CEDRP.
• Ensure wires and cables are securely held
within the connection terminals.
• The MESH-CEDRP should be protected by a 5
or 6 Ampere mcb or fuse.
• Disconnect the MESH-CEDRP from the
circuit before performing insulation testing
of the wiring circuit.
DIAGRAM 1
5m 10m
Strong
Detection Zone
i.e. person
walking towards
the CEDR6P
Secondary
Detection Zone
i.e. person
walking across
the CEDR6P
60° 120°
Side elevation view
5m 10m
Strong
Detection Zone
i.e. person
walking towards
the CEDR6P
Secondary
Detection Zone
i.e. person
walking across
the CEDR6P
60° 120°
Plan view
L N
Ceiling Socket
(Not included)
DANLERS
Code:
MESH-CESO
L
N
Back box or
BESA box
MESH-CEDRP or
MESH-CEDRPLR
230Vac
5A or 6A MCB
or fuse
DIAGRAM 2
5 YEAR WARRANTY
MESH-CEDRP comes with a 5 year
warranty from the date of manufacture
and is CE marked.
TECHNICAL DETAILS
INPUT
Voltage: 100 - 240Vac
Frequency: 50/60Hz
Max. mains current: 20mA
Standby current: 14mA
RADIO TRANSCEIVER
Operating frequencies: 2.4... 2,483 GHz
Max. output power: +4 dBm
LUX PARAMETERS
Range: 5 - 2000 lux
OPERATING CONDITIONS
Note: The temperature difference between the
detection target and the background must be
at least 4 °C.
Ambient temperature: -20... +40 °C (lout
20mA)
Storage temperature: -25... +75 °C
Max. relative humidity: 0... 80%, non cond.
CONNECTORS
Terminal block
Wire size:
0.5mm2- 2.5mm2
solid or stranded
Wire strip length: 6-7mm
Tightening torque: 0,4 Nm/4 Kgf.cm
MECHANICAL DATA
Dimensions: 74mm x 90mm x
140mm (adjustable)
Weight: 172g (unpacked)
Degree of protection: IP20
Protection class: Built-in Class 2
Material (casing) Flame-retardant
polycarbonate
Finish / Colour Matt /White (RAL
9003)
Protection class: Built-in Class 2
CONFORMITY AND STANDARDS
EMC emission:
EN 301 489-1 V2.2.0,
EN 301 489-17 V3.1.1,
EN 55032: 2015,
EN61000-3-2: 2014,
EN61000-3-3: 2013
EMC immunity:
EN 301 489-1 V2.2.0, EN 301 489-17 V3.1.1
Environment:
Complies with WEEE and RoHS directives
CB scheme:
IEC60669-1:1998,
IEC60669-1:1998/AMD1:1999,
IEC60669-1:1998/AMD2:2006,
IEC60669-2:2002,
IEC60669-2-1:2002/AMD1:2008,

PLEASE READ THESE INSTRUCTIONS BEFORE INSTALLING THE PRODUCT
NOTE: MESH-CEDRP is compatible with any qualified Bluetooth mesh components and commissioning tools.
We recommend Silvair Commissioning as a reliable solution.
MESH-CEDRP
Plug-in Directional Passive Infra Red
(PIR) Occupancy Detector & Photocell
Input: 100-240 Vac 50/60Hz
DANLERS Limited, Vincients Road, CHIPPENHAM, Wiltshire, SN14 6NQ, UK.
Telephone: [phone] Fax: [phone] E-mail: [email protected]
www.danlers.co.uk
Company Registered Number 2570169 VAT Registration Number 543 5491 38
11/10/19 INS374 MESH-CEDRP (Issue 03)
DIAGRAM 3
60
74
64
102
side
MESH-CESO (Not included)
HALL EFFECT / FACTORY RESET:
This function allows a reset to be carried out in order to restore the default
factory settings.
A factory reset will change the state of MESH-CEDRP from ‘provisioned’
to ‘unprovisioned’, i.e. all network settings will be lost. This functionality
is required to allow reprovisioning MESH-CEDRP where control over the
device is not functioning correctly.
TO REPROVISION:
Place a small magnet on the site of the Reset / Hall effect sensor
(see diagram 4 below). To trigger the reset the magnet must be held in
position for 5 seconds.
DIMENSIONS
STATUS LED BLINKING SEQUENCE:
MESH-CEDRP
Unprovisioned: 30ms ON 300ms OFF
MESH-CEDRP
Provisioned: 15ms ON 2000ms OFF
Factory Reset: 500ms ON 1000ms OFF
Factory Reset (initial burst): 100ms ON 1000ms OFF
MESH package received: 30ms ON 50ms OFF
Attention (from network): 500ms ON 500ms OFF
RESET ZONE (behind moulding).
Magnet to be placed over this
area for reprovisioning.
STATUS LED.
Flashes rapidly when
unprovisioned.
Flashes slowly when
provisioned.
DIAGRAM 4
