technetix AIMA3000.FT5P Operational manual

May/2016 - Version 1.0
AIMA3000.FT5P
1550 nm Forward Transmitter - Performance
Product User Manual

AIMA3000.FT5P Product User Manual
Technetix Group Limited
[email protected] •technetix.comMay/2016 - Version 1.0 2
AIMA3000.FT5P
1550 nm Forward Transmitter - Performance
Product User Manual

AIMA3000.FT5P Product User Manual
Technetix Group Limited
[email protected] •technetix.comMay/2016 - Version 1.0 3
Contents
1 About This Manual....................................................................................................................................................5
1.1 Chapter Overview ..................................................................................................................................................................................5
1.2 Related Documentation........................................................................................................................................................................5
1.3 Document Conventions........................................................................................................................................................................6
1.4 Technical Support...................................................................................................................................................................................6
2 Precautions.................................................................................................................................................................7
3 Overview.....................................................................................................................................................................8
3.1 Product Description ...............................................................................................................................................................................8
3.2 Product Key Features............................................................................................................................................................................9
3.3 Specifications...........................................................................................................................................................................................10
3.4 Block Diagram .........................................................................................................................................................................................12
3.5 Order Details............................................................................................................................................................................................13
4 Module Characteristics ............................................................................................................................................15
4.1 Module Appearance and Port Layout..............................................................................................................................................15
4.1.1 Overview ..........................................................................................................................................................................................15
4.1.2 Front Panel Layout ........................................................................................................................................................................16
4.1.3 Rear Panel Layout..........................................................................................................................................................................18
5 Installation ..................................................................................................................................................................20
5.1 Preparatory Work for Installation .......................................................................................................................................................20
5.2 Unpacking.................................................................................................................................................................................................20
5.3 Module Installation .................................................................................................................................................................................21
5.4 Connecting Optical Cables .................................................................................................................................................................22
5.4.1 Using the Sliding Fibre Guide....................................................................................................................................................22
5.4.2 Using the Fibre Tray......................................................................................................................................................................24
5.4.3 Cleaning the Fibre Connector Ends and Front-panel Optical Ports .............................................................................26
5.4.4 Connecting the Optical Fibres ..................................................................................................................................................27
5.5 Check Module LEDs ..............................................................................................................................................................................27
5.6 Test the Optical Output Signal............................................................................................................................................................28

AIMA3000.FT5P Product User Manual
Technetix Group Limited
[email protected] •technetix.comMay/2016 - Version 1.0 4
6 Module Configuration & Alarm setup....................................................................................................................31
6.1 Port Configuration screen....................................................................................................................................................................31
6.1.1 Confirming Input Signal ...............................................................................................................................................................34
6.1.2 Alarm Status Pages .......................................................................................................................................................................35
6.1.3 Module operating voltage and temperature alarm ............................................................................................................36
6.1.4 Module Port Alarms.......................................................................................................................................................................37
6.1.5 Alarm Monitoring Configuration................................................................................................................................................38
6.1.6 Input / Output Status Monitoring...............................................................................................................................................40
6.2 Logs Management..................................................................................................................................................................................43
6.3 Device Upgrade......................................................................................................................................................................................44
6.4 Restoring Factory Defaults ..................................................................................................................................................................45
6.5 Reboot........................................................................................................................................................................................................47
7 Troubleshooting.........................................................................................................................................................48
8 Declaration of Conformity .......................................................................................................................................50

AIMA3000.FT5P Product User Manual
Technetix Group Limited
[email protected] •technetix.comMay/2016 - Version 1.0 5
1 About This Manual
1.1 Chapter Overview
1. About This Manual: Preface
2. Precautions
3. Overview: Application module overview, including the module features, technical specifications, and
ordering information.
4. Module Characteristics: The appearance of the equipment, port and introduction of other components
5. Installation: Installation procedure
6. Module Configuration & Alarms: Web management configuration instructions.
7. Troubleshooting
8. Product Warranty
9. Declaration of Conformity.
1.2 Related Documentation
The following documents may be used in conjunction with this manual:
• Technetix.AIMA3000 - Product User Manual
• Technetix.AIMA ASMM - Product User Manual
• AIMA3000 NMS Web Management System Product User Manual
- Technetix.NMS3-EPSM - Basic Inventory Management
- Technetix.NMS3-EPSM - Basic Alarm Management
- Technetix.NMS3-EPSM - Basic System Management
- Technetix.NMS3-EPSM - Basic Template Management

AIMA3000.FT5P Product User Manual
Technetix Group Limited
[email protected] •technetix.comMay/2016 - Version 1.0 6
1.3 Document Conventions
Before you use the manual, please familiarise yourself with the format used in this manual.
‘*’ Asterisk: Points marked with an asterisk means there is a corresponding note on the page
1.4 Technical Support
If you need help in the process of setting up and maintaining an FT5P, please contact Technetix’s technical
support sta:
Europe:
Technetix BV
Kazemat 5
NL-3905 NR Veenendaal
P.O. Box 385
NL-3900 AJ Veenendaal
The Netherlands
Phone: [phone]
Email: customer.service.[email protected]

AIMA3000.FT5P Product User Manual
Technetix Group Limited
[email protected] •technetix.comMay/2016 - Version 1.0 7
2 Precautions
WARNING!
This equipment is intended for indoor applications. To prevent fire or electrical shock, or
damage to the equipment, do not expose units to water or moisture.
• You should carefully read and thoroughly understand the contents of the manual before
installing and using this equipment.
• A typical connector is the SC/APC 8°. Note: An 8 ° angle polished optical connectors must
be used.
• At any time, there may be dangerous voltage inside the device.
• DO NOT power up before the cover and the panels of the equipment are installed and the
enclosure is closed.
Cleaning
Only use a damp cloth for cleaning the front panel. Use a soft dry cloth to clean the top of the unit.
DO NOT use any spray cleaners or chemicals of any kind.
Outage or overload requiring service and repairs
Unplug the unit and refer the servicing to Technetix qualified service personnel only.
Servicing and repairs
DO NOT attempt to service this unit yourself. Refer all servicing needs to Technetix qualified service
personnel only.
WARNING!
Exposure to class 3A laser radiation is possible. Access should be restricted to
trained personnel only. Do not view exposed fibre or connector ends when handling
optical equipment.

AIMA3000.FT5P Product User Manual
Technetix Group Limited
[email protected] •technetix.comMay/2016 - Version 1.0 8
3 Overview
3.1 Product Description
The 1550 nm Forward Transmitter - Performance (FT5P) is designed to plug into Technetix latest Advanced Intelligent Multi-
services Access platform (AIMA3000).
This series of modules includes Monolithic Distributed Bragg Reflector (DBR) laser with a Silicon Optical Amplifier and an
Indium- Phosphide (InP) Mach-Zehnder Modulator provide AIMA with a cost-eective system for 1550 nm transmissions for
DWDM applications when used for optical ITU frequency grids.
Technetix AIMA3000 FT5P series transmitter is designed for multi-service operators (MSOs) to increase network
capacity to satisfy an ever-growing subscriber demand for more bandwidth. The FT5P can be used with Erbium Doped
Fibre Amplifiers (EDFA) in short haul Fibre-to-the-Home (FTTH) applications and medium haul set-ups with a high RF
performance of up to 60 km.
All FT5P models can also be conveniently monitored and controlled through a computer connected to one of the Ethernet
ports or an Android mobile device via the ASMM module. All module settings are retained in non-volatile memory to
ensure trouble-free operation. Bulk updating, automatic uploading and downloading of configuration files can be done
when using Technetix NMSE web-based management system.

AIMA3000.FT5P Product User Manual
Technetix Group Limited
[email protected] •technetix.comMay/2016 - Version 1.0 9
3.2 Product Key Features
• DOCSIS 3.1 Compatible with operating bandwidth up to 1218 MHz
• Suitable for DWDM applications supporting ITU channels with 100 GHz steps
• All-digital QAM loading from 45 MHz to 1218 MHz
• Link distance of up to 60 kilometers without any dispersion compensation required
• High SBS suppression level to allow launch power up to +20 dBm
• Automatic gain control (AGC) for a consistent optical modulation index (OMI)
• Automatic laser power control for consistent optical output
• Comprehensive alarm reporting and monitoring
• Remote firmware upgrade and auto upload/download of configuration files through ASMM web interface or
using Technetix NMSE
• Bulk firmware updates through Technetix NMSE
• FCC, CE and RCM (1) compliant
(1) See Declaration of Conformity for current status.

AIMA3000.FT5P Product User Manual
Technetix Group Limited
[email protected] •technetix.comMay/2016 - Version 1.0 10
3.3 Specifications
Optical Performance
Optical wavelength (1) ITU Channels 21 to 35 (optional: 18~60)
Optical outputs 1, 2
Optical output power per port 5~15 dBm
Optical connector SC / APC, LC / APC, FC/APC, E2000 / APC
Centre wavelength spacing 100 GHz
SBS Suppression +20dBm
RF Performance
RF bandwidth 45 ~ 1218 MHz
RF flatness ± 0.75 dB
RF input return loss > 18 dB
RF input level, nominal (2) 20 dBmV per channel
AGC range ±3 dB
RF impedance 75 Ω
Laser Input RF level test point -20 dB ± 1 dB relative to laser input
Port-to-port Isolation > 50 dB
(narrowcast to broadcast)
RF input connectors Single: 2 x GSK-type female (1 for NC, 1 for BC)
Double: 4 x GSK-type female (2 for NC, 2 for BC)
RF test points Single: 1 x Mini-SMB(3)
Dual: 2 x Mini-SMB(3)
Alarms and laser status Front-Panel LEDs, SNMP traps
Link Performance (4)
MER > 38 dB
BER < 1E-9
General
Power supply Powered via AIMA3000 backplane
Power consumption Single/Dual unit up to 6 dBm: < 14 W / 20 W
Single/Dual unit 7~15 dBm: < 20 W / 22 W
Operating temperature 0 ~ +55 °C
Operating humidity 90 % (Non-condensing)
Storage temperature -40 ~ +70 °C
Storage humidity 90 % (Non-condensing)
Dimensions (W*D*H) 24.6 * 410 * 152.5 mm
Weight 0.88 kg
Supported network Technetix NMSE or through ASMM’s Web Interface
management options

AIMA3000.FT5P Product User Manual
Technetix Group Limited
[email protected] •technetix.comMay/2016 - Version 1.0 11
Notes:
(1) The factory default ITU optical channel is 33.
(2) dBuV=60+dBmV
(3) One mini-SMB connectors on front panel to measure RF input before the laser transmitter.
(4) MER and BER are tested with 117 QAM256 (301.25 MHz~997.25MHz). All are measured thought EDFA, launch power of
+20 dBm, 20 km of fibre.

AIMA3000.FT5P Product User Manual
Technetix Group Limited
[email protected] •technetix.comMay/2016 - Version 1.0 12
3.4 Block Diagram
Table 3-1 FT5P Block Diagram Glossary
Figure 3-1 Block diagram FT5P
Parameters Glossary
NC Narrowcast
BC Broadcast
ATTEN Attenuator
-20 dB OMI TP -20 dB Test Point
TO BACK PLANE AND COMMS Data Bus
CPU Central Processing Unit

AIMA3000.FT5P Product User Manual
Technetix Group Limited
[email protected] •technetix.comMay/2016 - Version 1.0 13
3.5 Order Details
A-FT5P-[U]-[V]-[W]-[X]-[Y]-[Z] 1550 nm Forward Transmitter – Performance
Options:
U Optical Ports
SSingle (1)
DDual (2)
V Optical Output Power per Port (1)
05 5 dBm (3 mw)
06 6 dBm (4 mw)
07 7 dBm (5 mw)
08 8 dBm (6.3 mw)
09 9 dBm (8 mw)
10 10 dBm (10 mw)
11 11 dBm (12.6 mw)
12 12 dBm (15.8 mw)
13 13 dBm (20 mw)
14 14 dBm (25 mw)
15 15 dBm (31.6 mw)
16 16 dBm (39.8 mw)
17 17 dBm (50.12 mw)
06 6 dBm (4 mw)
W SBS Suspension
17 17 dBm
20 20 dBm
X Wavelength (2)
21 192.1 THz (1560.61 nm)
22 192.2 THz (1559.79 nm)
23 192.3 THz (1558.98 nm)
… …
33 193.3 THz (1550.92 nm)
34 193.4 THz (1550.12 nm)
35 193.5 THz (1549.32 nm)
Y Optical Connector Type
SSC / APC (3)
LLC/APC
FFC/AP
EE2000 / APC
Z Bandwidth
12 45-1218 MHz

AIMA3000.FT5P Product User Manual
Technetix Group Limited
[email protected] •technetix.comMay/2016 - Version 1.0 14
Note:
(1) Default 5 dBm, contact Technetix Representatives for order detailed 6~15 dBm output power.
(2) Default spacing is 100 GHz. For other wavelength configurations not listed, please contact Technetix.
(3) Standard option. Contact a Technetix Sales Representative for availability of other options.

AIMA3000.FT5P Product User Manual
Technetix Group Limited
[email protected] •technetix.comMay/2016 - Version 1.0 15
4 Module Characteristics
4.1 Module Appearance and Port Layout
4.1.1 Overview
Front Panel
Rear Panel
Figure 4-1 Module Appearance

AIMA3000.FT5P Product User Manual
Technetix Group Limited
[email protected] •technetix.comMay/2016 - Version 1.0 16
4.1.2 Front Panel Layout
Figure 4-2 FT5P Front Panel Layout

AIMA3000.FT5P Product User Manual
Technetix Group Limited
[email protected] •technetix.comMay/2016 - Version 1.0 17
Table 4.1 RT5S Front Panel Functions
Item Number Item Description
1 MODE LED
Module Gain Control Mode Indicator
MGC: Green Light Blinking
AGC: Green
2 STATUS LED
Module Alarm Indicator
Normal: Green
Minor Alarm: Amber
Major Alarm: Red
3 LSR1 LED
Laser 1 Status Indicator
ON: Green
OFF: Red
Major Alarm: Red
4 LSR1-TP Laser 1 Input Test Point
5 LSR2 LED
Laser 2 Status Indicator
ON: Green
OFF: Red
Major Alarm: Red
6 LSR2-TP Laser 2 Input Test Point
7 Orange tab-retaining clip
Used to plug and anchor the module
The tab-retaining clip will pop-up after
pressing the release and plug module.
8 OPT OUT 1 Optical output 1
9 OPT OUT 2 Optical output 2
10 Mounting Screw Module fastening screw
CAUTION!
“OPT OUT” emits a non-visible laser radiation when working.

AIMA3000.FT5P Product User Manual
Technetix Group Limited
[email protected] •technetix.comMay/2016 - Version 1.0 18
4.1.3 Rear Panel Layout
Figure 4-3 Rear Panel Layout

AIMA3000.FT5P Product User Manual
Technetix Group Limited
[email protected] •technetix.comMay/2016 - Version 1.0 19
Table 4-2 FT5P Rear Panel Functions
Serial Number Item Description
1 NC1 IN Narrowcast RF input
2 BC1 IN Broadcast RF input
3 NC2 IN Narrowcast RF input
4 BC2 IN Broadcast RF input
5 Air Vent Air vent allowing air to flow out of the module
6 Multi-pin connector Power and communication port
7 Placement Pin Used to position the module in the chassis

AIMA3000.FT5P Product User Manual
Technetix Group Limited
[email protected] •technetix.comMay/2016 - Version 1.0 20
5 Installation
5.1 Preparatory Work for Installation
Before installing this device, you must ensure that the unit is intact and ready for installation.
Unpack and check the unit: Open the box to check for any damage that may have occurred during shipment.
If damage is found, please contact a Technetix customer support representative.
Necessary equipment and tools for installation:
Table 5.1 Necessary equipment and tools for installation
Tools/Modules Description
Phillips screwdriver PH1/PH2 For use with the AIMA3000 chassis
FT5P Module The module to install into the AIMA3000 chassis
No. Description Qty
1 FT5P module 1
2 Individual test sheet (Certificate of Performance) 1
5.2 Unpacking
Unpack the module. Keep the packaging materials for future transport needs.
Check the packaging, record the product module type, serial number, purchase date, and any other relevant information to
facilitate later management and maintenance.
Table 5.2 Packing Manifest
