Techni Mobili RTA-2333 User manual

MODEL RTA-2333
MODEL RTA - 2333
Thanks for purchasing one of our products.
Please read carefully the assembly instructions before the installation.
Please save this manual for future reference.
ASSEMBLY INSTRUCTIONS

RTA-2333

RTA-2333 P.3
PARTS LIST
Right
Left
341 2
58
67
9
11 12
10
13
1
2
4
5
7
14
10
20
X4
Left Panel Right Panel Back Panel Top Panel
Bottom Panel Support Tubes Main Structure Short Tube
Long Tube Front Tube
Back Tube Studs Slider
X2 X3 sets

P.4
14 17
15
18 19 20
16
21
Drawer Front Panel Drawer Left Panel Drawer Right Panel Drawer Bottom Panel
Drawer Back Panel Handle Table Top
Drawer Connect
X3 X3 X3 X3
X3 X3
X6
RTA-2333

RTA-2333 P.5
A
B
D
C
E
14
36
12
6
16
PART QTY. ITEM PART QTY. ITEM
F18
G4
H
I
2
2
1
4
J
SCREWS LIST
6X40 MM
3X15 MM
4X35 MM
4X20 MM
4X14 MM
6X15 MM
6X35 MM
6X25 MM
6X60 MM
Ф16 MM

30mm
P.6
RTA-2333

P.7
ASSEMBLY STEPS:
1
3
4
SCREWS
4X20 MM
D
2PCS
SCREWS
4PCS
4X35 MM
C
2
F
SCREWS
2PCS
6X15 MM
SCREWS
B
4PCS
3X15 MM
15
16 16
15
21
14
16
15
17
18
16
15
14
19
Use screws B to assemble the Drawer Connects (21)
to the Drawer Left and Right Panels (15 & 16).
Use screws F to assemble
the Drawer Connects (21)
to the Drawer Front
Panel (14).
Slide in the Drawer Bottom Panel (17).
Use screws C to assemble the Drawer Back Panels (18) to
the Drawer Left and Right Panels (15 & 16).
Use screws D to assemble the Handle (19) to the Drawer
Front Panel (14).
RTA-2333

P.8
Left Right
Left
Right
SCREWS
B
4PCS
3X15 MM
REPEAT STEP 1 TO 5 FOR THE OTHER TWO DRAWERS
15
13 13 13
13
5
Grab the 2 sets of the Drawer Sliders (13) and separate the flat
ones from the “L” shaped ones. Place the drawer upside-
down as shown and use screws B to assemble the “L” shaped
Sliders to the Drawer Left & Right Panels (14 & 15) as shown.
IMPORTANT: REFER TO THE DRAWINGS FOR THE CORRECT
POSITION OF THE SLIDERS. If they get installed incorrectly,
the drawers will raise 1" with a gap at the bottom and the top
drawer will not close!
1
2
Right
Left
13 13
X2 X2
SCREWS
B
8PCS
3X15 MM
6
Grab 2 sets of the Flat Sliders (13) and use screws B to assemble
them to the Left & Right Panels (1 & 2) as shown.
The wheel on the sliders go facing to the FRONT and the screw
goes on the hole after the wheel as shown.
Attention: Do not assemble the sliders at the bottom of the
panels; it is done until Step 9 !
RTA-2333

P.9
1
2
3
SCREWS
4PCS
6X40 MM
A
12
3
4
5
SCREWS
10PCS
6X40 MM
A
7
8
First screw bolts A to the Left and Right Panel (1 & 2), then assemble
the Back Panel (3) as shown and as explained in page 5.
First screw bolts A to the Top Panel (4) and Bottom Panel (5),
then assemble these panels to the Left and Right Panel, Back
Panel (1, 2 & 3) as shown and as explained in page 5.
2
Right
13
SCREWS
B
4PCS
3X15 MM
1
Left
13
9Grab the last set of Flat Sliders (13)
and use screws B to assemble them
to the Left & Right Panels (1 & 2) as
shown.
The wheel on the sliders go facing to
the FRONT and the screw goes on the
hole after the wheel as shown.
RTA-2333

P.10
5
6
X4
SCREWS
16PCS
4X14 MM
E
7
12
9
8
F
SCREWS
4PCS
6X15 MM
10
11
Use screws E to assemble the Support Tubes (6) to the
Bottom Panel (5).
Use screws F to assemble the Long Tube (9) to the Main Structure (7)
and the Short Tube (8).
Insert the Studs (12) to the Main Structure (7).
10
7
8
F
SCREWS
4PCS
6X15 MM
12
Use screws F to assemble the Front Tube (10) to the Main Structure (7)
and the Short Tube (8).
Please pay attention to the direction of the Front Tube (10).
RTA-2333
(UPSIDE-DOWN)

P.11
11
8
7
F
SCREWS
4PCS
6X15 MM
8
7
20
SCREWS
2PCS
6X25 MM
H
2PCS
6X60 MM
I
I
H
13
14
Use screws F to assemble the Back Tube (11) to the Main
Structure (7) and the Short Tube (8).
Please pay attention to the direction of the Front Tube (11).
Use screws H & I to assemble the Short Tube (8) and the Main
Structure (7) to the Table Top (20).
ATTENTION: Make sure to use the correct screws (6x25MM).
Using wrong screws will cause damage to the Tabletop !
RTA-2333

P.12
14
14
14
14
14
14
10
11 11
10
44
OR
SCREWS
4PCS
6X35 MM
G
4PCS
JФ16 MM
15
16
Use screws G & J to assemble the Front Tube (10) and the Back
Tube (11) to the Top Panel (4).
Please note here are two options for you to assemble the cabinet
on the Left side or Right side.
Tighten any and all screws.
Insert the drawers into the cabinet,
starting with the bottom drawer.
You might have to insert it at a
downward tilted angle.
RTA-2333

English
- DO NOT EXPOSE THE SURFACES TO DIRECT SUNLIGHT OR EXTREME
ENVIRONMENTAL CONDITIONS. ANY DAMAGE RESULTING FROM SUCH
EXPOSURE IS NOT COVERED BY THE PRODUCT’S WARRANTY.
- THE PREFERABLE METHOD TO CLEAN THE SURFACES IS TO WIPE THEM
USING A SOFT CLOTH DAMPENED WITH A SOLUTION SOAP AND WATER,
THEN DRY WITH A CLEAN TOWEL.
- DO NOT SPRAY SOLVENTS OR CLEANING AGENTS DIRECTLY OVER THE
SURFACES, STRUCTURAL TUBES OR METAL PARTS.
- DO NOT LEAN, SEAT OR STAND OVER THE UNIT.
- DO NOT ALLOW CHILDREN TO PLAY OVER/UNDER THE UNIT, NOR ALLOW
THEM TO REACH INSIDE ANY COMPARTMENTS WITHOUT THE SUPERVISION
OF AN ADULT.
- BEFORE MOVING OR TRANSPORTING THE UNIT, MAKE SURE THAT:
ALL HEAVY OBJECTS OR THAT MIGHT FELL OFF ARE REMOVED FROM
THE UNIT.
IF THE UNIT ARE ON CASTERS (WHEELS), MAKE SURE THAT ALL ARE
UNLOCKED.
THE UNIT MUST BE HANDLED BY AT LEAST 2 PERSONS.
WHEN LIFTING THE UNIT, USE BOTH OF YOUR HANDS, AND BEND YOUR
KNEES. REMEMBER TO ALWAYS LIFT WITH YOUR LEGS, NOT YOUR BACK.
- IN CASE OF DAMAGE TO ANY PARTS, NOTIFY THE VENDOR AS SOON AS
POSSIBLE.
- IN CASE OF GLASS BREAKAGE (IF THE UNIT HAS A GLASS TABLE TOP OR
PARTS MADE OF GLASS) DO NOT HANDLE THE BROKEN GLASS WITH YOUR
BEAR HANDS, AND CONTACT THE VENDOR IMMEDIATELY. DO NOT ALLOW
CHILDREN NEAR THE BROKEN GLASS.
CARE AND MAINTENANCE
