Techni Mobili RTA-8413L User manual

MODEL RTA-8413L
ASSEMBLY INSTRUCTIONS
Thank you for purchasing our product
REV.042021-1

RTA-8413L P.1P.1
•Please read carefully the assembly instructions
before the installation.
•Do not discard this manual or any of the packaging
material until the unit has been completely
assembled.
•Might require two people.

RTA-8413L P.2P.2
Left Tabletop x1
Bx1
Cx1
D
Right Panel
x1
ECenter-Right Panel
x1
Fx1
Gx1
H
Right Shelf Panel
x1
Ix1 Jx1 Kx1 L
Right Tabletop
Center-Left Panel Shelf Left Support
Left Back panel Right Back panel Adjust panel
x1
ALeft panel
Shelf Right Support
MAIN PARTS LAYOUT (FOR REFERENCE)
A
B
C
J
EF
K
D
L
G
H
I

RTA-8413L P.3P.3
LIST OF HARDWARE, SCREWS AND FITTINGS
PART QTY. ITEM
1 2Pcs Long Dowel
Cam Lock &
Bolt Sets
8Sets
3
222Pcs Short Dowel
414Pcs
ST3.5 x 16
515Pcs
ST5 x 40
6 8Pcs
Caps for
Cam locks
7 15Pcs Screw Caps
8 3Pcs L Bracket
9 2Pcs Metal Plate
10 10Pcs
Nail-in Glide Stud
11 4Pcs Metal Pin

☛This unit uses cam bolts and locks. The following explains how to use them.
This is not an assembly step; it is a guide for when you are actually doing the
assembly using this kind of hardware.
Cam Bolt Cam Lock
1. Screw the bolt into the
corresponding panel.
2. Place the other panel over the
panel with the bolt, then insert the
cam lock to join the bolt’s head.
If the cam lock does not want to
enter, check its proper alignment.
There might be a very small gap
between the panels which is normal.
3. Turn the cam lock clockwise. This
will lock the parts together and will
close any gaps.
Alignment: The cross
points towards the panel
with the bolt.
RTA-8413LP. 4 P. 4

RTA-8413L P.5P.5
BEFORE YOU START THE ASSEMBLY, PLEASE READ THE FOLLOWING TIPS AND WARNINGS.
❶Do aquick inventory
to make sure the package
contains all the parts and
hardware listed in the
assembly instructions.
❷Missing, damaged
and defective parts can
be replaced at no cost
to you. Please refer to
the last pages on this
manual.
❹If during assembly
you find an issue or
need clarification, please
contact our Customer
Service for assistance.
Please refer to the last
pages on this manual.
❺On each step read the
instructions and analyze
the illustrations thoroughly
before proceeding to do the
assembly.
❽Do not overtighten
or force the screws as
they might break, strip,
damage the threads of
the holes or get stuck
inside the part.
❻Make sure you
understand which
hardware will be used on
each step.Using the
wrong size of screw, bolt
or pin might strip the
threads or cause damage
to the part in which it is
being used.
❼To avoid
misalignments, always
leave the screws loose
and tighten them until
all pieces are
positioned correctly.
❾Sometimes the laminate might cover
partially or entirely the hole on apanel.If there
is no visible hole for the screw, pass and press
the tip of your finger over the area where the
hole should be located to feel the indentation,
and once found, carefully pierce the laminate to
reveal the hole underneath.
❿If the hole seems too small for the screw,
first make sure you are using the correct size of
screw and that it’s been installed in the correct
hole.If the hole still appears to be too small,
carefully pierce the laminate to reveal the
hole’s actual size.
❸The replacement parts
service is limited to the
continental United States.
If you reside in Alaska,
Hawaii, Puerto Rico,
U.S. territories or other
countries, please contact
the supplier from where the
unit was purchased.

Install all the short dowels 2 into all panels as shown. Use a wooden or light rubber
hammer to avoid damage to the pins.
Please pay close attention to which holes you have to use, and do not join any parts
yet!
RTA-8413L P.6P.6
ASSEMBLY STEPS
STEP 1
Hardware/Tools:
222
Pcs
(NOT INCLUDED)
Install the long dowels 1 into the panel A in the holes shown in the illustration.
Please pay attention to the correct holes to use as other holes on the panel are
intended for other hardware in other steps.
STEP 2
Hardware/Tools:
12
Pcs
Short Dowel
(NOT INCLUDED)
(Front)
Long Dowel
(Panel is shown upside-down).
A
K
J
CEFDHI
G

First install bolts 3 into the panels A and B in the holes indicated in the illustration.
Then install the metal plate 9 on the panel B using screws 4 as shown.
RTA-8413L P.7P.7
STEP 3
Hardware/Tools:
38
Pcs
(NOT INCLUDED)
Attach L bracket 8 to the panels J and K with screws 4 making sure the
bracket corners go flush with the edge of the panels.
STEP 4
Hardware/Tools:
43
Pcs
(NOT INCLUDED)
44
Pcs
92
Pcs
83
Pcs
Bolt
ST3.5 x 16
(Front)
(Front)
ST3.5 x 16
(Top)
(Top)
(Panels are shown upside-down).
B
84
9
4
A
K
J
3

Assemble the panels D and G using screw 5 as shown.
RTA-8413L P.8P.8
STEP 5
Hardware/Tools:
52
Pcs
(NOT INCLUDED)
Assemble panel I to panel G with screw 5 making sure the big hole for the cam
lock on panel I goes facing towards the inside.
STEP 6
Hardware/Tools:
51
Pc
(NOT INCLUDED)
(Front)
(Top)
On panel I, the big hole
for the cam lock goes
facing towards the inside.
(Top)
ST5 x 40
ST5 x 40
(Front)
G
D
G
I

Flip over the pieces from step 6, and assemble the panel H to panel G with screw
5 as shown.
RTA-8413L P.9P.9
STEP 7
Hardware/Tools:
51
Pc
Assemble panel K to panel D with screws 5 from the inside as shown.
STEP 8
Hardware/Tools:
52
Pcs
On panel H, the big hole
for the cam lock goes
facing towards the inside.
(NOT INCLUDED)
(Top)
(NOT INCLUDED)
ST5 x 40
ST5 x 40
(Top)
G
H
D
K

Assemble the panel F to panel K using screws 5 as shown, then install the
glides 10 to the bottom of the panels D, F, H and I as shown.
RTA-8413L P.10P.10
STEP 9
Hardware/Tools:
52
Pcs
Assemble the panel C to panel J using screws 5 as shown.
STEP 10
Hardware/Tools:
52
Pcs
10 6
Pcs
(Top)
(Front)
(Front)
(Top)
ST5 x 40
(NOT INCLUDED)
(NOT INCLUDED)
F
K
C
J
10
5
D
I
H
5
(Right)

Assemble the panel E to panel J using screws 5 as shown, then install the
gildes 10 to the bottom of the panels C and E as shown.
RTA-8413L P.11P.11
STEP 11
Hardware/Tools:
52
Pcs
(NOT INCLUDED)
With the parts assembled in steps 9 and 11 positioned as shown in the
illustration, assemble the panels E and F using screws 5.
STEP 12
Hardware/Tools:
53
Pcs
10 4
Pcs
This illustration shows the same
parts from step 10, but viewed
from the right.
The parts assembled in steps 9
and 11 are shown here in the
normal upright position.
(Top)
(Left)
(Right)
ST5 x 40
ST5 x 40
(NOT INCLUDED)
E
J
F
E
10
C
5
(Top)

With the help of another person, place first the right tabletop B over the right
section of the unit, then place the left tabletop A over the left section. Then insert
the cam locks 3 into the holes of panels C, D, E, F, H and I making sure they go
aligned, and turn the cam locks as explained in page 4. Finally, cover the cam
locks with 6.
RTA-8413L P.12P.12
STEP 13
Hardware/Tools:
38
Pcs
Using screws 4, secure the metal plates 9 from panel B to panel A, and the L
Brackets 8 on panels J and K to panels A and B respectively.
STEP 14
Hardware/Tools:
47
Pcs
68
Pcs
3rd
2nd 1st
Last
(NOT INCLUDED)
(NOT INCLUDED)
B
8
A
E
B
C
I
D
H
F
3
6
A
44
9
K
J

Cover all the screw heads with caps 7 as shown. Insert the metal pins 11 into the
corresponding holes on panels D, H and I, and place the Shelf panel L over the
pins as shown.
RTA-8413L P.13P.13
STEP 15
Hardware/Tools:
715
Pcs
(NOT INCLUDED)
11 4
Pcs
I
11
H
7
D
L

RTA-8413L P.14P.14
Give yourself a nice pat on the back. You did a great job!
ALL DONE!

RTA-8413L P.15P.15
AFTER THE ASSEMBLY IS DONE, PLEASE READ CAREFULLY THE FOLLOWING
CARE AND MAINTENANCE WARNINGS:
110 Lbs (50Kg)
11 Lbs (5Kg)
11 Lbs (5Kg)
22 Lbs (10Kg)
WEIGHT LIMITS
·Do not exceed the indicated weight limits.
·Do not expose the surfaces to direct sunlight or to extreme environmental conditions.
·Clean the surfaces preferable with a clean cloth damped in a solution of mild soap and
water, then dry with a clean towel.
·Do not use solvents or abrasive materials to clean the unit.
·If you decide to use a cleaning agent, test first on an area hidden from view such as
underneath the tabletop.
·Do not sit on the unit or lean against it.
·Do not allow small children to play under or over the unit.
·Do not pull, push or drag the unit to move it for more than 1 feet. The unit must be
lifted by at least 2 persons when moving in the same or adjacent rooms.
·Before moving the unit, make sure to secure or remove any object that is heavy or
might fall off, and be careful handling the extended right tabletop to avoid damage
from bending and separation.
·When lifting the unit, use both hands and bend your knees, not your backs.
·When transporting the unit to places far away, protect and secure the unit to avoid
damage in transit. If possible, disassemble the unit in sections.
·Shall any part of the unit become defective during the warranty period, replacement
parts might be available to you at no charge. Please refer to the last pages on this manual.
·The warranty does not extend to regular wear and tear, nor the manufacturer assumes
liability for damages or consequences due to accidents, incorrect assembly,
negligence, improper use, modifications, or not heeding the above warnings.

RTA-8413L
P.16 P.16

RTA-8413L
