Techni Mobili RTA-7050 User manual

MODEL RTA-7050
ASSEMBLY INSTRUCTIONS
Thanks for purchasing one of our products.
Please read carefully the assembly instructions before the installation.
Do not discard this manual or the packaging material until the unit has
been completely assembled.
REQUIRES OF
2 PERSONS
Imported by:
Expandable and Reversible

Top panel for upper
section
Middle panel for
upper section
Short vertical panel
for upper section
Long exterior vertical
panel for upper
section
Long interior
vertical panel for
upper section
Bottom panel for
upper section
Top panel for
lower section
Bottom panel for
lower section
Left panel for lower
section
Right panel for
lower section
Middle-left panel
for lower section
Middle-right panel
for lower section
Back panel for
lower section
Drawer front panel Drawer left panel Drawer right panel
Drawer back panel Drawer bottom
panel
Drawer sliders, SET of 4 pcs
MAIN PARTS LIST
P.2
RTA-7050
P.2
❶
x1 ❷
x1 ❸
x2 ❹
x1
❺
x1 ❻
x1 ❼
x1 ❽
x1
❾
x1 ❿
x1 ⓫
x1 ⓬ x1
⓭
x1 ⓮ x2 ⓯ x2 ⓰ x2
⓱
x2 ⓲ x2 ⓳ x2
“FLAT”
“L” shaped

St3x14mm 16
⌀25 (felt) 10
⌀22 (laminate) 8
M6x35mm 26
⌀8x30mm 34
St7x58mm 16
St3.5x40mm 8
1. Screw the bolt in the
corresponding panel.
2. In the other panel, insert and
align the cam lock so it can receive
the head of the bolt.
3. Join the panels and turn the cam
lock. A small gap might happen
which is normal, and it will close
when all the cam locks are turned.
☛This unit uses special cam bolts and locks. The following explains how to assemble using this kind
of hardware. This is not and assembly step, just a guide for when you have to use these kind of
special hardware.
Bolt Cam lock
ALIGNMENT
DIRECTION
SCREWS LIST
P.3
RTA-7050
P.3
No. Figure Size qty. No. Figure Size Qty.
MAIN PARTS LAYOUT (for reference)
❶
❷
❸
❸
❹❺
❻
❼
❽
❾
⓬⓮
⓮

BEFORE STARTING THE ASSEMBLY, PLEASE READ THE FOLLOWING TIPS AND WARNING:
P.4
RTA-7050
P.4
•Do a quick inventory to make sure the product contains all the parts and hardware.
•Missing, damaged and defective parts can be replaced at no cost to you. Please refer to the CONTACT card
included with the product.
•The replacement parts service is limited to the continental United States. If you reside in Hawaii, Puerto Rico,
U.S. Dependencies or other countries, please contact the supplier from where the unit was purchased.
•
If during assembly you find an issue or need clarification, please contact our Customer Service for assistance.
Please refer to the CONTACT card included with the product.
•On each step read the instructions and analyze the illustrations thoroughly before proceeding to do the
assembly.
•Make sure you understand which hardware will be used on each step. Using the wrong size of screw, bolt or
pin might strip the threads or cause damage to the part in which it is being used.
•To avoid misalignments, always leave the screws loose and tighten them until all pieces are positioned
correctly.
•Do not overtighten or force the screws as they might break, strip, damage the threads of the holes or get
stuck inside the part.
•Sometimes the laminate might cover partially or entirely the hole on a panel, but the hole should still be
located under the laminate.
•If there is no visible hole for the screw, pass and press the tip of your finger over the area where the hole
should be located to feel the indentation, and once found, carefully pierce the laminate to reveal the hole
underneath.
•If the hole seems too small for the screw, first make sure you are using the correct size of screw and that it’s
been installed in the correct hole. If the hole still appears to be too small, carefully pierce the laminate to
reveal the hole’s actual size.

STEPS 1 THROUGH 11 IS FOR THE ASSEMBLY OF THE LOWER SECTION
P.5
RTA-7050
P.5
STEP 3
Screws:
🅐
M6x35mm
8
Pcs
🅑
Φ8
x30 8
Pcs
1st: Insert the wooden pins Ⓑin the corresponding holes on panel ⑦.
2nd: Insert the bolts Ⓐin the corresponding holes on panel ⑦.
3rd: Insert and align the cam locks Ⓐin the panels ⑨, ⑩, ⑪and ⑫.
4th: Assemble the panels ⑨, ⑩, ⑪and ⑫to panel ⑦as shown and as explained on
page 3.
STEP 1 Separate all the sliders pieces ⑲according to their shape (no assembly is done here):
-The “Flat” ones go on the side panels and will be used on step 2.
-The “L” shaped go on the drawers and will be used until step 10, please set them aside.
See page 3
With the panels ⑨, ⑩, ⑪and ⑫oriented as shown, assemble the “Flat” sliders ⑲on
the bottom of the panels using screws Ⓔas shown. Please note the correct holes to use on
the sliders and make sure the wheels face towards the front of the panels.
“Flat” sliders: Will be
used on step 2.
“L” shaped sliders:
Will be used on step 10.
STEP 2
Screws:
🅔
St3x14
8
Pcs
(Front)
(Front)
(Front)
(Front)
(All panels are shown upside-down

P.6
RTA-7050
P.6
STEP 4 Insert the back panel ⑬thru the groves of panels ⑦, ⑨and ⑩.
STEP 5
Screws:
🅑
Φ8
x30 8
Pcs
🅒
ST7x58
8
Pcs
1st: Insert the wooden pins Ⓑin the corresponding holes on panels ⑨, ⑩, ⑪and ⑫.
2nd: With the help of another person, place the bottom panel ⑧and assemble it to panels
⑨, ⑩, ⑪y ⑫using screws Ⓒas shown.
(The grove faces
down and towards
The back of the panel)
STEP 6
Screws:
🅕
Φ
25
(Felt)
6
Pcs
Peel off and adhere the felt covers Ⓕover the screw holes on panel ⑧as shown.
⓫
⓬

P.7
RTA-7050
P.7
Assemble the drawer back panel ⑰to the side
panels ⑮and ⑯using screws Ⓓas shown.
STEP 7
Screws:
🅓
ST3.5x40
4
Pcs
STEP 10
Screws:
🅔
ST3x14
4
Pcs
STEP 8
Insert the drawer bottom panel ⑱thru
the groves of side panels ⑮, ⑯and
⑰.
STEP 9
Screws:
🅐
M6x35mm
4
Pcs
See page 3
1st Insert the bolts Ⓐin the corresponding holes on the drawer front panel ⑭.
2nd: Insert and align the cam locks Ⓐin the side panels ⑮and ⑯.
3rd: Assemble panel ⑭to panels ⑮and ⑯as shown and as explained on page 3.
REPEAT STEPS T THROUGH 10 FOR THE SECOND DRAWER
With the drawer assembled in the previous step upside-down, assemble the “L” shaped
sliders ⑲using screws Ⓔas shown, making sure the wheel goes towards the back and
the sliders don’t protrude at the bottom.
VERY IMPORTANT!
INCORRECT:
Raises the
drawer 1” and
won’t fit in unit!
CORRECT:
Sliders don’t
protrude on
the bottom of
the drawer
(Front)
(The groves face
down towards the
bottom on all panels)
(Front)
(Front)

P.8
RTA-7050
P.8
Insert the drawers in the unit. If they don’t seem to fit, review steps 2 and 10 for the correct
assembly of the sliders.
STEP 11
STEPS 12 THROUGH 18 FOR THE ASSEMBLY OF THE UPPER SECTION
(All panels are shown upside-down)
STEP 12
Screws:
🅐
M6x35mm
4
Pcs
🅑
Φ8
x30 4
Pcs
1st: Insert the wooden pins Ⓑin the corresponding holes on panel ①.
2nd Insert the bolts Ⓐin the corresponding holes on panel ①.
3rd: Insert and align the cam locks Ⓐin the panels ③.
4th: Assemble the panels ③to the panel ①as shown and as explained on page 3.
See page 3

P.9
RTA-7050
P.9
STEP 13
Screws:
🅐
M6x35mm
2
Pcs
🅑
Φ8
x30 2
Pcs
1st: Insert the wooden pins Ⓑin the corresponding holes on panel ②.
2nd: Insert the bolts Ⓐin the corresponding holes on panel ⑤.
3rd: Insert and align the cam locks Ⓐin panel ②.
4th: Assemble the panel ⑤to panel ②as shown and as explained on page 3.
See page 3
(All panels are shown
upside-down)
STEP 14
Screws:
🅐
M6x35mm
2
Pcs
🅑
Φ8
x30 6
Pcs
1st: Insert the wooden pins Ⓑin the corresponding holes on panels ①and ③that were
assembled in step 12.
2nd: Insert the bolts Ⓐin the corresponding holes on panel ①.
3rd: Insert and align the cam locks Ⓐin panel ⑤.
4th: Assemble the panel ②to the panels ③, and the panel ⑤to the panel ①as shown
and as explained in step 3.
See page 3

P.10
RTA-7050
P.10
STEP 15
Screws:
🅐
M6x35mm
2
Pcs
🅑
Φ8
x30 2
Pcs
🅒
ST7x58mm
4
Pcs
1st: Assemble the panel ②to the panels ③using screws Ⓒ.
2nd: Insert the wooden pins Ⓑin the corresponding holes on panel ①.
3rd: Insert the bolts Ⓐin the corresponding holes on panel ①.
3th: Insert and align the cam locks Ⓐin panel ④.
5th: Assemble panel ④to panel ①as shown and as explained on page 3.
See page 3
STEP 16
Screws:
🅑
Φ8
x30 4
Pcs
🅒
ST7x58mm
4
Pcs
1st: Insert the wooden pegs Ⓑin the corresponding holes on panels ④and ⑤.
2nd: Assemble panel ⑥to panels ④and ⑤using screws Ⓒ.
Make sure to
assemble panel ④
with the cam locks
facing inwards

P.11
RTA-7050
P.11
STEP 17
Screws:
🅕
Φ
25 (felt) 4
Pcs
🅖
Φ
22
(laminate)
8
Pcs
Place the following adhesive lables:
- Felt Ⓕfor the screw holes on panel ⑥.
- Laminate Ⓖfor the cam lock holes on panels ③, ④and ⑤.
(Felt)
Place the upper section assembled in step 17 over the lower section assembled in step 11
according to your preference. The below illustrations show some suggestions.
WARNING:
For safety, when setting the unit in expanded option, do not place the upper section too
close to the edge of the lower section.
STEP 18
CLOSED: EXPANDED:
DONE! Before you start using the product, make sure that all the screws, bolts, cam
locks, etc. are properly tightened, and read all the warnings listed in the next page.
(Laminate)

•When setting the unit in expanded option, do not place the upper section too close to the edge of the lower
section.
•Do not exceed the indicated weight limits.
•Do not expose the surfaces to direct sunlight or to extreme environmental conditions.
•Clean the surfaces preferable with a clean cloth damped in a solution of mild soap and water, then dry with a
clean towel.
•Do not use solvents or abrasive materials to clean the unit.
•If you decide to use a cleaning agent, test first on an area hidden from view such as underneath the top.
•Do not seat or stand on the unit.
•Do not allow small children to play over the unit or under the upper section (expanded option), or reach inside
the drawers or compartments without your supervision.
•The unit must be handled by at least 2 persons when moving in the same or adjacent rooms.
•Before moving the unit, make sure to remove any object that is heavy or might fall off.
•When lifting the unit, use both hands and bend your knees, not your backs.
•When transporting the unit to places far away, protect and secure the unit to avoid damage in transit.
•Shall any part of the unit become defective during the warranty period, replacement parts might be available
to you at no charge. Please refer to the WARRANTY card included with the product.
•
The warranty does not extend to regular wear and tear, nor the manufacturer assumes liability for damages or
consequences due to accidents, incorrect assembly, negligence, improper use, modifications, or not heeding
the above warnings.
•The warranty is limited to the continental United States. If you reside in Hawaii, Puerto Rico, U.S.
Dependencies or other countries, please contact the store from where the unit was purchased.
