BullFrog OD2211 ECKfrog User guide

ASSEMBLY AND INSTRUCTION MANUAL
www.bullfrog-design.com
MODEL OD2211 ECKfrog
© 2022 K URT BEI E R &KATI QU I N G E R
2 functional armrests
completely foldable
Manual rocking skid lockFunctional back
foldable up to the relax position

P3
P3 P4
P4
P1
P1P2
P2
P5
P5
1. To lock the rocking skid lock, first li the front of the rocking runner slightly and turn the foot (A) right and le
towards the ground to the magnetic cylinder head screw (E).
2. Repeat the procedure at the back side of the runners with the 2 adjustable feet (B).
3. To return the ROCKfrog to rocking position, start at the back (in reverse order) and turn the rocking locks back
onto the magnetic cylinder head screws.
Use of the rocking skid lock:
4 x cylinder head
screw with magnet
E
8 x cap nuts F
4 x spring washers G
BB
C
C
AA
2 x front side feet A2 x back side feet B
B
A
C
C
D
E
E
D
G
F
F
P1
P1
P2
P2
C
D
OD2211 ECKfrog
© 2022 K URT BEI E R &KATI QU I N G E R
G
Front side
Assembly of the rocking skid lock:
Package scope (FP):
4 x round-head bolt D
Front side
Back side
Back side
Rocking skid lock
Unlocking the
rocking skid lock
1. Screw in hand-tight one foot (A/B) each into the runners from the inside (at the 4 positions P1) using a
round-headed bolt (D) and a spring washer (G) (note "front" and "rear" here).
2. Secure the bolts (D) with one cap nut (F) each and tighten them.
3. Screw the 4 cylinder head screws (E) into the runners from the inside at the 4 positions (P2).
4. Secure the screws (E) with one cap nut (F) each.

1. To adjust the desired position grip the back from the outside and pull it carefully towards yourself.
2 . To obtain zero position pull the back carefully beyond the top position towards yourself and fold it
down into zero position.
3. From zero position you can easily snap the back into desired position.
Functional back & functional armrests:
OD2211 ECKfrog
© 2022 K URT BEI E R &KATI QU I N G E R
For the adjustment of the armrests you can proceed in the same way.

Safety Instructions!
Please observe the following safety instructions for your pleasure with ECKfrog:
2. Attention! In case of any improper use, the runners may lead to injuries during the
rocking (trapping risk).
1. While rocking, it is not allowed for anyone to stay within the swing’s range, next
or below the rocking chair respectively swinging rocker (risk of injury).
3. Do not stand on the product. The rocking chair is not a toy, gymnastics equipment
or climbing frame. Children must not use the product without adult supervision. Do
not sit on the back or arm section.
No liability can be accepted for improper use.
No liability shall be assumed for direct and indirect consequential damages
caused by modifications of this product, the equipment, the performance and the
material usage done by the customer.
Subject to changes and error.
You have observed all of the safety instructions? Then, Bullfrog wishes you a good rocking time!
Maintenance care of the runners:
In order to keep unused threads serviceable, it is required to regrease them 1 x per year with machine
lubricant.
OD2211 ECKfrog
© 2022 K URT BEI E R &KATI QU I N G E R
Keep all documents relating to the purchase of your furniture carefully, even beyond the legal warranty period of 2 years. You will
find all important information in your product folder and also on our website www.bullfrog-design.com
