Techni Mobili RTA-1009 User manual

PARTS LIST
ATTENTION: Before you begin to assemble the
product, please make sure that all the parts are
included in the package and in good condition.
ASSEMBLY INSTRUCTIONS
CHAIR STYLE RTA-1009
Insert the casters (F) in the legs of the
base (C) using pressure, then place the
gas lift (E) and the cover (I) in the middle
of the base as shown.
Flip over the seat (B) with its front
towards you and assemble the armrests
(G) in the respective sides using screws
(K) as shown.
Assemble the backrest (A) to the
mechanism (D) from underneath using
screws (M) and washers (O) as shown.
NOTE: The position of the backrest
(forward or backward) depends on which
set of 4 holes you choose on the seat to
install the mechanism.
Assemble the mechanism (D) to the seat
(B) on one of the sets of 4 holes using
screws (L) and washers (O) as shown.
Place the top parts over the base parts
making sure the tip of the gas lift enters
into the hole of the mechanism.
Before seating and using the chair for
the first time, make sure that all
screws are properly tightened.
C
E
I
F
B
G (Right)
G (Left)
B
L+O
D
M+O
A
5-Star base
Backrest
Mechanism
Hydraulic
Gas Lift
Casters
F
x5
Seat
Ø 6x25mm
Ø 6x25mm
Base Cover Headrest
Ø 8x20mm
(Backrest)
(Armrests)
(Mechanism, backrest)
M
x3
E
x1
D
x1
C
x1
A
x1
B
x1
I
x1 J
x1
K
x6
L
x4
Ø 6x30mm
(Mechanism)
ATTENTION:
• Follow the instructions step by step.
• To avoid misalignments, leave the screws loose and do not tighten them until all are in their respective places.
• Do not overtighten or force the screws as they could break, strip, or damage the threads of the holes.
• Using the wrong size of screws on a part could result in damage to the screw or the part
12 3
45 6 Assemble the headrest (J) to the
backrest (A) using screws (N) as shown.
N
x2
O
x7 Allen wrench 6mm
Allen wrench 5mm
P
x1
When you seat on the chair, not looking at it.
G
Washers
(Headrest)
Q
x1
K
D
Allen wrench 4mm
R
x1
x1
Left
Armrests
x1
Right
J N
R
QQ
P

CHAIR’S FUNCTIONS:
(1) Chair height: Pull UP the lever located under the seat
on your RIGHT. The chair goes down while sitting on it,
or up if you lift your body.
(2) Backrest reclining: Pull UP the lever located under the seat
on your LEFT, the backrest will recline freely. You can lock the
reclining angle by pushing the lever DOWN.
(3) Reclining tension: Turn the mechanism’s knob in either
direction to apply more or less tension to the reclining function.
(4) Armrests: Push the buttons that are on the armrests
and release them once the desired height is reached. The
arms can also rotate and slide back and forth.
(5) The headrest can move UP and DOWN and tilt FRONT-BACK.
(6) The lumbar support can adjust FORWARD and BACKWARDS.
WARNINGS:
•Do not stand up on the chair or use it as ladder.
•Use the chair to seat only one person at a time.
•Do not use the chair if parts are damaged or if screws are loose or missing.
•Do not seat near the edge of the seat and always sit properly on the chair to avoid going beyond your balance point and fall off the chair.
•The chair is intended for teenagers and adults. If small children are using the chair, please keep close observation on them.
•Do not allow small children to play with the chair.
•Not paying attention to these warnings could result in severe injuries.
CUCARE AND MAINTENANCE:
•To clean the chair it is recommended to use a soft cloth lightly damped in a solution of smooth soap and water, then dry with a clean towel.
•Do not use solvents or abrasive materials to clean any part of the chair.
•Before applying a cleaning agent, test on a small hidden area of the chair, like underneath the seat.
•Do not expose the product to direct sunlight or to extreme environmental conditions.
•Every 4 months, inspect the chair completely and make sure that all screws are tighten.
(1)
(5)
(6)
(3)
(4)
(2)
