Technicolor CGM4231 User manual

TECHNICOLOR WIRELESS
GATEWAY - CGM4231
OPERATIONS GUIDE
Version - Draft 1.1
Copyright © 2018
Technicolor
All Rights Reserved
No portions of this material may be reproduced in any form without the
written permission of Technicolor.

1/8/2018 Proprietary and Confidential - Technicolor 2
Revision History
Revision
Date
Description
Draft 1.0
1/8/2018
Initial draft

1/8/2018 Proprietary and Confidential - Technicolor 3
Table of Contents
1!Introduction ............................................................................................................................ 7!
2!Technicolor Wireless Gateway .............................................................................................. 8!
2.1!System Information ....................................................................................................... 17!
3!Initial Configuration and Setup ............................................................................................ 19!
3.1!Accessing the WebUI .................................................................................................... 19!
4!WebUI Guide ....................................................................................................................... 20!
5!Status Pages ....................................................................................................................... 22!
5.1!Overview ....................................................................................................................... 22!
5.2!Gateway ........................................................................................................................ 22!
5.3!Local Network ............................................................................................................... 24!
5.4!Wireless Status ............................................................................................................. 26!
5.5!DOCSIS Status ............................................................................................................. 28!
5.6!DOCSIS Signal ............................................................................................................. 30!
5.7!DOCSIS Log ................................................................................................................. 34!
5.8!System .......................................................................................................................... 34!
6!Connection .......................................................................................................................... 37!
6.1!Devices ......................................................................................................................... 37!
6.2!LAN ............................................................................................................................... 37!
6.2.1!LAN Setup ............................................................................................................. 38!
6.3!WAN .............................................................................................................................. 39!
6.3.1!User Provisioning of WAN ..................................................................................... 39!
6.3.2!SNMP Provisioning for WAN ................................................................................. 43!
6.3.3!Dual Stack Router .................................................................................................. 43!
6.4!Routing .......................................................................................................................... 44!
6.4.1!Enable / Disable IGMP Proxy ................................................................................ 44!
6.4.2!RIP ......................................................................................................................... 44!
6.4.3!SNMP Provisioning for Routing ............................................................................. 46!
6.5!MoCA ............................................................................................................................ 47!
6.5.1!User Provisioning for MoCA .................................................................................. 47!
6.5.2!SNMP Provisioning for MoCA ................................................................................ 48!
6.6!Modem .......................................................................................................................... 49!
6.7!MTA ............................................................................................................................... 50!
6.8!Network Time ................................................................................................................ 50!
7!Wireless ............................................................................................................................... 52!

1/8/2018 Proprietary and Confidential - Technicolor 4
7.1!Radio ............................................................................................................................. 52!
7.1.1!User Provisioning for Radio ................................................................................... 53!
7.1.2!SNMP Provisioning for Radio ................................................................................ 54!
7.2!Security ......................................................................................................................... 54!
7.2.1!User Provisioning for Wireless Security ................................................................. 55!
7.2.2!SNMP Provisioning for Wireless Security .............................................................. 56!
7.3!Advanced ...................................................................................................................... 57!
7.3.1!User provisioning for Advanced Wireless .............................................................. 58!
7.3.2!SNMP Provisioning for Advanced Wireless ........................................................... 60!
7.4!Guest Network .............................................................................................................. 60!
7.4.1!User Provisioning for Guest Network ..................................................................... 62!
7.4.2!SNMP Provisioning for Guest Network .................................................................. 63!
7.5!MAC Control .................................................................................................................. 63!
7.5.1!User Provisioning for MAC Control ........................................................................ 64!
7.5.2!SNMP Provisioning for MAC Control ..................................................................... 65!
7.6!WPS .............................................................................................................................. 65!
7.6.1!User Provisioning for WPS .................................................................................... 65!
7.7!QOS .............................................................................................................................. 66!
7.7.1!User Provisioning for QOS .................................................................................... 67!
7.7.2!SNMP Provisioning for QOS .................................................................................. 68!
8!Security ................................................................................................................................ 69!
8.1!Firewall .......................................................................................................................... 69!
8.1.1!User Provisioning for Firewall ................................................................................ 69!
8.1.2!SNMP Provisioning for Firewall ............................................................................. 72!
8.2!IP Filter .......................................................................................................................... 72!
8.3!Device Filter .................................................................................................................. 72!
8.3.1!SNMP Provisioning for Device Filter ...................................................................... 73!
8.4!Site Filter ....................................................................................................................... 74!
8.4.1!SNMP Provisioning for Site Filter .......................................................................... 74!
8.5!Service Filter ................................................................................................................. 75!
8.5.1!SNMP Provisioning for Service Filter ..................................................................... 77!
8.6!VPN Settings ................................................................................................................. 77!
8.6.1!User Provisioning for VPN Settings ....................................................................... 77!
8.7!Email Settings ............................................................................................................... 83!
8.8!Reports.......................................................................................................................... 84!
9!Application ........................................................................................................................... 85!

1/8/2018 Proprietary and Confidential - Technicolor 5
9.1!Port Forward ................................................................................................................. 85!
9.2!Port Trigger ................................................................................................................... 85!
9.3!DDNS ............................................................................................................................ 86!
9.4!DMZ .............................................................................................................................. 87!
9.4.1!SNMP Provisioning for DMZ .................................................................................. 88!
9.5!UPNP ............................................................................................................................ 88!
9.5.1!User Provisioning of UPnP .................................................................................... 89!
9.5.2!SNMP Provisioning for UPNP ................................................................................ 89!
9.6!IP Passthrough ............................................................................................................. 89!
9.7!Media ............................................................................................................................ 90!
10!Administration ................................................................................................................... 92!
10.1!User ........................................................................................................................... 92!
10.2!WiFi Power ................................................................................................................ 92!
10.3!Remote Access ......................................................................................................... 93!
10.3.1!SNMP Provisioning for Remote Management ................................................... 94!
10.4!Backup & Restore ..................................................................................................... 94!
10.4.1!User Provisioning for Backup & Restore ............................................................ 94!
10.4.2!SNMP Provisioning for Backup & Restore ......................................................... 95!
10.5!Reboot & Reset ......................................................................................................... 95!
10.5.1!SNMP Provisioning for Factory Settings ............................................................ 96!
10.6!Restarting the Device ................................................................................................ 96!
10.6.1!SNMP Provisioning for Restarting the Device .................................................... 97!
10.7!Trouble Shooting ....................................................................................................... 97!
10.8!Remote Log ............................................................................................................... 98!
10.9!Historical Consumption ............................................................................................. 98!
11!Diagnostics ..................................................................................................................... 100!
11.1!System ..................................................................................................................... 100!
11.2!Interface .................................................................................................................. 100!
11.3!Network ................................................................................................................... 104!
11.4!Wireless ................................................................................................................... 106!
11.5!Clients ...................................................................................................................... 109!
11.6!Internet .................................................................................................................... 110!
11.7!Self Test .................................................................................................................. 110!
12!Isolation .......................................................................................................................... 112!
12.1!User Provisioning for Isolation ................................................................................. 112!
12.2!SNMP Provisioning for Isolation .............................................................................. 112!

1/8/2018 Proprietary and Confidential - Technicolor 6
13!TR-069 ............................................................................................................................ 114!
13.1!User Provisioning for TR-069 .................................................................................. 114!
13.2!SNMP Provisioning for TR-069 ............................................................................... 114!
14!Appendix1: Web User Interface Control ........................................................................ 116!
15!Appendix2: A Sample CM Config File ........................................................................... 122!
16!Abbreviations and Acronyms .......................................................................................... 125!

1/8/2018 Proprietary and Confidential - Technicolor 7
1 Introduction
This document provides information on the Technicolor 4231 Wireless Gateway to Technicolor’s
service provider customers. The audience for this document includes those personnel who are
tasked with deploying, maintaining, and servicing this device as well as those who provide
answers to questions from end users.

1/8/2018 Proprietary and Confidential - Technicolor 8
2 Technicolor Wireless Gateway
The Technicolor Wireless Gateway (Wireless Gateway) meets industry standards for DOCSIS
3.1 high-speed data connectivity along with reliable digital telephone service. The Technicolor
Wireless Gateway delivers data, voice and wired (Ethernet) or wireless (Wi-Fi) gateway
capabilities to connect a variety of devices at home or SOHO small home office that supports
high speed data access and voice services in one device.
Front Panel View
The following image represents the Wireless Gateway.
Figure 2.1

1/8/2018 Proprietary and Confidential - Technicolor 9
Top Panel View and LED Operations
The following image represents the front panel view of the Wireless Gateway
Figure 2.2
A
B
C
D
I
H
G
F
E

1/8/2018 Proprietary and Confidential - Technicolor 10
WPS Button (item A)
Wi-Fi Protected Setup (WPS) support, including an HW push button to activate WPS for
simplified and secure wireless setup.
Power LED (item B)
Downstream (DS) LED (item C)
State
Description
Solid on
Wi-Fi Protected Setup (WPS) support, including an HW push button to
activate WPS for simplified and secure wireless setup
Off
WPS setup not active
State
Description
Solid on
Main Power Supply (12volt, 4.5 Amp.). DUT is on Main Power Supply.
Blinking
Slow Blink - MoCA is enabled, Fast Blink – MoCA enabled and MoCA client
connected
Off
Power –Off
State
Description
Solid on
Down Stream channel locked
Off
Power-Off
Flashing with US
LED off
Searching for downstream signal
Flashing with US
LED on
Partial service mode
Both US and DS
Flashing
Software upgrade in progress

1/8/2018 Proprietary and Confidential - Technicolor 11
UP stream LED (US) (item D)
Online LED (item E)
2.4 GHz Wi-Fi LED (item F)
State
Description
Blinking
Data is being transferred over the wireless connection. Wi-Fi is connected.
Off
Wi-Fi access point is not enabled
5 GHz Wi-Fi LED (item G)
State
Description
Blinking
Data is being transferred over the wireless connection. Wi-Fi is connected.
Off
Wi-Fi access point is not enabled
State
Description
Solid on
UP stream channel locked
Off
Power-Off
Flashing with DS
Led off
Attempting to communicate with the CMTS
Flashing with US
Led on
Partial service mode
Both US and DS
Flashing
Software upgrade in progress
State
Description
Solid on
Modem provisioning complete
Flashing slow
Attempting DHCP
Flashing fast
Attempting TFTP and final registration with CMTS
Very slow blink
Network access disabled by configuration file
Off
Not connected to your service provider’s network

1/8/2018 Proprietary and Confidential - Technicolor 12
Telephone Line 1 led (item H)
State
Description
Solid on
Telephone Service on line -1 is enabled
Blinking
Telephone line 1 is connected to telephone and is operational
Flashing
Line two off (EMTA DHCP)
Both
lines Blinking
Device registering with call agent
Off
Line 1 is not connected to phone or not operational
Telephone Line 2 led (item I)
State
Description
Solid on
Telephone Service on line -2 is enabled
Blinking
Telephone line 2 is connected to telephone and is operational
Flashing
Line one off (EMTA DHCP)
Both
lines Blinking
Device registering with call agent
Off
Line 2 is not connected to phone or not operational.

1/8/2018 Proprietary and Confidential - Technicolor 13
Back panel
The following image shows the back of the Wireless Gateway.
Figure 2.3
Tel ports (item A)
Two-line embedded digital voice adapter for wired telephony service.
Ethernet switch (item B)
Four 1000/100/10BASE-T Ethernet ports to provide wired connectivity. Each Ethernet port has
two LEDs:
LED
LED Status
Description
A
B
C
D
E
F
G
H

1/8/2018 Proprietary and Confidential - Technicolor 14
Left LED
(Green)
Solid on
Connected to a Gigabit Ethernet device
Blinking
Connected to a Gigabit Ethernet device and sending/receiving
data
Off
Not connected to a Gigabit Ethernet device
Right LED
(Amber)
Solid on
Connected to a 1000Mbps/100Mbps/10Mbps device
Blinking
Connected to a 1000Mbps/100Mbps/10Mbps device and
sending/receiving data
Off
Not connected to a 100Mbps/10Mbps device
Reset Button (item C)
Press on the Reset button to reset the box.
Note:
Press and hold the reset button for more than 6 seconds to restore the gateway to factory
settings.
Cable port (item D)
Compliance with DOCSIS 3.0, 3.1 standards along with PacketCable™ and EuroPacketCable™
specifications to deliver high-end performance and reliability.
USB port (item E)
USB interface provides full access for advanced user
Technicolor Wireless Gateway does not support USB printing. Refer section
Power Switch (item F)
The power switch (Turn-On/Off) allows you to turn-on and turn-off the box.
Power inlet (item G)
The power inlet (Power) allows you to connect the power cord.
Wi-Fi Turn –On/Off Switch (item H)
The Wi-Fi switch (Turn-On/Off) allows you to turn-on and turn-off the Wi-Fi.

1/8/2018 Proprietary and Confidential - Technicolor 15
Bottom panel
The following image depicts the bottom panel view of the Wireless Gateway.
Figure 2.4
Product label: - The label on the bottom of the Gateway contains the following information
about your Gateway:
MTA MAC No. (Item A)
MTA MAC No of Device. It is of the following format:
MTA MAC –X XXXXXXXXXXX
WAN MAC No. (Item B)
WAN MAC No of Device. It is of the following format:
WAN MAC –X XXXXXXXXXXX
Serial Number of Device (Item C)
S/N of Device. It is of the following format:
S/N –X XXXX XXXX
CM MAC No. (Item D)
A
B
C
D
E
F
G
H

1/8/2018 Proprietary and Confidential - Technicolor 16
CM MAC No of Device. It is of the following format:
CM MAC –X XXXXXXXXXXX
2.4 GHz SSID (Item E)
Network Name (SSID) is the network name of the 2.4 GHz access point and is of the following
format:
2.4 GHz
SSID: X XXXXX
PRE- SHARED KEY of Device FOR 2.4 GHz (Item F)
PRE- SHARED KEY of Device. It is of the following format:
PRE - SHARED KEY –X XXXXXXXX
5 GHz SSID (Item G)
Network Name (SSID) is the network name of the 5 GHz access point and is of the following
format:
5 GHz
SSID: X XXXXX
PRE- SHARED KEY of Device FOR 5 GHz (item H)
PRE- SHARED KEY of Device. It is of the following format:
PRE - SHARED KEY –X XXXXXXXX
Other Features Details
• Compliance with DOCSIS 3.0, 3.1 standards along with Packet Cable™ and Euro Packet
Cable™ specifications to deliver high-end performance and reliability
• Two-line embedded digital voice adapter for wired telephony service
• Up to two 802.11 radios for the dual-band concurrent operation with up to eight SSIDs
per radio
• Wi-Fi Protected Setup TM (WPS) support, including an HW push button to activate WPS
for simplified and secure wireless setup
• User configurable Parental Control blocks access to undesirable Internet sites
• Advanced firewall technology deters hackers and protects the home network from
unauthorized access
• Attractive compact design that allows for horizontal, or wall-mounted operation
• Color-coded interface ports and corresponding cables to simplify installation and setup

1/8/2018 Proprietary and Confidential - Technicolor 17
• DOCSIS-8 compliant LED labeling and behavior provides a user and technician friendly
method to check operational status and act as a troubleshooting tool
• Automatic software upgrades by the service provider
• TR-069 Compliant Remote Management Capabilities
2.1 System Information
The following WebUI page of the Wireless Gateway provides the hardware and software version
information of the product.
Figure 2.5

1/8/2018 Proprietary and Confidential - Technicolor 18
Software File Name and Revisions
The data shown in the table below provides the information about the firmware of your Wireless
Gateway:
Figure 2.6

1/8/2018 Proprietary and Confidential - Technicolor 19
3 Initial Configuration and Setup
The Technicolor Wireless Gateway is configured using the Web UI
3.1 Accessing the WebUI
Procedure
There are 3 interfaces for the user/operator to connect to on the CGM4231:
• LAN (Default URL 192.168.0.1 on LAN side)
• Cable Modem (CM IP on the WAN side)
• eRouter (eRouter IP on the WAN side)
Apart from these 3 interfaces, there are 2 user levels, Home User and Advanced User.
When the user connects to the WebUI, the page prompts the user enter the username and
password. There is no user name and password set on default for the home user. On boot-up,
the user can login to the WebUI by pressing <ENTER> and the user will be directed to a page to
set the user name and password. After doing so, the user is directed again to the login page to
login to the system with new credentials.
For the advanced user, the user name is admin and the password would be the generated
password of the day.
Figure 3.1
The various pages on the WebUI may be accessible once the credentials are accepted.

1/8/2018 Proprietary and Confidential - Technicolor 20
4 WebUI Guide
Table 4.1 below describes the webpages available for the Home user (Advanced Access) in
online and offline states.
Top Tab
Webpage (sub-tab)
On-line
Off-line
Status
Overview
ü
ü
Gateway
ü
ü
Local Network
ü
ü
Wireless
ü
ü
DOCSIS Status
ü
ü
DOCSIS Signal
ü
ü
DOCSIS Log
ü
ü
System
ü
ü
Connection
Devices
ü
ü
LAN
ü
ü
WAN
ü
ü
MoCA
ü
ü
Routing
ü
ü
Modem
ü
ü
MTA
ü
ü
Network Time
ü
ü
Wireless
Radio
ü
ü
Security
ü
ü
Advanced
ü
ü
Guest Network
ü
ü
MAC Control
ü
ü
WPS
ü
ü
QoS
ü
ü
Security
Firewall
ü
ü
IP Filter
ü
ü
Device Filter
ü
ü
Site Filter
ü
ü
Service Filter
ü
ü
VPN
ü
ü
Email Settings
ü
ü
