I LOCATIONS OF CONTROLS
power only.
The unit is in the "standby" condition when this switch is set
to the standby cb posilion. Regardless oÍthe switch setling,
the primary circuit is always "live" as long as the power cord
is connected to an electrical outlet.
Power "standby Ó/on''
(power/r standbY Ó _
This switch switches ON and
switch
on)
oFF the secondary circuit
FM stereo indicator (stereo)
This indicator automatically illuminates when
an FM stereo broadcast is being received.
Note:
lt will not illuminate iÍthe FM mode selector is
set to the monaural mode.
The lndlcatlon AM used here lncludes
both MW and LW.
Band selectors (band)
FM:
Press this button to listen to an FM broadcast.
MW:
Press this button to listen to an MW broadcast.
allocatlon:
This butlon is also used to select a Írequency
step oÍeither 9 kHz or 10 kHz.
When the MW button is pressed tor about 4
seconds, the MW Írequency step will change to
10 kHz peístep.
ohis step is set to 9 kHz beÍore shipment.)
Set to the appropriate position Íot your locality.
ln order lo return to the original írequency indica-
tion, press this button Íorabout 4 seconds a9ain.
LW:
Press.this button to listen to an LW broadcast.
íreqshlít:
When the LW butlon is pressed íorabout 4
seconds during reception oÍan LW broadcast,
the LW írequency will decrease by 2 kHz.
So, íorexample, to receive 153 kHz' tune lo 'l55
kHz, and then press this button.
]n order lo return to the original írequency indica-
tion, press lhis button Íoraboul 4 seconds again.
Digital írequency display
The reception Írequency oÍthe FM or AM broadcast
selected by using the tuning buttons or the pÍeset-tun-
ing butlons is indicated by a digital-type display.
Quartz-lock indicator
(quartz lock)
This indicator illuminates when tuned
precisely to an FM or AM station.
Memory indicator (El)
This indicator illuminates when the
memory butlon is pressed.
Channel display
The channel number se]ected by the pÍeset'
tuning buttons is displayed.
Signal-strength indicators (signal )
These indicators show the relative strength oÍbroadcast
signals being received by the antenna. The best condi-
tion Íorreception, íorFM and AM' is when the indicators
illuminate completely to the right.
Tuning buttons (tuning)
These buttons are used Íortuning
to the desired broadcast station.
Memory button (memory)
This button is used when preset memory setting
oíthe preset-tuning buttons is made.
FM mode selector (FM mode)
This unit automatically switches into the stereo mode
when a steíeobroadcasl is received. Press this button
lo listen in the monaural mode. The slereo indicator will
not illuminate in the monaural mode.
Preset-tuning buttons (1-0)
(24 channel random presst tuning)
These buttons are used to preset FM and AM broadcasl
Írequencies into the memoíy oÍthis unit, arrd are also pressed
lo select the desired preset Írequencies.
Note:
Fle'er to page 6 íorinÍormation concerning presel memoÍy.
