TECHWOOD TVE-466T User manual



STAND FAN WITH REMOTE CONTROL
INSTRUCTION MANUAL
1


IMPORTANT SAFEGUARDS
❑Please read these instructions carefully before use.
❑Keep present instructions for future references.
❑Check that your mains voltage corresponds to that stated on
the appliance.
❑Only use the appliance for domestic purposes and
household or similar applications such as:
-staff kitchen areas, in shops, offices and other working
environments;
-by clients in hotels, motels and other residential type
environments;
- Environment type like :
• Farm Houses • Bed and Breakfast.
❑Only use the appliance in the way indicated in these
instructions.
❑Never use this unit near bathtub, shower, wash-hand basins
or other containers with water.
❑Never use this apparatus near water projections.
❑Never use this apparatus with the wet hands.
❑If, unfortunately the apparatus is wet, immediately withdraw
the cord of the socket-outlet.
❑Inform potential users of these instructions.
❑Never leave the appliance unsupervised when in use.
❑The appliance must be used only for its intended purpose. No
responsibility can be taken for any possible damage caused
by incorrect use or improper handling.
❑Children and persons with disabilities are not always aware of
the danger posed by the use of appliances.
❑This device can be used by children aged 8 years and older
and adults, with reduced physical, sensory or mental
capabilities or lack of experience and knowledge, if they have
been given supervision or instruction concerning use of the
2


appliance in a safe way and understand the hazards
involved.
❑Cleaning and maintenance must not be made by children
without supervision.
❑Keep the appliance and its cord out of reach of children aged
less than 8 years of age when it is energized or cooling down.
❑This device is not a toy, do not leave children or people with
disabilities to play with.
❑In order to ensure your children‘s safety, please keep all
packaging (plastic bags, boxes, polystyrene etc.) out of their
reach.
❑Warning! Never use without the guards in place. After
assembly, do not remove the guards for maintenance
purpose or cleaning.
❑Caution! Do not allow small children to play with the foil:
THERE IS A DANGER OF SUFFOCATION !
❑From time to time check the cord for damages. Never use the
appliance if cord or appliance shows any signs of damage.
❑Never immerse the appliance in water or any other liquid for
any reason whatsoever.
❑Never place it into the dishwasher.
❑Never use the appliance near hot surfaces.
❑Do not operate the appliance with a damaged cord or plug, or
after the appliance has been damaged in any manner.
❑If the supply cord or appliance is damaged, it must be
replaced by the manufacturer or its service agent or a
similarly qualified person in order to avoid a hazard.
❑Disconnect the power source cable before any operation of
cleaning of maintenance and accessories assembly.
❑Never use the appliance outside and always place it in a dry
environment.
3


❑Never use accessories, which are not recommended by the
producer. They could constitute a danger to the user and risk
to damage the appliance.
❑Never use any other connector than the one provided.
❑Never move the appliance by pulling the cord. Make sure the
cord cannot get caught in any way.
❑Never wind the cord around the appliance and do not bend it
❑Ensure that the power cord does not come into contact with
hot parts of this unit.
❑Make sure the appliance has cooled down before cleaning
and storing it.
❑The temperature of accessible surfaces may be very high
when the appliance is operating. Never touch these parts, of
apparatus, to avoid burning itself.
❑Make sure the appliance never comes into contact with
flammable materials, such as curtains, cloth, etc...& the
power cord and plug do not come in contact with water.
❑Before cleaning, always unplug the appliance from the power
supply and let it cool down.
❑This appliance is not intended to be operated by means of an
external timer or separate remote-control system.
❑Always place the unit on a flat surface. Ensure, also, not to
cover the device and not to put anything on it.
❑Always remove the plug from the wall socket when the
appliance is not in use.
❑When using an extension lead always make sure that the
entire cable is unwound from the reel. Use solely CE
approved extension leads. Input power must be at least 16A,
250V, 3000W.
❑Incorrect operation and improper use can damage the
appliance and cause injury to the user.
❑This device, designed for home use, complies with standards
relating to this type of product.
4


❑The appliance must be used and rested on a table or flat &
stable surface.
❑The item must not be left unattended when it is connected to
main supply.
❑The item is not to be used, if it has been dropped or if there
are visible signs of damage.
❑This appliance is only intended for household use.
GENERAL INFORMATION
The symbol "OPEN BOOK" means a recommendation
to read important things contained in the record.
The symbol "BIN" crossed out, abbreviation WEEE
(Waste of Electrical and Electronic Equipment) means
that at the end of life, it should not be discarded with
household waste, but filed to the sorting of the locality.
Waste recovery can help preserve our environment.
The symbol "CE" is the guarantee of compliance with
harmonized European standards, voluntary, reflecting
the essential requirements into technical
specifications. These standards are not mandatory
but are guarantees of compliance with essential
requirements.
The symbol ROHS (Restriction of use of some
Hazardous Substances) on the Environmental
Protection, certifies that for each of the five hazardous
substances • Lead • Mercury • (hexavalent) chromium •
products for protection against flames PBB and PBDE,
the peak concentration is equal to or less than 0.1% of
5


the weight of homogeneous material, and 0.01% for the
6th • cadmium.
The symbol "DOUBLE SQUARE" means a double
insulated. A basic insulation and supplementary
insulation. This device requires no connection to the
mass of a protective conductor grounded. The
materials are said : double insulation class II.
6


The symbol "TRIMAN" indicates that the consumer is
invited to dispose the product as part of a separate
collection (eg recycling bin, waste, voluntary intake
point).
For more information : http://www.quefairedemesdechets.fr
SPECIFIC SAFETY REQUIRED FOR THIS PRODUCT
1. Use the fan always set it on a flat surface.
2. Do not carry the device by holding the power cord.
3. Do not insert objects through the protective grill.
4. Do not use the device in a bathroom
5. Always use the fan with the included foot and upright.
6. Do not use near curtains etc.
No warranty will be applied if the appliance is used for other
than its intended use.
TO KNOW IT’S UNIT
1. Front Guard
2. Blade screw
3. Blade
4. Rear grid Nut
5. Rear Guard
6. Motor axis
7. Motor Housing
8. Oscillation Control
9. Motor Pivot safety Screw
10. Control panel
11. safety Screw motor / tube
12. Adjustable tube
13. Height setting Screw
14. Fix tube
15. Base
7


ASSEMBLING
● Take the two base cross and push the end caps
into the ends. Cross them over together as draw :
● Remove the four screws from the base and pole
the base on the fix tube to the base.
● Screw the 4 screws in the feet
● Slide the screw cover down over the adjustable
and lower base until it’s hide the screws.
● Set the height of the feet
● Attach the motor fan + panel control on top of the
upper tube and tighten it with retaining screw.
● Place the rear guard (2) onto the motor housing (pass the axis (1) in the hole
at the centre of the grid) and fix it with Central Fixing nut (3), and screw it
clock wise.
● Slide fan blade (4) onto the motor spindle ensuring that notch on the
rear line up with the spline on the shaft.
● Screw on the Blade with the Retaining Nut (5) turning anticlockwise
direction.
● Hang the front guard over the top of the rear guard and push the clips
inwards until the front guard is fastened to the rear guard.
8


● Finally fit the safety nut and screw 6) through the hole
in the bottom edge of the front guard arrowed and
tighten it.
CONTROL PANEL
1. Power on Light Indicator
2. Sensor for remote control
3. Timer Light Indicator (30 min/1h/1.5h/2h/2.5h/3h/
3.5h/4h/4.5h/5h/5.5h/6h/6.5h/7h/7.5h)
4. Speed Light Indicator (speed 3/2/1)
5. " Mode" indicator light
A. On and Speed selector
B. Mode selector Normal or Night or
Nature
C. Timer (Button
D. Stop button of the unit.
⇨All indicator lights must be off.
USE
● Unroll the power cord completely.
● Check that the tension in force in the country where you are corresponds to
that indicated on the apparatus.
● Connect the apparatus in a correct socket-outlet, (and connected to the ground
if the unit is Class I), to avoid any danger.
● Disconnect the power source cable before any operation of cleaning of
maintenance and accessories assembly.
● Never modify the appliance in anyway.
9


CONTROL PANEL INSTRUCTION
M / VITESSE = ON / SPEED
Press the “M/Vitesse” button (A) to turn the fan on.
When the fan is turned on it will start at the speed setting.
Select the desired speed by pressing the “M/Vitesse” (ON
/ Speed) button (A).
Once : Speed 1 will be on & Pilot light 1 will light.
Twice : Speed 2 will be on & Pilot light 2 will light.
3 times : Speed 3 will be on & Pilot light 3 will light.
By pressing the Stop button (D), the fan will stop.
TIMER
Select between the different setting time, by
pressing the timer button,
Each time changes the valour.
Once : Time is 30 minutes & Pilot light will light.
Twice : Time is 1 hour & Pilot light will light.
3 times : Time is 1.5 hour & Pilot light will light.
4 times : Time is 2 hour & Pilot light will light.
5 times : Time is 2.5 hour & Pilot light will light.
6 times : Time is 3 hour & Pilot light will light.
7 times : Time is 3.5 hour & Pilot light will light.
8 times : Time is 4 hour & Pilot light will light.
9 times : Time is 4.5 hour & Pilot light will light.
10 times : Time is 5 hour & Pilot light will light.
11 times : Time is 5.5 hour & Pilot light will light.
12 times : Time is 6 hour & Pilot light will light.
13 times : Time is 6.5 hour & Pilot light will light.
14 times : Time is 7 hour & Pilot light will light.
15 times : Time is 7.5 hour & Pilot light will light.
One more times & Time is back to 30min.
The fan will stay on for the selected amount of time.
By pressing the Stop button (D), the timer will be off
2


and the fan will stop.
3


MODE FUNCTION
Switch the Mode button (B)
between normal and sleep mode.
On “normal mode” :
The motor will run continuously.
On “sleep mode” :
the motor will run discontinuously.
5 seconds on & 5 seconds stop.
It is the Sleep program !
On “nature mode”:
the motor will be sometimes quickly,
sometimes slowly.
STOP BUTTON
Press the "Off" button (D) to stop program and fan.
ENSURE THAT ALL PILOT LIGHTS ARE TURNED OFF.
REMOTE CONTROL
All buttons are the same and have same functions as above explanations.
4


CLEANING AND MAINTENANCE
Before cleaning, always: switch off the appliance, disconnect the apparatus and
let it cool.
Clean the outside of the apparatus with a sponge or slightly wet linen.
Do not use abrasive cleaners, gritting, or metal brush or another cutting object.
The greasy dirt of the fan fuselage and fan blade should be cleaned so as not to
change its colour or be damaged.
Don’t clean it with water directly.
Don’t wipe it with acid detergent, lamp oil, alcohol or chemical cloth in case its
colour be changed or go bad.
Symptoms
Checking Points
The fan blade doesn’t work when
the fan starts.
Whether the plug is really put into the
outlet or not. Check fan blade.
There’s unusual sound
when the fan starts.
Check if fan blade is assembled properly.
STORAGE
-Ensure the unit is completely cool and dry.
-Do not wrap the cord around the appliance, as this will cause damage.
-Keep the appliance in a cool, dry place and out of reach from children.
GUARANTEE
Before being delivered, all our products are subjected to a rigorous control.
This apparatus is guaranteed 24 months starting from the date of purchase by the
consumer.
The documents in proof of guarantee are:
• The invoice and
• The filled and stamped warrantee plate (located on side or bottom of the gift
box). Without these documents in proof, no free replacement, nor no free repair,
can be carried out.
During the warranty period, we deal for free, the defects of the apparatus or the
accessories, rising from a defect of materials or manufacture by repair or,
5


replacement. The services within the framework of the guarantee do not involve
any extension of the warranty period and does not give right to a new guarantee !
In the event of recourse to the guarantee, bring back the complete apparatus to
your retailer, in its original packing, accompanied by the proofs of purchase.
The breakage of parts out of glass or plastic is, in all the cases, not warranted.
Defects on the accessories or the wearing parts (for example: coals of engines,
hooks, drive belts, remote control of replacement, teeth brushes of replacement,
webs etc) as well as cleaning, maintenance or it replacement of wearing parts are
not guaranteed and are thus to pay !
In the event of foreign intervention, the guarantee becomes null and void.
After flow of the warranty period, repairs can be carried out, against payment, by a
specialized trade or a repair service.
SPECIFICATIONS
Power supply 220-240V~ 50Hz
Power 40W
Norm Class II
Maximum fan flow rate 34,56 m3/min
Fan power input 38,19W
Service value 0.90 (m3/min)/W
Standby power consumption 0,45
Season electricity consumption 12,72 kWh/a
Fan sound power level 53.00 dB(A)
Maximum air velocity 2.12 meter/sec
Measurement standard for
Service value COMMISSION REGULATION (EU)
No 206/2012 & (EU) 2016/2282
IEC 60879: 1986 (corr.1992)
EN 50564: 2011
EN 60704-2-7: 1998
EN 60704-1: 2010+A11: 2012
Made in P.R.C
The characteristics can change without prior notice
CAUTION: In order to minimize the risks of electric shock, In the event of
breakdown, not to open the case but to call upon a qualified technician
for repairs.
6


This device complies with EC directives, it was controlled according to all current
European directives, applicable such as: electromagnetic compatibility (EMC) and
low voltage (LVD).
This device has been designed and manufactured in compliance with the latest
regulations and technical requirements for safety.
Contact details for obtaining More information &
Imported by Sotech International
" LE PERIPOLE " N°A-107
33, Avenue du Marechal de Lattre de Tassigny
94120 Fontenay sous-bois - France

7
