Tecknet X861 User manual

TeckNet X861 Gaming Keyboard & Mouse Combo

Welcome
Thank you for choosing this TECKNET product.To ensure optimum
performance and safety, please read these instructions carefully before
operating this product. It is strongly recommended you keep this manual
for future reference.
Product Layout
Shortcut Keys
FN + F1
Mute
FN + F2
Vol-
FN + F3
Vol+
FN + F4
Play/Pause
FN + F5
Previous
FN + F6
Next
FN + F12
Win Key
FN + 2
Decrease luminance
(Numeric keyboard)
FN + 5
Backlight Switch
FN + 8
Increase luminance
(Numeric keyboard)
(Numeric keyboard)
Package Contents
1 x TeckNet X861 Gaming Keyboard
1 x TeckNet WM-80 Gaming Mouse
1 x User Manual
1 x Warranty Card
01

TeckNet X861 Gaming Keyboard
Product Specifications
1.Three colors of backlight (red, blue, purple) with adjustable
brightness. 2.Adjustable “Breathing” light.
3.Game Lock Win key.
4.Multimedia functions.
5.Water resistant.
6.Both keyboard and mouse use USB 2.0 interface, plug & play, no
driver required.
7.Compatible with Windows OS (Windows 98, 2000, XP, Vista, WIN7,
WIN8, Win10, Mac OS).
8.USB cable length: 1.5M.
9.Operating voltage: +5VDC±10%.
10.Operating current: <250mA.
11.Keystroke force: 55±5g.
12.Key life: 10 million keystrokes.
X861Keyboard Functions:
3 Levels Adjustable Luminance
Increase Luminance: Simply press "FN" + "8" (Numeric keyboard), it
would increase the luminance.
Decrease Luminance: Simply press "FN" + "2" (Numeric keyboard)
for twice, it would decrease the luminance.
Permanent Luminance: Press "FN" + "2" (Numeric keyboard) for one
time, backlight would change to be permanent luminance.
Note: The backlight would turn off when press "FN"+"2"
(Numeric keyboard) for four times.
3 Adjustable Colors Backlit
3 adjustable colors(Blue, Red, Purple) backlit is available. Press
"FN" +"5"(Numeric keyboard) to switch the backlit color.
Direction key and numerical key exchange on Numeric keyboard
There is additional direction key on the numeric keyboard, simply press
"NumLk" would actualize exchange of direction key and numerical key.
Bracket Installation
There is a additional bracket for this keyboard. Firstly, take the keyboard
and bracket out from the package, reverse the keyboard, then position
the bracket to the fastener of the keyboard, when both slot of the bracket
are fastened by the keyboard, the bracket is installed successfully.
02

Game Lock Win Key
"FN" + "F12" key conveniently helps the player to avoid accidentally
pressing the Win key (which returns the screen back to desktop) during
gameplay. After pressing "FN" + "F12", the blue LED on the top right
corner will illuminate to indicate the Win key has been locked and cannot
be used. Press "FN" + "F12" again, the blue LED will turn off to indicate the
Win key is unlocked and the computer is ready for normal use.
TeckNet M985 Gaming Mouse
Product Specifications:
Note: This mouse is not programmable and no driver is needed.
1. Unique design.6D optical gaming mouse with precise sensor.
2. Plug & Play.
3. 5 keys and 1 wheel.
4. 800/1200/1600/2400 DPI shift, the default setting is 1200DPI.
5. Enhanced refresh rate.
6. Durable & comfortable scroll wheel design.
7.Compatible with Windows OS (Windows 98, 2000, XP, Vista, WIN7,
WIN8, WIN10).
8. Working voltage: 5.0V DC.
9. Current rating: ≤100mA.
10. Key life cycle: more than 1,000,000 clicks.
11.Dimension: 126 x 73 x 41.1mm (LxWxH).
12. Weight: 102g.
M985 Mouse DPI Switch
The mouse supports 800/1200/1600/2400DPI. To change the setting,
press the DPI button. The default setting is 1200DPI.
Press the DPI button on the top of the mouse once to change from 800DPI
to 2400DPI circularly.
IMPORTANT SAFETY INSTRUCTIONS-CAREFULLY FOLLOW
THESE INSTRUCTIONS.
1.SAVE THESE INSTRUCTIONS - This sheet contains important
safety and operating instructions.
2.Before using the product, read all instructions and caution markings
on the product, accessories and device using our product.
03

3.This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
4.Children should be supervised to ensure that they do not play with
the appliance.
5.Keep the product away from fire or explosion may occur.
6.For indoor use only. Do not expose to rain, water, excess moisture or snow. 7.Do
not place product in or near inflammable, explosive or hazardous object. 8.Do not
place in or near water, rain, excess moisture or extreme heat.
9.Do not operate product with damaged cord or plug.
10.Do not operate product if it has been damaged in any way.
11.Do not disassemble the product. Disassembly may result in a risk of
safety hazards.
12.Do not throw or shake the product
13.To reduce the risk of electric shock, unplug the product from the
power supply when not in use or switch off the power supply
Limited 18-Month Warranty:
What this warranty covers.
Shenzhen Unchain Technology Co., LTD. (Manufacturer: “Unchain”) warrants
to the original purchaser of this TeckNet product that the product shall be free
of defects in design, assembly, material, or workmanship.
What the period of coverage is.
Unchain warrants the TeckNet product for 18 Months.
What will we do to correct problems?
Unchain will repair or replace, at its option, any defective product free
of charge (except for shipping charges for the product).
What is not covered by this warranty?
All above warranties are null and void if the TeckNet product is not
provided to Unchain for inspection upon Unchain’s request at the sole
expense of the purchaser, or if Unchain determines that the TeckNet
product has been improperly installed, altered in any way, or tampered
with. The TeckNet Product Warranty does not protect against acts of God
such as flood, earthquake, lightning, war, vandalism, theft, normal-use
wear and tear, erosion, depletion, obsolescence, abuse, damage due to
low voltage disturbances (i.e. brownouts or sags), non-authorized
program, or system equipment modification or alteration.
How to claim the warranty
Please contact retailers or visit TeckNet website www.tecknet.co.uk for
more information 04

Warranty
We warrant that products purchased from authorized distributors will
meet the applicable product specifications and be free from all defects in
design, assembly, materials and workmanship. Please contact retailers
or visit our website (www.tecknet.co.uk)for more information.
Disclaimer
Every effort has been made to ensure that the information and procedures
in this guide are accurate and complete, no liability can be accepted for
any errors or omissions and we reserve the right to make any changes
without further notice to any products mentioned herein.
