TECLOCK SSL-250 User manual

User’s Manual
Bluetooth Digital Test Indicator
Type : SSL-250/SSL-260/(SSL-350)
Features
➢Resolution ：0.001 mm
➢Measuring range ：0.8 mm/2.0 mm
➢Measuring force ：0.15N/0.06N
➢IP protection ：IP54
➢Ｗｉｒｅｌｅｓｓ Communication ：Ｂｌｕｅｔｏｏｔｈ
1
Q-149-1-E Ver1.3

各部名称
①MODE button
②SET button
③Favorite button
④Dovetail mounting
⑤Contact point M1.4, interchangeable
⑥Slot for battery or Power cable
⑦Unit (mm / INCH)
⑧+ / - Indicator
⑨Low battery
⑩Preset mode
⑪MIN/MAX/DELTA mode
⑫Multiplication factor
⑬Hold measured value
⑭Analog scale range
⑮Button lock
⑯6 digits display
⑰Bluetooth active
⑱end data
⑲Analog display
2
Description
Type L(mm)
SSL-250 12.5
SSL-260 36.5
SSL-350 12.5/36.5

★Replacing the battery ★Reference setting
1. Operating features of the instrument
①Button
The instrument has two operating modes: basic functions (direct access) and advanced functions.
In addition to the configuration functions, you can access to MIN, MAX and DELTA (TIR) mode,
plus input of multiplication factor other than 1:1 (see chaps. 3 and 4).
②Button
The <favorite> key gives direct access to the function used most often (see chap. 6).
③Button
Sets a Preset value, resets the MIN/MAX mode, verifies a selection, and controls switching off the
instrument. By default, SIS mode enables automatic switch-off with no loss of origin (see chap. 7).
④Serial communication（Bluetooth/RS232/USB）
It is possible to activate or de-activate certain functions of the instrument via serial communication
(see chap. 9).Data transmission parameters are 4800bps,7bits,even parity, and 2 stop bits.
2. Start
Press a button. When used for the first time, after a battery change or a complete switch OFF, it is
necessary to set the reference ( --rEF-- ). Simply press (SET) when the touch probe is free in the center
position (see page 3).For a Bluetooth® connection (see chap. 5).
Set angle og the probe,
Press
★Linearity error
The axis of the measuring insert should be positioned
parallel to the surface of the component to minimize the
linearity error when measurements are taken (Fig. 1). In
case, this requirement cannot be met, the angle αmust
be determined and the indicator reading multiplied by the
corresponding angle correction factor.
Fig.1
3

3. Basic function :
Each short press on gives direct access to the basic functions.
4. Advanced functions
Prolonged pressure (>2s) on gives access to the advanced functions. Then, each short press
on accesses the required function:
PrE
ModE
bt
Bluetooth
nor
Min
MAX
dELtA
On
OFF
rESEt
MAC
Unit
MM
Inch
dir
MuLt
OFF
On
Auto
OFF
MAn
HId
bt.CFG
SIMPLE
PAIr
AnA
Loc
OFF
On
1scale=1digit
1scale=5digits
1scale=10digits
Of
4
Short press
Long press
・Assign NORMAL/
MIN/ MAX/DELTA
mode
・Bluetooth ON/OFF
・Reset Pairing mode
・Display the MAC add.
Assign measurement unit(mm/inch)
Assign measurement direction (+/-)
Assign multiplier mode OFF/ON
Assign the multiplier value
next digit
0～9
Save Mult.
Activates/deactivates the automatic switch-off
Auto : Activates / Man : De-activates
Assign Bluetooth profile(Config.)
SIMPLE/Pair/HID
Assign Button lock mode(OFF/ON)
Lock mode lock and .
To unlock, Press for 5 sec.
Assign Analogue scale.

5. Operation via Bluetooth
5.4. Bluetooth Connection :
1° Activate Bluetooth compatible software and hardware (Master: PC, Display Unit).
2° Start the instrument. By default the Bluetooth® module is active and the instrument is available for
connection (advertising mode).
3° If no connection is established during the advertisement period reactivate the Bluetooth® module
using the bt / On menu.
4° Instrument is ready to communicate (connected mode.)
5.5. Only with paired profile:
Pairing with master is automatically done at first connection.
To connect the instrument to a new master (new pairing), pairing information on the instrument must be
cleared using the bt/ rESEt menu.
5.6. Bluetooth Specifications:
5
5.1. HID mode（External Key board mode）
①Set HID mode by Advanced function.
②Set BT On mode by Advanced function.
③Reset Bluetooth mode by Basic function.
④Pairing connection the instrument to the PC.
（Instrument name：S_Dial TEST HID）
⑤Send the measured data by the DATA button.
5.2. Pair mode
①Set Pair mode by Advanced function.
②Set BT On mode by Advanced function.
③Reset Bluetooth mode by Basic function.
④Pairing connection the instrument to the PC.
（Instrument name：SY308）
⑤Send the measured data by the DATA button.
5.3. Bluetooth configuration
Items Specification
Frequency band 2.4GHz
Modulation GFSK
Max output power Class3(1mW)
Range
≦15m（open space），1-5m(industrial environment)
Version Bluetooth4.*
Display status Operating mode
off Bluetooth disconnected
blinkinng Bluetooth advertising
on Bluetooth connected
reset : clear pairing information
MAC : display the MAC address
Simple : profile without pairing
Pair : paired and secured profile
HID : virtual keyboard

6. Favorite key
The «favorite» key gives direct access to a predefined function, and can be configured according to the
needs of the user. In order to assign a function to the «favorite» key, give a prolonged press on ,
and then select the required function :
Note : It is able to set the same mode by serial command.
7. Switching off
The dial gauge goes automatically into stand-by if not used for 10 minutes, unless automatic switch-off
mode has been turned off (see Chap. 4, advanced functions).
Stand-by mode can be forced by a prolonged press (> 2 sec) on :
In stand-by mode, the value of the origin is retained by the sensor (SIS mode), and the instrument
automatically restarts with any movement of the measurement probe, RS command, Bluetooth® request
or press on button.
The instrument can be switched off completely for a long period of non-use, but this will necessitate a
reference setting on restart (the origin will be lost, see page 3) :
- Prolonged press (>4 sec) on :
8. Re-initializing the instrument
The initial instrument settings can be restored at any time by a prolonged press (>4 sec) simultaneously
on and until the message rESEt is displayed.
9. Connecting the instrument
The instrument can be connected to a peripheral via a Proximity (RS or USB), Power (RS or USB) cable
or Bluetooth®. See page 3 for connecting the Power cable.
Measured values can be transmitted and the instrument driven using predefined commands (see chap.
10 for a list of the main commands).
6

10. Serial communication commands
[8]Specifications
7
Selection and configuration Interrogation
CHA+ / CHA-
Assign measurement direction
CHA+:positive sense / CHA-:negative sense
CHA?
Measurement direction?
Response : CHA+ / CHA-
FCT0 / FCT1 / … / FCTA / … / FCTF
Assign «favourite» function FCT? «favourite» function ?
Response : FCT0～FCTF
MM / IN
Assign measurement unit
MM:mm/IN:inch UNI? Measurement unit active? Response : MM/IN
KEY0 / KEY1
Assign Keypad Lock
KEY0:Lock/KEY1:Unlock KEY? Keypad locked? Response : KEY0/KEY1
MUL +/-xx.xxxx Assign the multiplier value MUL?
Multiplier value?
Response : +/-xx.xxxx
PRE +/-xxx.xxx Assign preset value PRE?
Preset value?
Response : +/-xxx.xxx
STO1 / STO0
Assign Hold mode
STO1:ON / STO0:OFF STO?
Status of HOLD function?
Response : STO1/STO0
TOL1 / TOL0
Assign Tolerance mode
TOL1:ON /TOL0:OFF TOL?
Status of Tolerance mode?
Response : TOL1/TOL0
REF1 / REF2
Change active reference
Two tolerance values are REF1 or REF2
REF?
Active Reference ?
Response : REF1/REF2
ECO1 / ECO 0
Assign Economic mode
ECO1:ON / ECO0:OFF ECO?
Current economic mode?
Response : ECO1/ECO0
INTE1 / INTE0
Assign 2 points measurement mode
INTE1:ON / INTE0:OFF
INTE ?
2 points mode ?
Response : INTE1/INTE0
LCAL dd.mm.yy Modify last calibration date LCAL?
Date of last calibration?
Response : dd.mm.yyyy
NCAL dd.mm.yy Modify next calibration date NCAL?
Date of next calibration?
Response : dd.mm.yyyy
NUM x...x (up to 20 chars) Modify the instrument number NUM?
Instrument number?
Response : NUM x...x
MIN /MAX /DEL /NOR
Assign MIN, MAX, Delta, Normal mode
MIN:Minimum/MAX:Maximum/DEL:Delta=MAX-MIN/
NOR:Normal=Current value
MOD?
Active mode (MIN, MAX, Delta or Normal)?
Response : MIN/MAX/DEL/NOR
AOFF1 /AOFF0
Activates/deactivates the automatic switch-off
AOFF1:Activate/AOFF0:De-activate
AOFF?
Status of the automatic switch-off
Response:AOFF1/AOFF0
CFGBAR NOR / CFGBAR MAX
Assign Bargraph display
CFGBAR NOR:Normal bargraph/
CFGBAR MAX:Keep Bargraph on Max value
CFGBAR?
Bargraph configuration?
CFGBAR NOR/CFGBAR MAX
FACT1 / FACT2 / FACT5 / FACT10
Assingn analogue scale factor
FACT1:1scale=1digit/FACT2:1scale=2digits/
FACT5:1scale=5digits/FACT10:1scale=10digits
FACT?
Status of the analogue scale factor?
Response : FACT1/FACT2/FACT5/FACT10
RES1 / RES2 / RES3
Change of resolution
RES1:0.0001mm/RES2:0.001mm/RES3:0.01mm
RES?
Status of the current resolution?
Response : RES1/RES2/RES3
TOL +/-xxx.xxx +/-yyy.yyy
Inputting current tolerance limits
x:lower tolerance limit/y:upper tolerance limit
?
Current value (the displayed value)?
Response : +/-zzz.zzz ⇒current value
in the case of Tol mode
=+/-zzz.zzz ⇒current value
<+/-xxx.xxx ⇒lower tolerance limit
>+/-yyy.yyy ⇒upper tolerance limit
CLE Reset(Clear) of MIN, MAX or Delta SET?
Main instrument parameters?
Response : CHA+/CHA-,MM/IN,X1/X2/X5,
RES1/RES2/RES3,MIN/MAX/DEL/NOR,
STO0/STO1,KEY0/KEY1,BAT1/BAT0
UNI1 / UNI0
Activate / de-activate UNIT command(MM/IN)
UNI1:ON/UNI0:OFF
ID?
Instrument identification code?
Response : SYxxx
OUT1 /OUT0
Activate / de-activate continued data transmission
OUT1:ON/OUT0:OFF
BAT?
Status of Battery?
Response : BAT1: OK/ BAT0: low battery
PRE ON / PRE OFF Activate / de-activate Preset function(PRE command) VER?
Version No. and date of firmware
Response : Vx.x DD.MM.YYYY
ANA ON / ANA OFF Activate / de-activate the analogue scale MAC?
Bluetooth® MAC address?
Response :XXX…XXX(up to 12 chars)
PRE Recall Preset value
SET Zero reset
SBY xx xx number of minutes before stand-by
BT1 / BT0
Activate/de-activate Bluetooth® module
BT1:ON/BT0:OFF
BTRST Reset Bluetooth pairing information
OFF Switch-off (wake up using a button or RS)
RST Reset the instrument
SBY Put instrument in stand-by mode(SIS)
FAC RST Reset (Restores the factory parameters)
TOL +/-nnn.nnn +/-xxx.xxx +/-yyy.yyy
(In the case of SSI-650）
Inputting current tolerance limits
n :nominal value /
x :lower tolerance limit/y :upper tolerance limit

11. Specifications
12.Maintenance
Carefully dry all mechanical parts of the instrument after contact with liquids to ensure proper
operation and avoid corrosion.
Don’t use aggressive products (alcohol, trichloroethylene or others) to clean plastic parts.
Don’t expose the instrument to direct sunlight, heat or humidity.
8
Items SSL-250 SSL-260
Stylus length L=12.5 mm L=36.5 mm
Measuring range 0.8 mm 2.0 mm
Resolution
Indication error in forward direction whole range 3 µm 8 µm
Repeatability 1 µm 1 µm
Rivearsibirity 2 µm 3 µm
Measuring force 0.15N±20% 0.06N±20%
Friction on probe orientation 4N±20% 1.6N±20%
Max. meas. times / sec
Max. Preset value（in the case of 1/1000mm)
Data output
Data output format
Battery life
Working tempaerature
Strage tempaerature
Weight
IP Protection
EMC
Battery
5～40℃
-10～60℃
70 g
IP54
EN 61326-1
CR2032
0.001mm
Normal mode：10, MIN/MAX mode：20
±99.999mm
Bluetooth/USB/RS232
4800 bauds , 7 bits , parity , 2 stop bits
about 6 months(general using)

13.Description of Bluetooth module:
This module is based on Nordic Semiconductor nRF8001 μBlue Bluetooth Low Energy Platform. The
nRF8001 is a single chip transceiver with an embedded baseband protocol engine, suitable for ultra-low
power wireless applications conforming to the Bluetooth Low Energy Specification contained within v4.0
of the overall Bluetooth specification. The nRF8001, used in the current revision of ISP091201, is a
product using a ROM for the baseband protocol engine.
14.Certification
9
contains bluetooth module ISP091201D
Region Certification
USA FCC ID : 2AAQS-ISP091201
Canada IC : 11306A-ISP091201
Brazil Anatel : 0516-14-4534
Korea South MSIP-CRM-iNs-ISP091201
Mexico IFT : RCPSYIS14-0655
Japan 001-A06167
Taiwan CCAH18LP2040T6
EU
India WPC : ETA-1003/2-17-/RLO(WR)

CERTIFICATE OF CALIBRATION
We hereby certify that this product has been calibrated and found to be in accordance with the
applicable NATIONAL STANDARDS and TECLOCK STANDARDS, Equipment used in this calibration has
traceable accuracy to the NATIONAL LENGTH and FORCE STANDARD.
Notice for use
Be sure to conduct a routine check for this product according to the purpose of use before use. This
product is precision instrument, periodically considering frequency of use, environmental conditions and
method of use.
It is not guaranteed for the performance of this product, which has been repaired or disassembled by
other than TECLOCK.
For appearance and other design improvement, this products
subject to change without advance notice.
TECLOCK Corporation
TECLOCK SmartSolutions Corporation
http://www.teclock.co.jp
HEAD OFFICE
2-10-3 MARUTA-CHO, OKAYA-SHI, NAGANO-KEN 394-0042
PHONE:[phone], FACSIMILE:81-266-22-4914
E-mail:[email protected]
