Tecnoautomazione T182S User manual

21 345 6 78 9 10 11 12
21 345 6 78 9 10 11 12
OIL RECIRCULATION. DIP 6.
OFF = DISABLED
ON = ENABLED
21 345 6 78 9 10
21 345 6 78 9 10
DISABLED NOT WIRED N.C. INPUTS. DIP 8.
OFF =
N.C. INPUTS ENABLED
ON =
NOT WIRED N.C.
INPUTS DISABLED
21 345 6 78 9 10 11 12
21 345 6 78 9 10 11 12
INPUTS OPTION 1 - 7. DIP 9.
OFF =
ON =
INPUT 1 = START
INPUT 7 = PEDESTRIAN
INPUT 1 = OPEN
INPUT 7 = CLOSE
STAND BY, GATE CLOSED
GATE IN OPENING OR CLOSING PHASE,
GATE OPEN
BOARD STATUS:S1 S2 S3
PROGRAMMING ERROR
PHOTOCELLS ERROR
MOTOR ERROR:
A
B
C
CONNECTION
ERROR OR MOTOR
OVERHEATING
A
B
C
RC1 RC2
EXTERNAL
RECEIVER
RC2
+5
GND
R1
R2
R3
R4
S1 S2 S3
STATUS
REMOTE
OUT 1 OUT 1
OPEN
CLOSE
COM
13 14 15
GND
12 3 4567
FLASHING LAMP 24VAC / MAX 20W PHOTO TEST
9
GND
10 11 128
+ 24 VDC
RC1
GND
+5
INTERNAL
RECEIVER
ANTENNA
NL
20
x
230 VAC
A
B
C
19
INGRESSI
LIMIT SWITCH N.C. / N.O. DIP 7.
21 345 6 78 9 10
21 345 6 78 9 10
21 345 6 78 9 10
21 345 6 78 9 10
21 345 6 78 9 10
21 345 6 78 9 10
OFF / OFF = 40%
ON / OFF = 60%
OFF / ON = 80%
ON / ON = 100%
21 345 6 78 9 10
21 345 6 78 9 10
21 345 6 78 9 10
21 345 6 78 9 10
OFF / OFF = 0.1 sec
ON / OFF = 0.5 sec
OFF / ON = 1.0 sec
ON / ON = 1.5 sec
PEDESTRIAN TIME. DIP 8 - 9.
21 345 6 78 9 10
21 345 6 78 9 10
21 345 6 78 9 10
21 345 6 78 9 10
OFF / OFF = 3 sec
ON / OFF = 6 sec
OFF / ON = 9 sec
ON / ON = 12 sec
21 345 6 78 9 10
21 345 6 78 9 10
21 345 6 78 9 10
21 345 6 78 9 10
21 345 6 78 9 10
21 345 6 78 9 10
OFF =
LIMIT SWITCH N.C.
ON =
LIMIT SWITCH N.O.
21 345 6 78 9 10
21 345 6 78 9 10
21 345 6 78 9 10
21 345 6 78 9 10
OFF / OFF = PROGRAMMABLE
ON / OFF = 10 sec
OFF / ON = 20 sec
ON / ON = 60 sec
AUTOMATIC CLOSURE. DIP 3 - 4.
21 345 6 78 9 10
21 345 6 78 9 10
21 345 6 78 9 10
21 345 6 78 9 10
21 345 6 78 9 10
21 345 6 78 9 10
FAST CLOSURE. DIP 5.
21 345 6 78 9 10
21 345 6 78 9 10
MOTOR BREAK. DIP 10.
21 345 6 78 9 10 21 345 6 78 9 10
ON
PROGRAM
TIME
OBSTACLE
MOTOR
OUT 2 OUT 2
INPUTS:
1. START OR OPEN N.O.
2. STOP N.C.
3. EXTERNAL PHOTOCELL N.C.
closing phase: inverts the gate movement
4. INTERNAL PHOTOCELL N.C.
opening hase: pauses the gate movement
closing phase: inverts the gate movement
5. CLOSING LIMIT SWITCH N.C.
hanldes the closing limit switches
6. OPENING LIMIT SWITCH N.C.
hanldes the opening limit switches
7. PEDESTRIAN OR CLOSE N.O
2A FUSE
AUXILIARY OUTPUTS:
OUT1. ENABLED/DISABLED VIA REMOTE (R4)
OUT2. COURTESY LIGHT / ENABLED DURING
OPENING FOR 3 MINUTES
OFF = DISABLED
ON = ENABLED
POWER 100%
OFF = DISABLED
ON = ENABLED
OBSTACLE DETECTION SENSOR IN SLOW DOWN. DIP 5.
21 345 6 78 9 10
21 345 6 78 9 10 OFF = DISABLED
ON = ENABLED
OFF = DISABLED
ON = ENABLED
OFF / OFF = AUTOMATIC CLOSURE
ON / OFF = COMMUNITY MODE
OFF / ON = STEP-BY-STEP MODE
ON / ON = STEP-BY-STEP + AUTOMATIC
CLOSURE
OFF = DISABLED
ON = ENABLED
OFF = DISABLED
ON = ENABLED
LEFT DIP-SWITCH (1) FUNCTIONS RIGHT DIP-SWITCH (2) FUNCTIONS
SLOW DOWN. DIP 3.
MOTORS POWER. DIP 1 - 2. SOFT START. DIP 6 - 7. MODES. DIP 1 - 2.
OBSTACLE DETECTION SENSOR. DIP 4. MOTORS AND PHOTOCELLS TESTS. DIP 10.
T182S. SLIDING GATE CONTROL UNIT. 230 VAC POWER SUPPLY. 433.92 MHz FREQUENCY . 100 STORABLE CODES.
PROGRAMMING OF WORKING TIMES /
OBSTACLE SENSOR
OBSTACLE
DETECTED
LEDs:
S1.S2.S3. GATE STATUS / CONTROL BOARD STATUS LEDS
RC1.RC2.R1.R2.R3.R4. RADIO LEDS
RC1. SHOWS THAT A SIGNAL HAS BEEN RECEIVED FROM THE INTERNAL RADIO RC1
RC2. SHOWS THAT A SIGNAL HAS BEEN RECEIVED FROM THE EXTERNAL RADIO RC2
R1. START: INDICATES THAT A START BUTTON ON THE REMOTE HAS BEEN PRESSED
R2. STOP: INDICATES THAT A STOP BUTTON ON THE REMOTE HAS BEEN PRESSED
R3. PEDESTRIAN: SHOWS THAT A START PEDESTRIAN BUTTON ON THE REMOTE HAS BEEN PRESSED
R4. OUT1 ON/OFF: SHOWS THAT A OUT1 BUTTON ON THE REMOTE HAS BEEN PRESSED
A.B.C. PROGRAMMING LEDS
1.2.3.4.5.6.7. INPUTS
LEFT / DIP-SWITCH RIGHT / DIP-SWITCH
G
R
O
U
N
D

POWER SUPPLY START STOP MOTOR
X
N
L
1920
13 14 15
M
5678910 11 122 3 4
1
56789
TEST GND
10 11 122 3 4
156789
N.C.
RX RX
GND+VDC
10 11 122 3 4
1
PEDESTRIAN
FLASHING LAMP
56789
GND+VDC
10 11 122 3 4
1
N.C.
TX
5678910 11 122 3 4
1
5678910 11 122 3 4
5678 9 10 11 122 3 4
1
5678910 11 122 3 4
1
21 345 6 78910 11 12
21 345 6 78910 11 12
+VDC
1
5678910 11 122 3 4
1
21 345 6 78910 11 12
21 345 6 78910 11 12
+VDC
OUT 1 OUT 2
MAX 20 W
OUT1 ON/OFF
R1. OFF
R2. OFF
R3. OFF
R4. ON
X4
RC1
RC2
ON
PEDESTRIAN
R1. OFF
R2. OFF
R3. ON
R4. OFF
X3
STOP
R1. OFF
R2. ON
R3. OFF
R4. OFF
X2
START
R1. ON
R2. OFF
R3. OFF
R4. OFF
X1
OUT1 ON/OFF
R1. OFF
R2. OFF
R3. OFF
R4. ON
X1
START
R1. ON
R2. OFF
R3. OFF
R4. OFF
X4
STOP
R1. OFF
R2. ON
R3. OFF
R4. OFF
X3
PEDESTRIAN
R1. OFF
R2. OFF
R3. ON
R4. OFF
X2
RC1
RC2
ON
R1. ON
R2. ON
R3. ON
R4. ON
R1. OFF
R2. OFF
R3. OFF
R4. OFF
R1. OFF
R2. ON
R3. ON
R4. ON
R1. OFF
R2. OFF
R3. ON
R4. ON
R1. OFF
R2. OFF
R3. OFF
R4. ON
MEMORIZE A REMOTE
DELETE A REMOTE
ERASE ALL REMOTES
PRESS AND HOLD THE DESIRED BUTTON ON THE REMOTE, SIMULTANEOUSLY PRESS ONCE THE REMOTE BUTTON ON THE CONTROL BOARD TO
MEMORIZE THE START FUNCTION, PRESS TWICE THE REMOTE BUTTON ON THE BOARD TO MEMORIZE THE STOP FUNCTION, PRESS THREE TIMES
THE REMOTE BUTTON ON THE BOARD TO MEMORIZE THE PEDESTRIAN FUNCTION, PRESS FOUR TIMES THE REMOTE BUTTON ON THE BOARD TO
MEMORIZE THE OUT1 ON/OFF FUNCTION. THE CORRESPONDING LED (R1-START, R2-STOP, R3-PEDESTRIAN, OR R4-OUT1) WILL BE STEADY ON TO
CONFIRM MEMORIZATION.
TO ERASE ALL SAVED REMOTES PRESS AND HOLD THE REMOTE BUTTON ON THE BOARD FOR 6 SECONDS. LEDS R1, R2, R3, AND R4 WILL GO ON
STEADY THEN WILL GO OFF INDICATING CORRECT DELETION OF ALL REMOTES.
PRESS AND HOLD THE REMOTE
BUTTON ON THE BOARD FOR
ABOUT 6 SECONDS.
PRESS AND HOLD THE DESIRED BUTTON ON THE REMOTE, SIMULTANEOUSLY PRESS FOUR TIMES THE REMOTE BUTTON ON THE CONTROL BOARD
TO DELETE THE START FUNCTION, PRESS THREE TIMES THE REMOTE BUTTON ON THE BOARD TO DELETE THE STOP FUNCTION, PRESS TWICE THE
REMOTE BUTTON ON THE BOARD TO DELETE THE PEDESTRIAN FUNCTION, OR PRESS ONCE THE REMOTE BUTTON ON THE BOARD TO DELETE THE
OUT1 ON/OFF FUNCTION.
EXTERNAL PHOTOCELL INTERNAL PHOTOCELLPHOTOCELLS TRANSMITTER
AUXILIARY OUTPUTS
OUT2. COURTESY
LIGHT / ENABLED
DURING OPENING
FOR 3 MINUTES
OUT1. ENABLED/
DISABLED VIA
REMOTE
CLOSING LIMIT SWITCH OPENING LIMIT SWITCH
TERMINAL BLOCK CONNECTIONS
PROGRAMMING OF OBSTACLE DETECTION SENSOR. The programming must be operated while the gate is closed.
PRESS AND HOLD THE OBSTACLE BUTTON ON THE BOARD FOR 5 SECONDS. The automac procedures starts:
Led A is steady on.
The control board is
seng the sensor in
presence of an obstacle.
Led A and B are steady on.
The gate starts opening ,
then it slows down. The
control board is seng the
sensor in absence of
obstacles.
Led A,B and C are steady on.
The gate starts closing,
then it slows down. The
control board goes back to
the inial posion of
the gate. The procedure has ended.
The obstacle sensor is fully set.
A
B
C
S1 S2 S3
A
B
C
S1 S2 S3
A
B
C
S1 S2 S3
A
B
C
S1 S2 S3
PROGRAMMING OF GATE WORKING TIMES. The programming must be operated while the gate is closed.
1 2 3 4
A
B
C
S1 S2 S3 A
B
C
S1 S2 S3 A
B
C
S1 S2 S3
A
B
C
S1 S2 S3
PRESS AND HOLD THE
TIME BUTTON FOR 5
SECONDS
PRESS THE TIME BUTTON PRESS THE TIME BUTTON
PRESS THE TIME BUTTON
or a start commande
TO EXIT AND SAVE THE
PAUSE TIME
Led A is steady on. The gate is in the
opening phase. The control board
is acquiring the working me of
motor.
Led A is flashing. The gate connues
the opening phase in slow down
mode. The control board is
acquiring the slow down me of
motor.
Led A and B are steady on. Led C
flashes every second. The control
board is acquiring the pause me. The gate will automacally close
aer the set pause me.
or a start commande or a start commande
It's advisable to re-do the programming of the obstacle sensor every me the motor power is modified.

AUTOMATIC CLOSURE: THE GATE AUTOMATICALLY CLOSES AFTER THE SET PAUSE TIME.
• DURING CLOSING, A START OR PEDESTRIAN COMMAND INVERTS THE GATE MOVEMENT.
• DURING OPENING, A START OR PEDESTRIAN COMMAND STOPS THE GATE MOVEMENT.
COMMUNITY PLUS AUTOMATIC CLOSURE: THE GATE AUTOMATICALLY CLOSES AFTER THE SET PAUSE TIME.
• DURING CLOSING, A START OR PEDESTRIAN COMMAND INVERTS THE GATE MOVEMENT.
• DURING OPENING, A START OR PEDESTRIAN COMMAND IS IGNORED.
STEP-BY-STEP: THE GATE STAYS OPEN AT THE END OF THE OPENING PHASE.
• DURING CLOSING AND OPENING, A START OR PEDESTRIAN COMMAND STOPS THE GATE MOVEMENT.
STEP-BY-STEP PLUS AUTOMATIC CLOSURE: THE GATE AUTOMATICALLY CLOSES AFTER THE SET PAUSE TIME.
• DURING CLOSING AND OPENING, A START OR PEDESTRIAN COMMAND STOPS THE GATE MOVEMENT.
OBSTACLE SENSOR: IF THE CONTROL BOARD DETECTS AN OBSTACLE IT INVERTS THE GATE MOVEMENT OR ENDS THE WORKING PHASE. IT
INVERTS THE GATE MOVEMENT IF IT’S THE FIRST OBSTACLE DETECTION IN THE CURRENT WORKING CYCLE (OPENING/CLOSURE). OTHERWISE,
IT ENDS THE WORKING PHASE SO TO FIND THE FULLY OPEN/CLOSED GATE POSITION AND RESTORE THE STANDARD GATE FUNCTIONING.
SLOW DOWN: THE GATE SLOWS DOWN FOR THE SET SLOW DOWN TIME AT THE END OF THE OPENING AND CLOSING PHASES. DURING THE SLOW
DOWN PHASE THE MOTOR WORKS AT ITS MAX POWER.
PEDESTRIAN WORKING TIME: THE GATE OPENS AND CLOSES FOR THE SET PEDESTRIAN WORKING TIME.
SOFT START: THE MOTOR POWER INCREASES GRADUALLY TILL IT REACHES ITS MAX VALUE.
TESTS: THE CORRECT FUNCTIONING OF MOTOR AND PHOTOCELLS ARE CHECKED BEFORE ANY GATE MOVEMENT. IF ONE OF THE TWO TESTS
FAILS THE GATE DOES NOT MOVE. THE LEDS ON THE BOARD INDICATES THE TYPE OF FAILURE. THE MOTOR TEST FAILS WHEN THE MOTOR IS IN
TERMAL PROTECTION OR THERE IS A CONNECTION ERROR. THE PHOTOCELLS TEST FAILS IF TRANSMITTER AND RECEIVER ARE NOT PROPERLY
ALIGNED, IF THERE ARE INSTALLATION ERRORS, OR IF THE PHOTOCELLS ARE DAMAGED.
DISABLE NOT WIRED N.C. INPUTS: DISABLE ALL THE NOT WIRED N.C. INPUTS. IF LATER, A N.C. INPUT IS WIRED, THE BOARD WILL
AUTOMATICALLY ENABLE IT.
MOTOR BREAK: THE BOARD AUTOMATICALLY SLOWS DOWN THE MOTOR IF THE GATE REACHES THE LIMIT SWITCH WITHOUT THE GATE
SLOWING DOWN, PREVENTING MOTOR DAMAGE.
FAST CLOSURE: THE GATE STARTS THE CLOSING PHASE 3 SEC AFTER THE EXTERNAL PHOTOCELLS HAVE BEEN ACTIVATED. THIS FUNCTION
WORKS ONLY ONCE PER WORKING CYCLE AND ONLY IF THE GATE HAS NOT BEEN STOPPED DURING OPENING OR CLOSING.
OIL RECIRCULATION / COLD CLIMATE MODE: THE MOTOR IS ACTIVATED AT THE MINIMUM POWER FOR 1 MIN EVERY 10 MIN WHEN THE GATE IS
FULLY OPEN/CLOSED, IF MORE THAN 20 MIN LASTED FROM LAST GATE MOVEMENT.
SUGGESTIONS
THE RADIO CASE CAN BE
INSTALLED IN COMBINATION
WITH THE FLASHING LAMP ONE UP.
THE RADIO
MODULE
HOUSED INSIDE
THE RADIO CASE
(RANPC5T).
TO INCREASE THE SIGNAL RANGE DISCONNECT THE RADIO MODULE FROM THE INTERNAL RECEIVER
POSITION AND WIRE IT ON THE TERMINAL BLOCK EXTERNAL RECEIVER POSITION. IF AVAILABLE, WE
SUGGEST YOU USE THE RADIO CASE (CODE RANPC5T).
1. RADIO MODULE CONNECTED IN
INTERNALRECEIVER POSITION
(DEFAULT CONFIGURATION).
2. DISCONNECT THE RADIO
MODULE FROMTHE INTERNAL
RECEIVER POSITION.
3. WIRE THE RADIO MODULE ON THE
TERMINAL BLOCK EXTERNAL RECEIVER
POSITION.
3. WIRE THE RADIO MODULE
ON THE TERMINAL
BLOCK EXTERNAL
RECEIVER
POSITION.
FLASHING LAMP
24 VAC / MAX 5 W
EXTERNAL PHOTOCELLS
CONNECT TO TERMINAL 3.
DURING CLOSING INVERT
THE MOVEMENT.
INTERNAL PHOTOCELLS
CONNECT TO TERMINAL 4.
DURING OPENING INVERT
THE GATE MOVEMENT FOR
2 SECONDS THEN STOP THE
GATE.
ANTENNA
WITH RADIO
CASE
MOTOR
TYPICAL INSTALLATION
INTERNAL PROPERTY
FUNCTIONS DESCRIPTION
MODES
x x x

MADE IN ITALY
T.A. Tecno Automazione s.r.l. - Via Vicinale snc - 03018 - Paliano - (FR) - Italy - Tel [phone] - Fax [phone] - [email protected] - www.tecnoautomation.com - www.tecnoautomazione.com
USER MANUAL
T182S
ENG
For private households: Informaon on Disposal for Users of WEEE This symbol on the product(s) and / or accompanying documents means that used electrical and electronicequipment (WEEE)
should not be mixed with general household waste. For proper treatment, recovery and recycling, please take this product(s) to designated collecon points where it will be accepted free of
charge. Alternavely, in some countries, you may be able to return your products to your local retailer upon purchase of an equivalent new product. Disposing of this product correctly will help
save valuable resources and prevent any potenal negave effects on human health and the environment, which could otherwise arise from inappropriate waste handling. Please contact your
local authority for further details of your nearest designated collecon point. Penales may be applicable for incorrect disposal of this waste, in accordance with you naonal legislaon. For
professional users in the European Union If you wish to discard electrical and electronic equipment (EEE), please contact your dealer or supplier for further informaon. For disposal in countries
outside of the European Union This symbol is only valid in the European Union (EU). If you wish to discard this product please contact your local authories ordealer and ask for the correct
method of disposal.
