Tecnoware UPS EVO DSP PLUS 6.5 PF 0,9 User manual

Uninterruptible Power Supply
UPS EVO DSP PLUS 6.5 PF 0,9
User’s manual
Manuale utente

Index
User’s Manual - English........................................................................ 1
Safety Warnings................................................................................. 1
1Introduction ................................................................................. 2
2General Characteristics ................................................................... 3
3Receipt and site selection ................................................................ 3
4Operating Modes............................................................................ 4
4.1 NORMAL Mode ......................................................................... 5
4.2 BATTERY Mode ........................................................................ 5
4.3 BYPASS Mode .......................................................................... 5
5EXTERNAL DESCRIPTION .................................................................. 7
5.1 Front Panel ............................................................................ 7
5.1.1 Graphic LCD Panel.........................................................................8
5.1.2 Buttons.................................................................................... 11
5.1.3 LED Indicators............................................................................ 11
5.1.4 Acoustic Alarm ........................................................................... 12
5.2 Rear Side.............................................................................. 13
5.2.1 Input/Output Terminals ................................................................ 14
5.2.2 EPO (Emergency Power Off) ........................................................... 14
6Electrical Installation.....................................................................15
6.1 Installation............................................................................ 15
7First Start Up...............................................................................17
8Functioning.................................................................................17
8.1 Turning ON and OFF ................................................................. 17
8.2 Low Battery and Automatic Restart............................................... 18
8.3 Load Testing.......................................................................... 18
8.4 Battery Test .......................................................................... 19
8.5 Operation in Warning Status ....................................................... 19
8.6 Operation in Fault Mode ............................................................ 20
9Counication Interfaces ...................................................................20
10 Technical Characteristics................................................................22
11 Maintenance................................................................................23
11.1 UPS Cleaning ......................................................................... 23
11.2 Battery ................................................................................ 24
11.3 Operator Safety ...................................................................... 24
12 Troubleshooting ...........................................................................25
Conformity to the European Directives ...................................................27
Product Disposal ...............................................................................27
Lead Batteries .................................................................................27

Indice
Manuale Utente –Italiano ................................................................... 28
Avvisi di Sicurezza............................................................................ 28
1Introduzione............................................................................... 29
2Caratteristiche Generali ................................................................ 30
3Ricevimento e Collocazione ............................................................ 30
4Modi di Funzionamento ................................................................. 31
4.1 Modo NORMALE.......................................................................32
4.2 Modo BATTERIA.......................................................................32
4.3 Modo BYPASS..........................................................................32
5Descrizione Esterna...................................................................... 34
5.1 Pannello Frontale ....................................................................34
5.1.1 Pannello LCD Grafico ....................................................................35
5.1.2 Pulsanti ....................................................................................38
5.1.3 Indicazioni a Led .........................................................................38
5.1.4 Allarme Acustico .........................................................................39
5.2 Pannello Posteriore ..................................................................40
5.2.1 Morsettiera d’Ingresso/Uscita ..........................................................41
5.2.2 EPO (Emergency Power Off) ............................................................41
6Installazione Elettrica ................................................................... 42
6.1 Installazione ..........................................................................42
7Prima Accensione ........................................................................ 44
8Funzionamento ........................................................................... 44
8.1 Accensione e Spegnimento .........................................................44
8.2 Fine Autonomia e Riaccensione Automatica .....................................45
8.3 Controllo del Carico .................................................................45
8.4 Test Batteria..........................................................................46
8.5 Segnalazioni di Allarme .............................................................46
8.6 Segnalazioni di Guasto ..............................................................47
9Interfacce di Comunicazione........................................................... 47
10 Caratteristiche Tecniche................................................................ 48
11 Manutenzione ............................................................................. 49
11.1 Pulizia dell’UPS.......................................................................49
11.2 Batterie................................................................................50
11.3 Sicurezza dell’Operatore ...........................................................50
12 Anomalie ed Interventi.................................................................. 51
Conformità alle Direttive Europee ........................................................ 53
Smaltimento del Prodotto................................................................... 53
Batterie al Piombo............................................................................ 53

ENGLISH
UPS EVO DSP PLUS 6.5 1User’s manual
User’s Manual - English
Safety Warnings
Read this manual carefully and completely before installing and using the TECNOWARE EVO DSP PLUS
Uninterruptible Power Supply, which, from here after, will also be referred to as UPS.
This manual should be kept close to the UPS and read before the UPS is installed and used.
The UPS must be used only by properly trained personnel. To ensure correct and safe operations, it is
necessary that operators and maintenance personnel observe the general safety Standards as well as the
specific instructions included in this manual.
Risk of electric shock: do not remove the cover. The UPS contains internal parts which are at a high
Voltage and are potentially dangerous, capable of causing injury or death by electric shock.
The electric installation has to be done by qualified personnel. Follow all the Safety Standards (CEI
Standards in Italy or IEEE elsewhere) for the Input/Output connections and for the right section of
Input/Output cables.
There are no internal parts in the UPS which are user serviceable. Any repair or maintenance work must
be performed exclusively by qualified technical personnel authorized by TECNOWARE. TECNOWARE
declines any responsibility if this warning is disregarded.
Warning to the technical personnel authorized for Service: since internal components are connected to
the batteries, they will remain powered, and therefore dangerous, even after the UPS has been
disconnected from AC power mains. Before any repair or maintenance work, disconnect the batteries
from UPS, by removing the positive cable (red colour) from the first battery of the battery pack.
CAUTION - HIGH BATTERY VOLTAGE AND RISK OF ELECTRIC SHOCK - the battery pack nominal voltage is
144 Vdc (there are 12 batteries series-connected inside the UPS).
It is compulsory to ground the UPS according to Safety Standards.
Risk of electric shock at the Output lines when the UPS is ON.
Risk of electric shock at the Output lines while the unit is connected to the AC utility line.
We recoend to use a dedicate AC Input/Output power line for the UPS.
Do not obstruct ventilation slots or holes and do not rest any object on top of the UPS.
Do not insert objects or pour liquids in the ventilation holes.
Install the UPS indoors, in a protected, clean and moisture-free environment.
Do not expose to the direct sun light.
Do not keep liquids, flaable gases or corrosive substances near the UPS.

ENGLISH
User’s manual 2UPS EVO DSP PLUS 6.5
1Introduction
UPS EVO DSP PLUS (UPS means Uninterruptible Power Supply) is the result of constant technological research
aimed at obtaining the best performance at the lowest cost.
UPS EVO DSP PLUS is an advanced ON-LINE UPS built specifically to protect your computer from any irregularities
in the AC line (for example blackouts, brownouts, over voltages, micro-interruptions) which often cause damage to
hardware and software.
All that is possible because UPS EVO DSP PLUS is a Double-Conversion ON-LINE UPS.
Under normal AC line condition UPS EVO DSP PLUS provides an automatic Output Voltage regulation from the
Rectifier and Inverter blocks and filters out frequently occurring electrical disturbances (high Voltage transients,
spikes, interferences, etc.), thus protecting the devices connected to its outlets. During a power failure, UPS EVO
DSP continues supplying adequate AC power (with a true sine wave) to all connected devices through its internal
batteries and by its DC/AC converter (Inverter).
UPS EVO DSP PLUS protects the devices from accidental overload or Inverter fault by an Automatic Bypass that
directly connects the AC Input line with its outlets.
The EVO DSP PLUS models are factory-equipped with RS-232 and USB interfaces, which may be used for notify to a
computer a power failure or a Low Battery condition: this allows automatic data backup during an extended
blackout with the most coon operating systems (Windows, Linux, Unix, etc). Thanks to Interfaces, UPS EVO DSP
PLUS can counicate the several made measurements (Input/Output Voltage, batteries, absorption, Frequency,
etc.), and can also be prograed in order to start-up or shutdown automatically at fixed times.
This manual is a guide that enables you to correctly install and use your UPS. This
manual includes important SAFETY instructions for the operator, for the UPS correct
installation, and gives useful advice on the product and battery maintenance. For any
type of problem, please refer to this manual before calling the customer service.
EVO DSP PLUS is constantly being developed and improved: consequently, your unit may differ somewhat from the
description contained in this manual.
This manual includes the following models:
•EVO DSP PLUS 6.5 PF 0,9 (6.5 KVA)
In this manual EVO DSP PLUS will simply be referred to as UPS.
EVO DSP PLUS 6.5 model is made from a single unit that contains the electronics parts and the batteries.

ENGLISH
UPS EVO DSP PLUS 6.5 3User’s manual
2General Characteristics
UPS EVO DSP PLUS has all the advanced features which guarantee maximum reliability and safety:
•Double-Conversion ON-LINE Transformerless technology
•Sinusoidal wave generated by an IGBT Inverter
•Output Voltage regulation 1%
•Protection from overload and short circuits
•Automatic Bypass to protect from accidental overload or Inverter fault
•Start-up even under Mains OFF conditions
•Automatic protection when Battery is low
•Automatic restart, following an automatic shut-down due to Low Battery, once AC utility power comes
back on
•Selectable Input Frequency (50/60 Hz)
•Graphic LCD panel for visualization of the Input and Output Voltage measurements, batteries Voltage,
percentage of load, Frequency, alarms, overload, fault and path of energy flow
•Acoustic signals of various kinds indicating alarm situations
•Available settings of all the UPS parameters by user through front panel pushbuttons and graphic LCD
panel
•SNMP Adapter (optional)
•EPO (Emergency Power OFF)
•Counication with the computer through RS-232 and USB interfaces
•High efficiency
•Maximum reliability
•Smart design and easy to use
3Receipt and site selection
Carefully remove the UPS from its packaging, and carry out a meticulous inspection. We recoend keeping the
original packaging in a secure place, in case you need to send the UPS for maintenance purposes. In case of
transport damage, notify the carrier and dealer iediately.
We recoend paying attention to the below points in order to choose a correct placement for your UPS:
•The UPS is designed to operate in a protected environment (e.g. offices). We therefore recoend installing
it in a place with very little or no humidity, dust or smoke.
•When the UPS is brought from a cold place to a warmer place, humidity in the air may cause condensation
in the UPS. In this case, allow UPS to stand for two hours in the warmer place before beginning with the
installation.

ENGLISH
User’s manual 4UPS EVO DSP PLUS 6.5
•In all circumstances, see the “Technical Characteristics”chapter for environmental specifications and
check that the selected area meets these criteria.
•During normal operation the UPS discharges a minimal amount of heat. So it is necessary to leave at least
10 cm of unobstructed space all around the UPS in order to keep it properly ventilated.
•Do not obstruct ventilation holes.
•Do not insert objects or pour liquids in the ventilation holes.
•Do not rest any object on top of the UPS.
•Do not keep liquids, flaable gases or corrosive substances near the unit.
•Install the UPS on a properly tiled floor. Avoid the installation on a floor that is not tiled flat.
4Operating Modes
Figure 1 –Operating modes
BATTERY MODE
NORMAL MODE
BYPASS MODE

ENGLISH
UPS EVO DSP PLUS 6.5 5User’s manual
4.1 NORMAL Mode
The UPS typically works in Normal mode: Input mains power is available and its amplitude is within specifications.
Please refer to figure 1.
After the filter has eliminated any high Frequency interference present on the mains, the AC Input line is rectified
and conditioned in the Rectifier block (AC/DC conversion); the continuous power now enters into the Inverter
block and is then reconverted into alternated power (DC/AC conversion), overcoming the Automatic Bypass and
feeding the load after an extra filtration. At the same time the UPS recharges the batteries through the Battery
Charger block.
Please refer to figure 2, which describe the UPS front panel.
The Normal mode is identified by:
•Line led is ON.
•The graphic LCD panel shows the path of energy flow
during Normal mode.
4.2 BATTERY Mode
During operation in Normal mode, if the UPS finds the Mains OFF condition (due to a Blackout or
Overvoltage/Brownout), it then switches into Battery mode. In this case, the batteries supply the required Output
power thanks to the DC/AC conversion carried out by the Inverter. The UPS switches back to Normal mode a few
seconds after AC Input power is restored or Voltage comes back to internal specifications.
Please refer to figure 1.
The Battery mode is identified by:
•Battery led is ON.
•The graphic LCD panel shows the path of energy flow
during Battery mode.
•An acoustic signal every 4 seconds.
4.3 BYPASS Mode
In Bypass mode, the AC Input line is directly connected with the UPS outlets by an Automatic Bypass.
As indicated in figure 1, in Bypass mode the UPS recharges the batteries.
If you connect the AC Input line to the UPS and the Input line breaker on the rear is “ON”, the UPS will go to
Bypass mode.
The Bypass mode is an idle mode for the UPS: then by pressing ON button, the UPS turns ON completely, activating
the Inverter block.
When the UPS works in Bypass mode it can be considered as “not active”, since the Inverter block is not active.
The UPS is considered “active” when the Inverter block is ON (in Normal mode and in Battery mode).
Furthermore the UPS switches automatically to Bypass mode as a consequence of accidental overload or
Inverter fault thus protecting the supplied devices.

ENGLISH
User’s manual 6UPS EVO DSP PLUS 6.5
The Bypass mode is identified by:
•Bypass led is ON.
•The graphic LCD panel shows the path of energy flow
during Bypass mode.
•An acoustic signal every 2 minutes.
During Bypass mode, loads are fed directly from AC Input line. Therefore no protection
against AC Input line disturbances or interruptions is present.

ENGLISH
UPS EVO DSP PLUS 6.5 7User’s manual
5EXTERNAL DESCRIPTION
5.1 Front Panel
The front panel informs the user about operating status, alarm conditions and measurements. It also provides
access to controls and configuration parameters.
Front panel shown below consists of three parts:
1. Graphic LCD panel provides complete information about the energy flow path and existing alarms, Load and
Battery level, Input, Output and Battery measurements.
2. 4 LED’s when illuminated indicate UPS status.
3. 4 buttons enables the user to turn ON/OFF the UPS and to make selections of the functioning parameters.
Figure 2 –Front panel
Bypass
Line
Battery
Fault
OFF
TEST
MUTE
ON

ENGLISH
User’s manual 8UPS EVO DSP PLUS 6.5
5.1.1 Graphic LCD Panel
Please refer to figure 3.
Figure 3 –Graphic LCD Panel
Graphic LCD Panel
Function
Backup time information
Indicates how much time has passed in Battery mode.
H: hours, M: minutes, S: seconds
Fault information
Indicates the warning that a fault has occurred.
Indicates the Fault codes, and the codes are listed in the “Fault Table” of chapter
8.
Mute operation
Indicates that the UPS alarm is disabled (muted).
Output Voltage information
Battery
Info
Mode Operation
Info
Input & Battery
Voltage Info
Output
Voltage Info
Load
Info
Backup Time
Info
Fault Info
Buzzer Info

ENGLISH
UPS EVO DSP PLUS 6.5 9User’s manual
Indicates the Output Voltage or Frequency.
Vac: Output Voltage, Hz: Output Frequency

ENGLISH
User’s manual 10 UPS EVO DSP PLUS 6.5
Graphic LCD Panel
Function
Load information
Indicates the load level by 0-25%, 26-50%, 51-75%, and 76-100%.
Indicates Overload.
Indicates the load or the Output is short-circuited
Mode operation information
Indicates the UPS connects to the mains.
Indicates the Battery is working.
Indicates the Bypass circuit is working.
Indicates the Inverter circuit is working.
Indicates the Output is working.
Battery information
Indicates the Battery capacity by 0-25%, 26-50%, 51-75%, and 76-100%.
Indicates the Battery is faulty or defective.
Indicates Low Battery level and Low Battery Voltage.
Input and Battery Voltage information
Indicates the Input Voltage or Frequency or Battery Voltage.
Vac: Input Voltage, Vdc: Battery Voltage, Hz: Input Frequency

ENGLISH
UPS EVO DSP PLUS 6.5 11 User’s manual
5.1.2 Buttons
Functions of the buttons are given below:
Button
Function
ON
Turn ON: press and hold the button more than 0.5 sec to turn the UPS ON.
OFF
Turn OFF: press and hold the button more than 0.5 sec to turn the UPS OFF.
TEST
Battery Test: press and hold the button more than 0.5 sec to test the Battery while in Normal
mode.
MUTE
Mute the alarm: press and hold the button more than 0.5 sec to mute the buzzer. If you press it
again after the buzzer is muted, the buzzer will beep again.
5.1.3 LED Indicators
There are 4 LED’s on the front panel to show the UPS working status:
Status LED
Bypass
Line
Battery
Fault
UPS Start Up
●
●
●
●
Bypass Mode
●
○
○
○
Normal Mode
○
●
○
○
Battery Mode
○
○
●
○
Battery Test
●
●
●
○
Fault Mode
○
○
○
●
Note: ●means LED is lit (ON) and ○means LED is not lit (OFF).

ENGLISH
User’s manual 12 UPS EVO DSP PLUS 6.5
5.1.4 Acoustic Alarm
Description
Buzzer Status
OFF
UPS status
Bypass Mode
Beeping once every 2 minutes
YES
Battery Mode
Beeping once every 4 seconds
Fault Mode
Beeping continuously
Warning
Overload
Beeping twice every second
NO
Low Battery
Beeping once every second
Battery Unconnected
Over Charge
EPO condition
Fan failure/Over Temperature
Charger failure
Input Circuit failure
Overload (3 times in 30 min)
Fault
Vdc Bus Start failure
Beeping continuously
YES
Vdc Bus Over
Vdc Bus under
Vdc Bus Unbalance
Vdc Bus short-circuit
Inverter Soft Start failure
High Inverter Voltage
Low Inverter Voltage
Inverter Output short-circuit
Power Fault
Battery SCR short-circuit
Inverter short-circuit
Battery Voltage Loss
Parallel Counication failure
Output short-circuit
Over Temperature
CPU Counication failure
Overload
Note: OFF = YES means that the buzzer can be muted or stopped
OFF = NO means that the buzzer can NOT be muted or stopped

ENGLISH
UPS EVO DSP PLUS 6.5 13 User’s manual
5.2 Rear Side
Figure 4 –Rear side
1. Computer Interface (RJ45 connector): it is the counication RS-232 port.
2. Computer Interface (USB connector): it is the counication USB port.
3. EPO (Emergency Power OFF) connector
4. SNMP Interface slot: the SNMP Interface is optional in place of RS232-USB port .
5. Input circuit breaker
6. Metallic panel for access to the Input/Output terminals: upon removal, it is possible to access the
Input/Output terminals (see figure 5).
1
4
2
5
3
6

ENGLISH
User’s manual 14 UPS EVO DSP PLUS 6.5
5.2.1 Input/Output Terminals
Figure 5 –Input/Output Terminals
INPUT terminals: to connect AC Input line.
OUTPUT terminals: to connect OUTPUT line.
GROUND: GROUND screws to connect INPUT and OUTPUT GROUND cables
5.2.2 EPO (Emergency Power Off)
EVO DSP PLUS models have the EPO (Emergency Power OFF) connector on the rear side, (see figure 6).
This permits to iediately switch the UPS Output OFF from a distance in case of emergency.
The UPS is supplied with EPO short-circuited terminals and in this case the product works normally.
If you want to use an external switch to turn OFF the UPS by EPO, then remove the short-circuit from the EPO
terminals and connect the switch to the EPO terminals as described in the figure 6.
EPO
12
REMOTE EPO
SWITCH
Figure 6 –EPO (Emergency Power OFF)
If the switch is CLOSED the UPS works normally; if, on the contrary, the switch becomes
OPEN then the UPS Output turns OFF iediately.
To switch the UPS Output ON again after an EPO, it is necessary to close again the EPO switch.
The EPO terminals do not need an external feeding Voltage and are isolated from the dangerous voltages that
are present inside the UPS.
Input Neutral
Input Line
Output Neutral
Output Line
Ground

ENGLISH
UPS EVO DSP PLUS 6.5 15 User’s manual
6Electrical Installation
The electrical installation has to be done by qualified personnel. Follow all the Safety
Standards (CEI Standards in Italy or IEEE elsewhere) for the Input/Output connections
and for the right selection of Input/Output cables.
We recoend to use dedicate AC Input/Output power lines for the UPS.
For safety we recoend using external circuit breakers between Input mains and UPS AC
Input line and between UPS Output lines and the loads. The circuit breakers should be
qualified with leakage current protective function (leakage current < 30 mA).
The EVO DSP PLUS models are made of a single unit design that contains the electronic parts and batteries.
Before starting the installation procedure, be sure that:
1. The Input circuit breaker on the rear panel is “OFF” (see figure 4).
2. The AC Input Voltage for the UPS has been removed.
3. The UPS is completely OFF (only if graphic LCD panel is OFF).
The following table shows the recoended size for Input, Output and Battery wires.
Model
Wiring spec (cross section)
Input
Output
Ground
EVO DSP PLUS 6.5
4 2
4 2
4 2
The cables for EVO DSP PLUS 6.5should be able to withstand until 40A current. It is
recoended to use 4 2or thicker wire for safety and efficiency.
We recoend using only flexible TRI-RATED cables. Otherwise if you use rigid cables, it
will be difficult to move the UPS from initial positioning.
We recoend to use dedicate AC Input/Output power Lines for the UPS.
6.1 Installation
Connect the GROUND wire first when making wire connection. Disconnect the GROUND
wire last when making wire disconnection.
Make sure that the wires are connected tightly to the terminals.
We advise you to follow the steps below explained:

ENGLISH
User’s manual 16 UPS EVO DSP PLUS 6.5
1. Remove the metallic panel that covers the Input/Output terminals, see figure 4. The terminals are shown in
figure 5. All the cables have to reach the terminals from the rear side using the proper holes in the metallic
panel.
2. Connect the INPUT line (LINE, NEUTRAL and GROUND), paying attention to the right polarity, in accordance
with figure 5, as explained below:
Connect GROUND wire to the GROUND screw.
Connect INPUT LINE wire to the INPUT LINE terminal.
Connect INPUT NEUTRAL wire to the INPUT NEUTRAL terminal.
3. Connect the OUTPUT line (LINE, NEUTRAL and GROUND) as follow:
Connect GROUND wire to the GROUND screw.
Connect OUTPUT LINE wire to the OUTPUT LINE terminal.
Connect OUTPUT NEUTRAL wire to the OUTPUT NEUTRAL terminal.
4. Reassemble the metallic panel that gives access to the UPS terminals.
5. Restore the AC Input mains Voltage to the UPS.
It is compulsory to ground the UPS according to the Safety Standards.
The case of the UPS is internally connected to the ground terminal (GND) of the IN/OUT
terminals, in order to guarantee safety to the user. To guarantee safety it is necessary
to be sure that the local electric plant is supplied with GROUND (in compliance with the
Safety Standards), and that a valid connection is guaranteed between the GROUND of
the UPS and the GROUND of the local electric plant.
Any interruption of the GROUND conductor is absolutely prohibited.
We recoend to use dedicate AC Input/Output power Lines for the UPS.
Risk of electric shock at the Output lines if the UPS is ON, even when the UPS is not
connected to AC utility line.
Risk of electric shock at the Output lines while the unit is connected to the AC utility
line.
Risk of electric shock: do not remove the cover. The UPS contains internal parts which
are at a high Voltage and are potentially dangerous, capable of causing injury or death
by electric shock.
There are no internal parts in the UPS which are user serviceable. Any repair or
maintenance work must be performed exclusively by qualified technical personnel
authorized by TECNOWARE. TECNOWARE declines any responsibility if this warning is
disregarded.
Disregard for these warnings may lead to a risk of electric shock to operators.
