TECO MONARCH ML Series User manual

MONARCH
Single Phase Induction Motors
0.18 kW to 3 kW
MON SP Mk II-042004
TECO Australia Pty. Ltd.

MONARCH SINGLE PHASE INDUCTION MOTORS
INSTRUCTIONS FOR HANDLING, INSTALLATION AND MAINTENANCE
1. HANDLING AND STORAGE
Motors should be preferably stored in their normal operating positions. They should be stored in surroundings as
clean and dry and free from vibration as possible.
If motors have been exposed to moisture during long periods of storage then the insulation resistance of the
windings against the frame (earth) should be checked with the aid of a megger (max. d.c. voltage 500V) prior to
installation.
If any motor damage is to be claimed as “warranty”, TECO Australia must be consulted prior to any work being
carried out on motor.
2. INSTALLATION AND OPERATION
Motors should be installed to the requirements of AS3000:2000 SAA Wiring Rules
The installation of the equipment shall be carried out in a manner that does not reduce the protection afforded by
the equipment design.
When installing the motor the following points should be carefully checked:
• rated voltage and frequency
• ambient temperature should not exceed 40°C, unless confirmed with TECO sales office
• altitude does not exceed 1000 meters above sea level
• correct connection of motor (see below)
The use of the motor should conform to the specified degree of protection in accordance with AS1939.
Care must be taken to ensure that the cooling air can flow in and out unhindered. The space between the air
intake and the nearest wall should be approximately equal to the shaft height of the motor. Foundations must be
designed in such a way that vibration is avoided when the motor and the driven machine are running coupled.
Care should be taken to ensure that any condensate drain plugs are located at the lowest point of motor casing.
Before mounting the transmission parts, the motor shaft should be cleaned with a solvent.
Secure motor to a level surface. Unevenness leads to mechanical deformation of the motor. The motor should be
used only with coupling systems, which are elastic with respect to centre offset, angular displacement,
longitudinal shift and torsional strain. Rigid coupling systems are not permissible (unless previously agreed).
If direct coupling is employed check centre offset and angular offset with screwed on test arm and dial gauge.
The following deviations should not be exceeded:
• Centre offset (radial measurement) 0.03 mm in 2 pole motors. 0.05 mm in motors with more than 2
poles. (the dial shows twice the value of the deviation).
• Angular offset (axial measurement) 0.10 mm.
Check alignment at normal operating temperature.
With applications involving belt transmission, unnecessary axial forces on the bearings can be avoided by
positioning the shafts parallel to each other and keeping the pulleys perfectly aligned. The belt tension should be
just sufficiently stretched to prevent slipping in service. If the pulleys are too small the motor shaft is likely to bend
and this must be avoided.
2) CONNECTION DIAGRAMS
This connection is indicated on the connection diagram inside terminal box lid and as shown on page3.
For special voltages and the like, different connections will be noted on the motor nameplate beside voltage.
All Motors are suitable for operation in both directions.
2

MONARCH SINGLE PHASE INDUCTION MOTORS
INSTRUCTIONS FOR HANDLING, INSTALLATION AND MAINTENANCE
CONNECTION DIAGRAMS
CLOCKWISE DIRECTION ANTI-CLOCKWISE DIRECTION
V2 Z2 U2 V2
U1 V1 Z1 U1 V1 Z1
240 VOLTS 240 VOLTS
MY / ML 1.1 KW AND SMALLER
U2 V2 U2 V2
Cs
Cs
C/S C
r
C/S C
r
W2/W3 U3 V3 2/W3
U1 V1 W1 U1 V1 W1
240 VOLTS 240 VOLTS
U2 V2 U2 V2
Cs
Cs
C/S C
r
C/S C
r
W2/W3 U3 V3 2/W3
U1 V1 W1 U1 V1 W1
480 VOLTS 480 VOLTS
ML 1.5 KW AND LARGER
Z2 U2
U3 V3 W
U3 V3 W
3

MONARCH SINGLE PHASE INDUCTION MOTORS
INSTRUCTIONS FOR HANDLING, INSTALLATION AND MAINTENANCE
3. CLEANING, LUBRICATION AND MAINTENANCE
Periodical checking of the magnetic starter (where used) is recommended, in order to prevent serious problems
developing such as oxidation and poor electrical contact.
The intake and outlet openings as well as the channels between the cooling fins must be kept clean and
protected against clogging to prevent motor overheating.
Bearings are greased for life and need no further maintenance. This means that greasing can only be carried out
during general overhauls when the motor is disassembled.
4. PROTECTION DEVICES
Thermal Reset Overloads are fitted to motors up to and including 1.1 kW. If overload should trip motor should
be allowed to cool before the overload is reset. To reset the overload press the red button mounted on the motor
terminal box. Supply to the motor should be disconnected before restart is attempted and cause for the overload
should be investigated.
5. FAULT FINDING & RECOGNITION
Kind of Fault Symptom Cause Remedy
Power-off Consult power company
Switch-off Switch-on
No fuse Install fuse
Broken wires Check wires and repair
Broken lead Check leads and repair
Motionless
And soundless
Faulty winding Check winding and
repair
Overload tripped Reset overload
Short circuit Check circuit
Incorrect wiring Check wiring
Poor contact in circuit
switches
Check and repair
Broken wiring Check and repair
Poor contact of starting
switch
Check and repair
Fail to
Start without
Load
Fuse blowing –
(Circuit Breaker
trips off, slow start
with
electromagnetic
noise
Incorrect connection of
starting switch
Check and repair
Insufficient capacity of
fuse or breaker
Replace fuse or breaker
Overload Lighten load
Overload after
start
Fuse blowing –
Fail to restart due
to circuit breaker
tripping High load at low voltage Check circuit capacity
and reduce load
Faulty internal centrifugal
switchgear
Send for repair
Overload or Intermittent
Overload
Lighten Load
Under-voltage Check circuit capacity
and power source
Over-voltage Check power source
Fuse blowing (Single
phase rotating)
Install the specified fuse
Poor contact of circuit
switches
Check and repair
Overheating
of Motor
Poor contact of starting
switch
Check and repair
Voltage drop Check circuit and power
source
Overload after
Start
Speed falls sharply
Sudden overload Check machine
4

MONARCH SINGLE PHASE INDUCTION MOTORS
INSTRUCTIONS FOR HANDLING, INSTALLATION AND MAINTENANCE
Kind of Fault Symptom Cause Remedy
Insufficient capacity of
switch
Replace switchSwitch overheat
High load Lighten load
Misalignment between
motor and load
Re-align
Overload after
Start
Bearing Overheat
High bearing noise Replace damaged
bearing
Reduce load
Increase power supply
Decrease extension lead
length
Increase current carrying
capacity of extension
lead
Motor does
not start
Motors hums and /
or does not
accelerate
Load too great
Power supply is not
sufficient
Extension lead used
Move power supply
towards motor.
Occurrence from first
operation
Check noise not normalElectro-magnetic
noise induced by
electricity Sudden sharp noise and
smoking
Short circuit of windings.
Repair.
Bearing noise Excessive noise Replace the damaged
bearing
Loose belt sheaf Adjust key and lock the
screw
Loose coupling Adjust the position of
couplings and tighten
Loose screw Tighten screw
Mechanical noise
caused by
machinery
Fan rubbing Adjust fan position
Rubbing as a result of
ingress of foreign matter
Clean motor interior and
ventilation ducts
Wind noise Noise induced by air
flowing through
ventilation ducts
Noise
Mechanical noise
caused by
machinery
Induced by conveyance
machine
Repair machine
Short circuit of windings RepairElectro-magnetic
vibration Open circuit of rotor Repair
Unbalanced rotor RepairVibration
Unbalanced fan Repair
Broken fan blade Replace fan
Un-symmetrical centres
between belt sheaf
Align central points
Central points of
couplings do not lie on the
same level
Adjust the central points
of couplings on the same
level
Improper mounting
installation
Lock the mounting screw
Vibration
Mechanical
vibration
Motor mounting bed is not
strong
Reinforce mounting bed
5

MONARCH SINGLE PHASE INDUCTION MOTORS
INSTRUCTIONS FOR HANDLING, INSTALLATION AND MAINTENANCE
Performance Data 240 Volt, 50 Hz, Capacitor Start, Capacitor Run (ML series)
2 Pole – 3000 RPM
Rated
Power
(kW)
Frame
Size
Current
(Amps)
IN
Speed
(RPM)
Efficiency
(%)
Power
Factor
(p.u.)
Starting
Torque
Tst
TN
Break-
down
Torque
Tb
TN
Starting
Current
Ist
IN
Approx
net
Weight
IM1001
Kg
0.37 71 2.5 2800 67 0.92 2.3 1.8 5.9 7
0.55 71 3.6 2800 70 0.92 2.5 1.8 5.4 8
0.75 80 4.7 2800 72 0.92 2.5 1.8 5.8 8.5
1.1 80 6.5 2800 75 0.95 2.5 1.8 5.7 9.5
1.5 90S 8.7 2800 76 0.95 2.5 1.8 5.8 12.5
2.2 90L 12.5 2800 77 0.95 2.5 1.8 5.8 14
3 100L 16.7 2800 79 0.95 2.5 1.7 6.0 20.5
4 Pole – 1500 RPM
Rated
Power
(kW)
Frame
Size
Current
(Amps)
IN
Speed
(RPM)
Efficiency
(%)
Power
Factor
(p.u.)
Starting
Torque
Tst
TN
Break-
down
Torque
Tb
IN
Starting
Current
Ist
IN
Approx
net
Weight
IM1001
Kg
0.18 63 1.4 1400 60 0.92 2.3 1.7 5.9 5
0.37 71 2.6 1400 65 0.92 2.3 1.7 6.6 8.1
0.55 80 3.7 1400 68 0.92 2.5 1.7 5.3 8.9
0.75 80 4.8 1400 71 0.92 2.5 1.7 5.8 9.6
1.1 90S 6.6 1400 73 0.95 2.5 1.7 5.6 13
1.5 90L 8.8 1400 75 0.95 2.5 1.7 5.8 16
2.2 100L 12.8 1400 76 0.95 2.5 1.7 5.8 23
3 100L 17.1 1400 77 0.95 2.5 1.7 5.9 27
Dimensions: Capacitor Start, Capacitor Run (ML series)
6

MONARCH SINGLE PHASE INDUCTION MOTORS
INSTRUCTIONS FOR HANDLING, INSTALLATION AND MAINTENANCE
NOTES:
7

MONARCH SINGLE PHASE INDUCTION MOTORS
INSTRUCTIONS FOR HANDLING, INSTALLATION AND MAINTENANCE
Performance Data 240 Volt, 50 Hz, Capacitor Start Run (MY series)
4 Pole – 1500 RPM
Rated
Power
(kW)
Frame
Size
Current
(Amps)
IN
Speed
(RPM)
Efficiency
(%)
Power
Factor
(p.u.)
Starting
Torque
Tst
TN
Break-
down
Torque
Tb
TN
Starting
Current
Ist
IN
Approx
net
Weight
IM1001
Kg
0.37 71 2.7 1400 62 0.92 0.35 1.7 3.4 7
0.55 80 3.9 1400 64 0.92 0.35 1.7 3.5 9.5
0.75 80 5.0 1400 68 0.92 0.32 1.7 3.7 10
1.1 90S 6.8 1400 71 0.95 0.32 1.7 4.0 13
1.5 90L 9.0 1400 73 0.95 0.3 1.7 4.6 16
Dimensions: Capacitor Start Run (MY series)
Bolt on feet – Multi-mount construction
TECO Australia Pty. Ltd.
www.teco.com.au email: [email protected]
Sydney Head Office: 335-337 Woodpark Road, Smithfield, NSW 2164 Tel: 02 - 9765 8118 Fax: 02 - 9604 9330
Brisbane Office: 50 Murdoch Circuit, Acacia Ridge, QLD 4110 Tel: 07 - 3373 9600 Fax: 07 - 3373 9699
Melbourne Office: 16 Longstaff Road, Bayswater, VIC 3153 Tel: 03 - 9720 4411 Fax: 03 - 9720 5355
Perth Office: 28 Belgravia Street, Belmont, WA 6104 Tel: 08 - 9479 4879 Fax: 08 - 9478 3876
TECO New Zealand Pty. Ltd.: Unit 3, 477 Great South Road, Penrose, Auckland
Tel: 64 - 9 - 526 8480 Fax: 64 - 9 - 526 8484
8 MON SP MM MkII-112004
