Tectro TD 10 User manual

TD 10
2
6
5
3
4
>
u
1
:
=
y
TR
FIN
GEBRAUCHSANWEISUNG
BRUGSANVISNING
INSTRUCCIONES DE USO
MANUEL D'UTILISATION
KÄYTTÖOHJE
OPERATING MANUAL
ISTRUZIONI D’USO
BRUKSANVISNING
GEBRUIKSAANWIJZING
INSTRUKCJA OBSŁUGI
BRUKSANVISNING
NAVODILA ZA UPORABO
KULLANIM KILAVUZU
2
12
20
28
36
44
52
62
70
78
88
96
104

1PLEASE READ THE USER'S MANUAL FIRST.
2IF YOU HAVE ANY DOUBTS, CONSULT YOUR DEALER.
4
44
Dear Sir, Madam,
Congratulations with the purchase of your dehumidifier. You have acquired a high quality
product which will give you many years of pleasure, if you use it responsibly. Please read
the user's manual first in order to ensure the optimum life span of your dehumidifier. On
behalf of the manufacturer, we provide a two-year warranty on material- or manufacturing
defects.
Enjoy your dehumidifier.
Yours sincerely,
PVG International B.V.
Customer Service Department

IMPORTANT
COMPONENTS
Control panel
Adjustment
button/hydrostat
Dry air outlet
Removable water
container
Humid air inlet
Air filter
Drain spout
(ø13 mm) with cap
Plug and cord
Handle
A
B
C
4
E
F
G
H
I
4
45
1
2
5
4
9
G
H
3
6

SAFETY INSTRUCTIONS
Install the device only when it complies with local regulations, by-laws and standards. The
unit is only suitable for use in dry locations, indoors. Check the mains voltage and
frequency. This unit is only suitable for earthed sockets, connection voltage 220-240 V. / 50
Hz.
GENERAL
• To obtain optimum performance from your dehumidifier, do not place it near a
radiator or any other heat source.
• Ensure that all windows are closed in order to achieve maximum efficiency.
• The capacity of the dehumidifier depends on the temperature and the humidity in
the room. At lower temperatures, less moisture will be removed.
• Ensure that the screen filter is kept clean. This prevents unnecessary power
consumption and guarantees optimum efficiency.
• If the power supply has been interrupted, the defumidifier will restart after three
minutes. The automatic delay protects the compressor.
Beforeconnecting the unit, check the following:
•The voltage supply must correspond with the mains voltage stated on the rating
label.
• The socket and power supply must be suitable for the current stated on the rating
label.
• The plug on the cable of the device must fit into the wall socket.
• The device must be placed on a flat and stable surface.
The electricity supply to the device must be checked by a recognised professional if you
have any doubts regarding the compatibility.
• This device is manufactured according to CE safety standards. Nevertheless, you must
take care, as with any other electrical device.
• Do not cover the air inlet and outlet grill.
•Empty the water reservoir before moving the unit.
• Never allow the device to come into contact with chemicals.
• Never spray the unit with or submerge in water
•Do not insert objects into the openings of the unit.
• Always remove the plug from the electric power supply before cleaning or replacing
the unit or components of the unit.
• Never use an extension cable to connect the device to the electric power supply. If
thereis no suitable, earthed wall socket available, have one installed by a recognised
electrician.
GIMPORTANT
The device MUST always have an earthed connection. If the power supply is not
earthed, you may not connect the unit. The plug must always be easily accessible
when the unit is connected. Read these instructions carefully and follow the
instructions.
4
46

4
47
•For safety reasons take care when children are in the surrounding of the device, as
with any other electrical device.
• Have any repairs only carried out by a recognised service engineer or your supplier.
Follow the instructions for use and maintenance as indicated in the user manual of
this device.
•Always remove the plug of the unit from the wall socket when it is not in use.
• A damaged power cord or plug must always be replaced by a recognised electrician
or your supplier.
CONTROL LIGHTS ON THE CONTROL PANEL
This light indicates that the defrost function has been activated. This is necessary to
prevent excessive formation of ice in the device.
This light indicates that the water container is full. The device switches off
automatically.
The device is in operation when this light is on.
OPERATION
Ensure that the hydrostat is in the OFF position before inserting the plug into the wall
outlet.
Ensure that the water container has been positioned correctly. If the -light
switches on when you use the device for the first time, remove the water container
from the device and replace it in the correct position.
Turn the hydrostat to the desired position. The hydrostat is continuously adjustable.
Set the hydrostat to ‘NORMAL’, which produces a relative humidity of approximately
50% and provides a comfortable living environment.
The device starts to dehumidify when the relative humidity in the room is higher than the
set value.
The device switches offautomatically when the set value is reached, and restarts when the
humidity in the room rises again.
Setting the hydrostat to the ‘MAX.’ position keeps the device in continuous operation.
Turnthe adjustment button to the ‘OFF’ position to turn the device off.
4
3
2
1
GATTENTION!
• Never use the device with a damaged power cord, plug, cabinet or control
panel. Never trap the power cord or allow it to come into contact with sharp
edges.
• Failing to follow the instructions may lead to nullification of the guarantee on
this device.

WATER DRAINAGE
When the water container is full, the -light switches on and the dehumidifier switches
off automatically. Empty the container and replace it in the correct position. The device
will restart.
If desired, it is possible to connect a drainage hose to the device for permanent water
drainage. Follow these steps:
Unscrew the cap on the back.
Remove the rubber stop from the drainage spout.
Connect the drainage hose and ensure that the end of the hose is lower than the
spout, otherwise the water will not drain and flooding may occur.
Place the end of the drainage hose in a water outlet.
When you no longer wish to use the permanent water drainage, disconnect the drainage
hose from the device. Push the rubber stop back into the drainage spout and replace the
cap. Ensure that the water container is positioned correctly.
CLEANING
Switch the dehumidifier offand remove the plug from the socket before cleaning.
THE EXTERIOR
Clean the exterior with a soft, dry cloth. If the device is extremely dirty, use a mild cleaning
agent. Wipe the device with a slightly damp cloth. Never spray the device with water.
THE AIR FILTER
When used regularly, the filter may become clogged with dust and particles. Therefore the
filter should be cleaned every two weeks. Follow these steps:
Remove the water container from the device. Tilt the device backwards a little and
remove the filter.
Clean the filter with a vacuum cleaner or with water. Dry the filter and replace it.
Ensure that the filter is completely dry. Replace the water container.
GNever use the device without the air filter.
2
1
4
3
2
1
4
48

STORAGE
If the machine will not be used for a long period of time, take the following steps:
Remove the plug from the socket and empty the container. Allow the container and
the dehumidifier to dry completely.
Clean the air filter.
Store the device in a dust-free location, preferably covered with a sheet of plastic.
TROUBLE SHOOTING
Check the following before contacting technical support:
Problem Cause Solution
The powercord is not connected.
Insert the plug into the wall
outlet.
The hydrostat setting is too low.
Turn the hydrostat to the
desired setting.
The water container is full.
Remove the water from the
container.
The water container has not
been replaced correctly.
Place the water container in the
correct position.
The air filter is clogged. Clean the air filter.
The temperature or relative
humidity in the room where the
device is operating is too low.
It is normal that the device does
not dehumidify in these
conditions.
The room is too large.
We recommend using a
dehumidifier with a greater
capacity.
There are too many sources of
humidity.
We recommend using a
dehumidifier with a greater
capacity.
There is too much ventilation.
Reduce ventilation (e.g. close
curtains and shut doors).
The device does not
dehumidify.
The dehumidifier works,
but reduces the relative
humidity insufficiently.
The unit does not work.
3
2
1
4
49

CONDITIONS OF WARRANTY
There is a two-year warranty on your dehumidifier from the date of purchase. All material
or manufacturing defects will be repaired free of charge.
The following applies:
• All claims for compensation, including consequential damage, will not be
entertained.
• Any repairs or replacement of components during the warranty period will not result
in an extension of the warranty period.
• The warranty will expire if any alterations have been made, not genuine components
have been fitted or if the dehumidifier has been repaired by a third party.
• Components subject to normal wear and tear, such as the air filter, are not covered by
the warranty.
• The warranty is only valid on presentation of the original, unaltered, and date-
stamped purchase receipt.
• The warranty does not cover damage caused by actions that deviate from those as
described in the user’s manual or by neglect.
• Transportation costs and the risks involved during the transportation of the
dehumidifier or components shall always be for the account of the purchaser.
To prevent unnecessary expenses, we recommend that you always carefully read the user’s
manual first. If this does not provide a solution, take the dehumidifier to your distributor
for repair.
Waste electrical products should not be disposed with household waste. Please
recycle where facilities exist. Check with your local authority or retailer for
recycling advice.
Environmental information: This equipment contains fluorinated greenhouse
gases covered by the Kyoto Protocol. It should only be serviced or dismantled by
professional trained personnel.
This equipment contains R134a refrigerant in the amount as stated in the table
above. Do not vent R134a into atmosphere: R134a, is a fluorinated greenhouse gas
with a Global Warming Potential (GWP) = 1300
4
50

TECHNICAL SPECIFICATIONS
*Moisture removal at 32ºC, 80%RH
** Tobe used as indication
Subject to change without prior notice.
PERFORMANCE GRAPH
(to be used as indication only)
100
75
50
25
03 6 9 12 15 18 21 24 27 30 33
T [°C]
[%]
80 % RH
60 % RH
50 % RH
Nom. capacity
Model TD 10
Power consumption kW 0.22
Power supply V / Hz / Ph 220-240 / 50 / 1
Current (nom.) A 1.0
Dehumidifying capacity* L / 24h 10
Capacity water container L 1.0
Air flow (nom.)**
m3/h 130
For rooms up to**
m340 - 60
Operating range °C 5-32
Y
Y
Piston
Refrigerant type / charge r / gr R134A / 200 gr
Dimensions (w x d x h ) mm 295 x 280 x 440
Net weight kg 11.5
Gross weight kg 15.0
Noise level dB 40
Unit Protection IP IP 20
Automatic defrost
Hydrostat
Compressor type
4
51
0.22
1.6
1.1
R134A / 160
11.5
Fuse rating 250V, T6.3A
13.0
dB(A)
100
Sound pressure level

DISTRIBUTED IN EUROPE BY PVG INTERNATIONAL B.V.
PVG Traffic avg©070525 man_TD10
iÖSTERREICH
PVG Austria VertriebsgmbH
Salaberg 49
3350 HAAG
tel: [phone]
fax: [phone]
email: [email protected]
eBELGIË
PVG Belgium NV/SA
Industrielaan 55
2900 SCHOTEN
tel: [phone]
fax: [phone]
email: [email protected]
qSCHWEIZ
PVG Schweiz AG
Salinenstrasse 63
4133 PRATTELN
tel: [phone]
fax: [phone]
email: [email protected]
2DEUTSCHLAND
PVG Deutschland GmbH
Siemensstrasse 31
47533 KLEVE
tel: 0800 - 9427646
fax: [phone]
email: [email protected]
6DANMARK
Appliance A/S
Blovstroed Teglvaerksvej 3
DK-3450 ALLEROED
tel: [phone]
fax: [phone]
email: [email protected]
5ESPAÑA
PVG España S.A.
Pol. Ind. San José de Valderas II
Comunidad ”La Alameda”
C/ Aurora Boreal, 19
28918 LEGANÉS (Madrid)
tel: [phone]
fax: [phone]
email: [email protected]
3FRANCE
PVG France SARL
4, Rue Jean Sibélius
B.P. 185
76410 SOTTEVILLE SOUS LE VAL
tel: [phone]
fax: [phone]
email: [email protected]
SUOMI
Appliance Finland Oy
Piispantilankuja 6C
02240 ESPOO
tel: [phone]
fax: [phone]
email: [email protected]
FFIINN
4UNITED KINGDOM
Scott Brothers Ltd.
The Old Barn, Holly House Estate
Cranage, Middlewich, CW10 9LT UK
tel.: [phone]
fax: [phone]
email: [email protected]
>ITALIA
PVG Italy SRL
Via Niccolò Copernico 5
50051 CASTELFIORENTINO (FI)
tel: [phone]
fax: [phone]
email: [email protected]
uNORGE
Appliance Norge AS
Vogellunden 31
1394 NESBRU
tel: [phone]
fax: [phone]
email: [email protected]
1NEDERLAND
PVG International B.V.
P.O. Box 96
5340 AB OSS
tel: [phone]
fax: [phone]
email: [email protected]
9PORTUGAL
Gardena, Lda
Recta da Granja do Marquês
ALGUEIRÃO
2725-596 MEM MARTINS
tel: + 35 21 92 28 530
fax: + 35 21 92 28 536
email: [email protected]
:POLSKA
PVG Polska Sp. z. o. o.
ul. Kościelna 110
26-800 Białobrzegi
tel: [phone]
fax: [phone]
email: [email protected]
=SVERIGE
Appliance Sweden AB
Sjögatan 6
25225 HELSINGBORG
tel: [phone]
fax: [phone]
email: [email protected]
TURKEY
PVG Is›tma Klima So¤utma Ltd.fiti.
Atatürk Cad. No 380 Ak Iflhani Kat 6
35220 Alsancak
IZMIR - TURKEY
tel: + 90 232 463 33 72
fax: + 90 232 463 69 91
email: [email protected]
TTRR
