Teeter FitSpine System User manual

INVERTING
When correctly balanced, the inversion table will rotate in response to simple arm
movements. To invert, lift your arms overhead slowly and to return upright, bring your
arms back to your sides. Your arms provide the weight needed to rotate the table.
(Figure 9).
To ensure the table does not rotate too far, too quickly:
1. Set the Roller Hinges to Setting “C” (as explained on pg. 2);
2. Attach the Nylon Tether to the underside of the Table Bed and test to
max rotation;
3. Raise one arm at a time, and do so very slowly (the faster you move, the
faster the inversion table will rotate).
To use the traction bars on the Support Handles, push against them while inverted to
achieve a greater decompression and relaxation.
RETURNING UPRIGHT
• To return to the upright position, put your arms at your sides (Figure 10). Since
your body may have lengthened or shifted on the Table Bed during inversion, you
may need to bend your knees to shift your body weight to the foot side of the
pivot point. DO NOT lift your head or try to sit up.
FULL INVERSION
Definition: Hanging completely upside down by your ankles with your back free from the
table.
DO NOT attempt this step until you are comfortable with partial inversion.
• Disconnect the nylon tether.
• Set the Roller Hinges in the top hole setting “A” if you want the table to “lock”
firmly while inverted. If you are 220 lbs (100 kg) or more, set the roller hinges in
the “B” hole setting.
• From a balanced position on the table, slowly raise both hands over your head
to begin rotation. You may need to assist the last few degrees of rotation by
pushing on the floor or A-frame until the table pulls away from your back. In your
correct balance setting, your weight will keep the table “locked” in this position
until you are ready to return upright (Figure 11).
To Release from the Inverted “Locked” Position:
• Reach one hand over your shoulder and grip the corner of the Table Bed.
• Place the other hand on the bottom bar of the A-frame in front of you (Figure 12).
• Pull both hands together. This will rotate the table out of the “locked” position.
Slowly move your arms and elbows to your sides to complete the rotation. USE
CAUTION: Elbows protruding over the sides of the Table Bed could get pinched
between the A-frame and the Table Bed as you return upright.(Figure 13).
•
It is your responsibility to familiarize yourself with the proper use of the equipment and the inherent risks of inversion,
such as falling on your head or neck, pinching, entrapment or equipment failure.
DO NOT use the inversion table until you have thoroughly and carefully read the Owner’s Manual, reviewed all
accompanying documents and inspected the equipment. ALWAYS test and inspect the equipment for smooth
operation prior to each use.
WARNING
!
INVERT
tp
Sne
SYSTEM
TM
Owner’sManual
tp
Sne
SYSTEM
TM
For information about the 1-year warranty,
or if you have any problems assembling the equipment,
or questions about its use, please contact customer service at:
STL International, Inc.
9902 162nd St. Ct. E., Puyallup, WA 98375
Toll Free (Phone) 800-847-0143 (Fax) 800-847-0188
Local (Phone) 253-840-5252 (Fax) 253-840-5757
(e-mail) [email protected] (web) www.FitSpine-System.com
U.S. patents apply.
FitSpine™ is a registered trademark of STL International, Inc.
Specifications subject to change without notice.
© COPYRIGHT 2010, STL International, Inc.
International Law Prohibits Any Copying, 0210-1 LS-1000
Max User Height: 6 ft 6 in (198 cm)
Max User Weight: 300 lbs (136 kg)
tp
Sne
SYSTEM
TM
FAILURE TO FOLLOW INSTRUCTIONS AND WARNINGS COULD RESULT IN SERIOUS INJURY OR DEATH.
WARNING -To reduce the risk of injury to persons:
• Read and understand all the instructions, view the instructional video, review all other accompanying documents, and inspect the
equipment before using the inversion table. It is your responsibility to familiarize yourself with the proper use of this equipment and the
inherent risks of inversion, such as falling on your head or neck, pinching, entrapment, or equipment failure. It is the responsibility of the
owner to ensure that all users of the product are fully informed about the proper use of the equipment and all safety precautions.
• Close supervision is necessary when the inversion table is used near children, or by or near invalids or disabled persons.
• Use the inversion table only for its intended use as described in this manual. DO NOT use attachments not recommended by
the manufacturer.
• NEVER drop or insert any object into any opening.
• DO NOT use or store product outdoors.
• DO NOT use if you are over 6 ft 6 in (198 cm) or over 300 lbs. (136 kg). Structural failure could occur or head/neck may impact
the floor during inversion.
• DO NOT allow children to use this machine.
• Keep children, bystanders, and pets away from machine while in use.
• Keep body parts, hair, loose clothing and jewelry clear of all moving parts.
• The inversion table has no user serviceable parts.
• This product is intended for home use only. DO NOT use in any commercial, rental or institutional setting.
• DO NOT operate equipment while under the influence of drugs, alcohol, or medication that may cause drowsiness or disorientation.
• ALWAYS inspect the equipment prior to use. Make sure all fasteners are secure.
• ALWAYS replace defective components immediately and/or keep the equipment out of use until repair.
• ALWAYS position equipment on a level surface and away from water or ledges that could lead to accidental immersion or falls.
• ALWAYS wear securely tied lace-up shoes with a flat sole, such as a normal tennis style shoe. DO NOT wear any footwear that could
interfere with securing the ankle clamps, such as shoes with thick soles, boots, high-tops or any shoe that extends above the anklebone.
• ALWAYS make sure the equipment is properly adjusted to the correct user settings prior to each use.
• DO NOT use aggressive movements, or use weights, elastic bands or any other exercise or stretching device while on the inversion
table.
• New users, and users who are physically or mentally compromised, will require the assistance of a partner to ensure they are able to
find the correct balance setting and can return to an upright position unassisted.
• If you feel pain or become light-headed or dizzy while inverting, immediately return to the upright position for recovery and eventual
dismount.
• DO NOT use the equipment without a licensed physician’s approval. Carefully review the following list of medical contraindications for
inversion with your licensed physician: (This is not an exhaustive list, it is intended only for reference)
· Middle ear infection · Glaucoma · Heart or circulatory disorders · Bone weakness (osteoporosis)
· Extreme obesity · Retinal detachment · Spinal injury · Recent or unhealed fractures
· Pregnancy · Conjunctivitis · Cerebral sclerosis · Medullary pins
· Hiatal hernia · High blood pressure · Acutely swollen joints · Surgically implanted orthopedic supports
· Ventral hernia · Hypertension · Recent stroke or transient · Use of anticoagulants
ischemic attack (including high doses of aspirin)
• Refer to additional warning notices posted on the equipment. If a product label or Owner’s Manual should become lost, damaged or
illegible, contact Customer Service for replacement.
WARNING
!
Figure 9
Figure 10
Figure 11
Traction
bars
Figure 12
Figure 13
To reduce tipping hazard, confine all inverted activities to smooth movements.
Aggressive exercises that involve vigorous body movement can cause the table
to tip over, resulting in serious injury or death!
WARNING
!
UL Listed 53NJ
UL Listed 53NJ
Meets Medical-Grade Specifications

BEFORE YOU INVERT make sure that the table rotates smoothly
to the fully inverted position and back, and that all fasteners are
secure. Make sure the user settings described below are properly
adjusted for your unique needs and body type. Take your time
finding your proper settings and remember them. Check these
settings every time prior to using the equipment.
FIND YOUR SETTINGS
Figure 1
Figure 2
Figure 4
Figure 3
A
B
C
BALANCING
The inversion table is like a sensitively balanced fulcrum. It responds to very small changes in weight
distribution. As a result, you must always test to make sure you have the correct
height setting. Ensure that there is clearance to rotate in front, above and behind you.
• To begin, rest your head on the mat and place your arms at your sides, then slowly
place your arms on your chest. Check to see:
1. if your head is lower than your feet, then lengthen the height setting by one
hole and test again.
2. if your feet do not move at all, then shorten the height setting by one hole and
test again.
3. if the table comes to rest with your feet lifted a few inches off the A-frame,
then you have found the correct balance setting (Figure 8).
NOTE: The correct balance setting will allow your arm movements to rotate the
table backward smoothly and slowly, and return to the upright position in the same
manner. This is an important step; spend as much time as necessary to find the correct balance setting. Once
you find your setting, it should remain the same as long as your weight does not fluctuate substantially.
SECURE YOUR ANKLES
For your first few inversion sessions, ask a spotter to assist you until you are able to find your correct balance setting
and are comfortable with the operation of the table.
WARNING
!
INVERT
Figure 8
ALWAYS carefully check to be certain the Ankle Locking System is locked securely each time you use your inversion
table. ALWAYS make sure that the ankle clamps are snug against your ankles, or you could fall when the table inverts,
resulting in serious injury or death! DO NOT lean your upper body against the Table Bed before securing your ankles.
DO NOT deviate from these instructions.
WARNING
!
tp
Sne
SYSTEM
TM
tp
Sne
SYSTEM
TM
U-bar
1. Adjust the Roller Hinge:
The Roller Hinge setting controls the responsiveness or rate of rotation. There are
three holes; hole selection depends both on your body weight and the rotational
responsiveness you desire. For beginners, we recommend starting with Setting C
(See Figure 1). IMPORTANT: Place the Roller Hinges in the same hole setting on
each side.
2. Adjust the Height Setting:
The height settings are stamped on the Main Shaft in both inches and
centimeters.
• Pull out the height selector locking pin with your right hand, while sliding the
Main Shaft with your left (See Figure 2).
• Slide the Main Shaft until the last setting you can read is 1” greater than your
height (e.g., if you are 5’10’’ the last numbers you should read will be 5’11”).
NOTE: The best height setting for you will depend on your weight distribution
and could vary one or two inches on either side of your actual height. Starting
at one or two inches greater than your height will help
ensure that the rotation of the table is not too fast.
• Release the height selector locking pin so it fully engages in a hole.
3. Attach the Nylon Tether:
For first time users, attach the Nylon Tether to help control your angle of rotation
(See Figure 3). You can increase the angle of rotation allowed by the Nylon Tether
as you become more comfortable using the table, or remove it all-together for full
inversion.
4. Adjust the Foot Platform:
The FitSpine™ Foot Platform can be rotated into either a High or Low setting, with
a one inch height difference between the two sides. The ideal setting will vary by
user and the type of shoes worn. Ideally, the Foot Platform should be set so that
the ankle clamps secure around the smallest part of the ankles (with minimal dis-
tance between the foot clamp and the top of your foot) to reduce body slide while
inverted (Figure 4).
SECURING YOUR ANKLES
• Stand with your back to the Table Bed - do not use the inversion table face-down.
• Step over the Main Shaft, placing your feet on the floor on either side. To balance
yourself, rest only your lower body against the Table Bed as you slide one ankle at a
time between the Ankle Clamps onto the Foot Platform. Be sure to slide your ankle
in from the side (Figure 5); DO NOT insert the foot through the ankle clamps as you
would slide your foot into a shoe. Your feet should always be either on the floor or on
the Foot Platform; never use any other part of the inversion table as a step (Figures
6A and 6B).
• Press your ankles back firmly against the rear ankle clamps.
• Rotate the top of the rear clamps slightly inward toward your ankles, this will
increase your comfort while inverting.
• Push down on the handle of the Ankle Locking System, pull toward your legs and
release. Test the closure by jiggling the handle from front to back to make sure the
Ankle Clamps are locked securely. (Figure 7) Figure 7
WARNING
!
DO NOT step on the crossbar of the A-frame or on top of the Ankle Clamps as this
could cause the table to rotate resulting in serious injury or death!
Figure 6A
Figure 6B
Figure 5
