Teison TS-EDC60-001 User manual

DC 60-240KW
TS-EDC60-001／002
TS-EDC90-001／002
TS-EDC120-001／002
TS-EDC150-001／002
TS-EDC180-001／002
TS-EDC240-001

Product overview
Overall features
Parameter Instructions
Parameter Instructions
01
02
03
09
Installation instructions 16
TABLE OF CONTENTS

1
Product overview
RFID
IK
IK
RFID
OCPP
J-son
1.6 4G
WIFI
10
10
LCD screen
Logo
Equipment lock
Output cable
Charging Connector
RFID card
Emergency button
Indicator

Overall features
2
CCS2, CHAdeMO, GB/T, and CCS1 can be combined and customized.
Multiple standard charging port combinations
to choose from
Multiple power options are available, ranging from 30 KW to
480 KW with customizability.
Diverse power range
The maximum output voltage can reach 1000V, meeting the
needs of the vast majority of electric vehicles on the market.
High voltage output
It can not only operate on our platform but also connect with
various OCPP platforms.
Intelligent operation
More effective connection to the load system.
Load balancing
The status of the charging station can be monitored in the
background.
Backend monitoring

3
Parameter Instructions

9
Operating Instructions
1.1 Wifi connection
1.Instruction
Press the settings button in the upper right corner
Choose login with “User: Administrator”, password: 39935069

10
Choose “General Information”
Open “Android Virtual Keys”
Press the button in the red box

11
Click the button in the red box, to enter the menu bar
Select ‘Setting’ to enter
Connect “WIFI”

12
1.2 OCPP platform connection
Press “Charging Station”to return the charging systerm and close android Virtual
Keys
Press “Charging Settings”
Choose “Charging Station Management System”

13
Enter the corresponding URL to the platform, and the last section is the char-
ger’s ID number
You can exit after adding the corresponding ID number in the ‘Device Infor-
mation’ option
Successful login to the platform if the cloud with ‘√ ’

14
1.3 Charging Mode and Method
APP/RFID Mode: support QR code scanning and RFID prepaid charging mode
APP/RFID Mode Operation Diagram
Plug&Charge Mode Operation Diagram
Plug&Charge: no billing mode
TPU cable

15
Teison APP operation diagram shown as below:

16
Installation instructions
This manual is specifically for Teison DC model products. Before using the
product, please read this manual carefully and ensure that the installation
and operation are carried out according to the instructions. Please keep the
installation instructions in a safe place for maintenance or reference during
operation.
1.Scope
This charging station is an outdoor electric vehicle charging station that
meets the IP55 protection level and is suitable for installation in dry and less
dusty environments.
The foundation must ensure the stability and safety of the charging station
installation position.
Please ensure that the operating temperature is within the range of -20C to
+50C to ensure that the charging station operates in an optimal state.
When the charging station is installed in an open-air environment, in order to
better improve user experience and satisfaction, it is recommended to arrange
a rain-shielding roof above the device to prevent rain from directly falling on
the device and facilitate user operation.
The charging station installation environment should be well-ventilated and
away from water sources, heat sources, and flammable and explosive
materials. Avoid installing the charging station in an environment with direct
sunlight, dust, volatile gas, corrosive substances and excessive salt content.
2.Installation preparation
2.1. Installation environment
2.2. Installation spacing
The foundation must have a certain bearing capacity to support the weight
of the charging station and sufficient space to place the charging station.
Please place the charging station in a reasonable position on the foundation
according to the size of the charging station.

17
3.Handling method
The charging station can be handled with a forklift. When forking the machine,
the center of gravity of the machine should be at the center of the two forks,
and the handling process should be kept slow and steady.
If the site conditions permit, it is recommended to leave more space between
the machine and the surrounding device or walls for heat dissipation and
maintenance to ensure the stable and efficient operation of the charging station.
When forking the machine, the center of gravity of the machine should be at
the center of the two forks, and the handling process should be kept slow and
steady.
When lifting the equipment with a forklift, please ensure the stability of the fork
and keep the left and right balance.
During the moving process, Please keep the charging station vertical and
should not be put down or lifted suddenly.

18
4.Unboxing
Step 1: Check if the appearance of the device packaging is intact and if there is
any transportation damage. If there is any damage, please notify the carrier
immediately.
Step 2: Transport the device to the designated location. To prevent the device
from tipping over during transportation, when using an electric forklift or a
manual forklift for transportation, insert it from the front of the wooden pallet,
as shown in the figure below.
Step 3: Remove the outer packaging, take out the foam pad and plastic bag,
and extract the optional accessories and accompanying materials.
Forklift wall insertion position
