Teison TS-EVC07-002 User manual

Teison
Instruction
Manual

Troubleshoot and Maintenance
1.1 Appearance ................................................................................................ 5
1.2 Product Specification ............................................................................. 6
1.3 Product List .................................................................................................. 7
1.4 Transportation and Storage ............................................................... 7
2.1 Safety tips ...................................................................................................... 7
2.2 Installation guide ..................................................................................... 8
3.1 Charge preparation ............................................................................... 11
3.2 Charging（RFID）........................................................................... 11
3.3 LCD display ................................................................................................ 12
4.1 Maintenance caution ............................................................................ 13
4.2 Troubleshoot and Maintenance ........................................................... 14
4.3 Warranty Card .......................................................................................... 16

RFID charge.
LCD screen Display
Shows information such as charging status ,max and
charging current , voltage , power , Kwh and charging
time.
Supporting MID Meter values （Extra function）
Aplication
AC electric vehicle charger
Suitable for home and public charging sites
RFID card reader function
Simple self service use
Main Features
WARNING
Please read the below safety guide before use
WARNING
Never use if charging cable is damaged.
The charger must be fitted by a qualified electrician
using the appropriate RCB for the application.
A visual check for damage must be undertaken before
each use.
This charger must only ever be used to charge electric
(EVs) or hybrid vehicles (PHEVs).
The charger must be installed in a well ventilated area,
overheating and damage may occur in closed spaces.
Failure to follow the safety instructions may lead to
damage or serious injury.

Specification
Rated Voltage
Max Output Current
Frequency
Max Output Power
Display
RFID Function
Charging Outlet
Housing Material
Front Panel
Installation Method
Safety Standard
MTBF
Warranty
Protection Level
Working Altitude
Application Site
Product Size
Product Weight
Optional Parts
TS-EVC07-002（S）
230VAC ±10%
32A
50/60Hz
7.8kw
5.3/7.0KG
Energy Meter
5.2/8.2KG
TYPE B
MID certified
5.5/8.5KG
Residual current protection
Yes
LCD screen
3pcs cards
TYPE A 30mA+DC6mA
One charging socket （Type 2）/4.5M charging cable
PCV0 for outdoor
PC
Wall-mount/Floor-stand
EN 61851-1
100000 Hours
2years
IP67
-30~50°C/5%~95% without condensation
＜2000M
Indoor/Outdoor
398x324x120mm
TS-EVC11-002（S）
380VAC ±10%
16A
50/60Hz
11kw
TS-EVC22-002（S）
380VAC ±10%
32A
50/60Hz
22kw
Emergency Stop Button
Residual current protection
Temperature/Humidity

Charging device assembly
Wall-mount Bracket
Installation Fittings （bag）
RFID cards
Instruction Manual
1
2
1
3
1
2.1 Safety tips
This charging device must be installed by a qualified electrician.
Before first power up confirm with your installer that it is safe to use.
Make sure all cables are secure and the device is clean and is in a well
ventilated area. The charger cannot be installed in an area with possible
flame or gas exposure. Never allow children to touch the charger.

9
-Teison
Pedestal installation dimensions
0
Warning:
Ensure the backplate is fitted to
a sound structure ideally
200mm thick
Wall Installation:
Technology changes life
3. Install the backplate (A) with
the expansion screws
1.Offer up backplate to wall min 1
meter above ground mark hole position.
Drill holes in the wall.
2.Install expansion screws
.
A
4. Install the plate B to the back of the
charger
5. Secure the charger on the fitted
backplate.
Danger!
Installation must be carried out by a qualified electrician.
The electric shock would happen if don't install accord with
operation procedure.
The electric shock or the serious hazard would happen if
don't observe operation instruction of safety precaution.
10

Connect power to enter the
starting page.
Enter “Connecting”mode once
plug connection is confirmed Swipe the card to enter
“Charging”mode, the screen
shows the power, voltage,
charging current, Kwh ,charging
time and status.
3.3 LCD Display
Prompt to connect your charging
cable when it’s in the standby
status.
Users can choose three ways to
stop charging:
1. The charger will detect the
cars battery is fully charged.
2. Swipe the RFID card on
charger, charging will stop.
3. . Cut power to the charger.
After plug in，follow on screen prompts
Fault mode: see page 14
CONNECTED
Green light is on constantly
Blue light is on constantly
STANDBY

4.2 Breakdown and Maintenance
Red light flashes
Green light flashes Blue light flashes
END
Leakage
Protection
Creepage
Over
Voltage
Under
Voltage
Over
Current
Over
Temperature
0x0001
0x0002
0x0004
0x0008
0x0010
flash flash flash flash flash
1
2
3
4
5
Less voltage
protection
Over voltage
protection
Over temperature
protection
Over Voltage
protection
Solution
Relay is disconnected charging stops. The relay is cut off and the red light flashes. Power off and then on again. Over voltage charging stops automatically , the relay is cut off, the red light starts to flash. Power off and then on again.
Under voltage charging stops automatically , the relay is cut off, the red light starts to flash. Power off and then on again.
If the maximum current is 2A higher than the chargers maximum charging stops automatically , the relay is cut off, the red light starts to flash. Power off and then on again.
When the temperature is higher than 85 °C, the charging will stop automatically, the relay will be disconnected, the red light will start to flash, when the temperature drops below 85 °C the relay will automatically reset and charging will begin automatically. When the temperature is between 75 ° C and 85 ° C, the control box will automatically lower one gear position. When the temperature is lower than 75 ° C, the gear position will automatically recover.
Condition
Display
code
LCD
display
Status
indicator light
Status
indicator light
Malfunction and Maintenance
4.1 Maintenance
Regularly check charging cable for damage.
Inspect charger casing to ensure the seals are intact and no physical
damage exists.
Observe incoming lines to make sure no wire is damaged.

4.3 Warranty card
NTC brake
NTC short
E-stop
MID
RFID
CP
communication
flash flash flash flash flash flash
Temp
Brake
Temp
Short
Gun
Fault
EStop
Fault
Meter
Fault
Card
Fault
0x0020
0x0040
0x0080
0x0400
0x0100
0x0200
9
8
7
11
6
10
Solution
The temperature sensor is in open circuit, charging stops and the relay is cut off. Unit must be returned to factory for repair. The temperature sensor has a short circuit, charging stops and the relay is cut off. Unit must be returned to factory for repair. The CP of the charging cable is short-circuited, stop charging and cut power to the charger. Have cable inspected by a qualified electrician. If for whatever reason the red emergency stop button is pressed the charging will immediately stop. Press again to resume charging. Can not communicate with the meter for more than 5 seconds, charging stops and the relay is cut off, charging resumes once communication is resumed. Can not communicate with the RFID mode for more than 5seconds, charging stops and the relay is cut off, charging resumes once communication is resumed.
Condition
Display
code
LCD
display
Status
indicator light
Status
indicator light

-Teison -----------
17
