MUL-420 Tensioner for STEEL
Operation Manual
Strap Type
Regular Duty/High Tensile Steel
Strap Width
3/4" (19 mm) to 1 1/4" (32 mm)
Strap Thickness
Up to 0.044" (1.1 mm)
Joint Type
Seal
Weight
6.5 lbs (3 kg)
Footprint
L: 3.5"; W: 3.5"
Handle Length
16.5"

Fig. 1 –Starting Position
1. Based on type of the Seal 102 used (open or closed), place the seal on the strap accordingly.
Press down on Tension Handle 08 to raise Frame 06. Load both straps 100 and 101 under Feed Wheel
17 and release the Tension Handle 08 as shown on Fig. 2
Fig. 2

2. Apply tension by ratcheting Tension Handle 08 as shown on Fig. 3.
Fig. 3
3. Once satisfactory tension is achieved return Tension Handle 08 back by pressing on Tension Pawl 09.
Use appropriate sealer to close the Seal 102. With the Seal 102 securely in place press the Tension
Handle 08 to remove the tensioner by sliding the backfoot out to the side folowed by the front as shown
on Fig. 4. The operation cycle is now complete.
Fig. 4
