Teknion MYWMS Operating and maintenance instructions

Modesty Panel for Freestanding Height-Adjustable - Solid (MYWMS/EYWMS), Modesty Panel for Freestanding
Height-Adjustable - Smooth Felt (MYWMF/EYWMF)
Section:
Description: Page No:
Date:
Rev. No: 0
WWCOMP HA TABLES - AP & EU
SCREENS
Jan_2021 1 of 4
WWC_205
wwcomplements AP & EU Installation Guides
NOTE:Installation for
WWComplements Europe (EU)
is same as Asia Pacific (AP).
NOTE:For WWComplements
Europe (EU) products starts
with EY and for Asia Pacific
(AP) starts with MY.
NOTE:EYWMS0412B is shown as
Example.

Section:
Description: Page No:
Date:
Rev. No: 0
WWCOMP HA TABLES - AP & EU
SCREENS
Jan_2021 2 of 4
WWC_205
wwcomplements AP & EU Installation Guides
Part and Product Identification
C1 - Modesty Screen
(C05H-0243) x1
C2 - Modesty Screen Mounting Bracket
(A16-9785L) x1
C4 - #10 X 0.875", Screw Washer
(E07-0077) x4
C - Modesty Panel for Freestanding Height-Adjustable - Solid
(MYWMS) x1
C3 - Modesty Screen Mounting Bracket
(A16-9785R) x1
C5 - JCBC M6x20mm Blue Zinc
(E01H-0032) x4
D - Modesty Panel for Freestanding Height-Adjustable - Smooth Felt
(MYWMF) x1
Part and Product Identification
A1 - Modesty Screen
(C07-8000) x1
A2 - Modesty Screen Mounting Bracket
(A16-10081L) x1
A4 - #10 X 0.875", Screw Washer
(E07-0077) x4
A - Modesty Panel for Freestanding Height-Adjustable - Solid (EYWMS) x1
A3 - Modesty Screen Mounting Bracket
(A16-10081R) x1
A5 - 1/4-20 UNCx0.500" Screw,
(E01-0110) x4
B - Modesty Panel for Freestanding Height-Adjustable - Smooth Felt
(EYWMF) x1
B1 - Modesty Screen Assy, PET
(N01-5888) x1
B2 - Modesty Screen Mounting Bracket
(A16-10081L) x1
B3 - Modesty Screen Mounting Bracket
(A16-10081R) x1
B5 - #10 X 0.875",
Screw Washer
(E07-0077) x4
B4 - 1/4-20UNC. Nut Hex Keps Zinc
(A16-10081R) x1
D1 - Modesty Screen
(F04H-0010) x1
C2 - Modesty Screen Mounting Bracket
(A16-9785L) x1
C4 - #10 X 0.875", Screw Washer
(E07-0077) x4
C3 - Modesty Screen Mounting Bracket
(A16-9785R) x1
C5 - JCBC M6x20mm Blue Zinc
(E07T-0001) x4

Section:
Description: Page No:
Date:
ATTACH MOUNTING BRACKETS
Jan_2021 3 of 4
WWC_205
WWCOMP HA TABLES - AP & EU
SCREENS
wwcomplements AP & EU Installation Guides
STEP 1: Attach and Secure Mounting Brackets to the Screen as shown.
A5
A2
B1
NOTE: EYWMS0412B is shown as
Example.
NOTE: EYWMF0412B is shown
as Example.
A1
A3
B2
B3
B4
NOTE: MYWMF0412B is shown
as Example.
D5
D2
D1
D3
NOTE: MYWMS0412B is shown
as Example.
C5
C2
C1
C3

Section:
Description: Page No:
Date:
INSTALL SCREEN ASSEMBLY
Jan_2021 4 of 4
WWC_205
WWCOMP HA TABLES - AP & EU
SCREENS
wwcomplements AP & EU Installation Guides
STEP 2: Mount the Screen Assembly onto the Worksurface by aligning the Assembly to the Pilot Holes. Secure the assembly using Screws provided.
A4
A2
A3
