Teknion Leverage User manual

Panel Add-On Screen - Smooth Felt (KPZA) Part and Product Identification
Section:
Description: Page No:
Date:
Rev. No: 0
PANEL ADD-ON SCREENS
PANELS
Sept 2021 1 of 8
TLE_558
leverage Installation Guides
A - Leverage Add on Screen -
Smooth Felt (F03-0989-X) x1
B - Alignment Clip PET
(B02-0867) xVaries
Leverage Add on Trim Sub Assm. (N01-5997-X) x1
C1 - Leverage Add on Trim Cut
Lengths (A23-8380-X) x2
C2 - Hardware Kit
(X01-4273) x1
C2a - Trim Fastener
(D03-0065) xVaries
C2b - Through Plate for Leverage
Frameless Glass
(A16-2901) xVaries
C2c - 5/16-18 Lock Nut Zinc Plate
(E03-0437) xVaries
C2d - Top Trim Connection Clip
(B02-0202) x1
D - Leverage 90 deg Clip
(B02-0869) xVaries
KPZAB
Both Extended
KPZAE
One Side Extended
KPZAS
Both Standard
C1
A

Section:
Description: Page No:
Date:
LOOSEN HEAD SCREWS INSERT SCREEN
TLE_558
2 of 8
Sept 2021
PANEL ADD-ON SCREENS
PANELS
leverage Installation Guides
STEP 2: Insert Screen Assm. into extrusion making sure edge of Screen lines up with metal rail
as per specifications. Tighten the Button Head screws.
STEP 1: Loosen the Hex Socket Button Head screws alongthe side of the extrusion.
NOTE: Ensure that the Torque is between Min 8.5lbf-in to Max 14lbf-in.
C1
A
NOTE: Please Ensure that the
Torque is between Min 8.5lbf-in
to Max 14lbf-in.
NOTE: Please Ensure that the
Torque is between Min 8.5lbf-in
to Max 14lbf-in.

Section:
Description: Page No:
Date:
SLID IN TRIM FASTENERS INSTALL PANEL ADD-ON SCREEN
TLE_558
3 of 8
Sept 2021
PANEL ADD-ON SCREENS
PANELS
leverage Installation Guides
STEP 4a: Drop the Panel Add-On Screen on top of the Leverage Frame and lock in place with
the Spring Clip and Lock Nuts provided.
STEP 3: Slide in the Trim Fasteners into the bottom track of the sub-assembly.
C2a
C2b
C2c

Section:
Description: Page No:
Date:
COMPATIBILITY KIT INSTALLATION ON PANELS MANUFACTURED BEFORE JUNE 2011
Sept 2021 4 of 8
TLE_558
PANEL ADD-ON SCREENS
PANELS
leverage Installation Guides
STEP 4b: Place Compatibility Spacer Plate inside the channel, close to the Trim Fasteners.
Old Panel New Panel

Section:
Description: Page No:
Date:
MULTIPLE PANEL ADD-ON SCREENS INSTALLATION
Sept 2021 5 of 8
TLE_558
PANEL ADD-ON SCREENS
PANELS
leverage Installation Guides
STEP 4c: For multiple Panel Add-On Screens, connect them using the Top Trim Connection Clip. Install the assembly onto the Panels.
C2d

1/16''
1/16''
Section:
Description: Page No:
Date:
PANEL ADD-ON SCREEN INSTALLATION (CONTINUED)
Sept 2021 6 of 8
TLE_558
PANEL ADD-ON SCREEN
PANELS
leverage Installation Guides
NOTE: Please leave a 1/16" gap between Metal Sub-Assembly when installing multiple Panel Frames with Extended.
Front View Top View
NOTE: Please leave a 1/16" gap between Metal Sub-Assembly
when installing multiple Panel Frames with Extended.

Section:
Description: Page No:
Date:
PANEL ADD-ON SCREEN INSTALLATION (CONTINUED)
Sept 2021 6 of 8
TLE_558
PANEL ADD-ON SCREENS
PANELS
leverage Installation Guides
STEP 5: Install Alignment Clips on side to side applications when there is no Extended Option (minimum gap). NOTE: Alignment Clips are provided with the Add-on Screen depending on specs.
B

Section:
Description: Page No:
Date:
PANEL ADD-ON SCREEN - EXTENDED CORNER APPLICATION
Sept 2021 8 of 8
TLE_558
PANEL ADD-ON SCREENS
PANELS
leverage Installation Guides
Step 6: Install 90 deg Alignment Clip by pushing it between the two screens. NOTE: Always install 90° Corner Cover Trim together with the Panel Add-On Screen when Extended Screens meet
at the corner. The Cap of the Corner Cover has to engage into the trims. For 90° Corner Cover Trim installation, refer to installation guide TLE_205.
D
