Kestrel Stage Series
Section 1: Screen Design .
1.1 What is it?
The Kestrel Stage Series is a large venue portable, free standing electric projector screen. It is ideal for Rental &
Staging or other commercial (Pro AV) applications where a mobile projection screen would be required.
1.2 How does it work?
It is integrated into a sturdy wheeled stage case that has handles for easy transport and set-up. As an added
value, a matching roadie flight-case with detachable velvet skirt is included to complete the arrangement. The
flight-case combines with the cased-screen and skirt to create a professional-grade mobile projection display.
Models also available without the ATA Stage Travel Case.
Section 2: Product Features .
2.1 Characteristics
Screen Material
•GREENGUARD® Certified MaxWhite® Fiberglass (FG) with 1.1 Gain
•180° wide viewing angle
•Active 3D, 4K Ultra HD, and HDR ready
•Not compatible with Ultra/Short-throw Projectors
•Border masking frames the projection surface
•Material has black-backing
•Available in the following diagonal sizes:
•110" and 131" in 4:3 format
•100", 120" and 150" in 16:9 format
•125" and 154" in 16:10 format
Design and Installation
•Rises and lowers by our motorized precision "scissor-backed" cross spring risers
•Integrated stage case
•Wheeled-design includes handles on each side for easy transport and handling
•Black drape (skirt) included for enhanced aesthetics
•Detachable wheeled flight-case with internal storage shelves
•Screen assembly attaches to the flight-case halves when set up for video mode
•Wheel locking mechanisms
Control System
•In-line UP/STOP/DOWN control switch

PRODUCT WHITE PAPER
http://www.eliteproav.com
2
Elite Screens Inc. |Elite Screens Europe GmbH |Elite Screens France SAS |Elite Screens India
Elite Screens China Ltd. | Elite Screens Taiwan Corp. |Elite Screens Japan | Elite Screens Australia
•Includes IR and RF remotes for long distance control
•Standard three prong power connection
Quality and Reliability
•Tubular motor allows swift operation with a superior weight tolerance and operational lifespan
•Flame Resistant: Complies with NFPA 701 Standards
•GREENGUARD® and GREENGUARD® Gold Certified
•5-year manufacturer's warranty
2.2 Certifications
2.3 Model Numbers
Model Number Nominal
Diagonal
Aspect
Ratio
Viewing
Height
(in)
Viewing
Width
(in)
Screen
Material Gain Case Color
N.W.
(lbs)
G.W.
(lbs)
Packaging
Dimensions
(LxWxH)
FE110V-TC 110" 4:3 65.3 87.2 MaxWhite® FG 1.1 Black/Silver 141.8 178.8 97.2"11.0"x7.9"
FE131V-TC 131" 4:3 78.5 104.6 MaxWhite® FG 1.1 Black/Silver 174.7 209.3 164.1"x12.6"x5.9"
FE100H-TC 100" 16:9 49.0 87.1 MaxWhite® FG 1.1 Black/Silver 152.8 181.5 97.6"11.0"x7.9"
FE120H-TC 120" 16:9 58.8 104.6 MaxWhite® FG 1.1 Black/Silver 166.9 207.7 118.5"x12.6"x5.9"
FE150H-TC 150" 16:9 73.5 130.7 MaxWhite® FG 1.1 Black/Silver 188.1 230.5 142.5"11.0"x7.9"
FE125X-TC 125" 16:10 66.0 106.0 MaxWhite® FG 1.1 Black/Silver 163.8 202.6 118.1"11.0"x7.9"
FE154X-TC 154" 16:10 81.6 130.6 MaxWhite® FG 1.1 Black/Silver 190.3 231.6 142.5"11.0"x7.9"
Section 3: Screen Material Specifications .
3.1 Characteristics
MaxWhite® Fiberglass (FG) is fiberglass backed for added
stiffness which provides the flattest possible non-tensioned
screen surface with universal applications. This material
provides wide viewing uniform diffusion while giving precise
definition, color reproduction and black & white contrast. The
screen surface has a black-backing to eliminate light
penetration, is mildew resistant and washable with mild soap
and water.
* Manufacturer tip: This is an enhanced matte white product for higher end DLP/LCD projectors suitable for
commercial and residential presentations.

PRODUCT WHITE PAPER
http://www.eliteproav.com
3
Elite Screens Inc. |Elite Screens Europe GmbH |Elite Screens France SAS |Elite Screens India
Elite Screens China Ltd. | Elite Screens Taiwan Corp. |Elite Screens Japan | Elite Screens Australia
Features& Benefits
•Multi-layer weave with textured surface
•Fiberglass backing with black backing
•Gain: 1.1
•View Angle: 180° (90° ± LR)
•Not compatible with Ultra/Short-throw Projectors
•Mildew Resistant
•Active 3D, 4K Ultra HD, and HDR ready
•Surface can be cleaned with mild soap and water
•Flame Retardant: Complies with NFPA 701 Standards
•GREENGUARD® and GREENGUARD® Gold Certified | UL 2818
Specifications
Thickness
0.36 mm (0.014")
Weight 350 g/m²
Maximum Height 3.2 M (10 ft)
On-axis Gain 1.0
Half-Gain Angle Does not reach half gain
3.2 Gain and Viewing Angle

PRODUCT WHITE PAPER
http://www.eliteproav.com
4
Elite Screens Inc. |Elite Screens Europe GmbH |Elite Screens France SAS |Elite Screens India
Elite Screens China Ltd. | Elite Screens Taiwan Corp. |Elite Screens Japan | Elite Screens Australia
Section 4: Execution .
4.1 Product Description
The Kestrel Stage Series is a portable electric floor rising front projection screen that is ideal for event
applications used in Churches, hotels, schools, or other like venues. It includes two travel cases (one for the
screen and one split-two-sided storage cart). Complete the set up by attaching the complimentary drape kit
to give your presentation the finishing touch.
4.2 Product Parts and Hardware
1. Kestrel Stage Motorized screen
w/ travel case (main) X 1
2. Storage Cart X 1
3. Remote Control Wall Box X 1
4. Double sided bolt X 4
5. Butterfly Nut X 4
6. Ring-bolt X 1
7. Curtain fabric X 1
4.3 Product Assembly and Operation
1. Unlatch: Lift the butterfly locks and rotate them 90 degrees. Then, split the case open by pulling both sides
apart.
Note: Distance the two parts of the storage-box (item 2) to the corresponding length of the Kestrel’s case. Then
proceed to step 2.

PRODUCT WHITE PAPER
http://www.eliteproav.com
5
Elite Screens Inc. |Elite Screens Europe GmbH |Elite Screens France SAS |Elite Screens India
Elite Screens China Ltd. | Elite Screens Taiwan Corp. |Elite Screens Japan | Elite Screens Australia
2. Insert the shorter side of the double sided bolts (Item 4) into the bottom of the motorized screen’s carry
case as shown in the figure below. There should be two bolts (item 4) inserted into each bottom side of the
travel case of the motorized screen’s main case. Be careful to not over-tighten the bolt to avoid damaging
the threading in the screen’s carry case.
Safety precaution: We recommend that two people lift and mount the screen onto the cart.
3. Carefully place the main screen’s carry case on top ( facing the front) of the two separate carts by inserting
the longer side of the bolts in to the top front holes of the storage carts (item 2) as shown below.
4. Using the provided butterfly nuts, tighten the bolts to secure the screen’s carry case to the carts as shown in
the figures below. Be careful to not over-tighten the butterfly nuts to avoid damage to the threading in the
screen’s carry case.

PRODUCT WHITE PAPER
http://www.eliteproav.com
6
Elite Screens Inc. |Elite Screens Europe GmbH |Elite Screens France SAS |Elite Screens India
Elite Screens China Ltd. | Elite Screens Taiwan Corp. |Elite Screens Japan | Elite Screens Australia
5. Insert the ring bolt into the indicated hole on the back of the main travel case to help avoid damage to the
cover hinges.
6. Connect the power cable and control box (item3)
Connect together

PRODUCT WHITE PAPER
http://www.eliteproav.com
7
Elite Screens Inc. |Elite Screens Europe GmbH |Elite Screens France SAS |Elite Screens India
Elite Screens China Ltd. | Elite Screens Taiwan Corp. |Elite Screens Japan | Elite Screens Australia
7. Lock / unlock the wheel:
Push latch down to lock
8. Affix the top edge (Velcro) of the curtain to the inner edges (front, left and right side edges) of the storage
case.
Note: The curtain will stick to the Velcro inside of the case.
4.4 Accessories
A. IR Remote
B. RF Remote
C. 3-way Wall Switch
D. 5-12 volt trigger cable
E. IR extended “eye” receiver
F. AAA batteries
G. Bubble leveler
4.5 Screen Control System
Electric Current information: The screen operates on AC110V @ 60 Hz
1. Plug the screen’s power cord into a power outlet.
2. Once the screen has power, you’ll be able to control it using any of the 4 methods described below.
The shaded area in this figure
indicates the location of the
Velcro inside of the box.

PRODUCT WHITE PAPER
http://www.eliteproav.com
8
Elite Screens Inc. |Elite Screens Europe GmbH |Elite Screens France SAS |Elite Screens India
Elite Screens China Ltd. | Elite Screens Taiwan Corp. |Elite Screens Japan | Elite Screens Australia
4 Ways to Control your Kestrel Stage Series
1. IR remote control (Item A) and IR “Eye” Receiver (Item E): The IR remote control (fig.1) requires line-of-sight
to the IR sensor. The IR “eye” receiver must be connected to the Remote Control Wall box in order for the IR
remote control to function. The IR “Eye” Receiver plugs directly into the screen’s RJ-45 input (fig.2).
2. RF Remote Control (Item B): The radio waves eliminate the need for a direct line of sight with a range of 100
feet.
3. 3-Way Wall Switch (Item C, Fig 3): The 3-way wall switch manually controls the screens up/stop/down
button by connecting directly into the screen’s RJ-45 port.
4. 5-12 volt trigger (Item D, Fig 4): The built-in 5-12V trigger input allows your screen to synchronize its drop &
rise with the projector’s power cycle. The screen deploys when the projector powers up and will retract
when the projector powers down. The 5-12 volt RJ45 cable connects to your projector’s trigger output via a
separate cable that may or may not be provided by the manufacturer of the projector. The trigger feature
will not work without an output cable from the projector, but it can be tested by connecting the Red (+) and
Green (-) cable to a 9-volt battery.
UP
STOP
DOWN
Fig.1
IR/RF remote
Fig.2
Control box
3 Way Wall Switch (does not have IR sensor)
Fig.3
Fig.4

PRODUCT WHITE PAPER
http://www.eliteproav.com
9
Elite Screens Inc. |Elite Screens Europe GmbH |Elite Screens France SAS |Elite Screens India
Elite Screens China Ltd. | Elite Screens Taiwan Corp. |Elite Screens Japan | Elite Screens Australia
Section 5: Product Specifications .
5.1 Dimensions
Model
Number
Diag.
Size
Aspect
Ratio (A) (A1) (A2) (A3) (A4) (B) (B1) (B2) (B3) (B4) (B5)
Unit: Inches
FE110V-TC
110"
4:3
94.7
87.2
91.1
92.5
2.0
91.3
65.3
86.9
2.4
19.3
122.9
FE131V-TC
131"
4:3
113.6
104.6
108.5
110.5
2.0
90.5
78.5
85.5
2.4
4.7
122.1
FE100H-TC
100"
16:9
94.9
87.1
91.1
92.0
2.0
86.6
49.0
80.3
2.4
28.9
118.2
FE120H-TC 120" 16:9 113.5 104.6 108.5 111.2 2.0 86.6 58.8 80.7 2.4 19.5 118.1
FE150H-TC
150"
16:9
139.8
130.7
134.7
137.2
2.0
101.0
73.5
95.1
2.4
19.2
132.5
FE125X-TC
125"
16:10
115.0
106.0
109.9
111.2
2.0
92.7
66.0
87.8
2.4
19.4
124.3
FE154X-TC
154"
16:10
139.8
130.6
134.5
137.2
2.0
103.1
81.6
98.8
2.4
14.8
135.5
Unit: mm
FE110V-TC
110"
4:3
3352
3087
3225
3275
70
3232
2312
3076
84
683
4351
FE131V-TC
131"
4:3
4021
3703
3841
3912
70
3204
2779
3027
84
166
4322
FE100H-TC
100"
16:9
3359
3083
3225
3257
70
3066
1735
2843
84
1023
4184
FE120H-TC
120"
16:9
4018
3703
3841
3936
70
3066
2082
2857
84
690
4181
FE150H-TC 150" 16:9 4948 4628 4768 4857 70 3575 2603 3366 84 679 4691
FE125X-TC
125"
16:10
4071
3752
3890
3936
70
3282
2336
3108
84
687
4400
FE154X-TC 154" 16:10 4948 4623 4762 4857 70 3651 2889 3498 84 525 4797
5.2 Drawings

PRODUCT WHITE PAPER
http://www.eliteproav.com
10
Elite Screens Inc. |Elite Screens Europe GmbH |Elite Screens France SAS |Elite Screens India
Elite Screens China Ltd. | Elite Screens Taiwan Corp. |Elite Screens Japan | Elite Screens Australia
5.3 Pictures
Kestrel Stage Series Angled Front View

PRODUCT WHITE PAPER
http://www.eliteproav.com
11
Elite Screens Inc. |Elite Screens Europe GmbH |Elite Screens France SAS |Elite Screens India
Elite Screens China Ltd. | Elite Screens Taiwan Corp. |Elite Screens Japan | Elite Screens Australia
Kestrel Stage Series with Opened ATA Stage Cases
Kestrel Stage Series with Closed ATA Stage Cases

PRODUCT WHITE PAPER
http://www.eliteproav.com
12
Elite Screens Inc. |Elite Screens Europe GmbH |Elite Screens France SAS |Elite Screens India
Elite Screens China Ltd. | Elite Screens Taiwan Corp. |Elite Screens Japan | Elite Screens Australia
Remote Kit
Toggle Switch Detail

PRODUCT WHITE PAPER
http://www.eliteproav.com
13
Elite Screens Inc. |Elite Screens Europe GmbH |Elite Screens France SAS |Elite Screens India
Elite Screens China Ltd. | Elite Screens Taiwan Corp. |Elite Screens Japan | Elite Screens Australia
Life Style
Section 6: Company Description .
6.1 About EliteProAV™
EliteProAV™ is a the manufacturer of projector screens for the commercial AV sales channel. It is a division of
Elite Screens Inc., an ISO9001:2015 certified manufacturer that is presently the leading international brand of CE
Retail projector screens with offices located worldwide.
EliteProAV™ provides an array of dedicated commercial grade projector screens for professional integrators.
This includes certified products that are also compatible with building codes as well as programs, warranties
and trained professionals to assist installers every step of the way. Product is available through a series of
regional warehouses located in Southern California, Texas, Georgia, and Maryland. EliteProAV™ is located at
12282 Knott St. Garden Grove, CA 92841. For more information, please call 877-511-1211 or visit
http://www.eliteproav.com.
###
