Tektronix RSA306B User manual

RSA306B
Real-Time Spectrum Analyzer
Declassification and Security
ZZZ
Instructions
xx
www.tek.com
*P077124200*
077-1242-00

Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries
or suppliers, and are protected by national copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication
supersedes that in all previously published material. Specifications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
Contacting Tektronix
Tektronix, Inc.
14150 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
In North America, call 1-800-833-9200.
Worldwide, visit www.tek.com to find contacts in your area.

Table of Contents
Preface.............................................................................................................. iii
Memory devices .................................................................................................... 1
Clear or sanitize a non-functional instrument .......... ...... ............................................ ...... . 2
RSA306B Declassification and Security Instructions i

Table of Contents
ii RSA306B Declassification and Security Instructions

Preface
This document helps customers with data security concerns to sanitize or remove
memory devices from the Tektronix RSA306B Real-Time Spectrum Analyzer.
This product has data storage (memory) devices and data output devices (USB
ports). These instructions tell how to clear or sanitize the memory devices and
disable the data output devices. The instructions also tell how to declassify an
instrument that is not functioning.
Reference The procedures in this document are written to meet the requirements specified in:
NISPOM, DoD 5220.22–M, Chapter 8
ISFO Process Manual for Certification & Accreditation of Classified Systems
under NISPOM
Required documents No external documents are required to perform the procedures in this document.
Terms that may be used in
this document
The following terms may be used in this document:
Clear. This removes data on media/memory before reusing it in a secured
area. All reusable memory is cleared to deny access to previously stored
information by standard means of access.
Erase. This is equivalent to clear.
Instrument Declassification. A term that refers to procedures that must be
undertaken before an instrument can be removed from a secure environment.
Declassification procedures include memory sanitization and memory
removal, and sometimes both.
Media storage/data export device. Any of several devices that can be used
to store or export data from the instrument, such as a USB port.
Nonvolatile memory. Data is retained when the instrument is powered off.
Power off. Some instruments have a “Standby” mode, in which power is
still supplied to the instrument. For the purpose of clearing data, putting the
instrument in Standby mode does not qualify as powering off. For these
products, you will need to either pressarear-panelOFFswitchorremovethe
power source from the instrument.
Remove. This is a physical means to clear the data by removing the memory
device from the instrument. Instructions are available in the product Service
Manual.
Sanitize. This eradicates the data from media/memory so that the data cannot
be recovered by other means or technology. This is typically used when the
RSA306B Declassification and Security Instructions iii

Preface
device will be moved (temporarily or permanently) from a secured area to a
non-secured area.
Scrub. This is equivalent to sanitize.
User Accessible. User is able to directly retrieve the memory device contents.
User-modifiable. The user can write to the memory device during normal
instrument operation, using the instrument interface or remote control.
User-modifiable. The user can write to the memory device during normal
instrument operation, using the instrument interface or remote control.
Volatile memory. Data is lost when the instrument is powered off.
Device terms User data. Describes the type of information stored in the device. Refers to
waveforms or other measurement data representing signals connected to the
instrument by users.
User settings. Describes the type of information stored in the device. Refers
to instrument settings that can be changed by the user.
Both. Describes the type of information stored in the device. It means that
both user data and user settings are stored in the device.
None. Describes the type of information stored in the device. It means that
neither user data nor user settings are stored in the device.
Directly. Describes how data is modified. It means that the user can modify
the data.
Indirectly. Describes how data is modified. It means that the instrument
system resources modify the data and that the user cannot modify the data.
iv RSA306B Declassification and Security Instructions

Memory devices
Volatile memory devices
Type and
min. size Function
Type
of user
info
stored
Backed
up by
battery
Method
of
modification
Data
Input
method Location
User
accessible To clear To sanitize
CYUSB3014 USB3
interface
Spectrum
data in
FIFOs
No Run the
instrument
Firmware
operations
USB No Disconnect
power for
at least 5
seconds.
Disconnect
power for
at least 5
seconds.
Non-volatile memory
devices
Type and
min. size Function
Type
of user
info
stored
Method of
modification
Data
Input
method Location
User
accessibleTo clear To sanitize
4MBFlash Holds USB
and FPGA
images,
calibration
constants,
and board
ID
None USB 3.0 Firmware
operations
U50 No Not applicable.
Does not contain
user data
or settings.
Clearing
would disable
instrument
functionality.
Not applicable.
Does not
contain user
data or settings.
Clearing
would disable
instrument
functionality.
Data export devices There are no media or export devices that require declassification or security
procedures with this product.
RSA306B Declassification and Security Instructions 1

Clear or sanitize a non-functional instrument
Clearorsanit
ize a non-functional instrument
If your instrument is not functioning, return the instrument to Tektronix for repair.
No user data is stored on the instrument when the power is removed. Clearing or
sanitizing the instrument is not applicable.
Charges Replacement of any missing hardware will be charged according to the rate at
the time of replacement.
2 RSA306B Declassification and Security Instructions
