Tektronix TLA7012 User manual

Instructions
020-2664-00
TLA7012 Portable Logic Analyzer
Rackmount Kit
071-1750-00
*P071175000*
071175000
Warning
The servicing instructions are for use by qualified
personnel only. To avoid personal injury, do not
perform any servicing unless you are qualified to
do so. Refer to all safety summaries prior to
performing service.
www.tektronix.com

Copyright ©Tektronix, Inc. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries or
suppliers, and are protected by national copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supercedes
that in all previously published material. Specifications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
Contacting Tektronix
Tektronix, Inc.
14200 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
HIn North America, call 1-800-833-9200.
HWorldwide, visit www.tektronix.com to find contacts in your area.

TLA7012 Portable Logic Analyzer Rackmount Kit Instructions 1
Service Safety Summary
Only qualified personnel should perform service procedures. Read this Service
Safety Summary and the General Safety Summary in the product service manual
or the instruction manual.
Do Not Service Alone. Do not perform internal service or adjustments of this
product unless another person capable of rendering first aid and resuscitation is
present.
To prevent the instrument and rack from falling onto the operator, two or more
installers should install the instrument into the rack cabinet. After completing the
installation procedure, the installers should verify that the instrument and rack
cabinet will not tip forward while the instrument is in the extended position.
Disconnect Power. To avoid electric shock, switch off the instrument power, then
disconnect the power cord from the mains power.
Use Care When Servicing With Power On. Dangerous voltages or currents may
exist in this product. Disconnect power and disconnect test leads before
removing protective panels, soldering, or replacing components.
To avoid electric shock, do not touch exposed connections.

Service Safety Summary
2TLA7012 Portable Logic Analyzer Rackmount Kit Instructions

TLA7012 Portable Logic Analyzer Rackmount Kit Instructions 3
Kit Description
This introduction describes the installation of the rackmount kit to your standard
portable instrument.
CAUTION. This kit requires you to remove the right-side panel of the instrument
rack you intend to use. You must have access to the right side of your instrument
to connect the logic analyzer probes when the instrument is installed in the rack.
The rackmount kit is a collection of parts that, once installed, configure the
instrument for mounting into a standard 19-inch equipment rack.
Products
TLA7012 AllSerialNumbers

Kit Description
4TLA7012 Portable Logic Analyzer Rackmount Kit Instructions
Figure 1: Completed rackmount installation

Kit Description
TLA7012 Portable Logic Analyzer Rackmount Kit Instructions 5
Kit Parts List
Figure 2
on page 6 Quantity Part number Description
-- -- -- -- -- -- -- -- -- 1ea 020-2664-XX RACKMOUNT KIT TLA7012 CONSISTING OF
THE FOLLOWING:
-- -- -- -- -- -- -- -- -- 1 e a 071-1750-00 TECH MANUAL: INSTRUCTIONS, TLA7012
11ea436-0426-00 CHASSIS ASSY, TLA7012 RACKMOUNT,
INCLUDES 6-32 AND 10-32 SCREWS
21ea407-5122-00 BRACKET, LOCKING
32ea386-7459-00 PANEL, COSMETIC
41ea351-1119-00 GUIDE, SLIDE (RACKMOUNT, L AND R)
52ea407-5125-00 BRACKET, RACKMOUNT GUIDE, SET OF 4
W/HARDWARE
61ea407-5131-00 BRACKET, PORT RACKMNT ADAPTER (R)
71ea407-5124-00 BRACKET, PORT RACKMNT ADAPTER (L)
82ea 367-0530-00 HANDLE: BOW
NS - Not Saleable

Kit Description
6TLA7012 Portable Logic Analyzer Rackmount Kit Instructions
1
23
4
5
6
7
8
Figure 2: Rackmount kit parts

Kit Description
TLA7012 Portable Logic Analyzer Rackmount Kit Instructions 7
When the instrument is installed according to the instructions in this document,
the rackmounted instrument meets all warranted requirements listed in the
instrument specification except for those listed in Environmental Requirements
on page 8. Instruments mounted using methods other than those described in
these instructions may not meet their warranted requirements.
See Specifications in the user or service manual that applies to your instrument
model for tables of the warranted characteristics.
Cooling air enters from the bottom-front and right sides as shown in Figure 3.
You must provide adequate cool air to meet the ambient temperature require-
ments listed in Table 1.
Hot air out (rear)
Measure
input air
temperature
Figure 3: Instrument cooling
Warranted Characteristics

Kit Description
8TLA7012 Portable Logic Analyzer Rackmount Kit Instructions
The following environmental characteristics supercede those listed in the user or
service manual for your instrument.
Table 1: Warranted characteristics
Characteristic Description
Temperature, Inside Rack Cabinet
Operating +10 _Cto+45_C(+50_Fto+113_F)
Non-operating -- 2 2 _Cto+60_C(--7.6_F to +140 _F)
Clearance Requirements
The rack in which the rack adapted instrument is mounted must provide the
following clearance requirements:
HA minimum of 14.0 inches (355.6 mm) of vertical space.
HA minimum width of 17.717 inches (450 mm) between the left- and
right-front rails in the rack.
HA minimum depth of 20 inches (508 mm).
CAUTION. Adhering to these clearance requirements provides the rack-mounted
instrument with sufficient clearance for air circulation and accommodation of
the power cord and mounting hardware. Failure to provide these clearances can
result in overheating and can cause instrument faults or failure.
Environmental
Requirements

Kit Description
TLA7012 Portable Logic Analyzer Rackmount Kit Instructions 9
541. mm
(21.300 in)
412.02 mm
(16.230 in)
480.00 mm
(18.897 in)
352.1 mm
(13.862 in)
352.1 mm
(13.862 in)
Figure 4: Instrument with rack adapter installed

Kit Description
10 TLA7012 Portable Logic Analyzer Rackmount Kit Instructions

TLA7012 Portable Logic Analyzer Rackmount Kit Instructions 11
Installation Instructions
This section contains all procedures needed to rackmount the TLA7012
instrument.
CAUTION. This kit requires you to remove the right-side panel of the instrument
rack you intend to use. You must have access to the right side of your instrument
to connect the logic analyzer probes when the instrument is installed in the rack .
Minimum Tool and Equipment List
The following tools are required to attach the rack-adapter kit hardware, install
cabling hardware, and mount the rack-adapted instrument into a standard
equipment cabinet. All tools are standard tools that are readily available.
Table 2: Tools required for rackmount installation
Item
no. Name Description
1Screwdriver handle
(magnetic)
Accepts 1/4-inch hexagonal head driver tips
2No. 2 Phillips or
Pozidriv tip
Phillips or Pozidriv-driver tip for number 2 size screw heads
3T-15 Torx tip Torx-driver tip for T-15 size screw heads
411/32-inch wrench Wrench or nut driver can be used to install slides
5Torque driver Accepts 1/4-inch hexagonal head driver tips
These instructions are for personnel who are familiar with servicing the product.
If you need further details for disassembling or reassembling the product, refer to
the appropriate product manual. Contact your nearest Tektronix Service Center
or Tektronix Factory Service for installation assistance.

Installation Instructions
12 TLA7012 Portable Logic Analyzer Rackmount Kit Instructions
WARNING. To prevent the rackmounted instrument from tipping forward onto the
operator, install the instrument so that the operator will be able to access all of
its rear-panel connectors without pushing down on the instrument.
Verify that the rack does not become unstable with the instrument fully extended.
Do not leave the instrument extended when finished accessing the rear panel.
Assemble Shelf
Begin the installation procedure by attaching the brackets to the track assembly:
1. Remove the mounting screw that is attached to each track. (See Figure 5).
2. Mount one bracket to the front of each track assembly using two 8-32
flathead screws for each bracket. You must slide the rail within the track
assembly to gain access to the mounting screws and holes. See the latch
detail in Figure 6 on page 13).
Flat head screw
Mounting screw
Bracket
Figure 5: Preparing the track assembly

Installation Instructions
TLA7012 Portable Logic Analyzer Rackmount Kit Instructions 13
3. Next, use two 8-32 locking-nut washer assemblies to secure the track onto
the shelf assembly, applying 28 inch-lbs of torque. (You must move the rail
within the track to gain access to the rearward mounting hole).
Refer to Figure 6 to help you attach the tracks to the shelf.
Push in latch
to slide the rail
Slide the rail and add
the second screw
Use this hole for the
second screw
Figure 6: Rackmount shelf preassembly

Installation Instructions
14 TLA7012 Portable Logic Analyzer Rackmount Kit Instructions
Instrument Rack Preparation
This section describes mounting the rackmount parts to the instrument rack.
1. Remove the right-side panel of the instrument rack.
2. Select two 0.5 inch-spaced holes that have at least 14 inches of clearance
above, on all four rails of the rack. See Figure 7.
12.7 mm (0.50 in)(for
correct position of
securing holes)
355.60 mm
(14.00 in)
21.081 mm
(.830 in)
Figure 7: Vertical clearances for rack installation (left-front rail shown)

Installation Instructions
TLA7012 Portable Logic Analyzer Rackmount Kit Instructions 15
3. Select the mounting method according to rack type:
HTo mount the brackets with their rear flanges outside of the rear rails,
use the mounting method A shown in Figure 8 when doing
substep 4. Add a bar nut to the installation only if the rails have
untapped holes.
HTo mount with the rear flanges inside of rails, use the mounting
method B outlined in Figure 8. This mounting method assumes
untapped holes.
Mounting Method A Mounting Method B
Left-rear rail
Use two flat-head screws if the cabinet rails have
countersunk mounting holes; otherwise use two
pan-head screws
Use a bar nut if front rails
are not tapped
10-32 Flat-head
screws (4)
10-32 Pan-head
screws (4)
10-32 Pan-head
screws (4)
Left-rear rail
#10 M6 M5
English Metric
#12
Bracket
Rear flange
Bracket
Rear flange
Figure 8: Installation of slide-out track assemblies in rack (top view)

Installation Instructions
16 TLA7012 Portable Logic Analyzer Rackmount Kit Instructions
4. Using the method and hardware determined from step 3, secure the brackets
to the rear rails. The screws should be fully, but lightly, seated so mounting
can be adjusted later.
Rear bracket
Bar nut
Rear flange (mounts to
rear rail of rack)
Rear rail
Figure 9: Attaching the rear brackets to the instrument rails
5. Mount the cosmetic trim on the front, using two 10-32 screws each. See
item 2 in Figure 10. (This helps to guide you where to locate the shelf during
shelf installation).
Equipment Required: One screwdriver handle (Item 1), one number two Pozidriv
tip (Item 2), and one torque driver (Item 5).
NOTE. The rack hardware kit contains hardware for mounting the instrument in
several configurations. Not all of the hardware in the kit will be needed.
A standard equipment rack has rails with universal hole spacing. If you use a
rack with other than universal hole spacing, you may have to drill additional
mounting holes in the rack.
Procedure:
1. Grab the shelf/track assembly and slide the tracks into the brackets on the
rear rails of the instrument rack.
2. Align the front of the shelf to the bottom of the cosmetic trim on the front of
the instrument rack.
Install the Shelf/Track
Assembly into the Rack

Installation Instructions
TLA7012 Portable Logic Analyzer Rackmount Kit Instructions 17
1
3
4
2
Figure 10: Installing the shelf/track assembly
3. Install two 10-32, P2 screws through the front brackets to the rack on each
side of the shelf front.
4. Install two 8-32 screws through the shelf tracks to the rear brackets. Attach
the screws with the 8-32 lock nuts included in the kit.
5. Tighten all of the screws and check that the shelf slides in and out easily.
Loosen and adjust, if necessary.
This completes the installation of the shelf/track assembly into the rack. Next,
perform the Attach Brackets to the Instrument procedure.

Installation Instructions
18 TLA7012 Portable Logic Analyzer Rackmount Kit Instructions
Equipment Required: Screwdriver handle with T-15 tip (Items 1 and 3).
1. Set the instrument on its back feet to expose the instrument bottom.
2. Remove the four T-15 Torx screws near the bottom feet. See Figure 11.
Right--side
brackets
Left--side
brackets
Flip the
feet down
Figure 11: Location of screws for bracket mounting
3. Attach the right and left-side brackets to the bottom of the instrument using
the screws that you removed in the previous step.
4. Fold the front feet down flat against the bottom of the instrument.
This completes the installation of the rack-adapter hardware to the instrument.
Next, do the following procedure: Mount the Instrument to the Shelf.
Attach Brackets to the
Instrument
