Tektronix TekConnect Probe Interface Module 80A03 User manual

Instruction Manual
80A03
TekConnect Probe Interface Module
071-1298-03
Revision A
This document applies to firmware version 2.3
and above.
Warning
The servicing instructions are for use by qualified
personnel only. To avoid personal injury, do not
perform any servicing unless you are qualified to
do so. Refer to all safety summaries prior to
performing service.
www.tektronix.com

Copyright ©Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries or
suppliers, and are protected by national copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supercedes
that in all previously published material. Specifications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
Contacting Tektronix
Tektronix, Inc.
14200 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
HIn North America, call 1-800-833-9200.
HWorldwide, visit www.tektronix.com to find contacts in your area.

Warranty 2
Tektronix warrants that this product will be free from defects in materials and workmanship for a period of one (1)
year from the date of shipment. If any such product proves defective during this warranty period, Tektronix, at its
option, either will repair the defective product without charge for parts and labor, or will provide a replacement in
exchange for the defective product. Parts, modules and replacement products used by Tektronix for warranty work
may be new or reconditioned to like new performance. All replaced parts, modules and products become the
property of Tektronix.
In order to obtain service under this warranty, Customer must notify Tektronix of the defect before the expiration
of the warranty period and make suitable arrangements for the performance of service. Customer shall be
responsible for packaging and shipping the defective product to the service center designated by Tektronix, with
shipping charges prepaid. Tektronix shall pay for the return of the product to Customer if the shipment is to a
location within the country in which the Tektronix service center is located. Customer shall be responsible for
paying all shipping charges, duties, taxes, and any other charges for products returned to any other locations.
This warranty shall not apply to any defect, failure or damage caused by improper use or improper or inadequate
maintenance and care. Tektronix shall not be obligated to furnish service under this warranty a) to repair damage
resulting from attempts by personnel other than Tektronix representatives to install, repair or service the product;
b) to repair damage resulting from improper use or connection to incompatible equipment; c) to repair any
damage or malfunction caused by the use of non-Tektronix supplies; or d) to service a product that has been
modified or integrated with other products when the effect of such modification or integration increases the time
or difficulty of servicing the product.
THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THE PRODUCT IN LIEU OF ANY
OTHER WARRANTIES, EXPRESS OR IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
TEKTRONIX’ RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE SOLE AND
EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR BREACH OF THIS WARRANTY.
TEKTRONIX AND ITS VENDORS WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL,
OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER TEKTRONIX OR THE VENDOR HAS
ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.

80A03 TekConnect Probe Interface Module Instruction Manual i
Table of Contents
General Safety Summary iii...................................
Service Safety Summary v....................................
Environmental Considerations vii...............................
Getting Started 1............................................
The TekConnect Interface 2.........................................
Standard Accessories 3.............................................
Optional Accessories 3.............................................
Installing the TekConnect Probe Interface Module 4......................
Performing a Functional Check 9.....................................
Calibrating the TekConnect Probe Interface Module 12....................
Operating Basics 13..........................................
Understanding the Controls 13........................................
Triggering the Mainframe 14.........................................
Sampling Module Incompatibility 19...................................
Reference 21.................................................
Avoiding Damage from Overvoltage 21.................................
Avoiding Damage from Electrostatic Discharge 21........................
Specifications 23.............................................
Maintenance 27..............................................
Inspecting and Cleaning 27...........................................
Troubleshooting 27.................................................
Replacing Parts 28..................................................
Repackaging for Shipment 28.........................................
Replaceable Parts 29.........................................
Parts Ordering Information 29.........................................
Using the Replaceable Parts List 30....................................

Table of Contents
ii 80A03 TekConnect Probe Interface Module Instruction Manual
List of Figures
Figure 1: The 80A03 TekConnect Probe Interface Module 1........
Figure 2: TekConnect Probe Interface Module inputs
and outputs 4...........................................
Figure 3: Extender cable connection to the mainframe 5...........
Figure 4: Installing the sampling module into the
TekConnect Probe Interface Module 6.......................
Figure 5: Connecting the sampling module 7....................
Figure 6: Installing TekConnect probes 8.......................
Figure 7: Equipment setup for functional check 10................
Figure 8: Removing the semi-rigid cable 15.......................
Figure 9: Setup for triggering the mainframe using
the 80A03 TekConnect Probe Interface Module 16.............
Figure 10: Trigger offset indicator 17............................
Figure 11: Setup for triggering the mainframe and viewing
signals using the 80A03 TekConnect Probe
Interface Module 18.......................................
Figure 12: Insertion loss 25....................................
Figure 13: Return loss 25......................................
Figure 14: 80A03 replaceable parts 31...........................
List of Tables
Table 1: 80A03 features and standard accessories 3..............
Table 2: Recommended equipment for performing a
functional check 9.......................................
Table 3: Recommended equipment for triggering setups 14.........
Table 4: Electrical Characteristics 23...........................
Table 5: Environmental characteristics 23.......................
Table 6: Physical characteristics 24.............................

80A03 TekConnect Probe Interface Module Instruction Manual iii
General Safety Summary
Review the following safety precautions to avoid injury and prevent damage to
this product or any products connected to it.
To avoid potential hazards, use this product only as specified.
Only qualified personnel should perform service procedures.
While using this product, you may need to access other parts of the system. Read
the General Safety Summary in other system manuals for warnings and cautions
related to operating the system.
Connect and Disconnect Properly. Do not connect or disconnect probes or test
leads while they are connected to a voltage source.
Connect the probe output to the measurement instrument before connecting the
probe to the circuit under test. Disconnect the probe input and the probe ground
from the circuit under test before disconnecting the probe from the measurement
instrument.
Ground the Product. This product is indirectly grounded through the grounding
conductor of the mainframe power cord. To avoid electric shock, the grounding
conductor must be connected to earth ground. Before making connections to the
input or output terminals of the product, ensure that the product is properly
grounded.
Observe All Terminal Ratings. To avoid fire or shock hazard, observe all ratings
and markings on the product. Consult the product manual for further ratings
information before making connections to the product.
The common terminal is at ground potential. Do not connect the common
terminal to elevated voltages.
Connect the ground lead of the probe to earth ground only.
Do Not Operate Without Covers. Do not operate this product with covers or panels
removed.
Avoid Exposed Circuitry. Do not touch exposed connections and components
when power is present.
Do Not Operate With Suspected Failures. If you suspect there is damage to this
product, have it inspected by qualified service personnel.
Do Not Operate in Wet/Damp Conditions.
Do Not Operate in an Explosive Atmosphere.
Keep Product Surfaces Clean and Dry.
ToAvoidFireor
Personal Injury

General Safety Summary
iv 80A03 TekConnect Probe Interface Module Instruction Manual
Terms in this Manual. These terms may appear in this manual:
WARNING. Warning statements identify conditions or practices that could result
in injury or loss of life.
CAUTION. Caution statements identify conditions or practices that could result in
damage to this product or other property.
Terms on the Product. These terms may appear on the product:
DANGER indicates an injury hazard immediately accessible as you read the
marking.
WARNING indicates an injury hazard not immediately accessible as you read the
marking.
CAUTION indicates a hazard to property including the product.
Symbols on the Product. The following symbols may appear on the product:
CAUTION
Refer to Manual
Symbols and Terms

80A03 TekConnect Probe Interface Module Instruction Manual v
Service Safety Summary
Only qualified personnel should perform service procedures. Read this Service
Safety Summary and the General Safety Summary before performing any service
procedures.
Do Not Service Alone. Do not perform internal service or adjustments of this
product unless another person capable of rendering first aid and resuscitation is
present.
Disconnect Power. To avoid electric shock, switch off the instrument power, then
disconnect the power cord from the mains power.
Use Care When Servicing With Power On. Dangerous voltages or currents may
exist in this product. Disconnect power, remove battery (if applicable), and
disconnect test leads before removing protective panels, soldering, or replacing
components.
To avoid electric shock, do not touch exposed connections.

Service Safety Summary
vi 80A03 TekConnect Probe Interface Module Instruction Manual

80A03 TekConnect Probe Interface Module Instruction Manual vii
Environmental Considerations
This section provides information about the environmental impact of the
product.
Observe the following guidelines when recycling an instrument or component:
Equipment Recycling. Production of this equipment required the extraction and
use of natural resources. The equipment may contain substances that could be
harmful to the environment or human health if improperly handled at the
product’s end of life. In order to avoid release of such substances into the
environment and to reduce the use of natural resources, we encourage you to
recycle this product in an appropriate system that will ensure that most of the
materials are reused or recycled appropriately.
This symbol indicates that this product complies with the
European Union’s requirements according to Directive
2002/96/EC on waste electrical and electronic equipment
(WEEE). For information about recycling options, check
the Support/Service section of the Tektronix Web site
(www.tektronix.com).
This product has been classified as Monitoring and Control equipment, and is
outside the scope of the 2002/95/EC RoHS Directive.
Product End-of-Life
Handling
Restriction of Hazardous
Substances

Environmental Considerations
viii 80A03 TekConnect Probe Interface Module Instruction Manual

80A03 TekConnect Probe Interface Module Instruction Manual 1
Getting Started
The 80A03 TekConnect Probe Interface Module is an adapter that allows you to
use TekConnect probes with 80E0X sampling modules and the following main
instruments (mainframes):
HDSA8200 Digital Serial Analyzer
HCSA8000, CSA8000B, and CSA8200 Communications Signal Analyzers
HTDS8000, TDS8000B, and TDS8200 Digital Sampling Oscilloscopes
The interface is comprised of an enclosure that houses a compartment for one
80E0X electrical sampling module and two TekConnect probe inputs. The
interface connects to the mainframe through a permanently attached 1 meter
extender cable.
Figure 1: The 80A03 TekConnect Probe Interface Module
The 80A03 TekConnect Probe Interface Module also allows you the flexibility of
using the interface as a general-purpose sampling module extender cable by
simply disconnecting the short semi-rigid cables on the front panel of the
interface and using the sampling module inputs directly.

Getting Started
280A03 TekConnect Probe Interface Module Instruction Manual
The TekConnect Probe Interface Module supports probe interface conversion
between the previously listed mainframes and the following supported
TekConnect probes:
HP7225
HP7240
HP7260
HP7313
HP7313SMA
HP7330
HP7340A
HP7350
HP7350SMA
HP7360A
HP7380
HP7380A
HP7380SMA
HP7513
HP7516
The following electrical sampling modules are recommended for use with the
TekConnect Probe Interface Module.
Supported Tektronix
sampling modules
Description
80E011Single channel, 50 GHz
80E022Dual channel, 12.5 GHz
80E032Dual channel, 20 GHz
80E042Dual Channel, 20 GHz with TDR
80E061Single channel, 70 GHz
1Requires 2.4/1.85 mm to 2.92 mm SMA adapter (Tektronix part number 011- 0157- 00,
standard with these sampling modules). Also requires custom cable not available
from Tektronix: use a short high-quality SMA cable or fabricate your own semi-rigid
cable. Bandwidth using these modules is limited by the 80A03 adapter.
2Recommended for use with 80A03 TekConnect Probe Interface Module.

Getting Started
80A03 TekConnect Probe Interface Module Instruction Manual 3
The 80A03 disables the Probe Power interface on the front of the sampling
modules. Do not use the 80A03 with probes that connect directly to the Probe
Power, such as the P6209 and P6207.
There is also no support for TekProbe Level 2 legacy probes that utilize the
TCA-1MEG, TCA-BNC, and TCA75 adapters.
The TekConnect Interface
Power for the 80A03 TekConnect Probe Interface Module, sampling module, and
TekConnect probes is supplied through the cable that connects the TekConnect
Probe Interface Module to your mainframe. The same cable also provides a data
and communications path from the probe contact pins through the interface to
the mainframe. Power, signal, offset, and probe characteristic data transfers
through this interface.
When a probe is connected, the TekConnect Probe Interface Module reads
information from the probe, identifies the device, and turns on the appropriate
power supplies.
Standard Accessories
Table 1 lists the 80A03 TekConnect Probe Interface Module features and
standard accessories.
Table 1: 80A03 features and standard accessories
Accessory Description
Semi-Rigid Cables. Consists of two semi-rigid SMA-to-SMA cables for connecting the electrical
sampling module to the TekConnect Probe Interface Module, Tektronix part number
174-4857-XX.
Statement of
compliance
Statement of compliance. A certificate verifying the product was assembled and verified using
established procedures and work instructions. When applicable, test equipment is traceable to
known standards.
Included with product at initial shipment. This accessory cannot be ordered.
Instruction Manual. Provides instructions for operating and maintaining the 80A03 TekConnect
Probe Interface Module, Tektronix part number 071-1298-XX.

Getting Started
480A03 TekConnect Probe Interface Module Instruction Manual
Optional Accessories
No optional accessories are available for the 80A03 TekConnect Probe Interface
Module.
Installing the TekConnect Probe Interface Module
Figure 2 shows the TekConnect Probe Interface Module and locations of the
sampling module and probe inputs. The extender cable on the rear of the
interface connects to the mainframe front panel.
Sampling
module
TekConnect
probe input
Extender cable
Semi-rigid
cable
Figure 2: TekConnect Probe Interface Module inputs and outputs
Installing the TekConnect Probe Interface Module consists of the following
steps:
1. Connecting the Interface Module to the mainframe.
2. Installing the Sampling Module.
3. Installing the Semi-Rigid SMA Connector Cables.
4. Installing the TekConnect Probe.

Getting Started
80A03 TekConnect Probe Interface Module Instruction Manual 5
To install the TekConnect Probe Interface Module Extender Cable into the front
panel of your mainframe, perform the following tasks:
CAUTION. To prevent damage to the sampling module, never install or remove a
module when the mainframe is powered on or when either input connector is left
unprotected. Follow the precautions described in your sampling module and
mainframe documentation to avoid damage.
1. Turn off the mainframe using the front-panel On/Standby switch.
2. Install the TekConnect Probe Interface Module Extender Cable connector
into any of the small sampling module compartments on the front panel of
the mainframe. See Figure 3.
3. Push the module in slowly with firm pressure to seat it.
4. Tighten the hold-down screw to hold the connector in place. To remove the
connector later, loosen the hold-down screw and slide the ejector lever.
NOTE. Installing a large sampling module into a large compartment of the
mainframe may disable channels on a small module already installed. Refer to
the documentation for your mainframe about compartment interaction.
Mainframe
Hold-down
screw
Figure 3: Extender cable connection to the mainframe
NOTE. Do not use any additional extender cables to connect the 80A03
TekConnect Probe Interface Module to the mainframe.
Connecting the Interface
Module to the Main
Instrument

Getting Started
680A03 TekConnect Probe Interface Module Instruction Manual
To install the sampling module into the front panel of the TekConnect Probe
Interface Module, perform the following tasks:
CAUTION. Sampling modules are inherently vulnerable to static damage. Always
observe static-safe procedures and precautions as outlined in your sampling
module user manual.
1. Verify that the mainframe is powered off; if necessary, toggle the front-panel
On/Standby switch.
2. Insert the sampling module into the front-panel compartment of the
TekConnect Probe Interface Module as shown in Figure 4.
3. Push the module in slowly with firm pressure to seat it.
4. Once the module is seated, turn the hold-down screw to tighten the sampling
module in place. See Figure 4.
5. To release the module later, loosen the hold-down screw fully, and then slide
the ejector lever.
Ejector lever
Sampling module
Hold-down screw
Figure 4: Installing the sampling module into the TekConnect Probe Interface
Module
NOTE. To remove the sampling module, first loosen the hold-down screw; then
use the ejector lever on the interface module to eject the sampling module.
Installing the Sampling
Module

Getting Started
80A03 TekConnect Probe Interface Module Instruction Manual 7
To provide a signal path between the sampling module and the TekConnect
Probe Interface Module, perform the following tasks:
1. Connect your wrist strap to the antistatic connector on the front of the
mainframe.
2. Use the two semi-rigid SMA cables (included with this product) to connect
the TekConnect Probe Interface Module to the sampling module as shown in
Figure 5. You may need to bend the SMA cables slightly to obtain proper
alignment to mate the SMA connectors.
NOTE. Always use a calibrated torque wrench to install adapters, attenuators,
cables, or power sensors in any setup. Torque all connections to 8 ±0.3 inch
pounds. For information on proper installation and torquing techniques, refer to
your module user manual.
Figure 5: Connecting the sampling module
CAUTION. The semi-rigid SMA connector cables used on the 80A03 TekConnect
Probe Interface Module are not compatible with the input connections of
80E01and 80E06 sampling modules.
Do not attempt to force a connection between the semi-rigid connector cables on
the TekConnect Probe Interface Module and these sampling modules. Use the
proper adapter or damage to the module will occur. See page 2 for additional
information.
Installing the Semi-Rigid
SMA Connector Cables

Getting Started
880A03 TekConnect Probe Interface Module Instruction Manual
The TekConnect probe features a spring-loaded latch that provides audible and
tactile confirmation that a reliable connection has been made to the TekConnect
Probe Interface Module.
NOTE. It is not necessary to power off the mainframe when removing or
installing a TekConnect probe.
To connect a TekConnect probe to the TekConnect Probe Interface Module,
perform the following tasks:
1. Slide the probe into the TekConnect receptacle on the TekConnect Probe
Interface Module. The probe snaps into the TekConnect Probe Interface
Module when fully engaged. See Figure 6.
2. To release the probe from the TekConnect Probe Interface Module, grasp the
compensation box, press the latch button, and pull out on the probe.
Latch button
Figure 6: Installing TekConnect probes
NOTE. Use thumb screws to secure the probe on those models that have the
option.
Installing the TekConnect
Probe
