Teledyne Tekmar Torch User manual

Torch User Manual www.teledynetekmar.com
User Manual • Part # 15-0300-074

Torch User Manual www.teledynetekmar.com
Copyright © 2009 Teledyne Tekmar
All rights reserved. Reproduction, adaptation, or translation without permission is prohibited, except as allowed under
copyright laws. Printed in the U.S.A.
UPDATED INFORMATION
The information contained in this document is subject to change without notice.
TRADEMARKS
The companies indicated own the following trademarks:
Teledyne Tekmar.... Teledyne Tekmar Teon.......................E.I. Dupont deNemours
TekLink ..................... Teledyne Tekmar Pentium ..................Intel Corp.
PEEK ........................... Victory PLC Co. Upchurch ...............Upchurch Scientic
Windows XP............. Microsoft Inc. Swagelok................Swagelok Co.
Windows Vista ........Microsoft Inc. Microsoft ................Microsoft Inc.
DOCUMENT
Torch User Manual
Part Number: 15-0300-074 Rev C
December, 2009
Teledyne Tekmar
4763 Socialville Foster Road
Mason, OH 45040 U.S.A
www.teledynetekmar.com
Toll Free: 800-543-4461
Sales/Support: 800-874-2004
Main: 513-229-7000
Fax: [phone]

Torch User Manual www.teledynetekmar.com
Teledyne Tekmar (TEKMAR) warrants this product to be free from defects in material and workmanship under normal
use and care for a period of twelve (12) months from the date of initial installation or eighteen (18) months from the
date of invoice, whichever period comes rst. Consumables, spare parts, accessories, and services are warranted for
ninety (90) days from the date of shipment or completion of the services. If the Buyer identies any defects in material
or workmanship, Buyer will promptly notify TEKMAR in writing of the defective goods and the specic nature of the
defect. Prior to placing a service request, Buyer may be required to run diagnostic tests as determined by TEKMAR. If
warranty service is rendered for a malfunction caused by application contamination, devices not manufactured by
TEKMAR, defective gases or samples, or if warranty service eorts to isolate the cause of a malfunction are increased
as a result of the aforementioned, TEKMAR will charge the Buyer on a time and material basis for additional services.
TEKMAR at its sole discretion will repair or replace any such goods found by TEKMAR to be defective. If TEKMAR
authorizes the return of defective goods, Buyer will return the defective goods, transportation and insurance prepaid,
in accordance with instructions issued by TEKMAR including a Return Authorizations (RMA) number. TEKMAR’s
warranty does not apply to any goods that have been subjected to improper installation, misuse, alternation, repair,
neglect, accident, inundation, re, or the like. All replacements or repairs necessitated by inadequate maintenance,
normal wear and usage, unsuitable power sources, unsuitable environmental conditions, accident, misuse, user
induced contamination, improper installation, modication, repair, storage or handling, or any other cause not the
fault of TEKMAR are not covered by this limited warranty, and shall be at Buyer’s expense. This warranty specically
excludes the following parts: supply items and mechanical wear parts such as bearings, seals, traps, trap heaters,
syringes, septa, glassware, ttings, frits, batteries, fuses and light bulbs. TEKMAR shall not be obligated to pay any costs
or charges incurred by the Buyer or any other party except as may be agreed upon in writing in advance by an
authorized TEKMAR representative. All costs of dismantling, reinstallation and freight and the time and expense of
TEKMAR’s personnel for site travel and diagnosis under this limited warranty clause shall be borne by the Buyer unless
accepted in writing by TEKMAR. Goods repaired and parts replaced during the warranty period shall be in warranty for
the remainder of the original warranty period, or ninety (90) days, whichever is longer.
This warranty, including remedies, is exclusive and is in lieu of any and all other warranties, express or implied. No
warranty of merchantability or tness for a particular purpose is intended or given. TEKMAR shall not be liable for any
indirect or consequential damages. In the case of goods other than those of TEKMAR’s own manufacture, TEKMAR
makes no warranties, express, statutory or implied, including the implied warranties of merchantability, freedom from
patent infringement and tness for a particular purpose. Such goods shall carry only the warranty extended by the
original manufacturer of such goods.
This warranty applies to TEKMAR manufactured products purchased directly from TEKMAR. Products purchased
through other sources may have other terms and conditions for a warranty program. Please refer to the original source
of purchase for warranty details.
TEKMAR’s complete Terms and Conditions of Sale are available on our website at www.teledynetekmar.com. Any
questions regarding this policy and its application should be directed to:
TELEDYNE TEKMAR CUSTOMER SUPPORT CENTER
U.S.: [phone]
Outside the U.S.: Country Code + 1 [phone]
Warranty Information

Torch User Manual www.teledynetekmar.com
CHAPTER 1: INTRODUCTION
Essential Instructions.................................................................................................. 1 - 2
Safety ............................................................................................................................. 1 - 3
Safety Symbols .........................................................................................................................1 - 3
Working Safely..........................................................................................................................1 - 4
Introduction ................................................................................................................. 1 - 5
TOC Theory.................................................................................................................................1 - 5
TOC Overview ...........................................................................................................................1 - 6
NDIR Pressurization Overview ........................................................................................... 1 - 6
What is the Torch?....................................................................................................................1 - 7
Component Overview ................................................................................................ 1 - 9
Banner Display..........................................................................................................................1 - 9
Syringe Pumper and 7-port Valve......................................................................................1 - 9
IC Sparger .................................................................................................................................1 - 10
Combustion Furnace............................................................................................................1 - 10
Halogen Scrubber .................................................................................................................1 - 10
Moisture Control System (MCS)........................................................................................1 - 10
Non-Dispersive Infrared (NDIR) Detector......................................................................1 - 11
Flow Restrictors......................................................................................................................1 - 11
Mass Flow Controller (MFC) ...............................................................................................1 - 12
Acid Container ........................................................................................................................1 - 12
Autosampler............................................................................................................................1 - 13
CHAPTER 2: INSTALLATION & SETUP
Pre-Installation............................................................................................................. 2 - 2
Before You Begin......................................................................................................................2 - 2
Utility Requirements for the Torch ....................................................................................2 - 2
Minimum Computer Requirements..................................................................................2 - 3
Required Tools and Supplies for Installation .................................................................2 - 3
Installation.................................................................................................................... 2 - 4
Bench Placement.....................................................................................................................2 - 4
Installing the Combustion Tube ...................................................................................................................... 2 - 4
Furnace Setup...........................................................................................................................2 - 4
Furnace Quick Disconnect Power Fitting ......................................................................................................2 - 4
Packing the Combustion Tube..........................................................................................................................2 - 4
Installing the Combustion Tube .......................................................................................................................2 - 4
Electrical and Data Connections ........................................................................................2 - 5
Power Cord...............................................................................................................................................................2 - 5
I/O Cable....................................................................................................................................................................2 - 6
Ethernet Crossover Cable....................................................................................................................................2 - 6
Water, Reagent, and Gas Connections.............................................................................2 - 7
Connecting the Torch to a DI Water Supply .................................................................................................2 - 8
Connecting the Torch to an Acid Supply.......................................................................................................2 - 8
Connecting the Torch to the Waste Container ............................................................................................2 - 9
Using Nuts and Ferrules Supplied with the Torch......................................................................................2 - 9
Connecting the Torch to a Gas Supply ........................................................................................................ 2 - 10
Installing the Drain Tray and Carousel ...........................................................................2 - 11
Installing the Drain Tray.................................................................................................................................... 2 - 11
Installing the Carousel....................................................................................................................................... 2 - 11
Hardware Install Complete.................................................................................................2 - 12
Table of Contents

Torch User Manual www.teledynetekmar.com
CHAPTER 3: MATERIALS, REAGENTS, AND STANDARDS
Preparing Reagents and Standards ......................................................................... 3 - 2
Materials and Reagents .........................................................................................................3 - 2
Reagent Water (H2O) ............................................................................................................................................3 - 2
Nitric Acid (HNO3)..................................................................................................................................................3 - 2
Laboratory Glassware Cleaning Solution......................................................................................................3 - 2
Potassium Hydrogen Phthalate (KHP or C8H5KO4....................................................................................3 - 2
Sodium Bicarbonate (NaHCO3).........................................................................................................................3 - 3
Phosphoric acid, concentrated (H3PO4)........................................................................................................3 - 3
Glassware..................................................................................................................................................................3 - 3
Pipettors and Plastic Tip Pipettes.....................................................................................................................3 - 3
Analytical Balance..................................................................................................................................................3 - 3
Procedure for Glassware Cleaning.....................................................................................3 - 4
Preparation of Reagent Solutions......................................................................................3 - 5
Preparation of 21% Acid Reagent (weight/weight)...................................................................................3 - 5
KHP 1000ppmC 1 Liter .........................................................................................................................................3 - 5
Formula for Preparation of Standards ............................................................................................................3 - 6
Preparation of Working Calibration Solutions...............................................................3 - 6
20ppmC Working Calibration Solution..........................................................................................................3 - 6
10ppmC Working Calibration Solution..........................................................................................................3 - 6
1ppmC Working Calibration Solution.............................................................................................................3 - 6
Formula for Working Calibration Solutions ..................................................................................................3 - 6
CHAPTER 4: TOC TEKLINKTM SOFTWARE SETUP
TOC TekLinkTM Setup Overview ................................................................................. 4 - 2
TOC TekLinkTM Software Installation ........................................................................ 4 - 2
Stand-Alone Torch Conguration..................................................................................... 4 - 2
External PC Torch Conguration ........................................................................................4 - 2
Installing the Microsoft .NET 2.0 Framework from the Menu..................................4 - 3
Instrument Communication...................................................................................... 4 - 4
RS232 Connection...................................................................................................................4 - 4
Computer TCP/IP Conguration.........................................................................................4 - 4
Starting TOC TekLinkTM................................................................................................ 4 - 6
First Login: External PC ..........................................................................................................4 - 6
First Login: Internal PC...........................................................................................................4 - 6
Instrument TCP/IP Conguration.......................................................................................4 - 7
Editing Network Settings......................................................................................................4 - 9
Adding a New Instrument....................................................................................................4 - 9
TOC TekLink Basics .................................................................................................... 4 - 10
Using the Mouse....................................................................................................................4 - 10
Using the Keyboard ..............................................................................................................4 - 10
Key Points of Interest for User Interface ........................................................................4 - 10
Using the Menus....................................................................................................................4 - 10
TOC TekLinkTM Help................................................................................................................4 - 11
About Torch TekLinkTM ..........................................................................................................4 - 11
User Account Management..................................................................................... 4 - 12
User Manager..........................................................................................................................4 - 12
Add New User ....................................................................................................................... 4 - 12
Change Password ..................................................................................................................4 - 12
Reset Password.......................................................................................................................4 - 13
Table of Contents

Torch User Manual www.teledynetekmar.com
User Properties .......................................................................................................................4 - 13
General Tab............................................................................................................................................................ 4 - 13
Permissions Tab ................................................................................................................................................... 4 - 13
Comments Tab ..................................................................................................................................................... 4 - 13
Instrument Management ....................................................................................... 4 - 14
Main Application ...................................................................................................................4 - 14
TOC TekLinkTM Buttons and Menus. .............................................................................................................. 4 - 15
File Menu .............................................................................................................................................................. 4 - 15
View Menu ........................................................................................................................................................... 4 - 16
Instrument Menu ................................................................................................................................................ 4 - 16
Tools Menu. ........................................................................................................................................................... 4 - 17
Maintenance Tasks Submenu......................................................................................................................... 4 - 17
Windows Menu.................................................................................................................................................... 4 - 18
Help Menu ............................................................................................................................................................ 4 - 18
Instrument Manager ......................................................................................................... 4 - 19
Instrument Conguration...................................................................................................4 - 20
General Tab........................................................................................................................................................... 4 - 20
Conguration Tab ...............................................................................................................................................4 - 21
Advanced Tab ...................................................................................................................................................... 4 - 22
Comments Tab ................................................................................................................................................... 4 - 22
System Properties..................................................................................................................4 - 23
General Tab........................................................................................................................................................... 4 - 23
Archive Tab ............................................................................................................................................................ 4 - 23
Change Justication Tab ................................................................................................................................. 4 - 24
CSV Export Tab..................................................................................................................................................... 4 - 24
Diagnostics ........................................................................................................................... 4 - 25
Valves & Flows Tab ............................................................................................................................................ 4 - 25
Pumper Tab ...........................................................................................................................................................4 - 26
Autosampler Tab ................................................................................................................................................ 4 - 26
Benchmark Tab ................................................................................................................................................... 4 - 27
Analogue Board Tab.......................................................................................................................................... 4 - 28
Firmware Update...................................................................................................................4 - 28
Calibration Editor ................................................................................................................ 4 - 29
Method Editor....................................................................................................................... 4 - 30
General Tab............................................................................................................................................................ 4 - 30
Advanced Tab ....................................................................................................................................................... 4 - 31
Comments Tab .................................................................................................................................................... 4 - 32
Standards Editor.....................................................................................................................4 - 32
Standards Tab....................................................................................................................................................... 4 - 32
Options Tab .......................................................................................................................................................... 4 - 32
Schedule Editor ......................................................................................................................4 - 33
Samples Tab .......................................................................................................................................................... 4 - 34
Options Tab ..........................................................................................................................................................4 - 34
Comments Tab .................................................................................................................................................... 4 - 35
Sample Analysis .....................................................................................................................4 - 35
Instrument Blank ...................................................................................................................4 - 35
Report...................................................................................................................................... 4 - 36
Static Overview Tab ........................................................................................................................................... 4 - 36
Interactive Tab..................................................................................................................................................... 4 - 37
CHAPTER 5: OPTIONAL TOTAL NITROGEN MODULE
TN Analysis Overview.................................................................................................. 5 - 2
Torch with Total Nitrogen Module.................................................................................... 5 - 2
Measuring Total Nitrogen.................................................................................................... 5 - 3
Technical Specications .......................................................................................................5 - 4
Table of Contents

Torch User Manual www.teledynetekmar.com
Component Overview. ................................................................................................ 5 - 5
Ozone Generator . ...................................................................................................................5 - 5
Photomultiplier Tube .............................................................................................................5 - 6
Ozone Scrubber .......................................................................................................................5 - 6
Analysis Process............................................................................................................ 5 - 6
Total Carbon with Total Nitrogen (TC/TN) ..................................................................... 5 - 6
Total Organic Carbon with Total Nitrogen (TOC/TN) ..................................................5 - 7
Total Carbon Minus Inorganic Carbon with Total Nitrogen (TC-IC/TN)................5 - 7
Installation..................................................................................................................... 5 - 8
Before You Begin..................................................................................................................... 5 - 8
Unpack and Inspect. .............................................................................................................................................5 - 8
Bench Placement .................................................................................................................................................. 5 - 8
Installation of the TN.............................................................................................................................................5 - 8
Connect Oxygen Supply to Ozonator............................................................................................................ 5 - 9
Connect the Sample Gas Outlet to the Nitrogen Module.......................................................................5 - 9
Make Plumbing Alterations............................................................................................................................. 5 - 10
Initial Start-Up...................................................................................................................................................... 5 - 10
Preventative Maintenance ....................................................................................... 5 - 11
Preventative Maintenance Checklists ............................................................................5 - 11
Daily Checks.......................................................................................................................................................... 5 - 11
Weekly Maintenance Checks .......................................................................................................................... 5 - 11
Monthly Maintenance Checks ....................................................................................................................... 5 - 11
Preventive Maintenance Chart ...................................................................................... 5 - 12
Replacing Parts........................................................................................................... 5 - 13
Removing the Detector Assembly................................................................................. 5 - 13
CHAPTER 6: TUTORIAL
Software Tutorial ......................................................................................................... 6 - 2
Login.............................................................................................................................................6 - 2
Connecting to an Instrument ............................................................................................................................6 - 2
TOC TekLinkTM Main ............................................................................................................... 6 - 3
Creating a New Calibration.................................................................................................................................6 - 3
Creating a New Method ......................................................................................................................................6 - 4
Creating a New Standard ....................................................................................................................................6 - 4
Creating a New Schedule....................................................................................................................................6 - 6
Running the Schedule ..........................................................................................................6 - 8
Review ....................................................................................................................................... 6 - 9
Exporting a Report ........................................................................................................................................... 6 - 10
CHAPTER 7: 21 CFR 11 COMPLIANCE
21 CFR 11 Features and Compliance Tools .............................................................. 7 - 2
User Manager ...........................................................................................................................7 - 2
Setting Up User Accounts ...................................................................................................................................7 - 3
User Permissions ................................................................................................................................................... 7 - 3
Edit an Existing Account......................................................................................................................................7 - 4
Time-out................................................................................................................................................................... 7 - 4
Lockout .................................................................................................................................................................... 7 - 5
Data Versioning, History, and Archive............................................................................. 7 - 6
Report Data Security ..............................................................................................................7 - 6
Electronic Signatures............................................................................................................. 7 - 6
View/Print System History and Error Logs......................................................................7 - 8
Change Justication...............................................................................................................7 - 9
Table of Contents

Torch User Manual www.teledynetekmar.com
CHAPTER 8: SYSTEM OPERATIONS
System Operations....................................................................................................... 8 - 2
Instrument Preparation.........................................................................................................8 - 2
General Daily Startup Routine...........................................................................................................................8 - 2
Accessing Data Oine...........................................................................................................8 - 2
Disabling an Existing Instrument .................................................................................................................... 8 - 2
Creating a New Instrument with a Dummy Address.................................................................................8 - 2
Understanding the Analysis Types ....................................................................................8 - 3
Sample Introduction.............................................................................................................................................8 - 4
Total Organic Carbon (TOC) ............................................................................................................................. 8 - 5
Total Carbon (TC) .................................................................................................................................................. 8 - 5
Inorganic Carbon (IC)............................................................................................................................................8 - 6
Total Carbon Minus Inorganic Carbon (TC-IC)............................................................................................ 8 - 6
System Clean ...........................................................................................................................8 - 6
System Blank .......................................................................................................................... 8 - 6
Calibration ...............................................................................................................................8 - 7
Calibration Overview............................................................................................................................................8 - 7
Methods......................................................................................................................................8 - 8
Selecting the Correct Methods ........................................................................................................................ 8 - 9
Method Variables ................................................................................................................................................. 8 - 9
Selecting Standards............................................................................................................... 8 - 9
Selecting Check Standard Concentrations.....................................................................8 - 9
Schedule Setup ................................................................................................................... 8 - 10
Optimizing Results ............................................................................................................. 8 - 10
Special Applications .................................................................................................. 8 - 11
Sample Preservation for TOC........................................................................................... 8 - 11
Phosphoric Acid (H3PO4) ................................................................................................................................ 8 - 11
Sulfuric Acid (H2SO4)........................................................................................................................................ 8 - 11
Hydrochloric Acid (HCl).................................................................................................................................... 8 - 11
Nitric Acid (HNO3).............................................................................................................................................. 8 - 11
Applications........................................................................................................................... 8 - 12
Low-level Carbon .............................................................................................................................................. 8 - 12
High Acid Content ............................................................................................................................................. 8 - 12
High Fraction of Inorganic Carbon............................................................................................................... 8 - 12
CHAPTER 9: MAINTENANCE & TROUBLESHOOTING
Preventive Maintenance Checklist............................................................................ 9 - 2
Daily Maintenance Checks ..................................................................................................9 - 2
Weekly Maintenance Checks...............................................................................................9 - 2
Monthly Maintenance Checks ............................................................................................9 - 2
Preventive Maintenance Chart ..........................................................................................9 - 3
Replacing Parts............................................................................................................. 9 - 4
Combustion Tube and Catalyst.......................................................................................... 9 - 5
Packing the Combustion Tube..........................................................................................................................9 - 5
Removing the Combustion Tube ....................................................................................................................9 - 5
Installing a New Combustion Tube..................................................................................................................9 - 6
Injection Line Needle. ............................................................................................................9 - 6
Making a 1/2mL Injection Line Needle ..........................................................................................................9 - 6
Replacing the Injection Line Needle...............................................................................................................9 - 7
Furnace / TC Probe .................................................................................................................9 - 8
Furnace Fans............................................................................................................................. 9 - 9
Condensing Loop Fan .......................................................................................................... 9 - 9
Table of Contents

Torch User Manual www.teledynetekmar.com
Mist Trap ...................................................................................................................................9 - 10
Copper (Cu) and Tin (Sn) in Halogen Scrubber ..........................................................9 - 10
Permeation Dryer ..................................................................................................................9 - 11
Autosampler Needle.............................................................................................................9 - 12
7-port Valve..............................................................................................................................9 - 13
3-way Valve ..............................................................................................................................9 - 15
Motor Control Printed Circuit Board (PCB) ...................................................................9 - 16
DC Control PCB..................................................................................................................... 9 - 16
Analog Board...........................................................................................................................9 - 16
Fuse ............................................................................................................................................9 - 17
Power Entry Module (PEM).................................................................................................9 - 17
5VDC Power Supply .............................................................................................................9 - 18
12VDC Power Supply (Stand-alone Version Only) ................................................... 9 - 18
24VDC Power Supply............................................................................................................9 - 19
Mass Flow Controller (MFC) ............................................................................................. 9 - 20
Syringe Pumper.................................................................................................................... 9 - 20
NDIR Detector ........................................................................................................................9 - 21
Pressure Regulator ...............................................................................................................9 - 22
Leak Checking the Torch .......................................................................................... 9 - 23
Isolating a Leak and Manual Leak Checking ............................................................. 9 - 23
Furnace Path ....................................................................................................................................................... 9 - 23
IC Flow Path.......................................................................................................................................................... 9 - 25
Troubleshooting the Torch. ..................................................................................... 9 - 26
Arm Adjustment ....................................................................................................................9 - 27
Carousel Adjustment ...........................................................................................................9 - 27
Troubleshooting Chart ...................................................................................................... 9 - 28
Returning the Torch ..............................................................................................................9 - 29
Unit and Parts Disposal .......................................................................................................9 - 29
CHAPTER 10: GLOSSARY
Acronyms .................................................................................................................... 10 - 2
Terms ............................................................................................................................ 10 - 3
CHAPTER 11: DIAGRAMS
Electrical Schematic - Torch..................................................................................... 11 - 2
Electrical Schematic - TN Module............................................................................ 11 - 3
Torch Flow Diagrams - Basic ................................................................................... 11 - 4
Dispense Acid..........................................................................................................................11 - 5
Dispense Sample to IC Sparger ..................................................................................... 11 - 6
Drain Mode ..............................................................................................................................11 - 7
IC Sparge ................................................................................................................................ 11 - 8
Pressurize Furnace............................................................................................................... 11 - 9
Pull Acid ............................................................................................................................... 11 - 10
Pull Sample .......................................................................................................................... 11 - 11
Pull Sparged Sample ........................................................................................................11 - 12
Sample Inject....................................................................................................................... 11 - 13
System Sweep .....................................................................................................................11 - 14
Torch & TN Flow Diagrams - Basic .........................................................................11 - 15
TN Sample Flow ..................................................................................................................11 - 16
INDEX
Table of Contents

Torch User Manual www.teledynetekmar.com
Chapter 1: Introduction

Torch User Manual www.teledynetekmar.com
IT IS IMPORTANT THAT YOU READ THIS PAGE BEFORE PROCEEDING!
Teledyne Tekmar designs, manufactures, and tests its products to meet many national and international standards.
The Torch is a sophisticated technical product and must be properly installed, used, and maintained to ensure that it
operates within normal specications. You must adhere to and integrate the following instructions into your safety
program when installing, using, and maintaining the Torch. Failure to follow the proper instructions may invalidate
the warranty.
• Read all instructions prior to installing, operating, and servicing the product. Follow all warnings, cautions, and
instructions marked on, and supplied with the product and this manual. If you do not understand any of the
instructions, contact your Teledyne Tekmar representative for clarication.
• Educate your personnel in the proper installation, operation, and maintenance of the product. Only qualied
personnel should install, operate, update, program, and maintain the product.
• Install your equipment as specied in Chapter 2: Installation & Setup of this manual and according to applicable
local and national codes. Connect all products to the proper electrical and pressure sources.
• Only trained service personnel should replace blown fuses, and only after identifying and correcting the problem
which caused the fuse(s) to blow. For continued protection, replace only with same type and fuse rating of fuse.
• When replacement parts are required, ensure that qualied individuals use replacement parts specied by
Teledyne Tekmar. Unauthorized parts and products can aect the product’s performance and jeopardize safety.
Using look-alike substitutions may result in re, electrical hazards, or improper operation.
Ensure that all equipment doors are closed and protective covers are in place (except when maintenance is being
performed by qualied personnel) to prevent electrical shock and personal injury.
Essential Instructions
Introduction • Page 1-2

Torch User Manual www.teledynetekmar.com
SAFETY SYMBOLS
Corrosive substance! Use appropriate Personal Protective Equipment (PPE) and
care when handling.
Electrical Hazard!
Warning/Caution! A hazardous or potentially hazardous situation that, if not avoided,
will result in product and/or property damage and possible injury and/or death.
Fire Hazard!
Hot Surface or High Temperature!
Read the Appropriate Documentation!
Skin Contact Hazard! Use protective gloves and other appropriate PPE.
High Pressure Hazard!
Risk of Eye Injury. Wear safety glasses and other appropriate PPE.
Pinch Point Hazard! Keep hands and other appendages away.
Safety
Introduction • Page 1-3

Torch User Manual www.teledynetekmar.com
If the equipment is used in a manner not specied herein,
the protection provided by the equipment may be impaired!
Lift and position the Torch by the base only. Never use the Torch front cover, Autosampler
Mechanism (ASM) arm, glassware, or any other external component for lifting or positioning
support. Injury or damage to the Torch may occur if the unit is not properly lifted or
positioned. To prevent damage to and/or abnormal variation in the infrared detector:
• Maintain a consistent temperature environment.
• Avoid exposing the Torch to corrosive or combustible gas.
• Do not place the Torch near high frequency furnaces or other sources of EMI
(electromagnetic interference). If this situation is unavoidable, use a separate power line.
Route Tygon tubing drain lines to slope downward only. Do not extend tubing into the
waste bottle more than 3 to 5” (7.6 to 12.7cm). Failure to follow these directions may result in
improper drainage of the Torch.
Please be aware that if Torch, the Nitrogen Module, its components, and/or accessories are
used in a manner not specied by Tekmar, protection by the equipment may be impaired.
The TN must only be lifted and positioned from beneath its base. Failure to heed this warning
may result in bodily injury, or damage to the TN.
Running an improperly setup method may damage the Torch. Setting up a new method
should be performed by personnel who are properly trained, knowledgeable, and well
acquainted with the Torch.
Do not plug the Torch into an extension cord. An extension cord may overheat and cause a re.
Always replace fuses with the same type and rating of fuse.
NEVER use hydrogen or other ammable gas with the Torch. Follow the manufacturer’s
directions for safe handling of gas and chemicals. Also refer to the Material Safety Data Sheets
(MSDS) for information on specic chemicals.
Acid will burn eyes and skin. To prevent injury, wear safety glasses and skin protection
when using these chemicals. Refer to their MSDS for detailed information.
To avoid injury to yourself or damage to the Torch, do not exceed the recommended pressure
settings. Observe safety regulations when handling pressurized gas. For more information
see Matheson Gases Data Book (available from the Matheson Company, East Rutherford, New
Jersey)
Sample and associated waste may contain hazardous and toxic substances. Follow the
proper safety and health practices. Also, know regulatory limitations before using or disposing
of chemicals.
Working Safely
Introduction • Page 1-4

Torch User Manual www.teledynetekmar.com
To avoid electrical shock:
Turn OFF and unplug the Torch before servicing.
Do not process samples without the panels installed.
Plug the power cord into a properly grounded outlet.
Extremely high voltage! Turn o and unplug.
To avoid electrical shock, turn OFF and unplug the Torch before servicing.
Risk of Eye Injury. Wear safety glasses and other appropriate PPE.
Hot surface! Turn OFF power to the Torch and remove the AC power line from the back of the
instrument. Allow the furnace to cool to room temperature.
Put on Safety Glasses and Protective Clothing before proceeding to the next step.
TOC THEORY
Total organic carbon (TOC) analysis grew from the need to analyze waste water and municipal water for organic
matter. The need to protect it and establish criteria for screening and measuring contaminant levels was recognized
when Congress enacted the Resource Conservation and Recovery Act (RCRA) in 1976. This act requires operators
of waste disposal sites to monitor their groundwater on a quarterly basis for organic carbon levels and organic
halide levels.
TOC analyzers are also widely used in monitoring the quality of process water in the semiconductor and
pharmaceutical industries. Because organic material can cause contamination, TOC analysis is also performed to
protect process equipment such as boilers, turbines, and purication devices. Furthermore, TOC levels in solids such
as soils, clays and sediments are of increasing interest.
Using safe and proven High Temperature Combustion (HTC), oxidation of carbonaceous material to carbon
dioxide followed by Non-Dispersive Infrared (NDIR) detection of the CO2product, the Torch is sensitive from
50ppbC - 30,000ppmC. Varieties of carbon can be independently determined by selecting a pre-dened instrument
method. These include:
• Total Carbon (TC)
• Inorganic Carbon (IC)
• Total Organic Carbon (TOC = TC-IC)
• Non-Purgable Organic Carbon (NPOC or TOC by sparging)
Introduction
Introduction • Page 1-5

Torch User Manual www.teledynetekmar.com
The oxidation products are swept into the NDIR detector, which is CO2selective. The exit valve from the NDIR is
closed to allow the detector to become pressurized. Once the gases in the detector have reached equilibrium, the
concentration of CO2is analyzed. This pressurization of the sample gas stream in the NDIR, a patent-pending
technique, allows for increased sensitivity and precision by measuring the entirety of the oxidation products of the
sample in one reading, compared to ow-through technology. The output signal is proportional to the concentration
of CO2, created from the oxidation of the sample, in the carrier gas. The PC workstation uses the TOC TeklinkTM software
to control the above sequence of operations, process the detector signal, and report the nal concentration of the
sample based on linearized, multi-point calibration data.
TOC OVERVIEW
TOC analyzers can measure:
• Total Carbon (TC)
• Total Organic Carbon (TOC)
• Inorganic Carbon (IC)
• Non-Purgeable Organic Carbon (NPOC)
TOC measurement involves:
• Oxidizing organic carbon in a sample.
• Detecting and quantifying the oxidized carbon (CO2).
• Presenting the results in units of mass of carbon per volume of sample.
Total Carbon (TC) – The measure of all the carbon in the sample, both inorganic and organic, as a single parameter.
Generally, the measurement is made by placing the sample directly into the analyzer without pretreatment.
Total Organic Carbon (TOC) - The sum of all the organic carbon in the sample.
Direct TOC Measurement – In the direct approach, IC is rst removed by acidication and sparging and the
remaining carbon is measured as TOC. IC and POC are not recovered for further analysis in this approach. However,
since POC generally represents 1% or less of total carbon in a sample, it is considered negligible.
TOC Measurement by Dierence - This approach requires two analyses: one to measure TC, and one to measure IC.
The dierence between these two measurements is precisely TOC.
TOC Measurement by Sum - This approach measures NPOC and POC. The sum of these measurements is
precisely TOC.
Inorganic Carbon (IC) - Includes carbonate, bicarbonate, and dissolved carbon dioxide. IC is analyzed in liquid samples
by acidifying with an inorganic acid to pH 3 or lower, and then sparging with a stream of inert gas. The acidication
converts carbonates and bicarbonates to carbon dioxide, which is then removed along with dissolved CO2by the gas
stream, and measured to provide an IC value.
NDIR PRESSURIZATION OVERVIEW
Pressurized detection, or static read, is a technique used for concentrating the CO2produced by the oxidation of the
sample. The technique can be used for both qualitative and quantitative analysis. In this section the basics of the
pressurization technique will be described.
Using the traditional NDIR technology, these measurements are performed by oxidation of the specic carbon
component by high temperature combustion to create CO2, which is swept through an NDIR detector. In this
technique, the adsorption of the infrared light is measured over time as the CO2is swept through the detector. The
resulting measurement correlates to a peak, which can be integrated and correlated to a concentration.
Introduction • Page 1-6

Torch User Manual www.teledynetekmar.com
The use of a pressurized detection scheme, or static read, allows for the specic carbon component to be oxidized
and the resultant carbon dioxide swept into the detector using a non-interfering, inert gas, which is metered by a
Mass Flow Controller (MFC). A valve located at the outlet of the detector prevents the escape of any of the CO2from
the detector. A single measurement can be made to determine the amount of CO2in the detector cell. The reading
correlates directly to the concentration of the carbon contribution from the sample.
An inherent advantage of this technique is that all of the CO2is in the cell at the same time for the detector
measurement. With all of the CO2in the cell, the sensitivity of the analysis is signicantly increased.
Another advantage of this application is that there is one measurement made that represents the concentration of
CO2in the cell versus multiple measurements made in ow-through designs over time that result in a peak. Since this
technique is a static read, it eliminates the inherent error associated with time delays between measurements with
traditional ow through technology. These time delays add error to the integration of the CO2peak. The
elimination of this error allows for lower detection limits and increased precision.
The static read of the detector is accomplished by pressurizing the detector cell with carrier gas, which contains the
CO2from the oxidized sample. The pressure required for static read is generally between 30-60psig (2.1-4.1bar).
Teledyne Tekmar’s recommended pressurization setting is 50psig (3.4bar).
WHAT IS THE TORCH?
The Torch is a state-of-the-art analytical instrument designed to detect, with accuracy, carbon content in water and
other materials down to the ppb level. Chemistries and sample processing with Windows-driven PC control, provides
a fast, reliable test of the quality of water and solutions. It uses a High Temperature Combustion Furnace, which is an
improved version of the Apollo 9000 furnace, and a pressurized NDIR detector, which is a relatively new technology
(patent pending) that allows a degree of sensitivity previously unattainable.
The Torch analyzer is comprised of the following:
Component Function
Syringe Pumper Sample and reagent introduction
7-port Valve Transfer samples and reagents
IC Sparger IC analysis and sample preparation for TOC analysis
Combustion Furnace TC and TOC analysis
Mist Trap Moisture removal
Permeation Dryer Moisture removal
Halogen Scrubber Halogen removal
NDIR Detector Carbon dioxide detection
Table 1-1: Torch Components
Introduction • Page 1-7

Torch User Manual www.teledynetekmar.com
Torch Technical Specications
Chemistry: Combustion
Detector: Non-Dispersive Infrared (NDIR)
Analysis Type (modes) TC
TOC (NPOC)
TC-IC
IC
Range: Limit of detection: 50ppb
Maximum measurable concentration: 30,000ppm
(Sample volume and dilution dependant)
Precision ± 1%, ± 1ppb, or ± 0.02µgC RSD over 7 samples (whichever is greater)
Sample Size: 100µL to 2.0mL
Analysis Time: 29 Minutes for triplicate TOC analysis of a mid range standard
Liquid Handling: Syringe Pumper, 7-port Distribution Valve dilution method provided up to 30,000ppm
Auto-rinsing from sample and/or rinse water
Sample Introduction: Autosampler
Controller: PC, interface through Windows 2000/XP/Vista Business SP1
PC, interface through Windows 2000/XP/XP Professional SP2
Data Handling: Reports exportable XML/HTML/CSV format
Graphical display of detector readings
Ability to store customized individual test methods
Priority samples via scheduled interrupt
Outlier deletions
Recalculation of data (21 CFR Part 11 compliant)
Calibration: Multipoint (2 minimum)
Table 1-2: Torch Technical Specications
Methods, Applications, and Certication
Ocial Methods: EPA Methods 415.1 & 415.3
EPA Method 9060A
Standard Method 5310C
ASTM D4779
ASTM D4839
Cleaning Validation USP TOC Method <643>/EP 2.2.44/JP
Principle Applications: Boiler Feed Water
Cooling Water
Drinking Water
Surface Water
Ground Water
Certication: The unit has successfully completed all appropriate EMC, EMI, and safety requirements
per UL, FCC, CSA, IEC, and CB scheme.
EMC EN61326-1:2006 Class A
CAN/USA C22.2 #61010-1 2nd Edition 2008
ANSI/UL 61010-1 2nd Edition 2008
UL 61010-2-010, 1st Edition, 3/13/02
CAN/CSA C22.2 No. 61010-2-010:04, July 2004
INGRESS PROTECTION (IEC 60529): IPX0
Designed and manufactured under a quality system registered to ISO 9001:2000.
A Declaration of Conformity is available.
Table 1-3: Methods, Applications, and Certication
Introduction • Page 1-8

Torch User Manual www.teledynetekmar.com
COMPONENT OVERVIEW
This section briey describes the individual components of the Torch.
BANNER DISPLAY
The Banner Display, located at the bottom-front of the
instrument, displays a color indicating the current mode
of the instrument as shown in the table below:
Color Mode
White Bootup
Purple No Connection
Yellow Standby
Blue Ready
Green Running/Active Schedule
Red Error
Table 1-4: Banner Display Color Codes
SYRINGE PUMPER AND 7PORT VALVE
The Syringe Pumper is a precision measuring instrument
that aspirates and dispenses uid. The Syringe Pumper
contains electronics, syringe, and stepper motors that
drive a valve actuator and a syringe plunger. The
electronics control the motors and communication
between the Syringe Pumper and micro controller.
The Syringe Pumper can dispense 100μL to 2.0mL
(±1%) of sample.
The Syringe Pumper turns a 7-port Valve. To ensure an
airtight seal, each port on the valve is tted with a valve
washer, installed from the factory, before the insertion of
the appropriate tubing tting.
Introduction • Page 1-9
Figure 1-3: Banner Display
Figure 1-4: Syringe Pumper and 7-port Valve
Figure 1-2: Rear View
Figure 1-1: Front View

Torch User Manual www.teledynetekmar.com
IC SPARGER
The IC Sparger is a glass vessel that holds the sample
while the Torch:
• Purges the sample of IC
• Prepares the sample for TOC analysis.
After the addition of acid, carrier gas ows through the
sparger, removing the IC from the sample. The Torch
detects IC in the IC mode or sends it to vent while in the
TOC mode.
COMBUSTION FURNACE
The combustion furnace provides the high temperature
necessary to oxidize the carbon in the sample to CO2 . It
holds the quartz combustion tube between the bottom
connector and the injection port at the top. O-rings
provide gas-tight seals at each end. The combustion tube
contains a bed of proprietary catalyst that promotes
oxidation of organics. The top cap provides the interface
for the sample injection and carrier gas. The sample enters
from the top and the carrier gas from the side.
HALOGEN SCRUBBER
The detector, which measures carbon dioxide, can be
eected by halogens. To prevent analytical errors, the
Halogen Scrubber removes chlorine and other halogens
from the carbon dioxide before it enters the detector. The
Halogen Scrubber is a U-shaped tube led with Pyrex
wool, tin, and copper granules.
MOISTURE CONTROL SYSTEM MCS
The detector, which measures carbon dioxide, is aected
by water vapor, so the Torch is designed to remove
moisture from the sample. The Torch MCS consists of:
• Condensing Loop
• Cooling Fan
• Mist Trap
• Permeation Dryer
After oxidation of the sample, carrier gas sweeps CO2
and water vapor out of the Combustion Furnace through
tubing cooled by a fan to condense water vapor. Next, the
CO2travels through the Mist Trap, where most of the
condensate is collected and removed. The gases then
travel to the Permeation Dryer, which removes the rest of
the moisture from the sample gas.
Introduction • Page 1-10
Figure 1-5: IC Sparger
Figure 1-7: Halogen
Scrubber
Figure 1-6: Combustion Furnace
Figure 1-8: Condensing Loop
and Cooling Fan
Condensing
Loop
Cooling
Fan
Figure 1-9: Mist Trap
Figure 1-10: Permeation Dryer

Torch User Manual www.teledynetekmar.com
NONDISPERSIVE INFRARED NDIR DETECTOR
After the Torch oxidizes the sample, it is swept into the
detector and pressurized to ensure that the entire sample
is present. The NDIR detector then measures the
concentration of carbon dioxide.
The NDIR detector of the Torch is based on proprietary
sensing technology. It has three major components: a light
source, a Fabry-Perot Interferometer (FPI), and an IR
detector. The electronically pulsed light from the
miniature lament lamp is reected and re-focused back
to an IR detector located behind the FPI.
The FPI is a micro-machined silicon chip that contains two
parallel mirrors. The two parallel mirrors change distance
when a voltage is applied over the chip, allowing only
certain wavelengths of light to pass through to the IR
detector. The FPI is designed to pass light at the CO2
absorption wavelength (4.26μm) and a nearby,
non-absorbing wavelength. When the sensor is operating,
the FPI is regularly tuned back and forth between the
two wavelengths.
At the CO2 absorption wavelength, the intensity of
detected light is reduced in proportion to the concentration
of CO2 in the optical path. The light intensity measured
at the non-absorbing wavelength serves as a baseline for
comparison. The degree of light absorption in the gas,
indicated by the ratio of these two signals, is proportional
to the gas concentration. Carbon dioxide shows a unique
adsorption spectrum when infrared energy passes through
it, allowing the NDIR to distinguish it from other gases.
By regularly measuring CO2 absorption and the refer-
ence band, the FPI can automatically compensate for light
source intensity changes and loss of reectivity of the
optical sampling cell via contamination or otherwise.
This means that the NDIR detector itself can go for years
without re-calibration.
FLOW RESTRICTORS
Flow restrictors maintain the ow rate of the supply gas
as follows:
• 200mL/min to the Permeation Dryer
• 200mL/min to Valve C
Introduction • Page 1-11
Figure 1-11: NDIR Detector Diagram
Figure 1-12: Flow Restrictor Diagram
