TELEFONICA DOMO User manual

USER MANUAL
Ver.3

DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee 33
33
3
INTRODUCTION ........................................................................................................ 4
INSTALLATION ......................................................................................................... 6
TELEPHONE SETTING ............................................................................................. 7
DIALLING ................................................................................................................. 11
USING THE PHONEBOOK ..................................................................................... 13
DIRECT SERVICES KEYS ..................................................................................... 16
MUTE FUNCTION ................................................................................................... 17
LISTENING TO ACALL............................................................................................ 18
HANDS FREE FUNCTION ...................................................................................... 18
IDENTIFICATION OF CALL SERVICE ................................................................... 20
SUPPLEMENTARYSERVICES............................................................................... 23
Diverting Incoming Calls ......................................................................................................... 23
Answering Machine Service .................................................................................................... 24
Accessing the Answering Machine ......................................................................................... 24
Call Waiting ............................................................................................................................. 25
Making a Three-Way Call ........................................................................................................ 25
TEXT MESSAGING (SMT) ..................................................................................... 27
To Activate / Disable the Text Messaging Service (SMT) ........................................................ 28
Changing the Extension Number ............................................................................................ 29
Private Mail .............................................................................................................................. 31
Sending a Message ................................................................................................................ 33
Receiving Messages ................................................................................................................ 37
Reading Messages ...................................................................................................................37
DISTRIBUTION LISTS FOR MESSAGING .............................................................. 40
CHANGE ANSWERING SERVICE LANGUAGE TO ENGLISH .............................. 43
TROUBLESHOOTING ............................................................................................. 44
MAINTENANCE ....................................................................................................... 45
TECHNICAL SPECIFICATIONS .............................................................................. 45
GUARANTEE CERTIFICATE................................................................................... 46
CONDITIONS OF GUARANTEE ............................................................................. 47
Manual Credits and Copyright ................................................................................. 48
1. Viewer.
2. Key Answering machine.
3. Key Messages/Accept.
4. Key Deactivate/Exit.
5. Key LL. at Three.
6. Handset.
7. Keyboard of Machine.
8. Key R; change from/to Uppercase/
Lowercase.
9. Key Phone Book.
10. Key to Record.
11. Key Free Hands
12. Microphone.
13. Key Rellamada / To Pause.
14. Key Mute.
15. Speaker.
16. Key to access Personal
Attention of Telefónica
1004.
17. Key to Erase.
18. Key to Telefónica operator
1077.
19. Key to access European
Emergency Number 112.
20. Scroll Keys and Volume.
21. Key for Menu and Selecting
22. Key to hold second caller.
23. Key to Divert
24. Indicator light
CONTENTS
22
22
2

44
44
455
55
5
DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee
ASpanish version of this booklet is provided with the DOMO Messages Hands
Free telephone equipment. This English version has been produced by
John H. Sumner for the benefit of those who struggle to understand Spanish. It is
available to download free from many sites on the Interenet (in PDF format), or as
a printed booklet direct from the author - see back page for more details. Adouble-
size printed version for the sight-impaired, is also available from the author.
It is recommended that you read this manual thoroughly before using the new
telephone. It is laid out in an order that makes subjects easy to find, and includes
the methods to access the various services provided by Telefónica and describes
the messages that you can expect to see displayed in the viewer.
The DOMO Messages Hands Free is an electronic telephone of modern design
that incorporates the following characteristics -
-Dialling.
-Numeric keyboard with alphabetic characters.
-On-screen display of the dialled number.
-Phonebook with a memory for up to 50 names and number.
-A listing with the last 50 incoming or outgoing calls.
-Hands Free function X))).
-Adjustment of the volume of the speaker.
-Adjustment of the volume of the microphone.
-Key R.
-Redailling from a list of outgoing Calls.
-Insertion of pauses while dialling.
-Viewer window with three lines of information.
-Shortcuts to the Telefonica’s Supplementary Services: Call Waiting, Three-
Way Calls, Call Diversion andAnswering Machine Service.
-Text Messaging (SMT) - sending, receiving and editing text messages (SMT).
-Identification of incoming call numbers.
-Indicator light showing New Calls, Text Messages (SMT) and messages
stored in the Answering Machine (if available from the telephone network).
INTRODUCTION -Shortcut to the Telefónica Personal Attention line - 1004 (Blue Key).
-Shortcut to the European Emergency number - 112 (Red Key).
-Shortcut to the Telefónica Operator - 1077 (Green Key).
-Mute Function, with optical warning.
-Activation / Deactivation of the 1077 Code.
-All services available using one telephone line.
-Reception capsule giving help to people with hearing difficulties.
-Handset assessories such as line cords.
-Installation possible during evenings.
-Real-time clock.
-Selection of three melodies and two-tone levels.
The DOMO Messages Hands Free comes with -
The Telephone.
The Handset.
Spiral cord for handset/base.
Line cord.
User Manual with guarantee card and Quick Guide of Use.
NOTE:
To be able to use the Identification of Calls option and other Supplementary
Services that are offered with the DOMO Messages Hands Free telephone,
it is necessary to request those services from Telefónica.
To send or to receive text messages, it is necessary to activate the service
according to instructions as detailed on page 27 of this manual - SERVICE
OF MESSAGES OF TEXT (SMT). Keep in mind that it is necessary to have
requested the Identification of Calls Service.
IMPORTANT NOTICE:
To connect two or more handsets for using messages, use DIFFERENT
EXTENSION, see details on Extensions on page 27.

77
77
7
66
66
6DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee
INSTALLATION
Installing and connecting the DOMO Telephone.
This telephone should only be connected
to lines that have Multifrequency.
!
Connect the longest end into the
telephone base and the other end in
the hand piece as shown in the figure.
Connect the end of the input cable to
the apparatus and the other end into
the socket of the phone plug.
If you need to increase the apparatus
inclination on the table, insert the base
support bar into the apparatus and
press until it clicks into place.
Adjust the cables under the apparatus
to ‘exit’ in the best direction.
Fix a base support (optional) for wall
assembly, if necessary.
Use the template provided with the
base support, to mark the two holes
to be drilled in the wall.
Connect the cable of external line in
the screws located inside base.
Connect the cable of telephone line
in the connector so it is housed
internally.
Wind up surplus in the flukes as shown
in the figure.
Connection
of cord to the
handset
Connecting
the telephone
line
Assembly of
base stand
Assembly of
hand piece
So that the handset stays in place
when the apparatus is hung on a wall,
it is necessary to take remove and
rotate the piece of assembly as shown
in the figure..
TELEPHONE SETTINGS
Once connected to the telephone line, you may need to change phone settings to
suit your own requirements. You can change the ringtone and volume of the bell,
adjust the viewer contrast, to program the hour and date, to activate or disable the
tones of confirmation, validation and error, and to select the Code of Operator of
Telefónica.
These adjustments are carried out with the telephone handset down and by pressing
the Marcar/Menú key (21) repeated times until selected function is displayed in the
viewer.
Press the Marcar/Menú key (21) until
the message appears in the viewer.
With the keys cursorpq (20) one
of the three available ring tones can
be selected and will be heard during
selection.
Press Desactivar/Salir (4) when
selection is complete.
Press the key Marcar/Menú (21), until
the Timbre option is shown in the
viewer.
With the keyspq (20), select high
level or low level of sound. In the
viewer the selected level will be
shown as a message, and with an
Black bell icon (high) or half Black bell
(low).
Selection of
the melody
tones
Selection
bell level
sound
CAMBIO RING: é
TIMBRE: êHIGH é
TIMBRE: êLOW é

88
88
899
99
9
DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee
Press Desactivar/Salir (4) to return to
the normal display.
Press the Marcar/Menú key (21) until
the message appears in the viewer.
Press the pq keys (20) to increase
or decrease the contrast. The level
selected will be shown in the viewer.
Press the Desactivar/Salir key (4) to
return to the normal display.
Press the Marcar/Menú key (21) again
until PULSE HORA/FEC. Is displayed.
With the handset down adjust the hour
and date by typing them directly into
the keyboard. If you make a mistake,
use the Borrar key (17) to Erase.
For example, if the hour and date is
the 20th. of November and 2:11am,
type: 20100211.
Once the last digit of the date has
been typed, the new hour and date
will be displayed in the viewer. If the
process is not completed, the previous
and date will remain displayed.
After finishing this operation, you will
be able to select the next option by
pressing the Marcar/Menú (21) key
again, or return to the normal display
by pressing the Desactivar/Salir key
(4).
Remember, if you have the caller
Identification service enabled, when
receiving a call, the hour and date
display will be adjusted automatically.
Adjusting
the contrast
of the viewer
Setting the
hour and
dates
This Menu option lets you activate
or deactivate the beep tone, which
sounds when you press a key.
Press the Marcar/Menú key (21) until
the viewer shows one of the following
messages. If the beep has already
been activated, this message
appears in the viewer.
If the beep has already been de-
activated, this message appears in
the viewer.
Using the cursor keys pq(20) you
can activate or deactivate the beep.
Press the Desactivar/Salir key (4) to
return to the normal display in the
viewer.
This Menu option allows you hear
validation and error tones. The
validation tone is a long tone which
indicates that a function has been
executed correctly. If the operation
was incorrect, three short tones will
be heard.
Press the Marcar/Menú key (21) until
the viewer shows one of the following
messages. If the validation and error
tones are activated, this message is
shown in the viewer.
If the tones are disabled, this
message is shown in the viewer.
Using the cursor keys pq (20) you
can activate or deactivate the
validation and error tones.
Press the Desactivar/Salir key (4) to
return to the normal display in the
viewer.
Tone
confirmation
of a pressed
key
Validation
and error
tones
CONTRAST. éê
HORA/FEC PULSE.
HORA/FEC PULSE.
SONIDOS TECLA: SI
SONIDOS TECLA: NO
SONIDOS V/E: SI
SONIDOS V/E: NO

1010
1010
10 1111
1111
11
DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee
Activating the 1077 code.
This option is disabled when you
receive your DOMO telephone. This
means that the numbers of missed
calls, etc. cannot be viewed in the
viewer.
To activate, press the Marcar/Menú
key (21) until this message is
displayed in the viewer -
Type the sequence: *1077#
In the viewer this message will appear
for 2 seconds -
You can abandon programming by
pressing the key Desactivar/Salir (4),
in which case the configuration will not
have been changed.
Deactivating the 1077 code.
Press the Marcar/Menú key (21). If the
Code 1077 is already activated, this
message will be displayed in the
viewer.
Type the sequence: #1077 #.
In the viewer, this message will be
displayed for 2 seconds -
If #1077# has not been typed
correctly, the message in the viewer
will show -
Activation /
deactivation
of the 1077
code
DIALLING
Dialling with the handset down or in
hands free mode.
Pick up the hand piece or activate the
hands free function. Wait for the
dialling tone and then press the keys
for the required telephone number. As
you type, the numbers will be
displayed in the viewer.
Dialling with the hands free function
disabled.
Press the keys of required telephone
number, which will be shown in the
viewer as they are typed. To clear any
number incorrectly typed, press the
Borrar key (17).
To pick up the handset or activate the
free hands function, and then listen for
the dialling tone. Press the Marcar/
Menú key (21).
With any dialling type, the viewer will
display the length of time of the call
after the last digit has been typed.
You can zero the chronometer in any
time by pressing the key to Borrar key
(17). This chronometer doesn’t show
the real time of the duration of the call.
To stop dialling momentarily, press the
Rellamada/Pausa (13) key. There will
be a pause of 2 seconds.
If the DOME Messages Hands Free
apparatus is connected to a
switchboard, press the key R/A-a key
(8) followed by the extension number
to which the call has to be transferred.
Dialling
Instructions
To pause
during dialling
Transfer of
calls to an
extension
(R/A-a key)
ACTIVAR 1077
1077 ACTIVO
ACTIVAR 1077
DESACTIVAR 1077
1077 INACTIVO
DESACTIVAR 1077
1 2 3
4 5 6
7 8 9
*0 #
+
+
q p
LLamadas/
Volumen
Marcar/
Menu Borrar
+
q p
LLamadas/
Volumen
Marcar/
Menu Borrar
+
Grabar
Mute R/A - a
Rellamada Agenda
Pausa X)))
+
Grabar
Mute R/A - a
Rellamada Agenda
Pausa X)))

1212
1212
12 1313
1313
13
DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee
This way of dialling is carried out without
the necessity of using the numeric
keyboard, so that with the handset not
picked up, or with the activated or
disabled hands free function, it provides
three options.
Automatic Dialling from the
Phonebook.
See information on storing names and
numbers in the Phonebook on page 13
of this manual.
Automatic Dialling from list of
previous callers.
The DOMO Messages Hands Free
phone stores a chronologically list of
calls in its memory. To view the stored
numbers, do the following –
With the Handset down or picked up, or
with the disabled or activated hands free
function:
Press the Rellamada/Pausa (13) key.
Use the cursors keys pq(20) to find
the number to be called.
Once selected (you can put down the
handset or use the hands free function),
press the Marcar/Menú (21) key.
Automatic Dialling from the List of
Calls.
The DOMO Messages Hands Free has
a list of the last 50 calls (incoming and
outgoing) in chronological order. To
initiate this list, make sure that you have
ordered the caller Identification Service.
To automatically ring a number from the
stored list, do the following -
Automatic
Dialling.
- With the handset down or picked
up, or with the disabled or activated
hands free function :
Use the cursors pq (20) to select
the number to wish to call.
Once the number is selected (put
down the handset, or activate the
hands free function if you wish), press
the Marcar/Menú key (21) to begin
the call.
USING THE PHONEBOOK
The Phonebook has a maximum capacity of 50 entries into which you can type
numbers of up to 24 digits plus an associated name of 15 characters. Once entered,
a number and the associated name will be stored in alphabetical order in the
Phonebook.
You can make a Phonebook entry
during a conversation. This can be
done with the handset down or picked
up, or with the disabled or activated
hands free function.
Press the Grabar key (10) and this
message will be shown in the viewer.
A name is required for each entry as
each number is stored alphabetically.
Type the name (up to 15 characters)
using the letters on the numeric keys.
These keys offer the following
characters and numbers -
Key 1: 1. - > 1 i Key 7: P Q R S 7
Key 2: AB C 2 “ Ç Key 8: TU V 8 ? ü
Key 3: D E F 3 $ Key 9: W X YZ 9 ¿
Key 4: G H I 4 % Key *: * + ; ) ( •
Key 5: J K L 5 & Key 0: @ _ , ’ / o
Key 6: M N Ñ 0 6 Key #: (Space _) # : = <
Dialling from
the
Phonebook
o8! êMARINE ARAG
GRABAR NOMRE
FERNANDO ARAG
+
Grabar
Mute R/A - a
Rellamada Agenda
Pausa X)))

1414
1414
14 1515
1515
15
DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee
For example, to enter the letter S, press
the 7 key quickly four times.
Press the Grabar key (10) again to
record the name in the phonebook. The
viewer will display this message -
Enter the telephone number associated
with the name in up to 24 digits.
To conclude, press the Grabar key (l0)
to record the number. The viewer
display will now request the next name.
If you need to, you can enter another
name and number using the previous
instructions. If you have no more to be
entered, press the Desactivar/Salir key
(4) to return to the normal display.
With the handset down or picked up,
press the Rellamada/Pausa key (13).
Press the keys cursor pq (20) to select
the number that you want to record in
the Phonebook.
Press the Grabar key (l0) and the
viewer will display -
Type the name and press the Grabar
key (l0). The telephone will store the
name and number.
With the handset down or picked up,
or the hands free function disabled or
activated, press the cursor keys pq
(20) until you can see the number you
want to record in the Phonebook.
Press the Grabar key (l0) and in the
viewer this message will be displayed.
Type the name and press the Grabar
key (l0). The telephone will store the
name and number.
Recording
of the
rellamada in
the calendar
Recording
of the
rellamada in
the calendar
If the stored number has a name
associated with it, you can modify it
by typing it again. To conclude it press
Grabar key (l0).
Press the Agenda key (9).
Press the (7) key, which is the initial
of the name you want to find, or
several times, until in the viewer the
first name is displayed. If there is
more than one name starting with that
letter, press the cursor keys pq (20)
until it is found.
If the number shown has more than
15 digits, the symbols tuwill be
displayed to indicate that there is
additional information, which will be
shown after 4 seconds.
On the third line of the viewer, the
number of the alphabetical position
in the phonebook, will be displayed.
You can abandon the operation at any
time by pressing the Desactivar/Salir
key (4).
With the Handset up or down, or the
hands free function disabled or
activated:
Press the Agenda key (9).
Press the (7) key, which is the initial
of the name you want to find, or
several times, until in the viewer the
first name is displayed. If there is
more than one name starting with that
letter, press the cursor keys pq (20)
until it is found.
Using the
Phonebook
912397657
GRABAR NUMERO
GRABAR NOMBRE
GRABAR NUMERO
MIGUEL_
GRABAR NOMBRE
ç è
912397657
P:01
ç è
912397657234234
P:01
+
Grabar
Mute R/A - a
Rellamada Agenda
Pausa X)))

1616
1616
16 1717
1717
17
DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee
DIRECT SERVICES KEYS
Once the number is selected, put
down the handset, or activate the
hands free function, and press the
Marcar/Menú key (21) and the
number will be dialled.
While looking at a Phonebook entry,
pressing the Borrar key deletes that
entry. In the viewer a request for
confirmation will be displayed.
Press the # key to confirm, or press
Desactivar/Salir (4) to cancel.
Deleting a
Phonebook
entry
With the handset up or down and
with the hands free function
activated, listen for the dialling tone.
Press the Blue key (16).
See the viewer display.
With the handset up or down and
with the hands free function
activated, listen for the dialling.
Press the Red key (19).
See the viewer display.
Dial the number of the Telefónica
service required and with the handset
up or down and the hands free
function activated, press the Green
key (18).
The number of the Telefónica service
required will be prefixed to the
number you dialled and the call will
be started.
MUTE FUNCTION
You can also press the Green key
(18) with the handset down, to dial
the number, to pick up the handset
or to activate the hands free function
and to press the Marcar/Menú key
(21).
If it begins to dail after you put down
the handset in active hands free
function, press the Green key (18)
followed by the number.
During a call it is possible to turn off the sound to the speaker so that the speaker
cannot listen to you. To activate it:
Press the Mute key (14) during a
conversation.
In the viewer this message will be
displayed.
The Red light will blink slowly.
To disable this function and recapture
the conversation again, press the
Mute key (14) again.
In the viewer this message will be
displayed momentarily.
During the period while the Mute is
activated, you can use any of the
functions that you would normally
carry out with the taken handset down
or the active hands free function.
CONFIRMAR CON #
TELEFONICA
EMERGENCIA
1077912397657
OPERADOR
MUTE ACTIVO
MUTE INACTIVO
+
Grabar
Mute R/A - a
Rellamada Agenda
Pausa X)))
+
+
+

1818
1818
18 1919
1919
19
DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee
LISTENING TO ACALL
HANDS FREE FUNCTION
When a call is received, the sound will be that of the pre-selected tone and volume.
At the same time the Red light will be blinking.
To enter into conversation with the caller, pick up the handset or activate the hands
free function.
If you have requested the Caller Identification Service, you will see the telephone
number of the person calling displayed in the viewer. For more information on this
service, see page 20 of this manual.
The DOMO Messages Hands Free phone incorporates a speaker (15) and a
microphone (12) that allows you to speak and listen to the caller without having to
pick up the handset. The ))) key (11) will toggle this option between active and
disabled.
All the functions of the phone will remain active during the conversation in the hands
free way.
You can activate the hands free option
by pressing the ))) key (11) while the
handset is operating in picked up mode.
The Red light shows the hands free
mode is in operation, and you can
communicate with the caller (to See
remote 8) or begin a new call by means
of the dialling procedures described
previously.
If during hands free conversation it is
necessary to pick up the handset, the
viewer shows this message during the
following seconds.
If while maintaining a conversation
using the handset, you want to continue
the same one in hands free mode,
Activation
of hands
free mode
Changing
hands free
mode during
conversation
press the ))) key (11). The handset
is disabled and the conversation
continues in the hands free mode. The
viewer will display this message after a
few seconds -
To return to using the handset, simply
press the ))) key again (11).
While in the hands free mode, you can
end your conversation by pressings the
))) key (11). If however you are using
the telephone with the handset picked
up, you should press the ))) key (11).
Either way, the indicator light will go out.
During a conversation in hands free
mode, you can adjust the volume of the
speaker by pressing one of the cursor
pq keys (20) until in the viewer the
message is displayed (Corresponding
to the last level of recorded volume ).
Next you can increase the volume by
pressing the cursor pkey (20) or
diminish the volume by pressing the
cursor qkey (20).
During a conversation while using the
handset, you can adjust the volume of
the headphone. To do this press one of
the cursor pq keys (20) until this
message is displayed in the viewer.
(Corresponding to the last level of
recorded volume),
Next you can increase the volume by
pressing the cursor pkey (20) or
diminish the volume by pressing the
cursor qkey (20).
You will notice that the volume
adjustments of the speaker and
headphone are set independently.
Deactivating
the hands free
mode while in
conversation
Adjusting
the volume
of the speaker
Adjusting the
volume of the
handset
MICROTELEFONO
MANOS LIBRES
XVOLUMEN: é8ê
ÅVOLUMEN: é3ê
+
Grabar
Mute R/A - a
Rellamada Agenda
Pausa X)))
+
Grabar
Mute R/A - a
Rellamada Agenda
Pausa X)))
+
Grabar
Mute R/A - a
Rellamada Agenda
Pausa X)))

2020
2020
20 2121
2121
21
DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee
IDENTIFICATION OF CALL SERVICE
Requesting the Identification of Call service allows you to see in the viewer the callers
number (or name). This number remains displayed before you answer the call and
during it. It is necessary to have the Messages of Text (SMT) service activated.
When receiving the call, the number
of the caller is displayed.
If the caller’s number coincides with
one of those stored in the Phonebook,
and there is an associate name with
that number, the recorded name only
will be displayed. When picking up the
handset or using the hands free mode,
the number associated with that name
will be displayed. The hour and current
date are also displayed, which can be
viewed at a later time.
The number or name is displayed
during the whole conversation,
disappearing on hanging up the
handset or disabling the hands free
function, or if you perform another
operation during the conversation.
There may be a number of reasons for
the information not to be displayed in
the viewer. They could be -
- The caller doesn’t want to be identified.
- The identity of the caller cannot be
assertained (an example could be
international calls).
- The call is made from a public telephone
(from a different network).
With the handset picked up and with
the hands free function disabled, the
viewer displays the hour and date, the
total number of stored calls (received
and outgoing), the number of new
received calls from the last time it was
inspected, and the number of received
calls that have been repeated.
Information
in the viewer
(when the
indicator light
is not lit)
When new calls are received the Red
indicator light will flash to indicate a
call is waiting to be answered.
The indicator light will switch off
automatically when the call is
answered or the caller rings-off.
The phone can store up to 50 calls
(received and outgoing) and it can
update them with the handset picked
up or with the hands free disabled or
activated.
Press the key pq (20) to move
through the list of calls from the most
recent to the oldest or vice versa.
The viewer will display -
* On the first line is -
- the record number in the list.
- if the call was outgoing or incoming,
and if it is an assisted incoming call.
- Telephone number.
If the number coincides with one of
those stored in the Phonebook and
where there is an associate name, it
will display the name first, and later
the number after a few seconds.
If the number displayed is longer than
that which will fit in the viewer, the
symbols tor u, will be shown
indicating that you can assess the
remainder by using those keys.
Viewing the
incoming and
outgoing
calls.
912397657
NUMERO PRIVADO
No NO DISPONIBLE
TELEF. PUBLICO
20:00 02 11 10 63
02 ì917404119
02 î917404119
02üü
üü
üî917404119
LL.Espera Desvio LL a Tres
Contestador Mensajes Desactivar
Aceptar Salir
Z

2222
2222
22 2323
2323
23
DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee
On the second line of the viewer -
- Hours and dates (day and month) the
time the call was received or a call
was made.
- Indication of a repeated call.
If you want to make a call to any of the
stored numbers with the handset picked
up or in activate hands free function
mode, press the Marcar/ Menú key
(21).
The numbers on those that you have
dialled or assisted calls, are shown with
a tick symbol P to the right of the caller.
To return to the normal display, press
the Desactivar/Salir key (4) followed by
a por qkey (20) and allow time for it
to happen.
Deleting Call records -
Whilst looking at the Call entries in the
viewer, you can erase the current entry
by pressing the Borrar key (17). It will
be necessary to confirm the deletion of
the entry by pressing the # key.
Deleting all Call records -
With the handset picked up and hands
free function disabled, press the Borrar
key (17)
If call entries are not currently being
viewed, and are not displayed in the
viewer, confirmation is requested with
the # key.
If you have not viewed all the received
calls, you won’t be able to erase them.
If you want to cancel the operation,
press the Desactivar/Salir key (4).
Deleting
Calls
SUPPLEMENTARYSERVICES
The procedure is described in
‘Using the Phonebook’ starting on
page 13.
The following Supplementary Services have to be requested before they can become
available.
Activation
With the handset picked up or the
hands free function activated, press
the Desvio key (23).
Type the number that is to receive
your diverted calls.
Press the Desvio key again (23).
While the diversion number is
activated, an icon will be displayed.
When picking up the handset or in the
hands free mode, the number
displayed will be the one that the calls
have been diverted. While this service
is activated, you cannot receive Text
Messages (SMT).
Deactivation
With the handset lifted or the hands
free function activated -
Press the Desactivar/Salir key (4).
Press the Desvio key (23).
The icon will cease to be displayed in
the viewer.
Diverting
Incoming
Calls
Make a Record
in the
Phonebook
from the list of
received calls
01 üü
üü
üîFRANCISCO
BORRANDO
CONFIRMAR CON #
LL. SIN REVISAR
PULSE No + DESVIO
PULSE No + DESVIO
DESVIO
DESV. O CONTES?
DESVIO INACTIVO

2424
2424
24 2525
2525
25
DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee
IMPORTANT: The Redirect and Answering Machine can only be activated or
deactivated from your own DOMO Hands Free telephone. If you attempt to activate
and deactivate from different telephone or by means of the direct dialling codes of
performance from a keyboard of the services, the telephone viewer will not indicate
the correct situation of the service. Also if some failure of the telephone network
takes place during the selection of these services, once again the viewer will not
shown the correct situation.
To change the language of this service to English - see page 43.
Activation
Pick up the handset or using the hands
free function -
Press the Contestador key (2).
The Answering Machine icon will be
displayed in the viewer.
Deactivacion
Pick up the handset or using the hands
free function -
Press the Desactivar/Salir key (4).
Press the Contestador key (2).
The Answer Machine icon will cease to
be displayed.
If you have received calls and
messages that were stored in the
Answering Machine, the indicator light
will be lit in the viewer and a suitable
message will be displayed (if the
telephone network provides one).
To listen to messages -
Pick up the handset or using the hands
free function, press the Mensajes/
Aceptar key (3).
In the viewer this message appears -
ANSWERING
MACHINE
SERVICE
ACCESSING
the
ANSWERING
MACHINE
The Indicator Light will switch off after
a certain time when a messages is
received from another telephone.
During a conversation you can receive
a second call. You will hear tones
superimposed over your conversation
and the viewer will display the callers
number (if available from the
telephone network and providing Call
Identification has been requested).
To take the call –
Press the Ll Espera key (22). Wait a
moment.
In the viewer this message will be
displayed.
To get back to the first caller, press
the Ll Espera key (22). Wait a moment.
Pressing this key again will allow you
to talk with alternate callers.
To end the active conversation -
Press the Desactivar/Salir key (4)
Press the Ll Espera key (22). Wait a
moment.
You can have a conversation with
two people on different lines.
To enter into a three-way conversation
during a call -
Press the LI. a Tres key (5).
Type the second speaker’s number.
Once in conversation with the second
person, press LI. a Tres again (5).
CALL
WAITING
MAKING A
THREE-WAY
CALL
CONTEST.ACTIVO
DESV. O CONTES?
CONTES. INACTIVO
MENSAJES VOZ
OIR MENSAJES
LLAM. RETENIDA
PILSE LL. ESPERA
PULSE NUMERO

2626
2626
26 2727
2727
27
DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee
In the viewer this message will be
displayed -
together with these words -
The telephone network will confirm
that the function has been activated
with a periodic tone.
To conclude the three-way call, hang
up the handset or disable the hands
free function.
At any time you can separate the two
conversations -
Press the Ll Espera key (22) and wait
a moment.
Each press of the Ll Espera key (22)
will toggle between the other callers.
If during a communication you receive
a second call, you can enter into a
three-way conversation -
After pressing the Ll Espera key (22),
wait a moment.
Press the Ll a Tres key (5).
The process is the same as in the
previous case.
Once separated, the two conversa-
tions can completed with the one that
is in course -
Press the Desactivar/Salir key (4).
Press the Ll Espera key (22) and wait
a moment.
TEXT MESSAGING (SMT)
The DOMO Hands Free Messages telephone allows you to use the Text Messaging
service provided by the telephone network. This allows for -
- Receiving text messages (SMT) coming from other fixed terminals or mobiles
or from email addresses (*).
- Send text messages (SMT) to other fixed or mobile phones, and to email
addresses and Fax telephones (*).
(*) the telephone network may not offer all these options.
If two or more telephones are connected to the same line, to text messages, each
extension must be given a different extension number which must be between 1
and 9. As standard, the DOMO Hands Free Messages telephone is programmed at
the factory with the extension as 1. If it is necessary to change this number, see the
section on Change of Extension on page 29.
PLEASE NOTE: The relative information regarding the extension number for text
messages purposes is displayed in the viewer in the following way -
- If the extension number appears in brackets, the
phone cannot receive messages as another
telephone exists with the same extension
number. If it is the only extension with that
number, the extension number will be displayed
without brackets.
- If the extension number appears without
brackets, the telephone you will receive
messages on will be number 1.
Because each telephone can be used for more than an one user, the DOME Hands
Free Messages telephone also offers the option to receive and to send private
messages, to those 5 recipients that you will only have given high priority to. For
more information, consult the section on remote Private Mail on page 31.
To activate and configure the Messaging Service, use the following instructions -
All the performances in the Service of Messages of Text (SMT) are carried out
with the handset down and the hands free function disabled. The Mensajes/
Aceptar key (3) allows you to see the menu of Text Messages (SMT) and also
confirms any action needed. The cursor keys pand q(20) allow you to navigate
through the different menu options. To return to the previous screen, press the
Desactivar/Salir key (4).
LLAM. ATRES
LLAMADA A TRES
LLAM. RETENIDA
LLAM RETENIDA
LLAMADA A TRES
PULSE LL. ESPERA
TELEFONICA (1)
TELEFONICA 1
TELEFONICA 1

2828
2828
28 2929
2929
29
DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee
Activating Text Messaging Service
With the handset down and the hands
free function disabled, press the
Mensajes/Aceptar key (3) to view the
text messaging menu. Next press the
cursor keys pand q(20) until in the
viewer the following message is
displayed -
Only on the first occasion that you
press the Mensajes/Aceptar key (3)
will you be offered this option.
To activate the Service, press the
Mensajes/Aceptar key (3) and you will
be requested to type the extension
number of the terminal.
During this request, the last stored
extension number will be displayed. If
a terminal with that number already
exists the terminal will suggest another
number. Press the Mensajes/Aceptar
key (3) and a message will be
displayed showing the proposed
extension number.
To confirm this extension number,
press the Mensajes/Aceptar key (3)
again to continue.
Wait until the viewer displays this
message –
This message will remain displayed for
several seconds.
In the case of a problem that doesn’t
allow to activation of the service, an
error message (see page 39) will be
displayed for several seconds. You will
then be able to retry the operation by
pressing the Mensajes/Aceptar key (3).
To
ACTIVATE
or DISABLE
the Text
Messaging
Service
(SMT)
If at any time before confirming the
activation (detailed below), you want
to stop the process, press the
Desactivar/Salir key (4).
If you want to connect your
DOMO Free Hands Messages
telephone to the Text Messaging
Service (SMT) to a different
telephone extension number, it
must first be disconnected from
the previous extension number.
Deactivation of Service of
Messages of Text (SMT)
With the handset down and the hands
free function disabled, press the
Mensajes/Aceptar key (3). Next press
the cursor keys pand q(20) until
the viewer displays this message -
If you want to disable the Service,
press the Mensajes/Aceptar key (3).
Wait until the viewer displays this
message -
This message will remain for several
seconds.
In the case of a problem that doesn’t
allow you to activate the service, the
viewer will show an error message
(page 39) for several seconds,
followed by this message -
You can retry the operation by pressing
the Mensajes/Aceptar key (3).
If you use more than one extension
on the same telephone line for Text
Messaging, each extension must have
a different extension number, between
1 and 9.
CHANGING
THE
EXTENSION
NUMBER
ç è
ACTIVAR SMT
ACTIVAR EXT (1)
ESPERE
ACTIVADO
TELEFONICA (1)
ACTIVAR (1)
EXTENSION: ¿1?
DESACTIVAR SMT
ESPERE
DESACTIVADO
ç è
DESACTIVAR SMT

3030
3030
30 3131
3131
31
DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee
If you have already activated the
Text Messaging Service (SMT)
and you need to change the
extension number, first you must
first disable the service from the
current number before
proceeding with the change.
To change the extension number
follow these instructions -
With the handset down and the hands
free function disabled, press the
Mensajes/Aceptar key (3). Press the
cursor keys pand q(20) until this
option is displayed in the viewer -
Press the Mensajes/Aceptar key (3)
and you will be requested to assign a
new number.
The last stored extension number will
be displayed in the viewer. If an
extension already exists with the
number requested, the telephone will
offer an alternative number. Press the
Mensajes/Aceptar key (3) and a
message will appear showing the
proposed extension number.
To confirm the new number, press the
Mensajes/Aceptar key (3).
Wait until this message is displayed in
the viewer -
The message will remain displayed for
several seconds.
If there is a problem that doesn’t allow
activation of the service, an error
message (page 39) will be displayed
for several seconds. You will be able
to retry the operation by pressing the
Mensajes/Aceptar key (3).
The DOMO Hands Free Messages
telephone allows you to receive and
send up to 5 ‘private mail’ messages,
to those who have access to such mail,
and who have been defined using the
following parameters -
Name: Identification of a user with
private mail. This parameter can
consist of 1, 2, 3 or 4 characters.
Pin Number: This allows a user of
private mail to read messages having
first keyed in an easy to remember
security number. This parameter is
numeric and consists of 4 digits.
Next, you can see how to create, edit
and erase Private Mail.
With the handset down and the hands
free function disabled, press the
Mensajes/Aceptar key (3) to view the
menu of text messages (SMT). Then
press the cursor keys pand q(20)
until the viewer displays this message.
To continue, press the Mensajes/
Aceptar key (3) and this message will
be displayed -
Again press the Mensajes/Aceptar key
(3) and you will be requested to type
the user’s name. This is done using the
characters on the numeric keyboard
(7), This can consist of 1, 2, 3 or 4
characters. When complete, press the
Mensajes/Aceptar key (3). If the name
already exists, the viewer will display -
You will then be requested to enter the
user’s name again.
Next enter the security number
consisting of 4 digits. Press the
Mensajes/Aceptar key (3). Once
created, it will be displayed again.
PRIVATE
MAIL
To create
user
ç è
CAMBIAR EXTENS.
EXTENSION: ¿1?
ACTIVAR EXT (2)
ESPERE
ACTIVADO
TELEFONICA (2)
ACTIVAR (2)
ç è
CORREO PRIVADO
ç è
CREAR USUARIO
ç è
CORREO PRIVADO
¿NOMBRE?
JOSE
ERROR: YA EXISTE
¿CLAVE?
1234

3232
3232
32 3333
3333
33
DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee
To modify the name and/or the key
associated to a recipient of private
mail, access the submenu ‘Correo
Privado’ using the cursor keys pand
q(20) and press the Mensaje/
Aceptar key (3) and follow the
instructions for remote ‘Correo
Privado’ on page 31.
When displayed in the viewer, press
the Mensajes/Aceptar key (3).
Next the viewer will display a list of
names that they have already been
created and stored. Using the cursor
keys pand q(20), select the name
to be modified, and when found, press
the Mensajes/Aceptar key (3).
Change the name as required using
the characters on the numeric
keyboard (7), and press the Mensaje/
Aceptar key (3) when complete.
If you need to erase all the name, use
the Borrar key (17). Type the new
name using the characters on the
numeric keyboard (7) and press the
Mensajes/Aceptar key (3).
The modified name will now be
displayed in the viewer.
The modified name will be displayed
in the viewer under the associated key.
You can modify it, erase the currently
displayed name and add a new name,
following the same procedure.
To confirm the modification, press the
Mensaje/Aceptar key (3).
To erase a user name, from the
‘Correo Privado’ menu (see page 31),
press the Mensajes/Aceptar key (3).
Using the cursor keys pand q(20)
access the ‘Borrar Usuario’ option and
press the Mensajes/Aceptar key (3).
To modify a
user name
To delete a
user name
Access the list of names that they
have already been created and
stored. Move through the list using the
cursor keys pand q(20) and select
the user name to be deleted.
Press the Mensajes/Aceptar key (3).
A confirmation key will be requested.
Type this key and press the
Mensajes/ Aceptar key (3) again.
The actions you take will be displayed
in the viewer.
If you type an incorrect confirmation
key, this massage will be displayed
in the viewer -
If you make a second mistake, the
operation will fail and this message
will be displayed -
Attempting a third try will erase all the
messages associated with the name.
If you have forgotten the key
associated with the name, an
emergency option is offered. Note
- all messages associated with
that name will also be erased.
When you are requested to enter
the key, type it 3 times.
With the handset down and the hands
free function disabled, press the
Mensajes/Aceptar key (3) to access
the menu of text messages (SMT).
Next press the cursor keys pand q
(20) until the name required is dis-
played in the viewer.
Press the Mensajes/Aceptar key (3)
and type the message text using the
characters on the numeric keyboard
(7). Amessages can be up to 640
characters in total, in blocks of 160
characters as indicated in the corner
SENDING A
MESSAGE
ç è
MODIF. USUARIO
¿CLAVE?
1234
JOSE
JUAN
1234
4321
ç è
BORRAR USUARIO
¿CLAVE?
1234
BARRANDO
CLAVE ERRONEA
OTRO FALLO
HOLA_
ç è
ENVIAR / EDITAR

3434
3434
34 3535
3535
35
DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee
of the viewer (e.g. 1 of 4). Once you
have typed over 160 characters, a
double envelope will also be displayed
in the main part of viewer. The
assignment of characters and
symbols on the keyboard are as
follows -
Key 1: 1 . - > 1 i Key 7: P Q R S 7
Key 2: AB C 2 “ Ç Key 8: TU V 8 ? ü
Key 3: D E F 3 $ Key 9: W X YZ 9 ¿
Key 4: G H I 4 % Key *: * + ; ) ( •
Key 5: J K L 5 & Key 0: @ _ , ’ / o
Key 6: M N Ñ 0 6 Key #: (Space) # : = <
You can change between uppercase
and lowercase (and vice versa) by
pressing the R/A-a key (8).
If correct a mistake, press the Borrar
key (17), which will delete the last
entered character.
If a message cannot be sent
immediately, it will be stored as
indicated in the viewer by a flashing
envelope *.
The DOMO Hands Free Messages
telephone allows you to send text
messages (SMT), e-mail and faxes.
Once you have typed a message, or
modified an existing one, pressing
Mensajes/Aceptar key (3) will allow
you to select the despatch format for
the message.
Text Messaging (SMT) is the default
option with E-MAIL and FAX being
accessed by using the pand qkeys
(20). The following instructions details
how to proceed for each of these
options.
1. - To send a Text Message (SMT)
When this message is displayed in the
viewer -
Choosing
the despatch
format
(Message,
E-Mail or
Fax)
Press the Mensajes/Aceptar key (3).
The user’s telephone number will be
requested. Type the number using the
numeric keyboard (7) or select it from
the Phone Book by pressing the
Agenda key (9). Press the Mensajes/
Aceptar key (3) again.
Next you will be asked (optionally) to
type the user’s name (for purposes of
creating a Private Message). Press the
Mensajes/Aceptar key (3) anyway.
Next the destination extension will be
requested (optional - if there is more
than one extension on the telephone
number). Press the Mensajes/Aceptar
key (3) anyway. The message will be
displayed in the viewer.
To complete despatch of the
message, press the Mensajes/
Aceptar key (3). Otherwise, press the
cursor keys pand q(20) until an M
is displayed.
Press the Mensajes/Aceptar key (3)
and use the cursor keys pand q(20)
to choose between the options to
keep or erase. Press the Mensajes/
Aceptar key (3) to confirm the
selected option.
2. - To send an E-mail
When the E-mail option is displayed
in the viewer, press the Mensajes/
Aceptar key (3). Type the email
address and press the Mensajes/
Aceptar key (3) again.
This message will be displayed -
To send the E-mail, press the
Mensajes/Aceptar key (3) and this
message will be displayed -
If you decide not to send the e-mail,
press the cursor keys pand q(20)
until this message is displayed -
ç è
ENVIAR MENSAJE
ç è
ENVIAR MENSAJE
DESTINATARIO
¿NOMBRE?
¿EXTENSION?
ENVIANDO
ENVIAR: NO
DESTINATARIO
ENVIANDO
ç è
ENVIAR: SI
ç è
ENVIAR: E-MAIL
ç è
ENVIAR: NO
ç è
ENVIAR: SI

3636
3636
36 3737
3737
37
DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee
Press the Mensajes/Aceptar key (3)
and choose between the options to
keep or erase. Press the Mensajes/
Aceptar key (3) again to confirm.
3. - To send a Fax
When this message is displayed -
Press the Mensajes/Aceptar key (3).
First the subject title will be requested
(optional). Type this, if required, in up
to 255 characters and press the
Mensajes/Aceptar key (3) anyway.
Next, the addressee’s number will be
requested. Type it using the characters
on the numeric keyboard (7) or select
it from the Phone Book by pressing
the Agenda key (9) and pressing the
Mensajes/Aceptar key again (3).
When this message is displayed -
To send the Fax, press the Mensajes/
Aceptar key (3). See this message -
If you decide not to send the Fax, use
the cursor keys pand quntil this
message is displayed -
Press the Mensajes/Aceptar key (3),
and select the option to keep or to
erase the message by using cursor p
and qkeys (20) and pressing the
Mensajes/Aceptar key (3) to confirm
the selected option.
If a message cannot be delivered, you
will receive a message indicating the
reason (disabled service, agreement
doesn’t exist with the operator, the
extension doesn’t exist, etc.).
At any time during the above process,
you can cancel the operation by
pressing the Desactivar/Salir key (4).
When a text message is about to be
received, the telephone will produce
a tone and display this message -
When the message is received, the
telephone gives a second tone,
indicating that the message has been
received correctly, and this message
will be displayed -
When a communication error
happens, the message will be -
The existence of new messages is
indicated in the viewer with flashing
envelope *.
To read messages, press the
Mensajes/Aceptar key (3) with the
handset down and the hands free
function disabled. The display will be -
Information about the message will
be listed -
1. The position of the message in the
list.
2. Symbols ! or üindicate if it is a new
or saved message, respectively.
3. The characters îor ìshows if it is
an incoming or outgoing message.
4. Next,
- if the message is incoming, and not
private, the sender’s number or
the name if it is in the Phone
Book.
- if it is a private incoming message,
private user’s name will appear
in brackets.
- if the message is outgoing, the
destination will appear which that
can be, a telephone number or
user’s name if it is in the Phone
Book, a fax number or an Internet
address.
RECEIVING
MESSAGES
READING
MESSAGES
ç è
ENVIAR FAX
ç è
ENVIAR SI
ç è
ENVIAR NO
¿ASUNTO?
DESTINATATIO
ENVIAR: NO
ESPERE...
RECIBIDO
ERROR RECEPCION
MENSAJES TEXTO
01! îALMUDENA
01! î91445566
01! îALMUDENA
01! î(ALMU)
02! üü
üü
üî91445566
02! üü
üü
üîROSA ROMERO
ç è
LEER

3838
3838
38 3939
3939
39
DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee DOMODOMO
DOMODOMO
DOMO MessaMessa
MessaMessa
Messagg
gg
ges Hands Fes Hands F
es Hands Fes Hands F
es Hands Frr
rr
reeee
eeee
ee
Pressing the cursor keys pand q(20)
you can move through the list of
messages from the most recent to the
oldest or vice versa.
Having selected a message, press the
Mensajes/Aceptar key (3) to view the
text and with the cursor keys pand
q(20) to access it.
If it is a private message, in the finder
this message will be displayed -
Type the security key (of 4 digits) and
press the Mensajes/Aceptar key (3).
If the key is correct, the number (or
name) will be displayed, followed by
the text. Move through the text using
the cursor keys pand q(20).
To leave the message, press the
Desactivar/Salir key (4).
If the message is incoming (received),
press the Mensajes/Aceptar key (3)
to displayed in the viewer, these
options - to Respond, to Forward, to
Erase and to Keep.
For outgoing messages, the options are
- to Forward, to Erase and to Keep.
Using the cursor keys pand q(20),
you can access any of them.
When this message is displayed – (as
indicated in the section on reading
Messages on page 37), press the
Mensajes/Aceptar key (3). To reply to
the message, proceed as detailed on
page 33.
When this message is displayed – (as
indicated in the section on reading
Messages page 37), press the
Mensajes/Aceptar key (3),and you
can modify the message content.
Press the Mensajes/Aceptar key (3)
and proceed as indicated in the
‘Despatch of Messages’ on page 34.
On seeing this message - (as
indicated in the section on Reading
Messages on page 37), press the
Mensajes/Aceptar key (3) and the
message will be deleted.
From the list of messages that have
been ‘Read’, access the message
required and press the Borrar key
(17) to Erase it. Confirm by pressing
the # key. You cannot erase
messages that have not been read.
On seeing this message - (as
indicated in the section on Reading
Messages on page 37), press the
Mensajes/Aceptar key (3), and it will
store the message.
During the activation or deactivation
of the text messaging service (SMT),
as well as during the despatch or
reception of a text message, the
following errors may occur -
1. Despatch Error - this error appears
if the message has not been
possible to despatch because of
communication failure. In the
viewer this message will be
displayed for a few seconds.
2. Error - service not activated This
error happens when you try to send
a text message without first
activating the service. Displayed in
the viewer will be -
3. Destination Error - when the
addressee doesn’t have the text
messaging service activated. The
message in the viewer will be -
To erase
messages
To keep
messages
Error types
01! üü
üü
üî(PEPE)
¿CLAVE?
1234
ç è
REPONDER
ç è
REENVIAR
ç è
BORRAR
ç è
GUARDAR
ç è
RESPONDER
ç è
REENVIAR
BORRANDO
CONFIRME CON #
BORRANDO
GUARANDO
ERROR ENVIO
ç è
BORRAR
ç è
GUARDAR
ERROR, ACTIVESE
ERROR DESTINO
Table of contents
Other TELEFONICA Telephone manuals

TELEFONICA
TELEFONICA Office 25 Instruction manual

TELEFONICA
TELEFONICA Domo2 Instruction Manual

TELEFONICA
TELEFONICA Office 10 Instruction manual

TELEFONICA
TELEFONICA 1002 User manual

TELEFONICA
TELEFONICA Office 45 Instruction manual

TELEFONICA
TELEFONICA O2 Navigace User manual

TELEFONICA
TELEFONICA Telefono DOMO User manual
Popular Telephone manuals by other brands

Vimar
Vimar ELVOX Due Fili Plus K40515.M Installation and operation manual

Louroe Electronics
Louroe Electronics AOP-SP-E Installation and operating instructions

Jabra
Jabra GN 9050 user guide

Yealink
Yealink CP900 manual

Siemens
Siemens Gigaset SX303isdn user guide

Panasonic
Panasonic KX-T7720E Quick reference guide
