Telestream PRISM MPI2-25 Manual

071-3730-00B
PRISM MPI2-25
Media Analysis Platform
Installation and Safety Instructions
This document supports software version 2.1 and above.
www.telestream.net

Copyright © 2020 Telestream, LLC and its Affiliates. All rights reserved. Telestream products are covered by U.S. and foreign
patents, issued and pending. Information in this publication supersedes that in all previously published material. Specification
and price change privileges reserved.
TELESTREAM is a registered trademark of Telestream, LLC. All other trade names referenced are the service marks,
trademarks, or registered trademarks of their respective companies.
Telestream products are covered by U.S. and foreign patents, issued and pending. Information in this publication supersedes
that in all previously published material. Specifications and price change privileges reserved.
TELESTREAM is a registered trademark of Telestream, LLC.
Contact Telestream
Telestream
848 Gold Flat Roadwa
Nevada City, CA 95959
USA
For product information, sales, service, and technical support:
Worldwide, visit www.telestream.net/telestream-support/video/support.htm to find contacts in your area.

Warranty
Telestream on behalf of itself and its Affiliates (“Telestream”) warrants that this product will be free from defects
in materials and workmanship for a period of one (1) year from the date of shipment. If any such product proves
defective during this warranty period, Telestream, at its option, either will repair the defective product without
charge for parts and labor, or will provide a replacement in exchange for the defective product. Parts, modules
and replacement products used by Telestream for warranty work may be new or reconditioned to like new
performance. All replaced parts, modules and products become the property of Telestream.
In order to obtain service under this warranty, Customer must notify Telestream of the defect before the
expiration of the warranty period and make suitable arrangements for the performance of service. Customer
shall be responsible for packaging and shipping the defective product to the service center designated by
Telestream, with shipping charges prepaid. Telestream shall pay for the return of the product to Customer if the
shipment is to a location within the country in which the Telestream service center is located. Customer shall be
responsible for paying all shipping charges, duties, taxes, and any other charges for products returned to any
other locations.
This warranty shall not apply to any defect, failure or damage caused by improper use or improper or
inadequate maintenance and care. Telestream shall not be obligated to furnish service under this warranty a) to
repair damage resulting from attempts by personnel other than Telestream representatives to install, repair or
service the product; b) to repair damage resulting from improper use or connection to incompatible equipment;
c) to repair any damage or malfunction caused by the use of non- Telestream supplies; or d) to service a
product that has been modified or integrated with other products when the effect of such modification or
integration increases the time or difficulty of servicing the product.
THIS WARRANTY IS GIVEN BY TELESTREAM WITH RESPECT TO THE PRODUCT IN LIEU OF ANY
OTHER WARRANTIES, EXPRESS OR IMPLIED. TELESTREAM AND ITS VENDORS DISCLAIM ANY
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
TELESTREAM’S RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE SOLE AND
EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR BREACH OF THIS WARRANTY.
TELESTREAM AND ITS VENDORS WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL,
OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER TELESTREAM OR THE VENDOR HAS
ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.
[W2 – 15AUG04]

TELESTREAM SOFTWARE LICENSE AGREEMENT
THE PROGRAM, OR PROGRAMS, ENCODED OR INCORPORATED WITHIN EQUIPMENT OR ACCOMPANYING
THIS AGREEMENT, IS FURNISHED SUBJECT TO THE TERMS AND CONDITIONS OF THIS AGREEMENT.
RETENTION OF THE PROGRAM FOR MORE THAN THIRTY DAYS OR USE OF THE PROGRAM IN ANY
MANNER WILL BE CONSIDERED ACCEPTANCE OF THE AGREEMENT TERMS. IF THESE TERMS ARE NOT
ACCEPTABLE, THE UNUSED PROGRAM AND ANY ACCOMPANYING DOCUMENTATION SHOULD BE
RETURNED PROMPTLY TO TELESTREAM FOR A FULL REFUND OF THE
LICENSE FEE PAID. (FOR INFORMATION REGARDING THE RETURN OF PROGRAMS ENCODED OR
INCORPORATED WITHIN EQUIPMENT, CONTACT THE NEAREST TELESTREAM SALES OFFICE.)
DEFINITIONS
"Telestream" means Telestream, LLC, a Delaware limited liability company, and its Affiliates , or the local Telestream
legal entity that is supplying the equipment. "Program" means the Telestream software product (executable program
and/or data) enclosed with this Agreement or included within the equipment with which this Agreement is packed.
"Customer" means the person or organization in whose name the Program was ordered.
LICENSE
Customer may:
1. Use the Program on a single machine at any one time; and
2. Copy the Program for archival or backup purposes, provided that no more than one (1) such copy is permitted to exist
at any one time. Each copy of the Program made by Customer must include a reproduction of any copyright notice
or restrictive rights legend appearing in or on the copy of the Program as received from Telestream.
Customer may not:
1. Use the Program on more than one machine at any one time;
2. Transfer the Program to any person or organization outside of Customer or the corporation of which Customer is a
part without the prior written consent of Telestream, except in connection with the transfer of the equipment
within which the programs are encoded or incorporated;
3. Export or re-export, directly or indirectly, the program, any associated documentation, or the direct product thereof, to
any country to which such export or re-export is restricted by law or regulation of the United States or any foreign
government having jurisdiction without the prior authorization, if required, of the Office of Export Administration,
Department of Commerce, Washington, D.C. and the corresponding agency of such foreign government;
4. Modify the Program, create derivative works, or merge the Program with another program;
5. Reverse compile or disassemble the Program for any purpose, beyond the extent that such activity is expressly
permitted by applicable open source licenses or applicable law notwithstanding this limitation; or
6. Copy the documentation accompanying the Program.
For Programs designed to reside on a single-machine and support one or more additional machines, either locally or
remotely, without permitting the Program to be transferred to an additional machine for local execution, the additional
machines shall be considered within the definition of "single machine." For programs permitting the Program to be
transferred to an additional machine for local execution, a separate license shall be required for each such machine with
which the Program may be used. Title to the Program and all copies thereof, but not the media on which the Program or
copies may reside, shall be and remain with Telestream or others for whom Telestream has obtained a respective
licensing right. Customer shall pay when due all property taxes that may now or hereafter be imposed, levied or assessed
with respect to the possession or use of the Program or this license and shall file all reports required in connection with
such taxes. If the Program or any related documentation is acquired by or for an agency of the U.S. Government, the
Program and documentation
shall be considered “commercial computer software” or “commercial computer software documentation” respectively,
as those terms are used in 48 CFR §12.212, 48 CFR §227.7202, or 48 CFR §252.227-7014, and are licensed with only
those rights as are granted to all other licensees as set forth in this Agreement.

THE PROGRAM MAY NOT BE USED, COPIED, MODIFIED, MERGED, OR TRANSFERRED TO ANOTHER
EXCEPT AS EXPRESSLY PERMITTED BY THESE TERMS AND CONDITIONS. UPON TRANSFER OF ANY COPY,
MODIFICATION, OR MERGED PORTION OF THE PROGRAM, THE LICENSE GRANTED HEREIN IS
AUTOMATICALLY TERMINATED WITH RESPECT TO THE PARTY THAT TRANSFERS THE PROGRAM.
TERM
The license granted herein is effective upon acceptance by Customer, and shall remain in effect until terminated as
provided herein. The license may be terminated by Customer at any time upon written notice to Telestream. The license
may be terminated by Telestream or any third party from whom Telestream may have obtained a respective licensing
right if Customer fails to comply with any term or condition and such failure is not remedied within thirty (30) days after
notice hereof from Telestream or such third party. Upon termination by either
party, Customer shall return to Telestream or destroy, the Program and all associated documentation, together with all
copies in any form.
LIMITED WARRANTY
The Program is provided "as is" without warranty of any kind, either express or implied. Telestream does not warrant
that the functions contained in the Program will meet Customer's requirements or that the operation of the Program will
be uninterrupted or error-free.
TELESTREAM AND ITS VENDORS DISCLAIM ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE. LIMITATION OF LIABILITY, IN NO EVENT SHALL TELESTREAM OR
OTHERS FROM WHOM TELESTREAM HAS OBTAINED A LICENSING RIGHT BE LIABLE FOR ANY INDIRECT,
SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES ARISING OUT OF OR CONNECTED WITH
CUSTOMER'S POSSESSION OR USE OF THE PROGRAM, EVEN IF TELESTREAM OR SUCH OTHERS HAS
ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.
THIRD-PARTY DISCLAIMER
Except as expressly agreed otherwise, third parties from whom Telestream may have obtained a licensing right do not
warrant the program, do not assume any liability with respect to its use, and do not undertake to furnish any support or
information relating thereto.
GENERAL
This Agreement contains the entire agreement between the parties with respect to the use, reproduction, and transfer of
the Program. Neither this Agreement nor the license granted herein is assignable or transferable by Customer without the
prior written consent of Telestream. This Agreement and the license granted herein shall be governed by the laws of the
state of California. nAll questions regarding this Agreement or the license granted herein should be directed to the
nearest Telestream Sales Office.

i
Table of Contents
Important compliance and safety information ....................................................................................................ii
Preface..............................................................................................................................................................ix
Product description ...................................................................................................................................ix
Documentation..........................................................................................................................................xi
Conventions used in this manual ..............................................................................................................xi
Installation......................................................................................................................................................... 1
Initial product inspection ........................................................................................................................... 1
Accessories............................................................................................................................................... 2
Operating requirements ............................................................................................................................ 3
Portable cabinet and dual rack cabinet installation................................................................................... 5
Connectors................................................................................................................................................ 6
SFP module installation ............................................................................................................................ 8
Power-on and power-off procedures......................................................................................................... 9
Operation ........................................................................................................................................................ 12
Display elements..................................................................................................................................... 12
Methods of operation .............................................................................................................................. 13

ii
PRISM MPI2-25 Installation and Safety Instructions
Important compliance and safety information
United States of America Compliance Notices
Class A Interference Statement
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
Part 15, Subpart B of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a commercial installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. Operation of this equipment in a residential area is likely to cause harmful interference
in which case the user will be required to correct the interference at his own expense.
FCC Caution
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
Safety
UL 61010-1: 2012 R4.16: Safety Requirements for Electrical Equipment for Measurement, Control, and
Laboratory Use - Part 1: General Requirements.
Environmental
Perchlorate Materials: this product contains one or more type CR lithium batteries. According to the state of
California, CR lithium batteries are classified as perchlorate materials and require special handling.
See www.dtsc.ca.gov/hazardouswaste/perchlorat for additional information.
Canada Compliance Notices
Department of Communications Radio Interference Regulations
This digital apparatus does not exceed the Class A limits for radio-noise emissions from a digital apparatus
as set out in the Radio Interference Regulations of the Canadian Department of Communications. This
Class A digital apparatus complies with Canadian ICES-003.
Reglement sur le brouillage radioelectrique du Quadstere des Communications
Cet appareil numerique respecte les limites de bruits radioelectriques visant les appareils numeriques de
classe A prescrites dans le Reglement sur le brouillage radioelectrique du Quadstere des Communications
du Canada. Cet appareil numerique de la Classe A est conforme a la norme NMB-003 du Canada.
Safety
CAN/CSA-22.2 NO. 61010-1-12 + Gil + Gl2:: Safety Requirements for Electrical
Equipment for Measurement, Control, and Laboratory Use - Part 1: General
Requirements.
Sécurité
CAN / CSA-22.2 NO. 61010-1-12 + Gil + Gl2 :: Exigences de sécurité pour l'électricité

PRISM MPI2-25 Installation and Safety Instructions
iii
Matériel de mesure, de contrôle et d'utilisation en laboratoire - Partie 1: Généralités
Exigences.
European Union and European Free Trade Association (EFTA) Compliance
Notices
This equipment may be operated in the countries that comprise the member countries of the European
Union and the European Free Trade Association. These countries, listed in the following paragraph, are
referred to as The European Community throughout this document:
AUSTRIA, BELGIUM, BULGARIA, CYPRUS, CZECH REPUBLIC, DENMARK, ESTONIA, FINLAND,
FRANCE, GERMANY, GREECE, HUNGARY, IRELAND, ITALY, LATVIA, LITHUANIA, LUXEMBOURG,
MALTA, NETHERLANDS, POLAND, PORTUGAL, ROMANIA, SLOVAKIA, SLOVENIA, SPAIN, SWEDEN,
UNITED KINGDOM, !CELANO, LICHTENSTEIN, NORWAY, SWITZERLAND
Declaration of Conformity
Marking by the “CE” symbol indicates compliance with the Essential Requirements of the EMC Directive of
the European Union 2014/30/EU
This equipment meets the following conformance standards:
Safety
EN 61010-1: Safety Requirements for Electrical Equipment for Measurement, Control, and Laboratory Use -
Part 1: General Requirements
Low Voltage Directive 2014/35/EU
Emissions
EN 55032: 2012 + AC: 2013, CISPR 32: 2015, EN 61000-3-2: 2014,
EN 61000-3-3: 2013
Immunity
EN 55103-2: 2009, EN 61000-4-2: 2009,
EN 61000-4-3: 2006 + Al: 2008 + A2: 2010, EN 61000-4-4: 2004 + Al: 2010,
EN 61000-4-5: 2006, EN 61000-4-6: 2009, EN 61000-4-11: 2004
Environments: E2
Warnings
Warning! This is a Class A product. In a domestic environment, this product may cause radio interference,
in which case, the user may be required to take appropriate measures.
Achtung! Dieses ist ein Gerat der Funkstorgrenzwertklasse A. In Wohnbereichen konnen bei Betrieb dieses
Gerates Rundfunkstorungen auftreten, in welchen Fallen der Benutzer fur entsprechende
Gegenmal3nahmen verantwortlich ist.
Attention! Ceci est un produit de Classe A. Dans un environnement domestique, ce produit risque de creer
des interferences radioelectriques, ii appartiendra alors a l?utilisateur de prendre les mesures specifiques
appropriees.
Notes:
1. For Compliance with the EMC standards listed here, high quality shielded interface cables should be used.
2. Emissions which exceed the levels required by this standard may occur when this equipment is connected
to a test object.
Environmental Compliance
This section provides information about the environmental impact of the product.

iv
PRISM MPI2-25 Installation and Safety Instructions
Product end-of-life handling
Observe the following guidelines when recycling an instrument or component:
Equipment recycling
Production of this equipment required the extraction and use of natural resources. The equipment may
contain substances that could be harmful to the environment or human health if improperly handled at the
product's end of life. To avoid release of such substances into the environment and to reduce the use of
natural resources, we encourage you to recycle this product in an appropriate system that will ensure that
most of the materials are reused or recycled appropriately.
This symbol on the product or its packaging indicates that this product complies with the applicable
European Union requirements according to Directives 2012/19/EU and 2006/66/EC on waste electrical and
electronic - equipment (WEEE) and batteries.
It also indicates that this product must not be disposed of with your other household waste. Instead, it is
your responsibility to dispose of your waste equipment by handing it over to a designated collection point for
the recycling of waste electrical and electronic equipment. The separate collection and recycling of your
waste equipment at the time of disposal will help conserve natural resources and ensure that it is recycled
in a manner that protects human health and the environment. For more information about where you can
drop off your waste for recycling, please contact your local authority, or where you purchased your product.
Battery Recycling
This product may contain a rechargeable battery, which must be recycled or disposed of properly. Please
properly dispose of or recycle the battery according to local government regulations.
Transporting Batteries or products with Batteries in them
The capacity of the lithium ion secondary battery shipped with this product is under 100 Wh. The lithium
content of the installed primary battery is under 1 g. Each battery meets the applicable requirements of UN
Manual of Tests and Criteria Part Ill Section 38.3. Battery quantity is under the limit for shipment according
to Section II of the relevant Packing Instructions from the IATA Dangerous Goods Regulations. Consult your
air carrier for applicability and determination of any special lithium battery transportation requirements.
Restriction of Hazardous Substances
This product is classified as an industrial monitoring and control instrument, and is not required to comply
with the substance restrictions of the RoHS 3 Directives 2011 /65/EU and EU 2015/863 until July 22, 2021.
This product does, however, comply with the RoHS 2 Directive 2011/65/EU.
Korea Compliance Statement

PRISM MPI2-25 Installation and Safety Instructions
v
Taiwan Compliance Statement
Japan Compliance Statement
Important Safety Information
This manual contains information and warnings that must be followed by the user for safe operation and to keep the
product in a safe condition.
To safely perform service on this product, see the Service safety summary that follows the General safety summary.
General Safety Summary
Use the product only as specified. Review the following safety precautions to avoid injury and prevent damage to this
product or any products connected to it. Carefully read all instructions. Retain these instructions for future reference.
Comply with local and national safety codes.
For correct and safe operation of the product, it is essential that you follow generally accepted safety procedures in
addition to the safety precautions specified in this manual.
The product is designed to be used by trained personnel only.
Only qualified personnel who are aware of the hazards involved should remove the cover for repair, maintenance, or
adjustment.
Before use, always check the product with a known source to be sure it is operating correctly.
While using this product, you may need to access other parts of a larger system. Read the safety sections of the other
component manuals for warnings and cautions related to operating the system.
When incorporating this equipment into a system, the safety of that system is the responsibility of the assembler of the
system.
To Avoid Fire or Personal Injury
Use proper power cord: Use only the power cord specified for this product and certified for the country of use. Do not use

vi
PRISM MPI2-25 Installation and Safety Instructions
the provided power cord for other products.
Ground the product: This product is grounded through the grounding conductor of the power cord. To avoid electric
shock, the grounding conductor must be connected to earth ground. Before making connections to the input or output
terminals of the product, ensure that the product is properly grounded. Do not disable the power cord grounding
connection.
Power disconnect: The power cord disconnects the product from the power source. See instructions for the location. Do
not position the equipment so that it is difficult to operate the power cord; it must remain accessible to the user at all
times to allow for quick disconnection if needed.
Observe all terminal ratings: To avoid fire or shock hazard, observe all rating and markings on the product. Consult the
product manual for further ratings information before making connections to the product. Do not apply a potential to any
terminal, including the common terminal, that exceeds the maximum rating of that terminal.
Do not operate without covers: Do not operate this product with covers or panels removed, or with the case open.
Hazardous voltage exposure is possible.
Avoid exposed circuitry: Do not touch exposed connections and components when power is present.
Do not operate with suspected failures: If you suspect that there is damage to this product, have it inspected by qualified
service personnel.
Disable the product if it is damaged. Do not use the product if it is damaged or operates incorrectly. If in doubt about
safety of the product, turn it off and disconnect the power cord. Clearly mark the product to prevent its further operation.
Before use, inspect voltage probes, test leads, and accessories for mechanical damage and replace when damaged. Do
not use probes or test leads if they are damaged, if there is exposed metal, or if a wear indicator shows.
Examine the exterior of the product before you use it. Look for cracks or missing pieces.
Use only specified replacement parts.
Do not operate in wet/damp conditions: Be aware that condensation may occur if a unit is moved from a cold to a warm
environment.
Do not operate in an explosive atmosphere.
Keep product surfaces clean and dry: Remove the input signals before you clean the product.
Provide proper ventilation: Refer to the manual's installation instructions for details on installing the product so it has
proper ventilation.
Slots and openings are provided for ventilation and should never be covered or otherwise obstructed. Do not push
objects into any of the openings.
Provide a safe working environment: Always place the product in a location convenient for viewing the display and
indicators.
Be sure your work area meets applicable ergonomic standards. Consult with an ergonomics professional to avoid stress
injuries.
Use only the Telestream rackmount hardware specified for this product.
Service Safety Summary
The Service safety summary section contains additional information required to safely perform service on the product.
Only qualified personnel should perform service procedures. Read this Service safety summary and the General safety
summary before performing any service procedures.
To avoid electric shock: Do not touch exposed connections.

PRISM MPI2-25 Installation and Safety Instructions
vii
Do not service alone: Do not perform internal service or adjustments of this product unless another person capable of
rendering first aid and resuscitation is present.
Disconnect power: To avoid electric shock, switch off the product power and disconnect the power cord from the mains
power before removing any covers or panels, or opening the case for servicing.
Use care when servicing with power on: Dangerous voltages or currents may exist in this product. Disconnect power,
remove battery (if applicable), and disconnect test leads before removing protective panels, soldering, or replacing
components.
Verify safety after repair: Always recheck ground continuity and mains dielectric strength after performing a repair.
Terms in the Manual
These terms may appear in this manual:
WARNING. Warning statements identify conditions or practices that could result in injury or loss of life.
CAUTION. Caution statements identify conditions or practices that could result in damage to this product or other
property.
Terms on the Product
These terms may appear on the product:
DANGER indicates an injury hazard immediately accessible as you read the marking.
WARNING indicates an injury hazard not immediately accessible as you read the marking.
CAUTION indicates a hazard to property including the product.
Symbols on the Product
When this symbol is marked on the product, be sure to consult the manual to find out the nature of the potential hazards
and any actions which have to be taken to avoid them. (This symbol may also be used to refer the user to ratings in the
manual.)
The following symbol(s) may appear on the product:
General Safety Product Specific Statements
Use the product only as specified. Review the following safety precautions to
avoid injury and prevent damage to this product or any products connected to it.
Carefully read all instructions. Retain these instructions for future reference.
Comply with local and national safety codes.
For correct and safe operation of the product, it is essential that you follow
generally accepted safety procedures in addition to the safety precautions specified
in this manual. The product is designed to be used by trained personnel only.
Only qualified personnel who are aware of the hazards involved should remove
the cover for repair, maintenance, or adjustment.
Before use, always check the product with a known source to be sure it is
operating correctly.

viii
PRISM MPI2-25 Installation and Safety Instructions
This product is not intended for detection of hazardous voltages.
Use personal protective equipment to prevent shock and arc blast injury where
hazardous live conductors are exposed.
When incorporating this equipment into a system, the safety of that system is the
responsibility of the assembler of the system.
WARNING. To prevent injury or death, power off the instrument and disconnect it from line voltage before cleaning.
WARNING. To reduce the risk of fire and shock, ensure that the mains supply voltage fluctuations do not
exceed 10% of the operating voltage range.
WARNING. In the instrument, only the line conductor is fused for over-current protection. The fuse is
internal and not user replaceable. Do not attempt to replace the fuse. If you suspect the fuse has blown,
return the unit to an authorized service center for repair.
CAUTION. To reduce risk of fire and shock, use the certified power cord provided with the product.
CAUTION. Damage to the instrument can occur if this instrument is powered on at temperatures outside the
specified temperature range.
CAUTION. To minimize the risk of damage to the instrument, we strongly recommend that the power
cord be connected to the instrument before the power cord is connected to the AC power source.

PRISM MPI2-25 Installation and Safety Instructions
ix
Preface
This manual describes how to install the PRISM Media Analysis Platform and provides basic safety and operating
information. Detailed operating information is available in the user manual. A complete list of PRISM documentation is
provided in this manual. (See Documentation.)
Product description
The PRISM Media Analysis Platform provides flexible options and field-installable upgrades to monitor a diverse variety of
SDI and IP statistics as well as video and audio content. The comprehensive feature set, along with an intuitive and simplified
graphical presentation of IP statistics, including video quality and diagnostic information, enables engineers to ensure the
delivery of superior QoS levels in an increasingly complex broadcast environment involving compressed/uncompressed
video transmission through SDI/IP signal paths. PRISM is an ideal solution for monitoring SDI/IP hybrid environments
including master control rooms, production studios, OB vans, and signal contribution/distribution centers.

x
PRISM MPI2-25 Installation and Safety Instructions
Features and benefits for analysis of hybrid IP/SDI infrastructures
•A comprehensive analysis and monitoring tool for a hybrid IP / SDI broadcast systems that
provides system evaluation for long term system quality monitoring and reporting
•All-in-one instrument within 3RU half rack platform with full HD 9-inch screen can be used for
either portable or rackmount applications
•Extensive IP monitoring solution for SMPTE 2022-6, 2110, PTP, and ASPEN streams
•Graphical displays that show the traffic present in the 10G Ethernet link, allowing engineers to
understand what is on their network and to easily select the stream of interest
•Select a stream to view and monitor the content using the Picture, Waveform, and Audio
applications, and listen to audio with headphones for conformance monitoring
•Detect IP packet errors, monitor the packet inter arrival time (PIT) and time stamped delay factor
(TS-DF) to allow engineers to observe issues that may cause intermittent loss of Video, Audio or
Data
•Monitor PTP trend graphs to ensure proper IP system setup for robust sync system
•Telestream patented Timing display showing the relative timing of the input signal and PTP
reference that makes facility timing easy
•1 PPS output when the instrument is locked to a PTP reference
•Seamless switching to ensure proper SMPTE 2022 and 2110 redundant system operation API to
control PRISM from system management software
•Multipoint or remote site monitoring allowing one engineer to quickly respond to issues from
multiple points in the system Optional 10 GbE line rate packet capture for offline analysis
•Optional SDI and ST2110 IP signal generators for testing new or changing facility configurations
The Picture application provides a full HD 9-inch screen that can be used for confidence
monitoring NMOS IS-04 / IS-05 support for network discovery and connection management
Features and benefits for production tools supporting 4K/UHD, WCG and HDR content creation
•A comprehensive production tool set supporting 4K / WCG / HDR content creation
•SDI / IP hybrid interface supporting up to 4K resolution, up to 2160p60 format support with 12G-
SDI / Quad 3G-SDI interface, and up to 1080p60 format with SMPTE 2022-6/7 and 2110.
•Stop display for monitoring video signals with a variety of transfer functions in a consistent
manner
•Vector display equipped with a 3D LUT conversion, allowing operators to match skin tones of
video signals to standard BT.709 vector locations and verify wide color gamut compatibility to
BT.709 color gamut
•12G-SDI physical layer measurements to check SDI signal quality and integrity

PRISM MPI2-25 Installation and Safety Instructions
xi
Documentation
Table 1: Product documentation
Document
Manual type
Part number
Availability
Print
Web
User Manual
User
D00010019x
Provides detailed operating information.
√
Release Notes
Release Notes
D00010030x
Describes the new features, improvements,
and limitations of the instrument firmware.
√
Installation and Safety
Instructions
User
071-3730-xx
Describes how to install a PRISM MPI2-
25 instrument and provides basic safety
and operating information (included with
instrument).
√
PRISM MPI Dual
Rack Cabinet Version
2 Installation
Instructions
Field Install
Instructions
071-3725-xx
Describes how to install an MPI
instrument in a 19” equipment rack
using the optional MPI-RACK-MM
or MPI-RACK-MW dual rack
cabinet.
√
√
PRISM MPI2-RACK-MD
Installation and Safety
Instructions
Field Install
Instructions
071-3728-xx
Provides installation and safety
information for the PRISM MPI2-RACK-
MD Rack Cabinet with touch display.
√
√
Conventions used in this manual
These icons may be used throughout this manual.
Sequence Step Front panel
power
Connect power Network SVGA USB

PRISM MPI2-25 Installation and Safety Instructions
1
Installation
Initial product inspection
Perform this product inspection procedure when you receive your instrument:
1. Inspect the shipping carton for external damage, which may indicate damage to the
instrument.
2. Remove the PRISM monitor from the shipping carton, and then check that the instrument
has not been damaged in transit. Prior to shipment the instrument is thoroughly inspected
for mechanical defects. The exterior should not have any scratches or impact marks.
NOTE. Save the shipping carton and packaging materials for instrument repackaging in case
shipment becomes necessary.
3. Verify that the shipping carton contains the instrument, the standard accessories, and
any optional accessories that you ordered. (See Accessories.)
4. Verify that all of the product options you ordered are installed:
a. After you install and power-on the instrument, select the Settings icon.
b. Select the Utilities bar.
c. Select the Options bar.
The display lists all the installed product options (for example, MP2-IP-MEAS) and the license
expiration dates. If an Expiration reads “None” then the license will not expire.
Exterior cleaning
The instrument exterior was inspected for debris when it was shipped. If necessary, you can clean
the exterior of the instrument as follows.
WARNING. To prevent injury or death, power off the instrument and disconnect it from line voltage
before cleaning.
Clean the exterior surfaces of the chassis with a dry lint-free cloth or a soft-bristle brush. If any dirt
remains, use a cloth or swab dipped in a 75% isopropyl alcohol solution. Use a swab to clean
narrow spaces around controls and connectors. Do not use abrasive compounds on any part of
the instrument that may be damaged by it.
CAUTION. Avoid the use of chemical cleaning agents that might damage the plastics used in the
instrument. Use only deionized water when cleaning the front-panel buttons. Do not use glass or
chemical cleaners on the LCD touchscreen. Use a lint-free soft cloth to wipe the screen. The cloth
can either be used dry or dampened with water or eyeglass cleaner. For the rest of the instrument,
use a 75% isopropyl alcohol solution as a cleaner and rinse with deionized water. Before using any
other type of cleaner, consult your Telestream Service Center or representative.

2
PRISM MPI2-25 Installation and Safety Instructions
Accessories
Table 2: Standard and optional accessories
Accessory Std. Opt. Telestream part number
PRISM MPI2-25 Installation and Safety Instructions
√
071-3730-xx
Power cord (See
International power cords
.)
√
NA
SFP and transceiver modules:
SD/HD/3G Optical (1310 nm) SDI SFP transmitter module (to be
installed into SDI SFP cage for optical SDI loop through output)
√ MP-SFP Opt. 3GTO
SD/HD/3G DIN SDI SFP transmitter module (to be installed into SDI
SFP cage for SDI loop through output with DIN coaxial connector)
√ MP-SFP Opt. 3GTD
SD/HD/3G HDBNC SDI SFP transmitter module (to be installed into
SDI SFP cage for SDI loop through output with HDBNC coaxial
connector)
√
MP-SFP Opt. 3GTH
10G Ethernet short range (850 nm) transceiver module
√
MP-SFP Opt. 10GESR
10G Ethernet long range (1310 nm) transceiver module
√
MP-SFP Opt. 10GELR
25G Ethernet short range (850 nm) transceiver module
√
MP-SFP Opt. 25GESR
25G Ethernet long range (1310 nm) transceiver module
√
MP-SFP Opt. 25GELR
Portable cabinet
√
MPI2-PTBL
Dual rack cabinet (19 inch, 3RU)
For one MPI2-25 unit or two MPI2-25 units side-by-side
√
MPI-RACK-MM
For one MPI2-25 unit or one MPI2-25 unit in a side-by-side installation
with a WFM52x0, WFM7200, WFM8x00 instrument
√
MPI-RACK-MW
International power cords. Your instrument was shipped with one of the following power
cord options. Power cords for use in North America are UL listed and CSA certified. Cords
for use in areas other than North America are approved by at least one authority acceptable
in the country to which the product is shipped.
•Opt. A0 – North America power cord
•Opt. A1 – Universal EUR power cord
•Opt. A2 – United Kingdom power cord
•Opt. A3 – Australia power cord
•Opt. A4 – 240 V, North America power cord
•Opt. A5 – Switzerland power cord
•Opt. A6 – Japan power cord
•Opt. A10 – China power cord
•Opt. A11 – India power cord
•Opt. A12 – Brazil power cord
•Opt. A99 1 – No power cord
1 When ordering the A99 option, it is the responsibility of the end user to ensure that a certified power cord, for the
country or region it is installed, is used with this instrument.
CAUTION. To reduce risk of fire and shock, use the certified power cord provided with the product.
