LogTag WHO USRID-16W1 Specification sheet

USRID-16W
W1 & W2 WHO Version
Single-use USB PDF Electronic
Shipping Indicator
LogTag Recorders
Product User Guide
Document Release Version: 1.0
Published 27. January 2021
Copyright © 2004-2021, LogTag Recorders
www. .com [e-mail]1.800.561.8187

USRID-16W User Guide 2
Contents
Introduction 5
Required Equipment 5
What's in the Box 5
Features 5
Case 6
Buttons 6
Display 6
PDF 6
Software Requirements 8
Configuring the USRID-16W for logging 9
Standard Configuration Options 9
Alarms 10
Advanced Configuration Settings 11
File Settings 11
Finalizing the configuration 12
USRID-16W Start Options 12
Display Overview 13
Operating the Logger 15
After the Logger is configured 15
Starting the Logger 15
During Recording 16
Stopping the USRID-16W 17
Reviewing Min/Max values and Alarms 19
Plugging the USRID-16W into a USB port 20
Accessing the files 22
Interpreting the Data 23
Data Evaluation - Report 23
Data Evaluation - Data List 26
Technical Specifications 28
Appendix 1 - Glossary 30
www. .com [e-mail]1.800.561.8187

USRID-16W User Guide 3
Safety Information
The USRID-16W USB temperature logger contains a non-
replaceable Lithium Battery. When the battery indicates “LOW”,
the logger should be replaced, and the battery recycled or disposed
of according to your local regulations.
Do not expose the logger to extreme temperatures as it may lead to
the destruction of the battery and may cause injuries.
Keep out of the reach of children.
Liability
LogTag Recorders’ standard warranty terms apply. A copy can be requested by emailing
. In addition, LogTag Recorders shall not be held liable
lif the device was used beyond LogTag Recorders’ stated limitations;
lfor any claims due to the improper storage and use of the device;
lfor any problems with refrigeration units;
lfor the bad quality of the monitored goods, if any;
lfor incorrect readings if the device was used with a low battery; or
lfor consequential loss.
Battery Life
The battery in the USRID-16W is designed to power the device for up to 20 days, provided
lthe device was not stored for more than 18 months prior to activation;
lthe device is stored and operated according to LogTag Recorders’ recommendations.
The USRID-16Wloggers are unable to record readings when connected to USB. You
cannot use a USB power supply to power the device!
The USRID-16W's data is accessible for 6 months from the end of the trip directly on the
display, and can be downloaded indefinitely when plugged into a USB port during the
product's lifetime.
Disclaimer
The USRID-16W loggers monitor temperature exposure and not the quality of the goods
they accompany. Their purpose is to signal a requirement for further investigation.
www. .com [e-mail]1.800.561.8187

USRID-16W User Guide 4
Typographical Conventions
Unless this document specifically mentions the models USRID-16W1 or USRID-16W2, the
text USRID-16W is used and refers to both models.
Text in this font refers to buttons on the USRID-16W.
Text in this font refers to option settings, dialogue boxes or actions to be taken in
LogTag® Analyzer.
Text in this font describes features of the product.
This text describes certain aspects of the product, where incorrect use of a feature
may lead to inadvertent loss of data.
This text contains important information for the correct operation of
your USRID-16W.
This text contains information that explains some aspects of a feature in more
detail.
This text contains tips that help you get the best out of your USRID-16W logger
www. .com [e-mail]1.800.561.8187

Introduction USRID-16W User Guide 5
Introduction
LogTag’s USRID-16W models are pre-configured, single use USB PDF temperature
indicators with a data logging function.They feature a display, which allows select
statistical data to be reviewed directly on the unit without the need for a PC. Trip reports
can be generated without the need to install proprietary software or hardware at the
destination.
Each model is pre-configured to the requirements of the WHO PQS Shipping Indicator
specification (while still allowing limited configuration using LogTag® Analyzer) ready to
be started and placed with the goods to be monitored . At the destination the USRID-16W
can be plugged straight into a computer’s USB port and generates a PDF file, which can be
accessed using PDF software such as Acrobat Reader. For further analysis, data can be
downloaded using the free companion software LogTag® Analyzer, where you can display
data in chart, list or summary formats.
Required Equipment
Aside from the LogTag® USRID-16W Single-use USB PDF Electronic Shipping Indicator
you will need the following items:
la PC running Windows 7 SP1 or later and LogTag® Analyzer installed if you wish to
configure or download the logger
la PC with PDF reader software installed for viewing the generated PDF files
What's in the Box
lUSRID-16W
lWaterproof backing card
l6-language instruction booklet
Features
The USRID-16W Single-use USB PDF temperature loggers feature the familiar LogTag case
layout with an additional USB plug at the bottom.
www. .com [e-mail]1.800.561.8187

Features USRID-16W User Guide 6
Case
lMounting lug for secure fastening of logger to fixtures
lUSB plug with protective cap - shields USB connector from moisture and dirt
lTemperature sensor located inside case
lDurable polycarbonate case, IP65
Buttons
lSTART/Mark button ( )
This is used to start the unit and place an inspection mark in the data.
lSTOP/Review button ( )
This is used to review recorded data at the end of the trip directly on the display and
to stop the unit.
Display
lShows the last recorded temperature and information about alerts
lAllows reviewing statistical data about the current trip
lShows trip duration and recording status

PDF
The USRID-16W will generate a detailed PDFreport when plugged into a USB port of a PC.
The PDF report shows a summary of the trip, presents the data in chart and list format. A
CSV file of the data list is also available.
www. .com [e-mail]1.800.561.8187

Features USRID-16W User Guide 7
The PDF can be shown in several different languages:
lEnglish
lFrench
lGerman
lRussian
lSpanish
The default ex-factory language is English. You can select which language to use during
configuration in the File Settings tab.
You can only change the language during configuration, but not when viewing the
PDF.
www. .com [e-mail]1.800.561.8187

Features USRID-16W User Guide 8
Software Requirements
Software requirements vary depending on the type of file you want the USRID-16W to
generate when plugged into a USB port.
If you wish to configure USRID-16W products you will need to download the LogTag®
Analyzer software from LogTag®’s web site at
. Follow the instructions to install
and start the software.
Please note that the USRID-16W is fully configured ex-factory, ready to start. Only
a limited number of parameters can be configured, for which you will need this
software.
If you only plan to view a report, plug the USRID-16W into a computer’s USB port.
Depending on the settings made during configuration, a number of on-board files will be
generated1 and made available to you in a new drive:
la PDF file
you can open the file directly from the logger‘s USB memory storage with Acrobat
Reader 4.0 or later, or any other compatible PDF reader software of your choice2
la CSV file
this file can be imported into a spreadsheet program such as Microsoft Excel
lan LTD file
LTD files are LogTag® Analyzer's native, encrypted data files. You can open this file
in LogTag® Analyzer, where you can analyze data in detail, generate report files or
combine data from multiple recorders for comparison
You can also download data directly into LogTag® Analyzer without accessing the logger‘s
on-board files.
1 Depending on the configuration, the USRID-16W may produce all, some or none of the files.
2 PDF files generated by any USB logger can be opened directly in LogTag® Analyzer.
www. .com [e-mail]1.800.561.8187

Configuring the USRID-16W for
logging USRID-16W User Guide 9
Configuring the USRID-16W for logging
Each USRID-16W model is delivered to you pre-configured with the prescribed WHO
recording profile, ready to be started.
The display is off. Briefly pressing the STOP/Review button shows:
Although the logger is already configured, you can make a limited number of adjustments
to the configuration. These include:
lAdding a description, which will show on the PDF report
lChanging the appearance of the PDF report
lChanging the language in which the PDF report will be printed
lSelecting which files are generated at the end of the trip
This is done using LogTag® Analyzer software, which can also be used for downloading and
analyzing data, using the following steps:
lStart the LogTag® Analyzer software.
lRemove the protective cap from the logger's USB connector, plug it into a USB
socket on your computer and wait for the drivers to be installed3.
lFrom the menu click LogTag - Configure; LogTag® Analyzer will display the
configuration options for connected loggers.
Standard Configuration Options
The only parameter in the standard configuration options you are permitted to customize
is the Description.
All other parameters are preset to the requirements of the WHO for shipping indicators:
Start Option: Push Button
Number of days to record: 20
Recording Interval: 5 minutes
Start delay: 1 hour
3 You can configure more than one USRID-16W at the same time, however it is practical to limit the number of units to about 6,
using a powered USB hub. www. .com [e-mail]1.800.561.8187

Configuring the USRID-16W for
logging USRID-16W User Guide 10
Alarms
Configuring alarms for WHO PQS qualified USRID-16W1 and USRID-16W2 models is not
permitted. The alarm trigger requirements are set out in the WHO/PQS/E006/TR07 PQS
performance specification for Electronic Shipping Indicators. Each indicator is configured
with 3 different alarm trigger conditions for temperature.
Alarm trigger conditions consist of a threshold temperature value, an activation type
(which can be instant, consecutive or accumulative) and a delay time. If an alarm trigger
condition requires readings to exceed an upper threshold temperature it is called an upper
alarm . If an alarm trigger condition requires readings to go below lower thresholds it is
called a lower alarm .
An alarm event is generated, when at least one of the alarm conditions is triggered. The
threshold values themselves are included in the alarm range, i.e. if an upper alarm
threshold is set at +30.0 °C, a value of +30.0 °C will trigger an alarm, but a value of 29.9 °C
will not.
According to the PQS specification, alarms are triggered for different models as follows:
Type 1 (Model USRID-16W1)
Programmed with alarm settings suitable for the international shipment of DTP, DT, TT,
Td, HepB, IPV, liquid Hib and combination vaccines, MenAfriVac, HPV, Pneumo (other than
Prevenar).
lUpper Alarm
Consecutive Readings of 45 °C or above for 1 hour (single event)
lUpper Alarm
Accumulative Readings of 30 °C or above for a total of 10 hours
lLower Alarm
Consecutive Readings of -0.5 °C or below for 1 hour (single event)
Type 2 (Model USRID-16W2)
Programmed with alarm settings suitable for the international shipment of BCG,
lyophilized Hib, measles, MR, MMR, meningitis (polysaccharide), OPV, rabies, rotavirus
(other than rotateq) and yellow fever vaccines shipped with frozen water-ice packs.
lUpper Alarm
Consecutive Readings of 45 °C or above for 1 hour (single event)
lUpper Alarm
Accumulative Readings of 30 °C or above for a total of 10 hours
lUpper Alarm
Accumulative Readings of 10 °C or above for a total of 20 hours
An alarm event is generated, when either of the entered alarm conditions is triggered.
www. .com [e-mail]1.800.561.8187

Configuring the USRID-16W for
logging USRID-16W User Guide 11
Advanced Configuration Settings
Configuring advanced settings typically available in other logger models is not permitted
for USRID-16W1 and USRID-16W2 models.
Following options are preset and cannot be changed.
lThe "Paused" function is disabled.
lThe display is always switched off after 30 seconds until the logger is started. Once
started, the display remains permanently on.
lResetting the trip's minimum and maximum values on the display during recording
is not permitted.
lClearing and resetting alarms with the START/Mark button is not permitted.
lAlarms always remain turned on, even if readings return to the normal temperature
range again.
lUsers have the ability to stop the logger with the STOP/Review button.
For more information about what each parameter means please read the section about
Configuring a LogTag® for logging in LogTag® Analyzer’s User Guide or press F1 for
help.
File Settings
Select the File Settings tab to select which files are generated when the USRID-16W is
plugged into a computer's USB port, and what information these files contain. Select as
many file formats as you wish to generate.
Please note that the USRID-16W1 and USRID-16W2 models can only display temperatures
in °C, are always reporting times in UTC and always produce a PDF file.
Figure 1: USRID-16W File settings screen in LogTag® Analyzer 3
These parameters influence the appearance of all files:
lDate and time format
lMKT values
Following specifically influences the appearance of the PDF file:
www. .com [e-mail]1.800.561.8187

USRID-16W Start Options USRID-16W User Guide 12
lScaling parameters for the chart
lShowing or hiding grid lines
lShowing or hiding alarm threshold lines
lDisplay language
lGenerating the data list
For detailed information about each parameter please read the section about Configuring a
LogTag® for logging in LogTag® Analyzer’s User Guide or press F1 for help.
The PDF file can not only be viewed in a PDF viewer, but can also be opened with
LogTag® Analyzer directly.
Finalizing the configuration
Click Configure to upload the configuration data to the USRID-16W.
When the configuration is complete, unplug the USRID-16W from the USB socket and
replace the protective cap.
If you wish to configure more USRID-16W units with the same configuration, insert the
next loggers into USB sockets, wait until they are ready for configuration and click Repeat
Configure.
You can upload the configuration to a USRID-16W logger as often as required, however
once started the unit cannot be configured again.
USRID-16W Start Options
USRID-16W1 and USRID-16W2 models are pre-configured for a push button start with a 1-
hour start delay. After you have gone through a specific start sequence of pressing and
releasing the START/Mark button (see Starting the Logger on page15), a 1-hour countdown
timer starts, during which no temperature readings will be recorded. The logger will start
recording and displaying temperature readings once the timer has ended.
Pre-start readings are not enabled.
www. .com [e-mail]1.800.561.8187

Display Overview USRID-16W User Guide 13
Display Overview
ALARM/OK indicator
The symbol is shown as soon as the USRID-16W has registered an alarm event.While there are
no alarms, or if a previous alarm has been cleared, the symbol is shown.
Recording indicators
The recording indicators show what the USRID-16W is currently recording.
lIf READY is shown, the USRID-16W is ready to be started with the START/Mark button.
lIf the word DELAY is shown, the logger has been started with a start delay.
The time in hours and minutes until the start is also shown.
lIf is shown, the USRID-16W is recording temperature at the sample interval defined.
lIf the word STOPPED is shown, the USRID-16W has finished recording temperature data.
MIN/MAX indicator
The word MAX is shown when the temperature on the display represents the maximum
recorded temperature for the current trip. The word MIN is shown when the temperature
on the display represents the minimum recorded temperature for the current trip.
Temperature Units
For USRID-16W1 and USRID-16W2 models, this shows °C.
Temperature Value
This shows the most recently recorded temperature while the USRID-16W is recording. Once the
logger has stopped, nothing will be displayed. During review, this will show minimum or maximum
temperatures. It will also show the threshold values when reviewing triggered alarms.
Alarm Threshold Arrows
An up-arrow ( ) is shown for each triggered alarm threshold. The arrows point to the
corresponding alarm value on the label and can represent an upper or lower alarm.
www. .com [e-mail]1.800.561.8187

Display Overview USRID-16W User Guide 14
Figure 2: Alarm arrows pointing to the alarm labels
Battery Low
The battery low symbol will appear if the USRID-16W's battery is low. If the symbol is not
shown while the display is turned on, the battery is still OK.
www. .com [e-mail]1.800.561.8187

Operating the Logger USRID-16W User Guide 15
Operating the Logger
The following sections show how to operate the product, and what information you can
expect to see on the display.
After the Logger is configured
The USRID-16W is pre-configured for a push button start, and the word READY is shown.
Low Battery
If at any time during the operation the logger has a low battery, the low battery symbol is
shown.
A logger with a low battery cannot be started and must be discarded.
Starting the Logger
The logger's display must show READY for it to be started.
Press and hold the START/Mark button. READY turns off, and the symbol starts
flashing:
Once the symbol remains permanently on (after approx 5 seconds), release the
button within two seconds.
The symbol turns off, and USRID-16W starts the 1-hour countdown timer.
www. .com [e-mail]1.800.561.8187

Operating the Logger USRID-16W User Guide 16
The delay time is shown in hours and minutes. The time counts down and the USRID-16W
starts recording when it reaches 0 00.
The logger will not start
lif you release the button while the symbol is still flashing; or
lif you keep holding the button for more than 2 seconds after the symbol
remains permanently on.
During Recording
During normal operation, the display shows the most recently recorded temperature. The
elapsed time since the start of the trip is also displayed - in hours and minutes for the
first 24 hours, and in days and hours thereafter. A tick symbol is shown as long as no
alarm event has occurred.

Temperatures are shown in Celsius.
The temperature unit on the display is the same as used for the PDF and CSV files.
For USRID-16W1 and USRID-16W2 loggers, this is pre-set to °C in the factory.
An alarm was triggered
If an alarm event occurred, the alarm indicator is
displayed in the bottom left corner, as shown.
Additionally, one or more of the alarm threshold arrows
( ) indicate, which of the alarms were triggered.
In the example, the primary upper alarm was triggered,
with cumulative temperatures exceeding 30 °C for more
than 10 hours.
Marking a reading with an inspection mark
When you press the START/Mark button while the USRID-16W is recording, the next
reading taken will be identified in the downloaded data and on the PDF report with an
inspection mark.
Power Save
For USRID-16W loggers, Power Save is enabled until the device is started. The display
automatically switches off if none of the buttons have been pressed for 30 seconds.
www. .com [e-mail]1.800.561.8187

Operating the Logger USRID-16W User Guide 17
Pressing either button briefly will switch the display on, and show READY, indicating the
product is ready to start. It will show the Battery Empty symbol ( ), if the battery is
low.
As soon as the device has been started, the display remains permanently switched on,
even when the device has finished recording temperatures.
Battery Low while recording
If the battery is low while the USRID-16W is still recording, the battery low symbol is
shown in addition to any other currently displayed information.
At this stage, the product typically has sufficient battery capacity left to finish the trip
that was started, however, the length of storage once the product has stopped may be
affected.
Stopping the USRID-16W
Automatically
The USRID-16W automatically stops recording
temperature when the maximum number of readings
specified during configuration has been reached.
For USRID-16W1 and USRID-16W2 products this covers a
duration of exactly 20 days.
Manually
The USRID-16W is configured so it can be stopped with the STOP/Review button. Manually
stopping it ensures statistics are not falsified with readings taken after the shipment
completion. The stop function is automatically enabled for this product during
configuration.
Press and hold the STOP/Review button.
immediately disappears, and the STOPPED symbol
blinks for 4 seconds.The STOPPED symbol shows in
addition to for 2 seconds.
The symbol then shows permanently for 2 seconds.The
symbol turns off after 2 seconds. Release the
button and the logger stops taking temperature
readings.
www. .com [e-mail]1.800.561.8187

Operating the Logger USRID-16W User Guide 18
If the button is released while STOPPED is still blinkingon, or you wait until STOPPED
disappears, the display shows again, and the logger continues to record data. In this
case, an inspection mark will be recorded in the data against the next temperature reading.
Logger has stopped
Once the logger has stopped, the display will show:
lthe STOPPED symbol;
lthe OK indicator ( ) if no alarm was recorded;
lthe total duration for which the logger recorded data;
lthe alarm indicator ( ) and one or more threshold arrows if an alarm was recorded
during the trip;
lthe battery low symbol ( ) if the battery is low.
The logger does not show a temperature reading.



This is shown if the logger has stopped, and no alarms
were recorded during the trip.



Here, the logger has stopped, and an upper alarm was
recorded during the trip.

During the delay countdown the logger cannot be stopped.
www. .com [e-mail]1.800.561.8187

Operating the Logger USRID-16W User Guide 19
Reviewing Min/Max values and Alarms
Once the logger has stopped and is not plugged into a USB port, you can review the
recorded minimum and maximum temperature readings and alarm trigger events using the
STOP/Review button.
To initiate the review process, briefly press the STOP/Review button. After each press of the
STOP/Review button, the next review screen is shown.
Figure 3: Review cycle
During the review, the alarm cross ( ) and the alarm threshold markers ( ) continue to be
displayed.
You can exit the review screens at any time by pressing START/Mark button or by waiting 30
seconds without pressing any button.
The standard stopped screen will be shown.

After the first button press, the highest recorded
temperature during the trip is shown, indicated by TRIP
MAX.
The example screen shows that the highest recorded
temperature was 46.4 °C.

www. .com [e-mail]1.800.561.8187

Operating the Logger USRID-16W User Guide 20
Pressing STOP/Review for a second time will show the
lowest recorded temperature during the trip, indicated
by TRIP MIN.
The example screen shows that the minimum
temperature recorded was -1.5 °C.
Pressing STOP/Review again will show up to three more screens, one for each of the
configured alarm trigger conditions.
A screen for a specific alarm condition will only be shown if an alarm was triggered by this
threshold. If no alarm was triggered during the trip, only the MIN and MAX screens are
shown.
The additional alarm screens will show the alarm threshold values in descending order,
starting with the upper most alarm threshold.
In this example, all three alarms triggered, so all three screens are shown.
The first of the alarm screens shows the uppermost
alarm threshold, and the time that elapsed between the
start of the trip and the time the alarm was triggered.
In the example, the temperatures were equal/above +45
°C for one complete hour, and the alarm was triggered 17
days and 6 hours into the trip.

The second alarm screen shows the next threshold. In
the example, the temperatures were equal/above +30 °C
for a total of 10 hours, and the alarm was triggered 16
days and 21 hours into the trip.

The third alarm screen shows the lowest threshold. In
the example, the temperatures were equal/below -0.5 °C
for one complete hour, and the alarm was triggered 10
days and 4 hours into the trip.
Pressing STOP/Review again starts the review cycle again
with the MAX screen.
Plugging the USRID-16W into a USB port
As soon as you plug the USRID-16W into a USB port, the word USb appears.
If you have configured the logger to generate files, USb remains turned on until all files
have been generated.
www. .com [e-mail]1.800.561.8187
