Telex RadioCom ANT-FP User manual

FP-11 & ANT-FP
Flat Panel Directional Antenna & Dual Directional Antenna
The FP-11 and ANT-FP are at panel directional antennas. They are ideally suited for IEEE 802.11b and 802.11g wireless Local
Area Networks (LAN’s). Both panel antennas are for indoor and outdoor applications. The FP-11 is a single element directional
antenna while the ANT-FP is a dual element directional antenna with dual coax leads. The dual element feature allows the ANT-
FP antenna to be useful in operating in areas susceptible to the affects of multi-path interference. The FP-11 and ANT-FP are
provided with TNC reverse polarity connectors.
2.4 GHz ISM Band
IEEE 802.11b and 802.11g Superior performance
Light weight
Durable UV-stable, UL ame rated radome
Low loss solid brass elements
Can be installed for either vertical or horizontal polarization
Optional mounting brackets available
Indoor or Outdoor use
Features

FP-11 & ANT-FP Specications
Electrical Specications
Frequency
2400-2500 MHz
Horizontal Beam Width
FP-11: 30°
ANT-FP: 60°
Vertical Beam Width
30°
Impedance
50 Ohm
VSWR
< 1.5:1 avg.
Max Input Power
FP-11: 25 Watts
Lighting Protection
DC Short
Mechanical Specications
Radome Material
UV-inhibited Polymer
Flame Rating
UL 94HB
Operating Temperature
-40°C to 85°C (-40°F to 185°F)
Polarization
Horizontal or Vertical
Wind Survival
>150 MPH (241 KPH)
Product Dimensions/Weight
FP-11
8.5” x 8.5” x 1” (216mm x 216mm x 26mm),
.95 lbs (.43 kg)
ANT-FP
8.5” x 8.5” x 1” (216mm x 216mm x 26mm),
.95 lbs (.43 kg)
Shipping Dimensions/Weight
FP-11
9” x 12” x 1.5” (228.6mm x 304.8mm x 38.1mm),
2 lbs (.91 kg)
ANT-FP
9” x 12” x 1.5” (228.6mm x 304.8mm x 38.1mm),
2 lbs (.91 kg)
Ordering Information
FP-11
Flat Panel Directional Antenna (11 dB) with TNC
reverse polarity connector
Catalog Number: 302054006
ANT-FP
Flat Panel Dual Element Directional Antenna (11 dB),
with dual coax TNC reverse polarity connectors
Catalog Number: 302054001
This specications information is preliminary and is subject to change without notication.
Brand names mentioned are the property of their respective companies.
Contact Information
Telex Communications, Inc.
12000 Portland Avenue South
Burnsville, Minnesota 55337
Telephone: [phone]
Fax: [phone]
Form Number: LIT000272000 Rev A
Date: August 2008
