BC-800NM4 & BC-800NM
Battery Chargers
The BC-800NM4 4-bay and BC-800NM single-bay battery chargers provide users with a full featured charger and condition-
ing unit. Both chargers are specically designed to charge the BP-700NM NiMH rechargeable battery pack that is utilized by
the TR-700, TR-800, TR-825, TR-1, RKP-4 and the new TR-80N and TR-82N Narrow Band beltpacks. Both BC-800NM4 and
BC-800NM battery chargers offer a conditioning cycle, status indicators and rapid charge capability. The BC-800NM4 and BC-
800NM also offer “Intelligent Charging” that optimizes the battery charge cycle and maintains the battery pack at peak capacity
for extended periods of time.
Conditioning Cycle
Provides built-in maintenance capability to maximize battery cycle life.
Status Indicators
‘Charging’, ‘Ready’, ‘Rejected’ (dead battery), ‘Conditioning Cycle’ and ‘Power LED’ indicators make the BC-800NM simple
and easy to use.
Intelligent Charging
Optimizes the battery•
Battery can remain in the charger indenitely•
Maintains battery at peak capacity•
Rapid Charge Capability
Charges in less than 2 hours
Features

BC-800NM4 & BC-800NM Specications
Overall
ESD
8 KV continuous contact discharge; 15 KV from air to all
surfaces without contact
Humidity: 95% relative humidity (non-condensing)
Drop
Unit functions normally after 4ft./1.2m drop to concrete
Storage Temperature
-40° to 122°F/-40° to 50°C
Operating Temperature
32° to 122°F/0° to 50°C
Power Supply
BC-800NM4 (Universal): 90V-230 VAC, 50/60 Hz
Output: 15 VDC, 5A or 24 VDC, 4.5A
BC-800NM (Universal): 90V-230 VAC, 50/60 Hz Output:
15 VDC, 1.5A or 24 VDC, 1.3A
Safety Standards
Charger & power supply UL listed (UL 1950), CSA
Certied (C 22.2 No. 223); Compliant to FCC part 15
Class A and CE Marking (Electromagnetic Compatibility)
Directive 89/336/EEC and Low Voltage Directive 73/23/
EEC; C15PR-22 Class B
Performance Characteristics
Rapid Charging
Charges batteries to 90+% capacity in 2 hours or less
Complete Charge
Completes 100% capacity charge in 4 hours or less
Conditioning
Completely discharges a battery and automatically
switches to charging mode
Maintenance Charge
Maintains the battery at optimum capacity indenitely
User Interface
Power LED
Indicates POWER to charging slot
Conditioning/Charging LED: Flashing indicates
discharging process
Reject LED
Flashing indicates faulty battery
Conditioning/Charging LED: Solid indicates battery pack
is being charged
Ready LED
Solid indicates battery charged
Product Dimensions/Weight
BC-800NM4
13”W x 1.7”H x 7”D (33cm x 4.5cm x 17.8cm),
4lbs (1.5kg) without battery adapters
BC-800NM
3”W x 3.5”H x 6”D (7.62cm x 8.89cm x 15.24cm),
1lb 6oz (0.62kg)
Shipping Dimensions/Weight
BC-800NM4
11.5”W x 10.5”H x 18.5”D (29.2cm x 26.7cm x 47cm),
10 lbs 9oz (4.8kg) with battery adapters, power supply, &
rechargeable battery packs
BC-800NM
7”W x 4.5”H x 7”D (17.68cm x 11.43cm x 17.8cm),
2lbs 10oz (1.2kg) with rechargeable battery pack &
power supply
Material: ABS KJW re retardant plastic, textured
Ordering Information
BC-800NM
Single-Bay Charger for TR-1/700/800/825/RKP-4 with
USA power cord and BP-700NM
Catalog Number: PRD000070006
BC-800NME
Single-Bay Charger for TR-1/700/800/825/RKP-4 with
Euro power cord and BP-700NM
Catalog Number: PRD000070007
BC-800NM4
Four-Bay Charger for TR-1/700/800/825/RKP-4 with
USA power cord and BP-700NM
Catalog Number: PRD000070008
BC-800NM4E
Four-Bay Charger for TR-1/700/800/825/RKP-4 with
Euro power cord and BP-700NM
Catalog Number: PRD000070009
C800NM
Single-Bay Charger without Power Supply
Catalog Number: PRD000070000
CB800NM4
Docking Station, Four-Bay Charger
Catalog Number: PRD000070003
PS800NM4
Power Supply for Four-Bay Charger
Catalog Number: PRD000070004
PS-800NM
Power Supply for Single-Bay Charger
Catalog Number: PRD000070001
PC-UK
BC-800NM and BC-800NM4 UK Power Cord.
Catalog Number: 550024002
This specications information is preliminary and is subject to change without notication.
Brand names mentioned are the property of their respective companies.
Contact Information
Telex Communications, Inc.
12000 Portland Avenue South
Burnsville, Minnesota 55337
Telephone: [phone]
Fax: [phone]
Form Number: LIT000151000 Rev A
Date: August 2008
