QUICK SET UP AND OPERATION
Synching Up The
Transmitter
and Base
The synch operation only needs to be performed
t
he first time a system is used, or a new bodypack is used with a base previously synched
to
another bodypack.
Do
not perform the synch operation multiple
times;
it
only needs to
be done one time
when
a new bodypack is used with a new base.
1)
Turn the transmitter power switch to
ON
and place the transmitter in
the
recharge cradle of the base. The transmitter goes in the base with the
beltclip facing out.
2)
The recharge LED will light (Green if
fully charged, Red if charging). Leave
the transmitter in the cradle for 4 hours for a full charge.
3)
Press the In
-
Use but
ton on the transmitter and hold until the In
-
Use LED on
the transmitter and base start to flas
h
, the
n release the button.
4)
After a few seconds the light will stop flashing, and
a beep will sound (
If the
beep is enabled
).
5)
The transmitter and base are now syn
ched and will continue to be until
another transmitter is linked to that
ba
se
.
Normal Operation
1)
With the transmitter synched up, remove it from the cradle, plug in the lapel
microphone (if used) and place the transmitter on you
r belt.
2)
To start the recording, press the In
-
Use button and the In
-
Use LED will light a
constant green and you will h
ear
a short beep
3)
To end recording, press the In
-
Use button and the In
-
Use LED will turn off
and you will he
ar
a short beep.
4)
At the end of y
our shift turn the transmitter off and replace it in the charging
cradle
.
Out of Range
1)
If you use the Transmitter too far away from the Receiver during recording,
the transmitter will alert you with Audible warning beeps (two tone) and the
In
-
Use
LED
wi
ll blink in red.
2)
Move closer to the receiver base and the link will be re
-
established once you
return to normal range. The In
-
Use LED will light constant green when link is
back to normal operation.
3)
If the link is not re
-
established within 30 seconds, t
he transmitter and receiver
will return to standby mode.
4)
If you went out of range in Standby mode, or the unit reverted to standby
mode, re-
enter normal range and press the In
-
Use button. Operation will
return to normal.
5)
If you will be out of range for a
long period of time, turn the bodypack off.
Low Battery Warning
1)
If the transmitter Low BATT indicator (red) starts flashing or you hear warning
beeps, return the transmitter to its cradle on the receiver to fully charge the
transmitter
.
2)
The Charge LED i
ndicator will light constant green when the unit is fully
charged.
