Telex Vega IP-1616 User manual

The IP-1616 is a eight-line full-
featured desktop control console
designed with VoIP Technology for
use with conventional radio
systems. The IP-1616 is a self-
contained dual processor based
console that does not require CEB
or under the desk CPU equipment.
The IP-1616 can be easily con-
nected to any internal Ethernet
network by connecting a standard
10/100 baseT cable to the back of
the unit and assigning it an address,
thus allowing for an unlimited
number of IP-1616 consoles to have
full control and functionality over
the system.
To program the IP-1616 console
you simply connect to the Ethernet
port on the back of the console and
use your favorite Web Browser on
your computer.
Unlike analog circuits any number
of consoles can be put in parallel
without causing loading issues.
The IP-1616 console has the
capability of controlling a cross-
patch between two or all eight of
its eight-lines. The dispatcher can
communicate with the cross-patch
group or operate on the other
unused channels.
Its four-line Liquid Crystal Display
provides channel alpha/numeric
indication and features a 12/24-
hour clock and audio-level display.
The IP-1616 comes with many
standard features such as F1-F16
function tones, Four Alert tones,
TX-ALL, RX-ALL, DTMF Key-
pad, Two Auxiliary buttons, RX
and TX Block, Parallel update,
DTMF Select Call per line, Paging
(2-tone, DTMF and Manual entry),
Instant call recorder allows you to
retrieve the last 4 minutes of either
select or unselect TX and RX
audio, Group select and VoIP con-
nection. Summed recorder outputs
for selected and unselected audio.
The IP-1616 console is compatible
with Vega’s other VoIP products
such as the C-6200, IP-223, and
C-Soft. Through these platforms
Motorola, M/A Com, Daniels,
Kenwood, and other tone or direct
connected radios can be remotely
controlled. The migration path cre-
ated with our VoIP products allows
users to make a gradual move to the
benefits of the VoIP world.
•Police and Fire Departments
•Utility and Energy Companies
•Railroads and Airline Industries
•US Forestry and BLM Agencies
VoIP
Radio / Telephone
Crosspatch Control
8601 East Cornhusker Highway, Lincoln, NE 68507
Phone: [phone]
Fax: [phone]
E-mail: [email protected] Web: www.vega-signaling.com
Communications, Inc.
VEGA Signaling Products
1-800-752-7560
Vega’s Model IP-1616

Front panel controls
• Monitor, Intercom, PTT button
• Alert tones up to four
• Crosspatch
• Group Select, two pre-determined groups
• Supervisory control
• 16 digit DTMF keypad
• Volume controls
• Parallel TX LED detect
• Frequency Selection
• Instant PTT
• A-menu and B-menu buttons for direct menu control
• Four programmable buttons
• Page (2-tone, DTMF, Manual)
Features
➣Sixteen frequency control
➣Simplex/full duplex (field Programmable)
➣Cross mute (Ethernet Based)
➣Parallel console update
➣Paging (2-tone, DTMF, Manual)
➣IRR (Instant Call Recorder)
➣Line select call with alarm
Special features
◆Ethernet VoIP connection between consoles
◆External PTT
◆External audio input
◆External Aux power input
◆External speaker and recorder outputs
◆Field upgradeable software
◆SNTP Based Network Clock Synchronization
◆QOS (Quality of Service) packet marking built in
Microphones and Accessories
• Handset/Headset,
• Gooseneck Mic
• Desk Mic
• Footswitch
Specifications
Distortion: 3% maximum at full output
Hum and Noise: 50 db below operating levels
Speaker (two): 3 in, 8 ohm, heavy-duty
Amplifier Power: 5 W maximum at 3% THD
into an 8 ohm load or equivalent
Optional Handset Earpiece Level: Adjustable preset
level independent of speaker volume controls
Audio Frequency Response: + 1.5 db, 300 to 3000 Hz
Operating Temperature Range: 0 to +70 degree C
Power Requirements: 117 Vac, 60Hz, 25W, or 12.0
Vdc at 5 A maximum
Microphone Connection: Handset and Headset are
4-wire, and the Desk microphone is 6-wire
Dimensions: 15.75 in (39.4cm) W x 9.7 in (24.3cm)
D x 5.5 in (13.75cm) H
Weight: 25 LB (11.34 KM)
Warranty (Limited)
All Telex Communications, Inc. manufactured VEGA
signaling products are guaranteed against malfunction
due to defects in materials and workmanship for three
years, beginning at the date of original purchase. If
such a malfunction occurs, the product will be repaired
or replaced (at our option) without charge during the
three-year period, if delivered to the Telex factory.
Warranty does not extend to damage due to improper
repairs, finish or appearance items, or malfunction
due to abuse or operation under other than the
specified conditions, nor does it extend to incidental
or consequential damages. Some states do not allow
the exclusion or limitation of incidental or consequen-
tial damages, so the above limitation may not apply
to you. This warranty gives the customer specific
legal rights, and there may be other rights which
vary from state to state.
Specifications are subject to change without notice.
