Teltonika Telematics FMC150 Installation guide

FMC150
Advanced tracker with CAN data
reading feature
Quick Manual v1.6

Quick Manual v1.0 // FMC150 2
Telematics
CONTENT
Know your device ..................................................................................................................................................................................................3
Pinout......................................................................................................................................................................................................................4
Wiring scheme .......................................................................................................................................................................................................5
Set up your device.................................................................................................................................................................................................6
PC Connection (Windows) ....................................................................................................................................................................................7
How to install USB drivers (Windows) ................................................................................................................................................................7
Conguration (Windows)......................................................................................................................................................................................8
Quick SMS conguration ................................................................................................................................................................................... 10
Mounting recommendations............................................................................................................................................................................ 12
Basic characteristics........................................................................................................................................................................................... 13
LED indications ................................................................................................................................................................................................... 13
Electrical characteristics .................................................................................................................................................................................... 17
Safety information ............................................................................................................................................................................................. 19
Certication and Approvals............................................................................................................................................................................... 20
Warranty .............................................................................................................................................................................................................. 21
Warranty disclaimer .......................................................................................................................................................................................... 21

Quick Manual v1.0 // FMC150 3
Telematics
KNOW YOUR DEVICE
2X6
SOCKET
STATUS
LED
CAN
LED
MICRO SIM
SLOT
BATTERY
SOCKET
NAVIGATE
LED
MICRO
USB
TOP VIEW TOP VIEW (WITHOUT COVER)BOTTOM VIEW (WITHOUT COVER)

Quick Manual v1.0 // FMC150 4
Telematics
Pin number Pin name Description
1VCC (10-30) V
DC (+)
Power supply (+10-30
V DC).
2DIN 3 / AIN 2
Analog input, channel
2. Input range: 0-30
V DC / Digital input,
channel 3.
3DIN2-N / AIN1
Digital input, channel 2
/ Analog input, channel
2. Input range: 0-30 V
DC /GND Sense input
4 DIN1 Digital input, channel
1.
5CAN2L CAN LOW, 2nd line
6CAN1L CAN LOW, 1st line
7 GND (-) Ground pin. (10-30) V
DC (―)
8DOUT 1
Digital output, channel
1. Open collector
output. Max. 0,5 A DC.
9DOUT 2
Digital output, channel
2. Open collector
output. Max. 0,5 A DC.
10 1WIRE DATA Data for 1–Wire
devices.
11 CAN2H CAN HIGH, 2nd line
12 CAN1H CAN HIGH, 1st line
PINOUT
10
9
8
7
11
12
4
3
2
1
5
6
DOUT2
1WIRE DATA
CAN2H
GND
DOUT1
CAN1H
DIN2-N/AIN1
DIN1
CAN2L
DIN3/AIN2
+10...30 V DC
CAN1L
FMC150 2x6 socket pinout

Quick Manual v1.0 // FMC150 5
Telematics
WIRING SCHEME
BUZZER LED LIGHTS
30
8586
87a
87
IGNITION
DETECTION
FUEL GAUGE
RELAY
STARTER
IBUTTON
MULTIPLE
TEMPERATURE
SENSORS
CAN BUS
POWER SUPPLY
10 - 30V DC
ANALOG
LLS SENSOR
ALARM BUTTON
DOOR SENSOR
10
9
8
7
11
12
4
3
2
1
5
6
DOUT2
1WIRE DATA
CAN2H
GND
DOUT1
CAN1H
DIN2-N/AIN1
DIN1
CAN2L
DIN3/AIN2
+10...30 V DC
CAN1L
AIN2
DIN3
DIN2-N
DIN2
1WIRE PWR

Quick Manual v1.0 // FMC150 6
Telematics
SET UP YOUR DEVICE
HOW TO INSERT MICRO-SIM CARD AND CONNECT THE BATTERY
4
1COVER REMOVAL 3BATTERY CONNECTION 2MICRO-SIM CARD INSERT ATTACHING COVER BACK
Gently remove FMC150
cover using plastic pry tool
from both sides.
Insert Micro-SIM card as
shown with PIN request
disabled or read our Wiki1
how to enter it later in
Teltonika Congurator2.
Make sure that Micro-
SIM card cut-o corner is
pointing forward to slot.
1 wiki.teltonika-gps.com/index.
php?title=FMC150_Security_info
2 wiki.teltonika-gps.com/view/
Teltonika_Congurator
Connect battery as shown to
device. Position the battery
in place where it does not
obstruct other components.
After conguration, see “PC
Connection (Windows)”,
attach device cover back.

Quick Manual v1.0 // FMC150 7
Telematics
PC CONNECTION (WINDOWS)
HOW TO INSTALL USB DRIVERS (WINDOWS)
1. Please download COM port drivers from here1.
2. Extract and run TeltonikaCOMDriver.exe.
3. Click Next in driver installation window.
4. In the following window click Install button.
5. Setup will continue installing the driver and eventually the conrmation window will appear. Click Finish to complete the
setup.
1 teltonika-gps.com/downloads/en/FMC150/TeltonikaCOMDriver.zip
1. Power-up FMC150 with DC voltage (10 – 30 V) power supply using supplied power cable. LED’s should start blinking, see “LED
indications1”.
2. Connect device to computer using Micro-USB cable or Bluetooth connection:
• Using Micro-USB cable
• You will need to install USB drivers, see “How to install USB drivers (Windows)2”
• Using Bluetooth
• FMC150 Bluetooth is enabled by default. Turn on Bluetooth on your PC, then select Add Bluetooth or other device >
Bluetooth. Choose your device named – “FMC150_last_7_imei_digits”, without LE in the end. Enter default password 5555,
press Connect and then select Done.
3. You are now ready to use the device on your computer.
1 wiki.teltonika-gps.com/view/FMC150_LED_status
2 Page 7, "How to install USB drivers"

Quick Manual v1.0 // FMC150 8
Telematics
MS .Net requirements
Operating system MS .NET Framework version Version Links
Windows Vista
Windows 7
Windows 8.1
Windows 10
MS .NET Framework 4.6.2 32 and 64 bit www.microsoft.com1
1 dotnet.microsoft.com/en-us/download/dotnet-framework/net462
At rst FMC150 device will have default factory settings set. These settings should be changed according to the users needs. Main
conguration can be performed via Teltonika Congurator1software. Get the latest Congurator version from here2. Congurator
operates on Microsoft Windows OS and uses prerequisite MS .NET Framework. Make sure you have the correct version installed.
1 wiki.teltonika-gps.com/view/Teltonika_Congurator
2 wiki.teltonika-gps.com/view/Teltonika_Congurator_versions
CONFIGURATION (WINDOWS)

Quick Manual v1.0 // FMC150 9
Telematics
Downloaded Congurator will be in compressed archive.
Extract it and launch Congurator.exe. After launch software
language can be changed by clicking 🌐in the right bottom
corner.
Conguration process begins by pressing on connected device.
FMC150
Various Status window1 tabs display information about GNSS2,
GSM3, I/O4, Maintenance5and etc. FMC150 has one user
editable prole, which can be loaded and saved to the device.
After any modication of conguration the changes need to
be saved to device using Save to device button. Main buttons
oer following functionality:
 Load from device – loads conguration from device.
 Save to device – saves conguration to device.
 Load from le – loads conguration from le.
 Save to le – saves conguration to le.
 Update rmware – updates rmware on device.
 Read records – reads records from the device.
 Reboot device – restarts device.
 Reset conguration – sets device conguration to
default.
Most important congurator section is GPRS – where all
your server and GPRS settings6 can be congured and Data
Acquisition7– where data acquiring parameters can be
congured. More details about FMC150 conguration using
Congurator can be found in our Wiki8.
After connection to Congurator Status window will be
displayed.
FMC150
1 wiki.teltonika-gps.com/view/FMC150_Status_info
2 wiki.teltonika-gps.com/view/FMC150_Status_info#GNSS_Info
3 wiki.teltonika-gps.com/view/FMC1501_Status_info#GSM_Info
4 wiki.teltonika-gps.com/view/FMC150_Status_info#I.2FO_Info
5 wiki.teltonika-gps.com/view/FMC150_Status_info#Maintenance
6 wiki.teltonika-gps.com/index.php?title=FMC150_GPRS_settings
7 wiki.teltonika-gps.com/index.php?title=FMC150_Data_acquisition_
settings
8 wiki.teltonika-gps.com/index.php?title=FMC150_Conguration

Quick Manual v1.0 // FMC150 10
Telematics
QUICK SMS CONFIGURATION
Default conguration has optimal parameters present to ensure best performance of track quality and data usage.
Quickly set up your device by sending this SMS command to it:
Note: Before SMS text, two space symbols should be inserted.
GPRS SETTINGS:
 2001 – APN
 2002 – APN username (if there are no APN username,
empty eld should be left)
 2003 – APN password (if there are no APN password,
empty eld should be left)
SERVER SETTINGS:
 2004 – Domain
 2005 – Port
 2006 – Data sending protocol (0 – TCP, 1 – UDP)
« setparam 2001:APN;2002:APN_username;2003:APN_password;2004:Domain;2005:Port;2006:0»
1 2 3 4 5 6
1
2
3
4
5
6
