Tema Telecomunicazioni AD696/B User manual

AD696/B
Paging Microphone Base for Announcements
Serie Audio Over IP Network
PRODUCT MANUAL
Version HW 1.0
Revision
Date
Revision reason
Prepared
Checked/Approved
1 25/02/2020 Update DP DP, FL
TEMA TELECOMUNICAZIONI
“IP COMMUNICATION AND SECURITY COMPANY”
WWW.TEMATLC.IT
Products for VoIP SIP LAN networking Communications, Paging Amplifiers Systems and
Audio Applications. Zone Announcements, Night Ringer, Multicast general call,
Background music, Standard SIP call or Emergency call, SD memory with pre-recorded
messages, Relays for LAN drives.

TEMA TELECOMUNICAZIONI AD696/B Paging Microphone Base for Announcements
MAS-AD696-B-REV01EN Page 2 of 8
We, TEMA TELECOMUNICAZIONI SRL Via C. Girardengo, 1/4 - 20161 MILANO
declare under our sole responsibility that the product:
Product name Base microfonica per annunci
Trade name TEMA TELECOMUNICAZIONI Srl
Type or model AD696/B
and accessories --
to which this declaration relates is in conformity with the essential requirements and other
relevant requirements of the R&TTE Directive ( 1999/5/EC, 2006/95/EC, 2004/108/EC ).
The product is in conformity with the followings standards and/or other normative documents:
HEALT & SAFETY EN 60950-1:2006 +A11:2009 +A1:2010 +A12:2011
EMC EN 55022:2010, EN 55024:2010, EN 61000-3-2:2006
EN 61000-3-3 :2008
MILANO, 27 February 2018 TEMA TELECOMUNICAZIONI SRL
D. Pontillo
I. IMPORTANT INFORMATIONS REGARDING THE RECOVERY AND RECYCLING OF THIS
ELECTRONIC DEVICE
DICHIARAZIONE DI CONFORMITÀ CE
DECLARATION OF CONFORMITY CE
The crossed
-
out wheeled bin symbol below indicates that this electronic equipment is
intended to be disposed in a separate collection and not in an unsorted municipal
waste, in order to provide for the treatment of WEEE (Waste Electrical and Electronic
Equipment) using best available recovery and recycling techniques. Specific treatment
for WEEE is indispensable in order to avoid the dispersion of pollutants and other
hazardous substances into the waste stream, while recycling leads to reduction of
disposal of waste and the negative impacts on environment and human health. That is,
priority is given to reuse of WEEE in its components, subassemblies and
consumables. As the final holder, the user has an important role in contributing to
reuse, recycling and other forms of recovery of WEEE and is responsible to return this
waste in the collection facilities set up by EC Member States and to fulfill other duties
in compliance with Directive 2002/96/EC and local laws.
UNI EN ISO 9001:20
15
TEMA TELECOMUNICAZIONI is
a certified company

TEMA TELECOMUNICAZIONI AD696/B Paging Microphone Base for Announcements
MAS-AD696-B-REV01EN Page 3 of 8
RECOMMENDATIONS
1. It is recommended to read this entire manual before proceeding to the installation of the device.
2. The installation and commissioning of the device can only be performed by specialized technicians.
3. The device is accurately manufactured and tested. In any case, the product is not recommended for use
where an error of operations can cause property damage and/or injury to persons.
4. It is expressly not recommended maintenance inside the device which must be carried out by Tema
Telecomunicazioni, the removal of the closures will invalidate the warranty and makes accessible internal
parts with risk of electric shock.
5. Tema Telecomunicazioni accepts no responsibility for damage to property and/or persons resulting from
incorrect use of the equipment or by procedures that do not comply with the instructions in this manual.
Tema Telecomunicazioni reserves the right to make modification to the technical and functional
specifications at any time and without any notice.
6. Products powered via PoE (Power over Ethernet) may only be connected with cables coming from the
internal network company (inside the building), are not allowed connections LAN cables coming from outside
the building.
7. Use for this device only and exclusively original spare parts and consumables supplied by Tema
Telecomunicazioni. The company is not responsible for damage caused by the use of materials not supplied
by the same.
8. Do not expose the unit to direct sunlight, protect from heat, dust, humidity and chemicals.
9. Tema Telecomunicazioni reserves the right to vary the product characteristics for improvement without prior
notice. Check the WWW.TEMATLC.IT website for any updates to the latest firmware, manuals, and
technical documentation.
10. This document is property of Tema Telecomunicazioni, It is forbidden any duplication and reproduction, even
partial, as well as storage on any medium without written permission of Tema Telecomunicazioni.
This symbol in the descriptions indicates a gene
ral warning or a damage danger
to equipment or people.
This symbol in the descriptions indicates useful information or a suggestion for
the optimization of the device functionality.

TEMA TELECOMUNICAZIONI AD696/B Paging Microphone Base for Announcements
MAS-AD696-B-REV01EN Page 4 of 8
1. PRESENTATION ........................................................................................................................................ 5
2. TECHNICAL SPECIFICATIONS ............................................................................................................... 6
3. PACKING LIST ........................................................................................................................................... 6
4. OPERATION................................................................................................................................................ 7
5. CONNECTION AND PREPARATION OF THE MICROPHONE BASE ................................................ 7
INDEX PAGE

TEMA TELECOMUNICAZIONI AD696/B Paging Microphone Base for Announcements
MAS-AD696-B-REV01EN Page 5 of 8
1. PRESENTATION
The AD696/B amplified paging microphone base can be connected to an AD615/S Tema Encoder to launch
announcements on the LAN network in Multicast channels to the network amplifiers or to the IP-SIP AD600 series
loudspeakers of the SipComStage line.
The desktop base is equipped with a "Talk" button to enable the microphone and a switch to enable the "Always
on" function.
The flexible arm allows the microphone to be oriented according to the best position for the user.
The microphone, of high quality, allows to transmit crystal-clear and intelligible voice announcements.
The 1.5 meter cable is terminated with a RJ45 connector specifically wired for the TEMA AD615/S Encoder.
LAN
NETWORK
Microphone B
a
se
AD696/B
AD696/B Paging Microphone Base with AD615/S Encoder
IP PBX
AD611
IP-SIP Amplifier terminal
unidirectional 2 x 6W with
passive loudspeakers
AD635
IP-SIP Speaker idirectional
terminal 2 x 6W
Mic
r
o
phone
Audio source
Radio, Compact Disk,
iPod, PC, etc…
Other
AD600 series
SipComStage
terminals
Multicast
Encoder
AD615/S

TEMA TELECOMUNICAZIONI AD696/B Paging Microphone Base for Announcements
MAS-AD696-B-REV01EN Page 6 of 8
2. TECHNICAL SPECIFICATIONS
Microphone capsule
E
lectret condenser
Polar diagram
Cardioid
Frequency response
50 ÷
16.000
Hz
Output impedance
1
50
Ohm
Sensi
tivity
-
40dB (0dB 1V/Pa @1Khz)
Controls
“
PTT
”
button, “
Always On
” switch
Signalings
1 LED (“Speak”)
Arm
F
lexible gooseneck with 2 points,
removable, with XLR connector
Arm lenght
455mm
Arm body
shock resistant metal alloy
Windproof cap
black polyurethane foam
Power Supply
5Vdc,
directly po
wered by the
AD615/S
system
Conne
c
tor/Ca
ble
RJ45 8
-
way
proprietary, C5 1,5mt
Operating temperature
-
10°
÷
+
55°C
Storage temperature
-
20°
÷
+65°C
Umidity
0
-
95%
non
-
condensing
Dimensions
113 x 140 x H35 mm (base) + 455 mm (
arm
)
Weight
0.45
kg
cable inc
luded
3. PACKING LIST
The systems are supplied with the parts included in the following list:
• One AD969/B base with integral cable, microphone arm and windproof cap
• A paper manual, system documentation, installation, use
• A CD-ROM with complete documentation

TEMA TELECOMUNICAZIONI AD696/B Paging Microphone Base for Announcements
MAS-AD696-B-REV01EN Page 7 of 8
4. OPERATION
The AD696/B microphone base is specifically designed to work with the AD615/S audio Encoder system, one of
the components of the Tema Telecomunicazioni paging sound system.
AD696/B allows to one operator to transmit a message to a network of IP speakers for the purpose of alerts or
announcements, it has the “Always On” function useful for the launch of an announcement without the need to
keep the PTT button pressed.
Every operator who has the AD696/B microphone base can spread an announcement on the network speaker in a
simple way:
•Press and hold the PTT button (or activate the “Always On” switch)
•The Speak led lights up
•Now it is possible to speak into the microphone clearly and quietly to give the message
•At the end of the announcement release the PTT button (or deactivate the “Always On” switch)
•The SPEAK led goes off and the microphone will be muted
The selection lever on the AD615/S system connected to AD696/B must be in the central position. In case
AD615/S is used for broadcasting background music in the environment, its lever must be placed upwards
(AD615/S controls the broadcast).
Any background music broadcasted by AD615/S will still be replaced by the AD696/B microphone message. For
further information on the AD615/S system and its operation, refer to its specific user manual.
5. CONNECTION AND PREPARATION OF THE MICROPHONE BASE
The AD696/B microphone base is powered by the AD615/S system to which it must be directly connected. Insert
the 8-pole plug connector of the integral cable connected to AD696/B into the black RJ45 socket on the AD615/S
module as clearly indicated in the photos below.
W
indproo
f
cap
Switch to activate
the “Always On”
function
Button for
activating the
microphone
message
announcement
Microphone
announcement LED
