Tema Telecomunicazioni AD696/AA User manual

AD696/AA
Microphone Base for PC compatible with ADAM Software
Serie Audio Over IP Network
PRODUCT MANUAL
Version HW 1.0
Revision
Date
Revision reason
Prepared
Checked/Approved
0 01/03/2018 First release DP DP, FL
TEMA TELECOMUNICAZIONI
“IP COMMUNICATION AND SECURITY COMPANY”
WWW.TEMATLC.IT
Products for VoIP SIP LAN networking Communications, Paging Amplifiers Systems and
Audio Applications. Zone Announcements, Night Ringer, Multicast general call,
Background music, Standard SIP call or Emergency call, SD memory with pre-recorded
messages, Relays for LAN drives.

TEMA TELECOMUNICAZIONI AD696/AA Microphone Base For PC
MAS-AD696-AA-REV00EN Page 2 of 8
We, TEMA TELECOMUNICAZIONI SRL Via C. Girardengo, 1/4 - 20161 MILANO
declare under our sole responsibility that the product:
Product name Base microfonica per annunci per PC
Trade name TEMA TELECOMUNICAZIONI Srl
Type or model AD696/AA
and accessories --
to which this declaration relates is in conformity with the essential requirements and other
relevant requirements of the R&TTE Directive ( 1999/5/EC, 2006/95/EC, 2004/108/EC ).
The product is in conformity with the followings standards and/or other normative documents:
HEALT & SAFETY EN 60950-1:2006 +A11:2009 +A1:2010 +A12:2011
EMC EN 55022:2010, EN 55024:2010, EN 61000-3-2:2006
EN 61000-3-3 :2008
MILANO, 27 February 2018 TEMA TELECOMUNICAZIONI SRL
D. Pontillo
I. IMPORTANT INFORMATIONS REGARDING THE RECOVERY AND RECYCLING OF THIS
ELECTRONIC DEVICE
DICHIARAZIONE DI CONFORMITÀ
CE
DECLARATION OF CONFORMITY CE
The crossed
-
out wheeled bin symbol below indicates that
this electronic equipment is
intended to be disposed in a separate collection and not in an unsorted municipal
waste, in order to provide for the treatment of WEEE (Waste Electrical and Electronic
Equipment) using best available recovery and recycling techniques. Specific treatment
for WEEE is indispensable in order to avoid the dispersion of pollutants and other
hazardous substances into the waste stream, while recycling leads to reduction of
disposal of waste and the negative impacts on environment and human health. That is,
priority is given to reuse of WEEE in its components, subassemblies and
consumables. As the final holder, the user has an important role in contributing to
reuse, recycling and other forms of recovery of WEEE and is responsible to return this
waste in the collection facilities set up by EC Member States and to fulfill other duties
in compliance with Directive 2002/96/EC and local laws.
UNI EN ISO 9001:20
15
TEMA TELECOMUNICAZIONI is a certified company

TEMA TELECOMUNICAZIONI AD696/AA Microphone Base For PC
MAS-AD696-AA-REV00EN Page 3 of 8
RECOMMENDATIONS
1. It is recommended to read this entire manual before proceeding to the installation of the device.
2. The installation and commissioning of the device can only be performed by specialized technicians.
3. The device is accurately manufactured and tested. In any case, the product is not recommended for use
where an error of operations can cause property damage and/or injury to persons.
4. It is expressly not recommended maintenance inside the device which must be carried out by Tema
Telecomunicazioni, the removal of the closures will invalidate the warranty and makes accessible internal
parts with risk of electric shock.
5. Tema Telecomunicazioni accepts no responsibility for damage to property and/or persons resulting from
incorrect use of the equipment or by procedures that do not comply with the instructions in this manual.
Tema Telecomunicazioni reserves the right to make modification to the technical and functional
specifications at any time and without any notice.
6. Products powered via PoE (Power over Ethernet) may only be connected with cables coming from the
internal network company (inside the building), are not allowed connections LAN cables coming from outside
the building.
7. Use for this device only and exclusively original spare parts and consumables supplied by Tema
Telecomunicazioni. The company is not responsible for damage caused by the use of materials not supplied
by the same.
8. Do not expose the unit to direct sunlight, protect from heat, dust, humidity and chemicals.
9. Tema Telecomunicazioni reserves the right to vary the product characteristics for improvement without prior
notice. Check the WWW.TEMATLC.IT website for any updates to the latest firmware, manuals, and
technical documentation.
10. This document is property of Tema Telecomunicazioni, It is forbidden any duplication and reproduction, even
partial, as well as storage on any medium without written permission of Tema Telecomunicazioni.
This symbol in the descriptions indicates a general warning or a damage danger
to equipment or people.
This symbol in the descriptions indicates useful information or a suggestion for
the optimization of the device functionality.

TEMA TELECOMUNICAZIONI AD696/AA Microphone Base For PC
MAS-AD696-AA-REV00EN Page 4 of 8
1. PRESENTATION ........................................................................................................................................ 5
2. TECHNICAL SPECIFICATIONS ............................................................................................................... 7
3. PACKING LIST ........................................................................................................................................... 7
4. O PERATION............................................................................................................................................... 8
5. CONNECTING THE MICROPHONE BASE TO THE PC........................................................................ 8
IND
EX
PAGE

TEMA TELECOMUNICAZIONI AD696/AA Microphone Base For PC
MAS-AD696-AA-REV00EN Page 5 of 8
1. PRESENTATION
The AD696/AA microphone base can be connected to a PC running the ADAM software for the centralized
management of Tema IP audio devices.
Through the AD696/AA microphone base enabled by the ADAM software, the announcements can be made on the
LAN network in Multicast channels to the network amplifiers or to the AD600 series IP-SIP speakers of the
SipComStage line.
The arm, which is flexible at two points, is removable and is fixed to the base with a standard XLR connector.
The cable itself has an XLR connector that ends with a 3.5mm jack to be connected to the microphone port of a
generic PC.
Typically used with the ADAM program (**) the AD696/AA base allows to operate in different ways
Standard mode, microphone always open and available to the software to make announcements:
from the microphone page of the ADAM program the microphone is activated to be able to emit the message on
the network and simply the voice will be broadcasted on the speakers network. This mode is obtained by leaving
the switch on the microphone base always in position "I".
Mode with protected message output, ideal for short messages, microphone available to the software to make
announcements but open when the button is pressed on the microphone base:
from the microphone page of the ADAM software the microphone is activated to be able to emit the message on
the network but the audio received from the microphone is not diffused on the loudspeaker network until the
operator presses and holds the button on the microphone base.
Mode with protected message emission, indicated for announcements or long-term warnings, microphone available
to the program to make announcements but open to the command of the switch on the microphone base:
from the microphone page of the ADAM software the microphone is activated to be able to emit the message on
the network but the audio received from the microphone is not diffused on the loudspeaker network until the
operator moves the switch which is normally kept in position "0" on the "I" position. At the end of the
announcement, the switch must be returned to position "0".
For all three modes of use, it is possible to precede the message received by the microphone from a CHIME
warning issued automatically by the ADAM software when the microphone is activated.
(** = for the complete functions and details on the use of the software refer to the specific product manual)

TEMA TELECOMUNICAZIONI AD696/AA Microphone Base For PC
MAS-AD696-AA-REV00EN Page 6 of 8
VoIP SIP Amplifiers-Speakers Products and Accessories of the AD600 “SipComStage” series
AD610
2X2W PoE IP-SIP
Amplifier Module,
External Amplifier Adapter with Sound Isolation
Transformer. Directly pilot external power
amplifiers or 8 Ohm external passive speakers.
AD611
IP-SIP PoE 10W Amplifier Modul
e
(2X5W). Directly pilot 8 Ohm external passive
speakers.
AD633
IP-SIP speaker 12W PoE ceiling
mount version.
AD635
IP-
SIP PoE 12W speaker for wall
mounting with the possibility of integrating a PoE
injector adapter.
AD333/12XTP
Passive 8 Ohm 12W
speaker with anti-
flame cover (AD333/12TP
without cover), internal transformer for 100V
audio line. Ideal for connecting to AD610-611-
612
or as 2nd speaker to the AD63x series IP-
SIP
speakers.
AD335/06TP
Passive 8 Ohm 6W speaker
with 100V audio line transformer. Ideal for
connecting to AD610-611-
612 or as 2nd speaker
to the AD63x series IP-SIP speakers.
AD330/25T
Passive horn speaker 25W 8
ohm with transformer for 100V audio line. Ideal
for connecting to the AD610-611-
612 modules or
as 2nd speaker for AD63x IP-
SIP speakers
series.
AD330/xx
Are available Speakers of
different power, Horn
s and Loudspeakers
for flush and ceiling mount.
AA
-
39DL
Plug Power Supply 220Vac/12Vdc-1,0A.
A
A
-
39P4
PoE injector 230Vac/48Vdc 0,5A.
AA
-
39E3 /
-
E6V
DIN Power Supplies 220Vac/24Vdc-1,5A
220Vac/24Vdc-2,5A.
AA
-
36
Protected Power Relay
Actuator 250Vac/16A/4KVA,
command in
AC/DC 12V/24V, 1 contact, Led, contacts
protected by electric arcs.
Ideal for
driving loads up to 4.000W.
AD612
IP-
SIP PoE 40W (2x20W) Amplifier
Module when powered with an external power
supply.
Directly pilot 8 Ohm external passive
speakers.
AA
-
699xxx
Flash lights with Xeon
lamp or high brightness LEDs. Ideal to be
controlled by the relay of the IP-
SIP
speakers of the AD630 series or by the
IP-SIP amplifier AD610, AD611, AD6
12
modules, with a call in progress add a
light signal to the acoustic signal.
AD320/30
PA 100V audio line
transformer 30W, constant voltage, high
efficiency toroidal type with low magnetic
flux leakage.
AD32
Isolation transformer, balanced,
mixer, attenuator, audio signal filter, low
impedance output. Ideal for decoupling
devices of audio sources to other
amplifiers to eliminate noises.
AD615/S
Audio Encoder Module from
analog to digital on LAN Network in
Multicast/Broadcast Channels.
AD301R
30W analog amplifier,
2 channels, Volume-High-Low +/-
12dB
controls
AD630
IP-
SIP PoE 25W Horn Speaker
with 40W internal amplifi
er (2x20W) IP65
protection.
AD633C
SIP IP-
12W PoE Speaker ceiling
mount version with IP54 flameproof cover.
AD634
IP-
SIP PoE 20W Sound Projector
metal version.
AA
-
39D1A
DIN Power Supply 220Vac/15Vdc-1,0A.

TEMA TELECOMUNICAZIONI AD696/AA Microphone Base For PC
MAS-AD696-AA-REV00EN Page 7 of 8
2. TECHNICAL SPECIFICATIONS
Microphone capsule
Electret condenser
Polar diagram
Cardioid
Frequency
response
50 ÷
16.000
Hz
Output impedance
1
00
0
Ohm
Sensitivity
-
40dB (0dB 1V/Pa @1Khz)
Control
s
Momentary PTT button
,
“
ALWAYS
-
ON
”
switch
Arm
Flexible gooseneck in 2 points
(removable from the base, inserted on XLR connectors)
Arm length
455mm
Body
S
h
ock and handling resistant
metal alloy
Windproof cap
B
lack polyurethane foam
Power supply
From the microphone port of the sound card to which it is
connected
Connector
/Ca
ble
With
XLR
connector
and
3.5mm
jack
Operating temperature
-
10°
÷
-
55°C
Stora
g
e
temperature
-
20°
÷
+65°C
Umidity
0
-
95%
non
-
condensing
Dimen
sions
113
x
140 x H3
5 mm (base) +
455
mm (
arm
)
Weight
0.
5
kg
cable included
3. PACKING LIST
The systems are supplied with the parts included in the following list:
• One AD969/AA base with the cable, microphone arm and windproof cap
• A printed system documentation, installation, programming, user manual

TEMA TELECOMUNICAZIONI AD696/AA Microphone Base For PC
MAS-AD696-AA-REV00EN Page 8 of 8
4. OPERATION
The operator who has the AD696/AA microphone base at his disposal, to issue an announcement on the speaker
network after activating the "Microphone" function on the ADAM software window can:
switch in "I" position On permanently enabled microphone (Recommended with ADAM software)
•Speak immediately afterwards in a clear and calm way to give the announcement
switch in "0" position Off (Microphone not permanently active)
•Press the unstable button for the duration of the announcement
End the activity by deactivating the "Microphone" window of the ADAM software.
5. CONNECTING THE MICROPHONE BASE TO THE PC
Connect the cable with the supplied XLR connector on the back of the microphone base.
The other end of the cable will be connected to the audio system used, typically a sound card inserted into a
computer where the ADAM software is running.
Connection cable
plug to the sound
card
Microphone rod
engagement
Microphone open
button for short
messages
Continuous
microphone
opening switch for
long messages
Colored ring and
windproof cap to
protect the
microphone capsule
