Temptech 56L User manual

This manual contains important information including safety and
installation instructions of the appliances. Please read it carefully before
use and follow all safety information & instructions. It is recommended
to keep this manual for easy reference so that you can be familiar with the
operation of the appliance.
V2/2017
55L 56L 130L
22L 58L 88L 116L 145L
270L 428L 468L 490L
USER MANUAL
Wine Coolers

--CONTENTS--
01 IMPORTANT SAFETY INFORMATION
03 SCRAPPING OLD APPLIANCES
04 Conformity
04 Energy Saving
04 Service
05 DESCRIPTION OF APPLIANCE AND INSTALLATION
05 55L Control In Cabinet
06 56L Control On Door
09 130L Control In Cabinet
11 22L Control In Cabinet
12 58L Control In Cabinet
13 88L Control In Cabinet
14 116L Control In Cabinet
15 145L Control In Cabinet-Height:81.3cm
16 145L Control In Cabinet-Height:86.3cm
17 145L Control On Door-Height:86.3cm
18 270L Control In Cabinet
19 428L Control In Cabinet
20 468L Control In Cabinet
21 490L Control In Cabinet
22 490L Control On Door
23 490L Control On Door-Five Strong Shelves
24 490L -Tripe Zone Control In Cabinet
25 ACCESSORY INSTALLATION BEFORE OPERATING
25 UNPACKING AND CLEANING THE WINE COOLER
25 Adjusting the height and levelling o your wine cabinet
26 Installing The Handle
26 LOCK & UNLOCK THE DOOR (FOR OPTION)
26 OPERATING THE WINE COOLER
26 WORKING CLIMATE
27 WINE STORAGE
28 CONTROL PANEL (Control In Cabinet)
28 POWER ON/OFF CONTROL
29 UNLOCKING THE CONTROL PANEL
29 INTERIOR LIGHTING ON/OFF CONTROL
29 TEMPERATURE DISPLAY WINDOW
29 TEMPERATURE RANGE SETTING
30 TEMPERATURE SETTING
31 SELECTING FAHRENHEIT(ºF) & CELSIUS (ºC) DISPLAY
32 FUNCTION INDICATING LIGHT
33 CONTROL PANEL 145L, 490L Control On Door
33 POWER ON/OFF CONTROL
34 UNLOCKING THE CONTROL PANEL
34 INTERIOR LIGHTING ON/OFF CONTROL

34 SELECTING FAHRENHEIT(ºF) & CELSIUS (ºC) DISPLAY
34 TEMPERATURE SETTING
36 TEMPERATURE DISPLAY WINDOW
37 CARE AND MAINTENANCE
37 CLEANING THE WINE COOLER
37 REMOVING THE SHELVES
38 Carbon Filter Change (Option)
38 Defrosting
39 Moving Your Wine Cooler
39 Power Failure
39 Vacation Time
39 Disconnecting From Power
40 TROUBLESHOOTING
41 REVERSE THE DOOR SWING
41 For 55L Control in Cabinet
43 For 56L Control On Door
43 For 130L Control in Cabinet
47 For 116L Control in Cabinet
47 For 22L/58L/88L/145L Control in Cabinet
53 For 270L/428L/468L/490L Control In Cabinet


INSTRUCTION MANUAL
•Please removed all packaging, stickers and films from the products surface and clean the
product’s surfaces with a damp cloth and mild deturgent before using for the first time.
•Let the appliance stand upright for approximately 24 hours before connecting it to the
power source, which helps to reduce the possibility of a cooling-system malfunction from
handling during transportation.
Before using your Wine Coolers, please carefully read this instruction manual
in order to maximize its performance. Store all documentation for subsequent
use or for other owners.This product is intended solely for household use or similar
applications such as:
--thekitchen area forpersonnelinshops, ocesandotherworking environments
--on farms, byclienteleofhotels,motelsandotherenvironmentsofaresidentialtype
--atbedandbreakfasts(B&B)
--forcatering servicesandsimilarapplicationsnotfor retail sale.
This appliance is intended to be used exclusively for the storage of wine or beverage,
any other use is considered dangerous and the manufacturer will not be responsible for
anyomissions.Also, it is recommended thatyoutakenoteof the warranty conditions.
IMPORTANT SAFETY INFORMATION
The Wine Coolers contains a refrigerant gas (R600a: isobutane)
and insulating gas (cyclopentane), with high compatibility with the
environment, that are, however, inammable.
We recommend that you follow the following regulations so as to avoid
situations dangerous to you:
Before performing any operation, unplug the power cord from the power
socket.
● The refrigeration system positioned behind and inside the Wine Coolers
contains refrigerant. Therefore, avoid damaging the tubes.
● If in the refrigeration system a leak is noted, do not touch the wall outlet
and do not use open ames. Open the window and let air into the room.
Then call a service centre to ask for repair.
● Do not scrape with a knife or sharp object to remove frost or ice that
occurs. With these, the refrigerant circuit can be damaged, the spill
from which can cause a re or damage your eyes.
● Do not install the appliance in humid, oily or dusty places, nor expose it
to direct sunlight and to water.
● Do not install the appliance near heaters or inammable materials.
● Do not use extension cords or adapters.


INSTRUCTION MANUAL
● Do not excessively pull or fold the power cord or touch the plug with wet
hands.
● Do not damage the plug and/or the power cord; this could cause electrical
shocks or res.
● It is recommended to keep the plug clean, any excessive dust residues on
the plug can be the cause re.
● Do not use mechanical devices or other equipment to hasten the defrosting
process.
● Absolutely avoid the use of open ame or electrical equipment, such as
heaters, steam cleaners, candles, oil lamps and the like in order to speed
up the defrosting phase.
● Do not use or store inflammable sprays, such as spray paint, near the
Wine Coolers. It could cause an explosion or  re.
● Do not use electrical appliances inside the food storage compartments,
unless they are of the type recommended by the manufacturer.
● Do not place or store inflammable and highly volatile materials such
as ether, petrol, LPG, propane gas, aerosol spray cans, adhesives, pure
alcohol, etc. These materials may cause an explosion.
● Do not store medicine or research materials in the Wine Coolers. When
the material that requires a strict control of storage temperatures is to
be stored, it is possible that it will deteriorate or an uncontrolled reaction
may occur that can cause risks.
● Maintain the ventilation openings in the appliance enclosure or in the
built-in structure, free of obstruction.
● Do not place objects and/or containers lled with water on the top of the
appliance.
● Do not perform repairs on this Wine Coolers. All interventions must be
performed solely by qualied personnel.
● This appliance can be used by children aged from 8 years and above
and by persons with reduced physical, sensory or mental capabilities or
with a lack of experience and knowledge; provided that they have been
given adequate supervision or instruction concerning how to use the
appliance in a safe way and understand the hazards involved.
● Children should not play with the appliance. Cleaning and user
maintenance should not be made by children without supervision
● This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.


INSTRUCTION MANUAL
Children should be supervised to ensure that they do not play with the
appliance.
● The appliance must be positioned so that the plug is accessible
● If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualied persons in order to avoid a hazard.
● The appliance shall not be installed in the laundry
● GWP for R600a: 3
● Do not store explosive substances such as aerosol cans with a ammable
propellant in this appliance.
– WARNING: Keep ventilation openings, in the appliance enclosure or in
the built-in structure, clear of obstruction.
– WARNING: Do not use mechanical devices or other means to accelerate
the defrosting process, other than those recommended by the
manufacturer.
– WARNING: Do not damage the refrigerant circuit.
– WARNING: Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type
recommended by the manufacturer
SCRAPPING OLD APPLIANCES
This appliance is marked according to the European directive 2012/19/EU
on Waste Electrical and Electronic Equipment (WEEE).
WEEE contains both polluting substances (which can cause negative
consequences for the environment) and basic components (which can
be re-used). It is important to have WEEE subjected to specic treatments,
in order to remove and dispose properly all pollutants, and recover and
recycle all materials.
Individuals can play an important role in ensuring that WEEE does not
become an environmental issue; it is essential to follow some basic rules:
--WEEE should not be treated as household waste;
--WEEE should be handed over to the relevant collection points managed
by the municipality or by registered companies. In many countries, for
large WEEE, home collection could be present.


INSTRUCTION MANUAL
In many countries, when you buy a new appliance, the old one may be
returned to the retailer who has to collect it free of charge on a one-to-one
basis, as long as the equipment is of equivalent type and has the same
functions as the supplied equipment.
Conformity
By placing the marking on this product, we declare, on our own responsibility,
compliance to all of European safety ,health and environmental requirements stated in
the legislation for this product.
Energy Saving
--Always ensure good ventilation. Do not cover ventilation opening or grille.
--Always keep fan louvers clear.
--Do not place appliance in areas of direct sunlight or close to a stove,
heather or similar object.
--Open or keep the doors open as little as possible
--Remove dust present on the rear of the appliance
Service
● You should not attempt to repair the appliance
yourself, as this could cause injury or a more serious
malfunction. If you require a service call then please
contact the Customer Care Department


INSTRUCTION MANUAL
DESCRIPTION OF APPLIANCE AND INSTALLATION
The following pictures only show description of appliance. The dimension and shelf
quantity may dier among the models of the same series.
55L Control In Cabinet
A.
C.
B.
D.
E.
Control Panel
Glass Door
Beech Shelves
Handle
Gasket
A
D
B
C
BE
Single Zone 18 Bottles
565~575
605~615
>560
200cm² Min.
200cm² Min.
453
460
555
555
590
455
440
2mm
3.5
20


INSTRUCTION MANUAL
To fix the appliance with Cabinet, pls. screw the 4 screws (ST4.2*12mm)
through the Top Bracket. The Top Bracket is pre-installed on top of
appliance.
A Top Bracket B Screws ST*mm
56L Control On Door
Control Panel
Handle
Long Shelf
Door
Short Shelf
Gasket
Outside Cabinet
Condenser
Adjustable
Foot
Single Zone 24 Bottles


INSTRUCTION MANUAL
>22
⁄”
>560mm
22⁄”
560mm
⁄”
(3mm)
⁄”
(3mm)
21
¼”
(540mm)
¾”
(20mm)
17⁄”
(455mm)
23⁄”
(592mm)
17¾”
(451mm)
31in
2
Min.
(200cm
2
Min.)
31in
2
Min.
(200cm
2
Min.)
17¾”
(453mm)
23⁄”-24¼”
(605-615mm)
22¼”-22¾”
(565-575mm)
⁄” Min.
(8mm) Min.
18⁄” Min.
(461mm) Min.
¾” (23mm)
⁄” Min.
(8mm) Min.


INSTRUCTION MANUAL
Front view of cabinet and Wine Cooler
 Before inserting the unit into the kitchen cabinet please unscrew the
original leveling feet in white and screw the short leveling
feet in black  which are packed as the accessory to the front
bottom of the unit
 Tighten the screws to fix the
Bottom Mounting Bar which has
been xed on the bottom of the unit to the kitchen cabinet
 For a rmly xing of the unit you can install an extra
Top Mounting
Bar which is an accessory packed with the unit onto the topside of
the unit and screw it with the kitchen cabinet See right drawing


INSTRUCTION MANUAL
130L Control In Cabinet
Dual Zone 41 Bottles
Control Panel
Handle
Long Shelf
Door
Short Shelf Gasket
Outside Cabinet
Condenser
Adjustable
Foot
>22
>560mm
¼”
(5mm)
¼”
(5mm)
21
¼”
(540mm)
¾”
(20mm)
23
(592mm)
23 -24¼”
(605-615mm)
22¼”-22¾”
(565-575mm)
Min.
(8mm) Min.
34
(878mm)
34½”
(876mm)
34
(885mm)
34
(886mm)
22
560mm
¾” (23mm)
⁄” Min.
(8mm) Min.
31in
2
Min.
(200cm
2
Min.)
31in
2
Min.
(200cm
2
Min.)


INSTRUCTION MANUAL
Front view of cabinet and Wine Cooler


INSTRUCTION MANUAL
 Before inserting the unit into the kitchen cabinet please unscrew the
original leveling feet in white and screw the short leveling
feet in black  which are packed as the accessory to the front
bottom of the unit
 Tighten the screws to fix the Bottom Mounting Bar which has
been xed on the bottom of the unit to the kitchen cabinet
 For a rmly xing of the unit you can install an extra Top Mounting
Bar which is an accessory packed with the unit onto the topside of
the unit and screw it with the kitchen cabinet See right drawing
22L Control In Cabinet
Control Panel
Chrome Shelf
Front Louver
Adjustable Foot
Outside Canbinet
Handle
Door
Gasket
Single Zone 7 Bottles
33½”
(850mm)
34¼”
(870mm)
>20⁄”
(525mm)
>34¼”
(870mm)
5⁄”
(150mm)
6⁄”
(155mm)
20⁄”
(525mm)
18¾”
(475mm)
•Height Adjustable:
863-883mm


INSTRUCTION MANUAL
58L Control In Cabinet
Control Panel
Control Panel
Long Shelf
Short Shelf
Front Louver Adjustable Foot
Outside Cabinet
Handle
Door
Gasket
Single & Dual Zone
Single Zone 19 Bottles 17 Bottles
Dual Zone
•Height Adjustable:
863-883mm


INSTRUCTION MANUAL
88L Control In Cabinet
Control Panel
Single Zone Dual Zone
34 Bottles 32 Bottles Single & Dual Zone
Long Shelf
Short Shelf
Front Louver
Outside Canbinet
Handle
Door
Gasket
Control Panel
Adjustable Foot
>22⁄”
(570)
≥15⁄”(385)
>33⁄”(860)
337⁄”
(860)
33⁄”
(840)
3⁄”
(100)
14⁄”(380)
•Height Adjustable:
853-873mm


INSTRUCTION MANUAL
116L Control In Cabinet
38 Bottles
Left & Right Zone
Control Panel (Left )
Control Panel(Right)
Long Shelf
Front Louver
Short Shelf
Adjustable Foot
Outside Cabinet
Handle
Door
Gasket
>22
(570)
≥23 (600)
23 (595)
>34¼”
(863)
34¼”
(863)
33½”
(850)
5
(150)
•Height Adjustable:
863-883mm


INSTRUCTION MANUAL
145L Control In Cabinet-Height:81.3cm
Control Panel
Single Zone Dual Zone
46 Bottles 46 Bottles Single & Dual Zone
Long Shelf
Short Shelf
Front Louver
Outside Canbinet
Handle
Door
Gasket
Control Panel
Foot
Adjustable
>22⁄”
(570)
≥23⁄”(600)
>32⁄”
(813)
32⁄”
(813)
31½”
(800)
23⁄”(595)
•Height Adjustable:
813-833mm


INSTRUCTION MANUAL
145L Control In Cabinet-Height:86.3cm
Control Panel
Single Zone Dual Zone
46 Bottles 46 Bottles Single & Dual Zone
Long Shelf
Short Shelf
Front Louver
Outside Canbinet
Handle
Door
Gasket
Control Panel
Foot
Adjustable
•Height Adjustable:
863-883mm


INSTRUCTION MANUAL
145L Control On Door-Height:86.3cm
Control Panel
Single Zone Dual Zone
54 Bottles 46 Bottles Single & Dual Zone
Long Shelf
(W/ 3-fold Rail)
Short Shelf
(W/ 2-fold Rail)
Front Louver
Outside Canbinet
Handle
Door
Gasket
Foot
Adjustable
•Height Adjustable:
863-883mm
