INTRODUCTION
This manualprovides necessary service and
maintenance instructions.
Read thismanual completely and
understand the machine before
servicing it.
This machinewill provide excellent service. However,
the best results will be obtained at minimum costs if:
SThe machine is operated with reasonable care.
SThe machine is maintained regularly-per the
maintenance instructions provided.
SThe machine is maintainedwith manufacturer
supplied or equivalentparts.
To view, print or download manualsonline visit
www.tennantco.com/manuals
PROTECT THE ENVIRONMENT
Please dispose of packaging materials
and used machine components such
as batteries in an environmentally safe
way according to yourlocal waste
disposal regulations.
Always remember to recycle.
Tennant Company
PO Box 1452
Minneapolis, MN 55440
Phone: [phone] or (763)513- 2850
www.tennantco.com
www.nobles.com
Trojan and HydroLINK are registered trademarks of Trojan Battery Company.
Specificationsandparts are subject to change withoutnotice.
OriginalInstructions. CopyrightE2014 Tennant Company.
All rights reserved. Printed in U.S.A.
INTENDED USE
The burnisher machine is intended for commercial use,
for example in hotels, schools, hospitals, factories,
shops, offices and rental businesses. It is designed to
burnish smooth dry hard floor surfaces (VCT, terrazzo,
marble, finishedhardwood, coated concrete, etc.) in an
indoorenvironmentonly. Do not use this machine on
carpeted surfaces. Use only recommendedburnishing
padsintended for machineapplication.Do not use this
machine other thandescribed in this Operator Manual.
MACHINE DATA
SERIAL NUMBER LABEL LOCATIONS
B7
SpeedGleam 7
B5
SpeedGleam 5
Please fillout at time of installation
for future reference.
ModelNo. -
SerialNo. -
InstallationDate -

B5/7, SpeedGleam®5/7 Service Information (1-14) 3
CONTENTS
Safety PrecautionS........................ 11
General information ..................... 21
COMPONENT LOCATOR.................... 22
ELECTRICAL SCHEMATIC, SYMBOLS........ 23
ELECTRICAL SCHEMATIC
DRIVE MODEL ...................... 24
ELECTRICAL SCHEMATIC
PUSH MODEL ...................... 26
OPERATIONAL MATRIX..................... 28
SPECIFICATIONS ........................... 29
FASTENER TORQUE ..................... 29
GENERAL MACHINE DIMENSIONS/
CAPACITIES/PERFORMANCE ........210
MACHINE DIMENSIONS................213
maintenance
MAINTENANCE CHART..................... 32
AFTER DAILY USE ....................... 33
AFTER WEEKLY USE ..................... 33
AFTER EVERY 50 HOURS OF USE ........ 34
AFTER EVERY 100 HOURS OF USE ....... 34
AFTER EVERY 200 HOURS OF USE ....... 34
AFTER EVERY 1000 HOURS OF USE...... 35
BATTERY MAINTENANCE .................. 35
SEALED/AGM BATTERIES ............... 35
WET/LEADACID BATTERIES ............ 35
HYDROLINK™BATTERY WATERING
SYSTEM OPTION ................... 36
MACHINE JACKING ........................ 37
PUSHING TOWING AND TRANSPORTING
THE MACHINE .......................... 37
STORING MACHINE ........................ 38
troubleShootinG
BDI FAULTS ................................ 42
SUBSYSTEM TROUBLESHOOTING .......... 44
BURNISH MOTOR ....................... 44
BATTERY CHARGER ON BOARD........ 46
BATTERY CHARGER OFF BOARD ....... 48
POWERUP CIRCUIT....................410
PROPEL OPTION .....................412
BURNISH HEAD
LIFT ACTUATOR OPTION...........414
VACUUM FAN OPTION................416
Service
SOFTWARE CONFIGURATION TOOL ........ 52
CONNECTING TO THE INTERFACE
MODULE ............................ 52
MACHINE CONFIGURATION
SOFTWARE .......................... 53
BATTERY CHARGER SETTING............... 54
PAD PRESSURE SETTING ................... 55
Contents Page
BURNISH MOTOR .......................... 56
VACUUM FAN.............................. 58
CONTROL MODULES....................... 59
ONBOARD BATTERY CHARGER............511
INTERFACE MODULE......................512
BAIL SWITCH OR POTENTIOMETER........513
Contents Page

CONTENTS
4B5/7, SpeedGleam®5/7 Service Information (1-14)

B5/7, SpeedGleam®5/7 Service Information (1-14) 1-1
SAFETY PRECAUTIONS
IMPORTANTSAFETY INSTRUCTIONS - SAVE THESEINSTRUCTIONS
The followingwarning precautions are used throughout
this manual as indicated in theirdescription:
WARNING: To warn of hazards or unsafe
practiceswhich couldresult in severe personal
injury or death.
FOR SAFETY: To identify actionswhich must be
followed for safe operation of equipment.
The followinginformation signalspotentially
dangerous conditions to the operator. Knowwhen
these conditions can exist. Locate all safety devices on
the machine.Report machinedamage or faulty
operation immediately.
WARNING: To Reduce the Risk of Fire,
Explosion, Electric Shock or Injury:
- Readmanual before operatingmachine.
- Do not use or pick up flammablematerials.
- Do not use near flammableliquids, vapors or
combustibledusts.
Thismachineisnot equipped with an
explosion proof motor. The electric motor will
sparkupon start up and duringoperation
which couldcauseaflash fire or explosion if
machine is usedinanareawhere flammable
vapors/liquids or combustibledusts are
present.
-Batteries emit hydrogen gas. Explosion or fire
canresult. Keep sparks and open flame away
when charging.
- Disconnect batterycables and charger cord
before cleaning and servicingmachine.
- Do not charge batteries with damaged cord. Do
not modify plug.
If the charger supply cord is damaged or
broken, it must be replaced by the
manufacturer or its service agent orasimilarly
qualified person in order to avoid a hazard.
The use of incompatible battery chargersmay
damage the battery and potentiallycauseafire
hazard.
- Do not use outdoors or on wet surfaces. Store
indoors.Thismachine is for dry use only.
-Thismachineisnot suitable for picking up
hazardousdust.
- Spinning pad, keep hands away.
FOR SAFETY:
1. Do notoperate machine:
- Unless trained and authorized.
- Unlessoperator manual is read and
understood.
- Unlessmentally and physicallycapable of
followingmachineinstructions.
- Under the influence of alcohol or drugs.
-While using a cell phone or other types of
electronic devices.
- If not in proper operating condition.
- In outdoor areas.Thismachine is for
indoor use only.
-With pads or accessories not supplied or
approved by Tennant. The use of other
pads may impair safety.
- In areaswith possible fallingobjects.
- In areas that are too dark to safely see the
controlsoroperate machine.
-Withoutdust bag and filters in place.
2. Before operatingmachine:
- Make sure all safety devicesare in place
and operate properly.
3. When operatingmachine:
-Useonly as described in thismanual.
-Report machine damage or faulty operation
immediately.
- Wear closed- toe, non- slipwork shoes.
-Reduce speedwhen turning.
-Keep hands away from spinning pad.
- Go slowly on inclines and slippery
surfaces.
- Do notburnish on inclines that 9% grade or
transport on inclines that exceed19.5%
grade.
- Do notcarry passengers on machine.
-Usecarewhen reversingmachine.
-Keep children and unauthorized persons
away from machine.
- Do not allow to be used asatoy.

1-2 B5/7, SpeedGleam®5/7 Service Information (1-14)
SAFETY PRECAUTIONS
4. Before leaving or servicingmachine:
- Stop on level surface.
- Set the parking brake, if equipped.
- Turn off machine and remove key.
5. When servicingmachine:
- Disconnect battery connection and charger
cord before working on machine.
- All work must be donewith sufficient
lighting and visibility.
- All repairs must be performed by trained
personnel.
-Use Tennant supplied or approved
replacement parts.
- Do not modify the machine from its original
design.
- Avoid moving parts. Do not wearloose
clothing or jewelry and secure long hair.
- Do notdisconnect the off- board charger’s
DC cord from the machine’s receptacle
when the charger is operating.Arcingmay
result. If the charger must be interrupted
during charging,disconnect the AC power
supply cord first.
- Do not use incompatible battery chargers
as thismay damage battery packs and
potentiallycauseafire hazard.
-Inspect charger cord regularly for damage.
-Keepwork area well ventilated.
- Avoid contactwith batteryacid.
-Keep all metal objects off batteries.
- Do notpower sprayorhose off machine.
-Use a hoist or adequate assistance when
lifting batteries.
-Jackmachine up at designated locations
only. Support machinewith jack stands.
- Block machine tires before jackingmachine
up.
- Useahoist or jack that will support the
weight of the machine.
- Wear personal protection equipment as
needed and whererecommended in this
manual.
For Safety: wear protective gloves.
For Safety: weareye protection.
For Safety: wear protective dust mask.
6. When loading/unloadingmachineonto/off
truck or trailer:
-Usearamp that can support the machine
weight and operator.
- Do notoperate the machine on a ramp
incline that exceedsa19.5% grade level.
-Useawinch if rampinclineexceeds a
19.5% grade level.
-Lower the pad driver after loading.
- Turn machine off and remove key.
- Set parking brake (if equipped).
- Block machinewheels.
-Use tie- down straps to secure machine.

B5/7, SpeedGleam®5/7 Service Information (1-14) 1-3
SAFETY PRECAUTIONS
SAFETY LABELS
The safety labelsappear on the machine in the locationsindicated.Replace labels if they are missing or become
damaged or illegible.
WARNING LABEL - Located on side of control console.
WARNING LABEL -
Disconnect battery
cables before servicing
machine.
Located on control board
cover.
WARNING LABEL -
Batteries emit
hydrogen gas.
Explosion or fire
canresult. Keep
sparks and open
flame away when
charging.
Located on backside
of machine cover.
WARNING LABEL -
Spinning Pad. KeepHands Away.
Located on burnishinghead.

1-4 B5/7, SpeedGleam®5/7 Service Information (1-14)
SAFETY PRECAUTIONS

GENERAL INFORMATION ..................... 21
COMPONENT LOCATOR.................... 22
ELECTRICAL SCHEMATIC, SYMBOLS........ 23
ELECTRICAL SCHEMATIC
DRIVE MODEL ...................... 24
ELECTRICAL SCHEMATIC
PUSH MODEL ...................... 26
OPERATIONAL MATRIX..................... 28
SPECIFICATIONS ........................... 29
FASTENER TORQUE ..................... 29
GENERAL MACHINE DIMENSIONS/
CAPACITIES/PERFORMANCE ........210
MACHINE DIMENSIONS................213
GENERAL INFORMATION
SECTION 2
Contents Page
2-1
B5/7, SpeedGleam®5/7 Service Information (1-14)

2-2 B5/7, SpeedGleam®5/7 Service Information (1-14)
GENERAL INFORMATION
COMPONENT LOCATOR B7 SHOWN
I
A
H
F
E
G
B
C
D
L
K
N
M
O
J
P
Q
Components
AHalf-Bridge Control Module
BCircuit Breakers
CBase Control Module
DI-Drive Control Module
(B/SG5*)
EDust bag and HEPA panel lter
FBurnish Head - 20", 24", 27"
(B7, 27" shown)
GBurnish Motor
HContact Switch, Pad Up/Down
IHead Lift Actuator*
JE-Stop Switch*
KUSB Programming Port
LInterface Control Module
MBurnish/Propel* Activation Bail
NPropel Transaxle*
OVacuum Fan*
PCover Contact Switch
QOnboard Battery Charger*
* Optional Equipment

B5/7, SpeedGleam®5/7 Service Information (1-14) 2-3
GENERAL INFORMATION
ELECTRICAL SCHEMATIC SYMBOLS
1
2
2
1
+ -
+ -
Switched B+
From Buss Bar
Switched B+
B- From
Stando
B- From
Stando
S-5 Seat Switch (N.O.)
Amer
Encoder
Cable
C1 Capacitor (0.01Uf)
R1
(11 Ω/40W)
+ -
MTR
ecH2O
Pump
J3-2 Brush RT-
J3-5 Brush LT+
J3-6 Brush LT-
Right/Rear Brush
Left/Front* Brush
* Cylindrical = Uses Adaptor
ecH2O
Control
Module
T16
Control
Board
VCC_A
Alarm
Com N.C.
N.O.
S-14 Pressure Sw.
N.C. Opens @ 25 +/- 2 psi
Enable
GND_A
GND_B
Pressure IN
(ECH2O SW)
(ECH2O SW)
VCC_B
VCC_C
Pump
(SOL-A)
ecH2O Valve
Sparger
e-Cell
65EA/BLU
5EA/GRN
8EA/GRY
7EA/PUR
3EA/ORA
4EA/YEL
(SOL-B)
(SPA-A)
(SPA-B)
(CELL-A)
(CELL-B)
(LED GND)
(LED RED)
(LED GRN)
Squeegee
Actuator
Battery Positive +
Battery Negative -
D-8
FU2
100A
70/TAN
M4A
86 85
B+
J7-1 B+ Control
B-
Cable
8/GRY
FU1
100A
FU1
100A
102/BRN
Sweep OFF/Down = 2-1, 6-5
Sweep ON/Center = 2-3, 6-7
Vac & Sweep ON/Up = 3-4, 7-8
Cable
Pre-Sweep
Brush Relay
CB3 (2.5A)
CB19 (25A)
CB16 (15A)
J7-4 Sweep
Note:
ecH2O Enable:
J7-10 Low=Turn ON ecH2O
Note:
Pre-Sweep Enable:
J6-10 B+ = Sweep Enable ON
Sweep Enable J6-10
37/PUR
38/GRY
CB9 (2.5A) 79/WHT
CB10 (2.5A)
Note:
ecH2O Side Brush
J7-12 Low=SV3 H20 Valve ON
ecH2O Pump ON 100%
13/BLK
88/GRY
9EA/WHT
S-15
Flush Switch
13EA/BLK
21/PNK
Extend
Limit Sw.
22/BRN
MTR 26/BLU
25/GRN
2/BRN
Switched B+
From Buss Bar
Switched B+
From Buss Bar
Switched B+
To: CAN Open-
(J6-14)
To: Throttle
Sensor (GND)
To: Curtis 1234
(I/O GND)
To: CAN Open+
(J6-13)
To: Back-Up
Light Circuit
To: Back-Up
Alarm Circuit
80/TAN
PMC001
12
12
MTR
10 4
1
3
2
7
9
6-4
6-8
5
6
11
12
8
6-1
6-2
6-3
6-6
6-5
6-7
ON
OFF
6
2
8
5
4
1
FWD
REV
6
2
8
BA
5
4 J1-33
GND Cable
J1-34
J1-21
W/WHT
V/GRN
U/ORN
J1-3
J1-4
J1-13
J1-11
BLU2 J1-32
J1-26
J1-31
J1-7
J1-18 J1-15
66/BLU 61/PNK
62/BRN 12/BRN
17/PUR
Propel Motor Assembly
17/PUR
15/GRN
87/PUR
Temp Sender
Brake Solenoid
59/WHT
58GRY
RED1 WHT5 BLK6
YEL
T2
B1 B2
T1
YEL
J1-16 J1-35 J1-23
P1-C
BLU
YEL
P1-B
P1-D
BLK
P1-A
RED
J1-22
J1-9
J1-1
B+
J1-29
J1-28
J1-25
1
1
3
5
7
2
4
6
8
Pre-Sweep Switch
Sweep OFF/Down = 2-1, 6-5
Sweep ON/Center = 2-3, 6-7
Vac & Sweep ON/Up = 3-4, 7-8
1
3
5
7
2
4
6
8
M3B
MTR
MTR
MTR
MTR
FaST/ES Pump
D-9
D-6
D-7
D-12
67/PUR
64/YEL 81/PNK
Pre-Sweep
Vacuum Fan
LH Side Broom Motor
Main Broom Motor
13/BLK
13/BLK
65/GRN
65/GRN
65/GRN
68/GRY
69/WHT
D-11
30 87
M3A
Curtis 1234
Controller
PROG +
TX
RX
B+
KSI
INTERLOCK
FWD
FWD/REV Switch
Throttle Sensor
REV
B -
GND
B+
THROTTLE
BRAKE
CAN TERM L
CAN TERM H
U
DRV3
DRV4
DRV1 THERMISTOR I/O GND PHASE A PHASE B +5V DRV2
COIL RETURN
V
W
BRAKE IN
(0-5 vdc)
(0-5 vdc) THROTTLE
CAN L
8/GRY 8/GRY
18/GRY
16/BLU
94/YEL
9/WHT
11/PNK
14/YEL
58/GRY
58/GRY
CAN H
6 Volt
IGN
15
ACC
30
BAT T
75
50 Start
ST
To: Back-Up
Alarm Circuit
+ -
Com N.C.
N.O.
1
3
5
7
2
4
6
8
MTR MTR
M3B
30 87
M3B
30 87a
M3A
IGN ST
+ -
Note: Key Switch ON
Key Switch
Battery
DPDT Switch
Pressure Switch
Motor
3 Phase AC
Induction Motor
Motor Encoder
Momenary Switch N.O.
Contact Switch N.C.
Solenoid Valve
Sensor
(Variable Resistor)
Circuit Breaker
Fuse
Diode
Single Continuation Tab
Double Continuation Tab
Relay Coil
N.C. Relay Contacts
N.O. Relay Contacts
Horn or Alarm
Light
Connected
Not Connected
Connector
Energized
Adaptor Harness
Notes
Assembly
AC Plug
Capacitor
Electro-
Magnetic
Brake
Enabled (Applied)
• Key O
• Neutral - Ready State
• Brake Command
• Seat Switch Open
• Curtis 1234 Fault
(See Troubleshooting)
• Throttle Command
• Seat Switch Closed
Disabled (Released)
Operational Matrix:
Propel
Enabled
•Seat Switch Closed
• Foot Throttle
Command
• Fwd/Rev Switch Input
• Seat Switch Open
• Neutral-Ready State
• Brake Command
• Curtis 1234 Fault
Disabled
Operational Matrix:
* SV2 Water Valve Voltage
Range
Low 1-LED
2-LEDs
3-LEDs
1-LED
2-LEDs
3-LEDs
1-LED
2-LEDs
3-LEDs
20%
30%
45%
30%
55%
80%
55%
80%
100%
7.2 Volts
10.8 Volts
16.2 Volts
10.8 Volts
19.8 Volts
28.8 Volts
19.8 Volts
28.8 Volts
36 Volts
Med
(Default)
High
Level PWM% @ Nominal
36 VDC

2-4 B5/7, SpeedGleam®5/7 Service Information (1-14)
GENERAL INFORMATION
ELECTRICAL SCHEMATIC (DRIVE MODEL) - 1 of 2
B5/SpeedGleam5 (3 x 12 vDC)
B7/SpeedGleam7 (6 x 6 vDC)
36 VOLT CONFIGURATIONS
PROPEL
MODULE
(OPTIONAL)
CAN BUS
SW-9:
HOOD DISABLE SWITCH (OPEN = HOOD UP = MACHINE OFF)
SW-2
13
OFF BOARD CHARGER CABLE (OPTION)
SW-1 = CHARGER INTERLOCK SWITCH OFF-BOARD CHARGER ONLY: SW.
N.O.
N.C.
COM
I-DRIVE STATUS
COMMUNICATION CABLE (SHIELDED)
POWER ON/OFF CIRCUITRY
B5 CABLE B+/FUSE ASSY B7 CABLE B+/FUSE ASSY
GROUND
B+
SWITCHED, B+
OPERATOR'S SWITCH/LIGHT PANEL
I-DRIVE PROPEL SYSTEM
OPTIONAL ON B5/SpeedGleam 5
STANDARD ON B7/SpeedGleam 7
CABLE, CHARGER
BDI_0
BDI_1
BDI_2
BDI_3
BDI_4
MTR HOT
SERVICE
DB FULL
IRIS
DP LOW
DP MED
DP HIGH
GROUND
INCREASE
DECREASE
REVERSE SWITCH
(GND. = REV.)
SW-4
ENABLE I-DRIVE
(B+ = ON)
FOOTPEDAL / PAD CHANGE
I-DRIVE SUPPLY VOLTAGE DETECT
AC PLUG
KEY SWITCH
J1-9 J1-8 J1-7 J1-6 J1-10 J1-11 J1-12
J1-5
J1-4
J1-3
J1-2
J1-1
J2-8
J2-2
J2-1
J10-1
J10-2
J10-3
J11-1
J11-2
BAIL SWITCH INPUT @J4-4: 0V OR 5V
0V = NEUTRAL / BURNISH MTR OFF.
5V = MAX. PROPEL / BURNISH MTR ON.
BAIL SWITCH (N.O.)
SW-5:
NO CONNECTION
SENSOR OUTPUT: 0.5 TO 4.5VDC.
0.5V = NEUTRAL
4.5V = MAX. PROPEL
SENSOR REPL. SW-5.
J4-4
J4-1
J4-3
OPT: BAIL POSITION SENSOR ASSY
LED1
LED2
LED3
LED4
LED5
LED7
LED6
LED8
LED9
LED10
LED11
LED12
SW2
SW1
OPT: Active Down Pressure
NOTE: The Active Down Pressure
buttons and LEDs exist on all
machines, but are only visible on
models equipped with automated
down pressure. On models
equipped with mechanical “Set and
Forget™” down pressure, the LH (SW1)
button is used to enter pressure
adjust mode. Refer to the operator’s
manual for more information.
OPT: BAILSW. HARNESS
I-DRIVE_AUX2
I-DRIVE_AUX3
CAN GROUND
NO CONNECTION
J4-2
NO CONNECTION
J2-4 J2-3
CAN BUS
RS232 DEBUG PORT
CAN BUS
STATIC GROUNDING
(PART OF MAIN HARNESS
AND OP.STATION HARNESS)
CABLE, CHARGER
CABLE, CHARGER
1/RED
BLK
1/RED
13/BLK1/RED
9/WHT
10/TAN
13/BLK 13/BLK1/RED YRG/8YRG/8
NRB/21NRB/21
34/YEL
35/GRN
33/ORA
CABLE: RED
CABLE: BLACK
1/RED
3/ORA
RED
CABLE: NATURAL
7/PUR
6/BLU
4/YEL
35/GRN
34/YEL
33/ORA
SHIELD/GRN
CABLE:NATURAL
CABLE: RED
CABLE: BLACK
SHIELD/GRN
37/PUR
36/BLU
37/PUR
36/BLU
24/YEL
27/PUR
KNP/11KNP/11
13/BLK
5/GRN
6/BLU
KLB/31KLB/31 13/BLK
13/BLK
GRN
GRN
GRN
WHT
WHT
BROWN (+5VDC)
BLACK (SENSOR OUTPUT)
BLU (GROUND)
CAN+ /YEL CAN- /GRN
4/YEL
4/YEL
7/PUR
5/GRN
30/TAN
31/PNK
LEY/41LEY/41
ULB/62ULB/62
113/BLK/WHT
113/BLK/WHT
CAN- /GRN
CAN+ /YEL
105/GRN
105/GRN
105/GRN
105/GRN
105/GRN
13/BLK
TO: BATT. GROUND
13
1
6
24
27
CAN+ CAN-
13
113
113
CAN-
CAN+
CAN- CAN+
13
SW-1
CHARGER: ON BOARD
NC
P2-2
GND
P1-B-
B+
P1-B+
COM
P2-3
CAN+
P2-6
CAN-
P2-10
NO
P2-4
CAN_GND
P2-1
SENSE+
P2-5
SENSE-
P2-14
RESERVED3
P2-11
LED+
P2-12
LED-
P2-13
RESERVED1
P2-8
RESERVED2
P2-9
RETURN
P2-7
OP.STATION
CB-1
2.5A
6 VDC
+ --
12 VDC
+ --
BURNISH HEAD
I-DRIVE
B+
P2-B+
ON/OFF
P1-5
M2
P2-M2
M1
P2-M1
GND_REF
P1-13
B-
P2-B-
AUX2_OUT
P1-3
FUSED, B+_OUT
P1-7
STATUS
P1-10
POT LOW
P1-8
REVERSE
P1-12
SPD LIMIT
P1-9
POT HIGH
P1-2
AUX3_OUT
P1-11
PROG_B+
P3-2
LOW SPEED
P1-4
DIGITAL_GND
P3-1
TX
P3-3
RX
P3-4
WIPER_IN
P1-1
OPEN_B
P1-6
OPEN_C
P1-14
VAC FAN
100K PROPEL SPEED LIMIT
POT.-1
1
2
3
6 VDC
+ --
6 VDC
+ --
CHASSIS GND. STRAP @ FRAME
INTERFACE MODULE
+5V OUT
J4-1
CAN-
J3-2
CAN+
J3-1
CHARGER INPUT
J7-9
KSI
J7-10
SENSE_GND
J4-3
COMM_GND
J5-1
TX
J5-3
RX
J5-4
V_BUS
J6-1
SHLD_GND
J3-3
N/C
J3-4
SENSOR_IN
J4-4
WIPER OUT
J5-2
GND
J7-8
COM_GND2
J2-3
TX_2
J2-1
RX_2
J2-2
+5VDC_OUT
J7-1
D-
J6-2
D+
J6-3
ID
J6-4
GND_SHIELD
J6-5
LSD_OUT_0
J7-5
LSD_OUT_1
J7-6
LSD_FLYBACK
J7-7
INPUT_0
J7-2
INPUT_1
J7-3
INPUT_2
J7-4
LED_+5VDC_OUT
J9-1
BDI_0_LED
J9-2
BDI_1_LED
J9-3
BDI_2_LED
J9-4
BDI_3_LED
J9-5
BDI_4_LED
J9-6
MTR_HOT_LED
J9-7
SERVICE_LED
J9-8
DB_FULL_LED
J9-9
IRIS_LED
J9-10
DP_1_LED
J9-11
DP_2_LED
J9-12
DP_3_LED
J9-13
SPARE_LED
J9-14
GND_1
J9-15
DP_INC_SW
J9-16
DP_DEC_SW
J9-17
SPARE_SW1
J9-18
SPARE_SW2
J9-19
GND_2
J9-20
NOT USED
J4-2
6 VDC
+ --
OPT: BAIL POS. SENSOR
GND
2
+5V
3
OUTPUT
1
MTR1
PROPEL MOTOR
2 1
6 VDC
+ --
12 VDC
+ --
KEY SWITCH
CB3
30A
6 VDC
+ --
12 VDC
+ --

B5/7, SpeedGleam®5/7 Service Information (1-14) 2-5
GENERAL INFORMATION
ELECTRICAL SCHEMATIC (DRIVE MODEL) - 2 of 2
ENABLE I-DRIVE
CABLE MOTOR TO 1/2 BRIDGE PCB
J5 & J11 (EVEN PINS 2 THROUGH 20) = GROUND.
GROUND
B+
SWITCHED, FUSED, B+
CAN+ CAN-
RIBBON CABLE ASSY.
I-DRIVE B+ DETECT
E-STOP SWITCH
INTERNAL TO BURNISH MOTOR
FOOTPEDAL / PAD CHANGE
FOOT PEDAL/PAD CHANGE SW.
(GND. = ENABLE BURNISH)
SW-7: N.O.H.C.
I-DRIVE STATUS
I-DRIVE_AUX3
I-DRIVE_AUX2
HOUR METER
5.0 AMPS
OPTIONAL: BURNISH HEAD ACTUATOR
1/2 BRIDGE MODULE
BASE BURNISHER MODULE
CABLE B+/FUSE ASSY
RS232 DEBUG PORT
7-2J6-2J
J2-5
CABLE B+/FUSE ASSY
13/BLK13/BLK
24/YEL
CAN- /GRNCAN- /GRN
6/BLU 6/BLU6/BLU
1/RED
BLU2/BRN
13/BLK 13/BLK2/BRN
6/BLU
CAN+ /YELCAN+ /YEL
11/PNK38/GRY38/GRY
13/BLK13/BLK
13/BLK28/GRY
27/PUR
27/PUR 13/BLK27/PUR
ULB/62ULB/62
LEY/41LEY/41
NRB/21NRB/21
17/PUR
1/RED ULB/61ULB/61
19/WHT
22/BRN
23/ORA
38/GRY
11/PNK
13/BLK17/PUR
25/GRN19/WHT
13/BLK13/BLK
24
13
6
1
CAN-
CAN+
11
27
12
26
14
13
+ -
MTR3
OPTIONAL: VAC FAN
21
BASE CONTROLLER
GND_POWER_A
J12-7
B+_MONITOR
J11-1
HOURMETER+
J10-4
KSI
J10-1
ACT_2
J12-6
B+_B
J12-2
VAC
J12-4
ACT_1
J12-5
GND_RETURN
J5-10
CAN-
J3-2
CAN+
J3-1
I-DRIVE STATUS
J5-5
AUX2 INPUT
J5-3
OPEN
J5-6
MTR TEMP
J10-3
E-STOP OUT
J5-2
AUX3 INPUT
J5-4
SHIELD_GND
J3-3
N/C_1
J3-4
B+ FROM I-DRIVE
J5-7
+5V
J11-3
+12V
J11-5
I_SET
J11-7
I_PEAK
J11-9
OVER_I
J11-11
PWM
J11-13
ENABLE
J11-15
SPARE_2
J11-17
SPARE_1
J11-19
I-DRIVE ENABLE
J5-1
SPARE_A
J5-8
SPARE_B
J5-9
M1_COIL-
J10-5
M1_COIL+
J10-6
B+_A
J12-1
PAD CHANGE
J12-3
GND_POWER_B
J12-8
CAN+_2
J6-1
CAN-_2
J6-2
SHIELD_GND_2
J6-3
N/C_2
J6-4
RX
J2-2
TX
J2-1
RS232_GND
J2-3
GND_RETURN_2
J10-2
FUSE-1
100A
SW-6
MOTOR TEMP. SW. (N.C.)
A B
CB2
15A
MTR2
BURNISHER MOTOR
21
1/2 BRIDGE
B+
J2-1
GND
J4-1
MTR, LOW SIDE
J1-1
B+_OUT
J5-1
+5V
J5-3
+12V
J5-5
I_SET
J5-7
I_PEAK
J5-9
OVER_I
J5-11
PWM
J5-13
ENABLE
J5-15
SPARE_2
J5-17
SPARE_1
J5-19
EXTEND LIMIT SW.
RETRACT LIMIT
BLU
BRN
BLK
RED
MTR4
2
1

2-6 B5/7, SpeedGleam®5/7 Service Information (1-14)
GENERAL INFORMATION
ELECTRICAL SCHEMATIC (PUSH MODEL) - 1 of 2
B5/SpeedGleam5 (3 x 12 vDC)
36 VOLT CONFIGURATIONS
CAN BUS
SW-9:
HOOD DISABLE SWITCH (OPEN = HOOD UP = MACHINE OFF)
SW-2
13
OFF BOARD CHARGER CABLE (OPTION)
SW-1 = CHARGER INTERLOCK SWITCH OFF-BOARD CHARGER ONLY: SW.
N.O.
N.C.
COM
POWER ON/OFF CIRCUITRY
B5 CABLE B+/FUSE ASSY
GROUND
B+
SWITCHED, B+
OPERATOR'S SWITCH/LIGHT PANEL
CABLE, CHARGER
BDI_0
BDI_1
BDI_2
BDI_3
BDI_4
MTR HOT
SERVICE
DB FULL
IRIS
DP LOW
DP MED
DP HIGH
GROUND
INCREASE
DECREASE
AC PLUG
KEY SWITCH
J2-8
J2-2
J2-1
BAIL SWITCH INPUT @J4-4: 0V OR 5V
0V = NEUTRAL / BURNISH MTR OFF.
5V = MAX. PROPEL / BURNISH MTR ON.
BAIL SWITCH (N.O.)
SW-5:
NO CONNECTION
SENSOR OUTPUT: 0.5 TO 4.5VDC.
0.5V = NEUTRAL
4.5V = MAX. PROPEL
SENSOR REPL. SW-5.
J4-4
J4-1
J4-3
OPT: BAIL POSITION SENSOR ASSY
LED1
LED2
LED3
LED4
LED5
LED7
LED6
LED8
LED9
LED10
LED11
LED12
SW2
SW1
OPT: Active Down Pressure
NOTE: The Active Down Pressure
buttons and LEDs exist on all
machines, but are only visible on
models equipped with automated
down pressure. On models
equipped with mechanical “Set and
Forget™” down pressure, the LH (SW1)
button is used to enter pressure
adjust mode. Refer to the operator’s
manual for more information.
OPT: BAILSW. HARNESS
CAN GROUND
NO CONNECTION
J4-2
NO CONNECTION
J2-4 J2-3
CAN BUS
RS232 DEBUG PORT
CAN BUS
STATIC GROUNDING
(PART OF MAIN HARNESS
AND OP.STATION HARNESS)
CABLE, CHARGER
CABLE, CHARGER
1/RED
BLK
1/RED
13/BLK1/RED
1/RED
3/ORA
RED
7/PUR
6/BLU
4/YEL
13/BLK
5/GRN
6/BLU
KLB/31KLB/31 13/BLK
13/BLK
BROWN (+5VDC)
BLACK (SENSOR OUTPUT)
BLU (GROUND)
CAN+ /YEL CAN- /GRN
4/YEL
4/YEL
7/PUR
5/GRN
30/TAN
31/PNK
113/BLK/WHT
113/BLK/WHT
CAN- /GRN
CAN+ /YEL
105/GRN
105/GRN
105/GRN
105/GRN
105/GRN
13/BLK
TO: BATT. GROUND
13
1
6
CAN+ CAN-
13
113
113
CAN-
CAN+
CAN- CAN+
13
SW-1
CHARGER: ON BOARD
NC
P2-2
GND
P1-B-
B+
P1-B+
COM
P2-3
CAN+
P2-6
CAN-
P2-10
NO
P2-4
CAN_GND
P2-1
SENSE+
P2-5
SENSE-
P2-14
RESERVED3
P2-11
LED+
P2-12
LED-
P2-13
RESERVED1
P2-8
RESERVED2
P2-9
RETURN
P2-7
OP.STATION
CB-1
2.5A
12 VDC
+ --
BURNISH HEAD
VAC FAN CHASSIS GND. STRAP @ FRAME
INTERFACE MODULE
+5V OUT
J4-1
CAN-
J3-2
CAN+
J3-1
CHARGER INPUT
J7-9
KSI
J7-10
SENSE_GND
J4-3
COMM_GND
J5-1
TX
J5-3
RX
J5-4
V_BUS
J6-1
SHLD_GND
J3-3
N/C
J3-4
SENSOR_IN
J4-4
WIPER OUT
J5-2
GND
J7-8
COM_GND2
J2-3
TX_2
J2-1
RX_2
J2-2
+5VDC_OUT
J7-1
D-
J6-2
D+
J6-3
ID
J6-4
GND_SHIELD
J6-5
LSD_OUT_0
J7-5
LSD_OUT_1
J7-6
LSD_FLYBACK
J7-7
INPUT_0
J7-2
INPUT_1
J7-3
INPUT_2
J7-4
LED_+5VDC_OUT
J9-1
BDI_0_LED
J9-2
BDI_1_LED
J9-3
BDI_2_LED
J9-4
BDI_3_LED
J9-5
BDI_4_LED
J9-6
MTR_HOT_LED
J9-7
SERVICE_LED
J9-8
DB_FULL_LED
J9-9
IRIS_LED
J9-10
DP_1_LED
J9-11
DP_2_LED
J9-12
DP_3_LED
J9-13
SPARE_LED
J9-14
GND_1
J9-15
DP_INC_SW
J9-16
DP_DEC_SW
J9-17
SPARE_SW1
J9-18
SPARE_SW2
J9-19
GND_2
J9-20
NOT USED
J4-2
OPT: BAIL POS. SENSOR
GND
2
+5V
3
OUTPUT
1
12 VDC
+ --
KEY SWITCH
12 VDC
+ --

B5/7, SpeedGleam®5/7 Service Information (1-14) 2-7
GENERAL INFORMATION
ELECTRICAL SCHEMATIC (PUSH MODEL) - 2 of 2
ENABLE I-DRIVE
CABLE MOTOR TO 1/2 BRIDGE PCB
J5 & J11 (EVEN PINS 2 THROUGH 20) = GROUND.
GROUND
B+
SWITCHED, FUSED, B+
CAN+ CAN-
RIBBON CABLE ASSY.
I-DRIVE B+ DETECT
E-STOP SWITCH
INTERNAL TO BURNISH MOTOR
FOOTPEDAL / PAD CHANGE
FOOT PEDAL/PAD CHANGE SW.
(GND. = ENABLE BURNISH)
SW-7: N.O.H.C.
I-DRIVE STATUS
I-DRIVE_AUX3
I-DRIVE_AUX2
HOUR METER
5.0 AMPS
OPTIONAL: BURNISH HEAD ACTUATOR
1/2 BRIDGE MODULE
BASE BURNISHER MODULE
CABLE B+/FUSE ASSY
RS232 DEBUG PORT
7-2J6-2J
J2-5
CABLE B+/FUSE ASSY
13/BLK13/BLK
24/YEL
CAN- /GRNCAN- /GRN
6/BLU 6/BLU6/BLU
1/RED
BLU2/BRN
13/BLK 13/BLK2/BRN
6/BLU
CAN+ /YELCAN+ /YEL
11/PNK38/GRY38/GRY
13/BLK13/BLK
13/BLK28/GRY
27/PUR
27/PUR 13/BLK27/PUR
ULB/62ULB/62
LEY/41LEY/41
NRB/21NRB/21
17/PUR
1/RED ULB/61ULB/61
19/WHT
22/BRN
23/ORA
38/GRY
11/PNK
13/BLK17/PUR
25/GRN19/WHT
13/BLK13/BLK
24
13
6
1
CAN-
CAN+
11
27
12
26
14
13
+ -
MTR3
OPTIONAL: VAC FAN
21
BASE CONTROLLER
GND_POWER_A
J12-7
B+_MONITOR
J11-1
HOURMETER+
J10-4
KSI
J10-1
ACT_2
J12-6
B+_B
J12-2
VAC
J12-4
ACT_1
J12-5
GND_RETURN
J5-10
CAN-
J3-2
CAN+
J3-1
I-DRIVE STATUS
J5-5
AUX2 INPUT
J5-3
OPEN
J5-6
MTR TEMP
J10-3
E-STOP OUT
J5-2
AUX3 INPUT
J5-4
SHIELD_GND
J3-3
N/C_1
J3-4
B+ FROM I-DRIVE
J5-7
+5V
J11-3
+12V
J11-5
I_SET
J11-7
I_PEAK
J11-9
OVER_I
J11-11
PWM
J11-13
ENABLE
J11-15
SPARE_2
J11-17
SPARE_1
J11-19
I-DRIVE ENABLE
J5-1
SPARE_A
J5-8
SPARE_B
J5-9
M1_COIL-
J10-5
M1_COIL+
J10-6
B+_A
J12-1
PAD CHANGE
J12-3
GND_POWER_B
J12-8
CAN+_2
J6-1
CAN-_2
J6-2
SHIELD_GND_2
J6-3
N/C_2
J6-4
RX
J2-2
TX
J2-1
RS232_GND
J2-3
GND_RETURN_2
J10-2
FUSE-1
100A
SW-6
MOTOR TEMP. SW. (N.C.)
A B
CB2
15A
MTR2
BURNISHER MOTOR
21
1/2 BRIDGE
B+
J2-1
GND
J4-1
MTR, LOW SIDE
J1-1
B+_OUT
J5-1
+5V
J5-3
+12V
J5-5
I_SET
J5-7
I_PEAK
J5-9
OVER_I
J5-11
PWM
J5-13
ENABLE
J5-15
SPARE_2
J5-17
SPARE_1
J5-19
EXTEND LIMIT SW.
RETRACT LIMIT
BLU
BRN
BLK
RED
MTR4
2
1

2-8 B5/7, SpeedGleam®5/7 Service Information (1-14)
GENERAL INFORMATION
FUNCTION ENABLED
B5/7, SpeedGleam5/7 OPERATIONAL MATRIX
DISABLED
Burnish Motor - On • Burnish Head Down
• Burnish Bail Activated
• Burnish Head Up
• Burnish Bail Release
• Low Battery Voltage (< 32.5 vDC)
• Load Current Fault
• Battery Charger ON Interlock
• Access Cover Open
Vacuum Fan
(Optional)
• Burnish Head Down
• Burnish Bail Activated
• Burnish Head Up
• Burnish Bail Release
• Low Battery Voltage (< 32.5 vDC)
• Load Current Fault
• Battery Charger ON Interlock
• Access Cover Open
MOM001
Propel (Optional on B/SG5) • Battery Charger ON Interlock
• Neutral - Ready State
• Low Battery Voltage (< 30.0 vDC)
• Load Current Fault
• Access Cover Open
• Neutral Input at Power Up
• Burnish/Propel Bail
Activated

B5/7, SpeedGleam®5/7 Service Information (1-14) 2-9
GENERAL INFORMATION
FASTENER TORQUE
Thread
Size
SAE
Grade 1
SAE
Grade 2
Carriage
Bolts
Thread
Cutting
Thread
Rolling
SAE
Grade 5
Socket &
Stainless
Steel
SAE
Grade 8
Headless
Socket Set
Screws
Square
Head Set
Screws
4 (.112) (5) - (6.5) (4) - (6)
Inch Pounds
5 (.125) (6) - (8) (9) - (11)
6 (.138) (7) - (9) (20) - (24) (9) - (11)
8 (.164) (12) - (16) (40) - (47) (17) - (23)
10 (.190) (20) - (26) (50) - (60) (31) - (41)
1/4 (.250) 4 - 5 5 - 6 7 - 10 7 - 10 10 - 13 6 - 8 17 - 19
Foot Pounds
5/16 (.312) 7 - 9 9 - 12 15 - 20 15 - 20 20 - 26 13 - 15 32 - 38
3/8 (.375) 13 - 17 16 - 21 27 - 35 36 - 47 22 - 26 65 - 75
7/16 (.438) 20 - 26 26 - 34 43 - 56 53 - 76 33 - 39 106 - 124
1/2 (.500) 27 - 35 39 - 51 65 - 85 89 - 116 48 - 56 162 - 188
5/8 (.625) 80 - 104 130 - 170 171 - 265 228 - 383
3/4 (.750) 129 - 168 215 - 280 313 - 407 592 - 688
1 (1.000) 258 - 335 500 - 650 757 - 984 1281 - 1489
Thread
Size
4.8/5.6 8.8
Stainless Steel
10.9 12.9 Set
Screws
M3 43 - 56 Ncm 99 - 128 Ncm 139 - 180 Ncm 166 - 215 Ncm 61 - 79 Ncm
M4 99 - 128 Ncm 223 - 290 Ncm 316 - 410 Ncm 381 - 495 Ncm 219 - 285 Ncm
M5 193 - 250 Ncm 443 - 575 Ncm 624 - 810 Ncm 747 - 970 Ncm 427 - 554 Ncm
M6 3.3 - 4.3 Nm 7.6 - 9.9 Nm 10.8 - 14 Nm 12.7 - 16.5 Nm 7.5 - 9.8 Nm
M8 8.1 - 10.5 Nm 18.5 - 24 Nm 26.2 - 34 Nm 31 - 40 Nm 18.3 - 23.7 Nm
M10 16 - 21 Nm 37 - 48 Nm 52 - 67 Nm 63 - 81 Nm
M12 28 - 36 Nm 64 - 83 Nm 90 - 117 Nm 108 - 140 Nm
M14 45 - 58 Nm 102 - 132 Nm 142 - 185 Nm 169 - 220 Nm
M16 68 - 88 Nm 154 - 200 Nm 219 - 285 Nm 262 - 340 Nm
M20 132 - 171 Nm 300 - 390 Nm 424 - 550 Nm 508 - 660 Nm
M22 177 - 230 Nm 409 - 530 Nm 574 - 745 Nm 686 - 890 Nm
M24 227 - 295 Nm 520 - 675 Nm 732 - 950 Nm 879 - 1140 Nm
METRIC
SAE (STANDARD)

2-10 B5/7, SpeedGleam®5/7 Service Information (1-14)
GENERAL INFORMATION
MODEL (20 in / 510 mm) Push Model (20 in / 510 mm) Drive Model
Length 59 in / 1499 mm 59 in / 1499 mm
Width 24.5 in / 622 mm 24.5 in / 622 mm
Height 43 in / 1092 mm 43 in / 1092 mm
Weight 193 lb / 87.5 kg 198 lb / 90 kg
Weight with batteries 507 lb / 230 kg 572 lb / 259 kg
Burnish path width 20 in / 510 mm 20 in / 510 mm
Productivity rate (max.) 16,260 ft/hr / 1,500 m/hr 20,000 ft/hr / 1,900 m/hr
Productivity rate (practical) 13,500 ft/hr / 1,200 m/hr 18,000 ft/hr / 1,670 m/hr
Burnishing speeds (Variable) Pad Assist Min: 100 fpm / 30 mpm
Max: 200 fpm / 60 mpm
Transport speed (max.) n/a Fwd: 240 fpm/ 73 mpm
Rev: 144 fpm/ 44 mpm
Aisle turn (min.) 60 in / 1,524 mm 60 in / 1,524 mm
Grade level (max.) Burnishing: 9%, Transport: 19.5% Burnishing: 9%, Transport: 19.5%
Propel Motor n/a 24 V, 14 A, .363 hp / 0.27 kW, 271 W
Pad motor 36 V, 75 A, 2.8 hp max / 2.1 kW 36 V, 75 A, 2.8 hp max / 2.1 kW
Pad Pressure Variable Variable
Pad speed 2100 rpm 2100 rpm
Vacuum motor (Active Dust Collection) 36 V, 5 A, 180W / 0.18 kW 36 V, 5 A, 180W / 0.18 kW
HEPA ltration (Active Dust Collection) 99.97% @ 0.3 micron 99.97% @ 0.3 micron
Filtration (Passive Dust Collection) 95% @ 0.3 micron 95% @ 0.3 micron
Dust bag capacity 1.27 qt / 1.4 l 1.27 qt / 1.4 l
Machine Voltage 36 VDC 36 VDC
Battery capacity 3 - 12V, 185 Ah Wet/lead-acid (std.)
3 - 12V, 225 Ah Wet/lead-acid (opt.)
3 - 12V, 234 Ah AGM (opt.)
3 - 12V, 225 Ah Wet/lead-acid (std.)
3 - 12V, 234 Ah AGM (opt.)
Total power consumption 60 A / 1.9 kw nominal 60 A / 1.9 kw nominal
Run time (max.) 2.5 hours 2.5 hours
Battery charger 120 VAC, 60 Hz, 36 VDC, 25 A 120 VAC, 60 Hz, 36 VDC, 25 A
220/240 VAC, 60 Hz, 36 VDC, 25 A 220/240 VAC, 60 Hz, 36 VDC, 25 A
Protection grade IPX3 IPX3
*Sound pressure level LpA
(Active Dust Colletion Model)
64 dB(A) 64 dB(A)
*Sound pressure level LpA
(Passive Dust Colletion Model)
65 dB(A) 65 dB(A)
*Sound uncertainty KpA 3.0 dB(A) 3.0 dB(A)
*Sound power level LwA + uncertainty KwA xx dB(A) xx dB(A)
*Machine vibration at hand-arm <2.5 m/s <2.5 m/s
*Machine vibration uncertainty K 0.2 m/s 0.2 m/s
Ambient operating temperature Min: 32°F/0°C
Max: 110°F/43°C
Min: 32°F/0°C
Max: 110°F/43°C
B5/ SpeedGleam®5 GENERAL MACHINE DIMENSIONS/CAPACITIES/PERFORMANCE
*Values per EN 60335-2-72
Specications are subject to change without notice.

B5/7, SpeedGleam®5/7 Service Information (1-14) 2-11
GENERAL INFORMATION
MODEL (24 in / 610 mm) Drive Model (27 in / 690 mm) Drive Model
Length 61.5 in / 1562 mm 63 in / 1602 mm
Width 30 in / 762 mm 31.5 in / 800 mm
Height 43 in / 1092 mm 43 in / 1092 mm
Weight 246 lb / 111.5 kg 254 lb / 115 kg
Weight with batteries 616 lb / 279 kg 797 lb / 362 kg
Burnish path width 24 in / 610 mm 27 in / 690 mm
Productivity rate (max.) 24,000 ft/hr / 2,200 m/hr 27,000 ft/hr / 2,500 m/hr
Productivity rate (practical) 22,000 ft/hr / 2,000 m/hr 25,000 ft/hr / 2,300 m/hr
Burnishing speeds (Variable) Min: 100 fpm / 30 mpm
Max: 200 fpm / 60 mpm
Min: 100 fpm / 30 mpm
Max: 200 fpm / 60 mpm
Transport speed (max.) Fwd: 240 fpm/ 73 mpm
Rev: 144 fpm/ 44 mpm
Fwd: 240 fpm/ 73 mpm
Rev: 144 fpm/ 44 mpm
Aisle turn (min.) 62.5 in / 1,588 mm 64 in / 1,626 mm
Grade level (max.) Burnishing: 9%, Transport: 19.5% Burnishing: 9%, Transport: 19.5%
Propel Motor 24 V, 14 A, .363 hp / 0.27 kW, 271 W 24 V, 14 A, .363 hp / 0.27 kW, 271 W
Pad motor 36 V, 90 A, 3.6 hp max / 2.6 kW 36 V, 90 A, 3.6 hp max / 2.6 kW
Pad Pressure Variable Variable
Pad speed 1875 rpm 1875 rpm
Vacuum motor (Active Dust Collection) 36 V, 5 A, 180W / 0.18 kW 36 V, 5 A, 180W / 0.18 kW
HEPA ltration (Active Dust Collection) 99.97% @ 0.3 micron 99.97% @ 0.3 micron
Filtration (Passive Dust Collection) 95% @ 0.3 micron 95% @ 0.3 micron
Dust bag capacity 1.27 qt / 1.4 l 1.27 qt / 1.4 l
Machine Voltage 36 VDC 36 VDC
Battery capacity 6 - 6V, 240 Ah Wet/lead-acid (std.)
6 - 6V, 312 Ah AGM (opt.)
6 - 6V, 360 Ah Wet/lead-acid (opt.)
6 - 6V, 240 Ah Wet/lead-acid (std.)
6 - 6V, 312 Ah AGM (opt.)
6 - 6V, 360 Ah Wet/lead-acid (opt.)
Total power consumption 75 A / 2.4 kw nominal 75 A / 2.4 kw nominal
Run time (max.) 3 hours 3 hours
Battery charger 120 VAC, 60 Hz, 36 VDC, 25 A 120 VAC, 60 Hz, 36 VDC, 25 A
220/240 VAC, 60 Hz, 36 VDC, 25 A 220/240 VAC, 60 Hz, 36 VDC, 25 A
Protection grade IPX3 IPX3
*Sound pressure level LpA
(Active Dust Colletion Model)
63 dB(A) 63 dB(A)
*Sound pressure level LpA
(Passive Dust Colletion Model)
65 dB(A) 65 dB(A)
*Sound uncertainty KpA 3.0 dB(A) 3.0 dB(A)
*Sound power level LwA + uncertainty KwA xx dB(A) xx dB(A)
*Machine vibration at hand-arm <2.5 m/s <2.5 m/s
*Machine vibration uncertainty K 0.2 m/s 0.2 m/s
Ambient operating temperature Min: 32°F/0°C
Max: 110°F/43°C
Min: 32°F/0°C
Max: 110°F/43°C
B7/ SpeedGleam®7 GENERAL MACHINE DIMENSIONS/CAPACITIES/PERFORMANCE
*Values per EN 60335-2-72
Specications are subject to change without notice.

2-12 B5/7, SpeedGleam®5/7 Service Information (1-14)
GENERAL INFORMATION
SPECIFICATIONS
Component Measure
Actuator, Scrub head lift 1 - 3 Amps Continuous
Motor, Vacuum Fan 5 Amps
Motor, Propelling
(transport speed)
Variable to 14 Amps, 24 V
B5/ SG5 - Actuator Pressure Burnish Motor Measure
Down Pressure 1 LED 42-49 Amps
Down Pressure 2 LEDs 57-64 Amps
Down Pressure 3 LEDs 72-79 Amps
B7/ SG7 - Actuator Pressure Burnish Motor Measure
Down Pressure 1 LED 57-64 Amps
Down Pressure 2 LEDs 72-79 Amps
Down Pressure 3 LEDs 87-94 Amps
B5/ SG5 - Mechanical Pressure Burnish Motor Measure - Mechanical Pressure Adjust Mode
BDI LED #1 (LH) Less than 42 Amps (Blink), 42-49 Amps (Steady)
BDI LED #2 49-57 Amps
BDI LED #3 57-64 Amps
BDI LED #4 64-72 Amps
BDI LED #5 (RH) 72-79 Amps (Steady), Greater than 79 Amps (Blink)
B7/ SG7 - Mechanical Pressure Burnish Motor Measure - Mechanical Pressure Adjust Mode
BDI LED #1 (LH) Less than 56.5 Amps (Blink), 57-64 Amps (Steady)
BDI LED #2 64-72 Amps
BDI LED #3 72-79 Amps
BDI LED #4 79-87 Amps
BDI LED #5 (RH) 87-94 Amps (Steady), Greater than 94 Amps (Blink)
ELECTRICAL COMPONENTS (For Reference Only)
Specications are subject to change without notice.
