Terex Genie S-80 Installation and operating manual

Service and Repair Manual
Serial Number Range
S®-80
from S8016H-13643
to
S8016H-13999
This manual includes:
Repair procedures
Fault Codes
Electrical and
Hydraulic Schematics
S®-85
from S8516H-13643 to
S8516H-13999
S®-80X
from S80X16H-13643 to
S80X16H-13999
from S80H-14000
from S85H-14000
from S80XH-14000
f
except S8516H-13685
except S8516H-13711
f
For detailed maintenance
procedures, refer to the
appropriate Maintenance
Manual for your machine.
Part No. 1287339GT
Rev A
March 2018

Service and Repair Manual March 2018
Introduction
ii S-80 • S-85 • S-80X Part No. 1287339GT
Intr oduct io n Intr oduct io n
Important
Read, understand and obey the safety rules and
operating instructions in the appropriate Operator's
Manual on your machine before attempting any
procedure.
This manual provides troubleshooting and repair
procedures for qualified service professionals.
Basic mechanical, hydraulic and electrical skills are
required to perform most procedures. However,
several procedures require specialized skills, tools,
lifting equipment and a suitable workshop. In these
instances, we strongly recommend that
maintenance and repair be performed at an
authorized Genie dealer service center.
Compliance
Machine Classification
Group B/Type 3 as defined by ISO 16368
Machine Design Life
Unrestricted with proper operation, inspection and
scheduled maintenance.
Technical Publications
Genie has endeavored to deliver the highest
degree of accuracy possible. However, continuous
improvement of our products is a Genie policy.
Therefore, product specifications are subject to
change without notice.
Readers are encouraged to notify Genie of errors
and send in suggestions for improvement. All
communications will be carefully considered for
future printings of this and all other manuals.
Contact Us:
Internet: www.genielift.com
E-mail: [e-mail]
Find a Manual for this Model
Go to http://www.genielift.com
Use the links to locate Service Manuals,
Maintenance Manuals, Service and Repair
Manuals, Parts Manuals and Operator's Manuals.
Copyright © 2015 by Terex Corporation
1287339GT Rev A, March 2018
First Edition, First Printing
"Genie" and "S" are registered trademarks of Terex South
Dakota, Inc. in the USA and many other countries.

March 2018 Service and Repair Manual
Introduction
Part No. 1287339GT S-80 • S-85 • S-80X iii
Revision History
Revision Date Section Procedure / Page / Description
A 3/2018 Initial Release
Reference Examples: Electronic Version
Click on any content or procedure in the Table of Contents to view
the update.
Section – Repair Procedure, 4-2
Section – Fault Codes, All charts
Section – Schematics, Legends and schematics

Service and Repair Manual March 2018
Introduction
iv S-80 • S-85 • S-80X Part No. 1287339GT
Serial Number Legend
To August 31, 2016
1 Model
2 Model year
3 Facility code
1 Sequence number
2 Serial label (located under cover)
3 Serial number (stamped on chassis)
From September 1, 2016
1 Model
2 Facility code
3 Sequence number
1 Serial label (located under cover)
2 Serial number (stamped on chassis)

March 2018 Service and Repair Manual
Safety Rules
Part No. 1287339GT S-80 • S-85 • S-80X v
Section 1 Safet y Rul es
Danger
Failure to obey the instructions and safety rules in
this manual and the appropriate Operator's Manual
on your machine will result in death or serious
injury.
Many of the hazards identified in the operator's
manual are also safety hazards when maintenance
and repair procedures are performed.
Do Not Perform Maintenance
Unless:
RYou are trained and qualified to perform
maintenance on this machine.
RYou read, understand and obey:
•manufacturer's instructions and safety rules
•employer's safety rules and worksite
regulations
•applicable governmental regulations
RYou have the appropriate tools, lifting
equipment and a suitable workshop.

Service and Repair Manual March 2018
Safety Rules
vi S-80 • S-85 • S-80X Part No. 1287339GT
Personal Safety
Any person working on or around a machine must
be aware of all known safety hazards. Personal
safety and the continued safe operation of the
machine should be your top priority.
Read each procedure thoroughly. This
manual and the decals on the machine,
use signal words to identify the following:
Safety alert symbol—
used to alert
personnel to potential personal
injury hazards. Obey all safety
messages that follow this symbol
to avoid possible injury or death.
Indicates a
imminently hazardous
situation which, if not avoided, will
result in death or serious injury.
Indicates a potentially hazardous
situation which, if not avoided,
could result in death or serious
injury.
Indicates a potentially hazardous
situation which, if not avoided,
may cause minor or moderate
injury.
Indicates a potentially hazardous
situation which, if not avoided,
may result in property damage.
Be sure to wear protective eye wear and
other protective clothing if the situation
warrants it.
Be aware of potential crushing hazards
such as moving parts, free swinging or
unsecured components when lifting or
placing loads. Always wear approved
steel-toed shoes.
Workplace Safety
Any person working on or around a machine must
be aware of all known safety hazards. Personal
safety and the continued safe operation of the
machine should be your top priority.
Be sure to keep sparks, flames and lighted
tobacco away from flammable and
combustible materials like battery gases
and engine fuels. Always have an
approved fire extinguisher within easy
reach.
Be sure that all tools and working areas
are properly maintained and ready for
use. Keep work surfaces clean and free of
debris that could get into machine
components and cause damage.
Be sure any forklift, overhead crane or
other lifting or supporting device is fully
capable of supporting and stabilizing the
weight to be lifted. Use only chains or
straps that are in good condition and of
ample capacity.
Be sure that fasteners intended for one
time use (i.e., cotter pins and self-locking
nuts) are not reused. These components
may fail if they are used a second time.
Be sure to properly dispose of old oil or
other fluids. Use an approved container.
Please be environmentally safe.
Be sure that your workshop or work area
is properly ventilated and well lit.

March 2018
Table of Contents
Part No. 1287339GT S-80 • S-85 • S-80X vii
Introduction Introduction ..........................................................................................................ii
Important Information............................................................................................. ii
Find a Manual for this Model.................................................................................. ii
Serial Number Legend .......................................................................................... iv
Section 1 Safety Rules..........................................................................................................v
General Safety Rules.............................................................................................v
Section 2 Specifications.......................................................................................................1
Machine Specifications...........................................................................................1
Performance Specifications ...................................................................................2
Hydraulic Oil Specifications....................................................................................2
Hydraulic Component Specifications .....................................................................5
Manifold Component Specifications.......................................................................6
Deutz TD2011L04i Engine Specifications..............................................................7
Deutz TD 2.9 Engine Specifications.......................................................................8
Perkins 404D-22 Engine Specifications.................................................................9
GM 3.0L Engine Specifications............................................................................10
Machine Torque Specifications............................................................................11
Hydraulic Hose and Fitting Torque Specifications ...............................................12
Torque Procedure ................................................................................................13
Section 3 Repair Procedures .............................................................................................15
Introduction...........................................................................................................15
Platform Controls...............................................................................................17
1-1 ALC-500 Circuit Board...................................................................................17
How to Remove the ALC-500 Circuit Board ...................................................17
1-2 Joysticks.........................................................................................................18
How to Adjust the Joystick Max-out Setting....................................................18
How to Adjust the Joystick Ramp Rate Setting ..............................................19
How to Adjust the Joystick Threshold Setting.................................................21
How to Calibrate the Boom Angle Sensor ......................................................22

March 2018
Table of Contents
viii S-80 • S-85 • S-80X Part No. 1287339GT
Platform Components .......................................................................................23
2-1 Platform..........................................................................................................23
2-2 Platform Leveling Slave Cylinder...................................................................24
How to Remove the Platform Leveling Slave Cylinder...................................24
How to Bleed the Slave Cylinder....................................................................24
2-3 Platform Rotator.............................................................................................25
How to Remove the Platform Rotator.............................................................25
How to Bleed the Platform Rotator.................................................................26
2-4 Platform Overload System.............................................................................27
Jib Boom Components......................................................................................30
3-1 Jib Boom........................................................................................................30
3-2 Jib Boom Lift Cylinder....................................................................................31
Boom Components............................................................................................32
4-1 Cable Track....................................................................................................32
How to Remove the Cable Track, S-80..........................................................32
How to Repair the Cable Track.......................................................................34
4-2 Boom..............................................................................................................34
How to Shim the Boom...................................................................................34
How to Remove the Boom..............................................................................35
4-3 Boom Lift Cylinder .........................................................................................37
4-4 Boom Extension Cylinder ..............................................................................39
4-5 Boom Extend/Retract Cables ........................................................................41
How to Adjust the Extend/Retract Cables ......................................................41
How to Replace the Boom Extend/Retract Cables.........................................43
4-6 Platform Leveling Master Cylinder.................................................................45
4-7 Primary Boom Angle Sensor, S-80X .............................................................46
Engines ...............................................................................................................48
5-1 RPM Adjustment............................................................................................48
5-2 Flex Plate.......................................................................................................48
How to Remove the Flex Plate.......................................................................48
How to Install the Flex Plate...........................................................................51
How to install the Pump and Bell Housing Assembly.....................................52

March 2018
Table of Contents
Part No. 1287339GT S-80 • S-85 • S-80X ix
Ground Controls.................................................................................................53
6-1 Control Relays................................................................................................53
Hydraulic Pumps................................................................................................54
7-1 Function Pump...............................................................................................54
7-2 Drive Pump ....................................................................................................55
How to Prime the Drive Pump.........................................................................56
Manifolds.............................................................................................................58
8-1 Function Manifold...........................................................................................58
8-2 Valve Adjustments - Function Manifold..........................................................60
How to Adjust the System Relief Valve...........................................................60
How to Adjust the Boom Down Relief Valve...................................................60
How to Adjust the Boom Extend Relief Valve.................................................61
8-3 Brake/Two-Speed Manifold Components......................................................62
8-4 Turntable Rotation Manifold Components .....................................................63
8-5 Platform Rotate Manifold Components..........................................................64
8-6 Platform Manifold Components, S-80............................................................65
8-7 Platform Manifold Components, S-85............................................................66
8-8 2WD Traction Manifold Components.............................................................67
8-9 4WD Traction Manifold Components.............................................................68
8-10 Drive Oil Diverter Manifold Components (welder option).............................70
8-11 Valve Adjustments - Traction Manifold ........................................................71
8-12 Valve Coils ...................................................................................................72
Valve Coil Resistance Specifications..............................................................72
Fuel and Hydraulic Tanks..................................................................................74
9-1 Fuel Tank .......................................................................................................74
9-2 Hydraulic Tank ...............................................................................................75
Turntable Rotation Components......................................................................77
10-1 Turntable Rotation Drive Hub Assembly......................................................77
How to Remove the Turntable Rotation Drive Hub Assembly........................77
How to Remove the Turntable Rotation Hydraulic Motor ...............................78
How to Adjust the Turntable Rotation Gear Backlash ....................................79

March 2018
Table of Contents
x S-80 • S-85 • S-80X Part No. 1287339GT
Steer Axle Components ....................................................................................81
11-1 Yoke and Drive Hub.....................................................................................81
11-2 Drive Motors.................................................................................................82
11-3 Drive Hubs...................................................................................................82
11-4 Steer Cylinders ............................................................................................83
Non-steer Axle Components.............................................................................84
12-1 Drive Motor ..................................................................................................84
12-2 Drive Hub.....................................................................................................84
Oscillating Axle Components...........................................................................85
13-1 Oscillate Axle Cylinders...............................................................................85
13-2 Oscillate Directional Valve...........................................................................86
How to Adjust the Oscillate Relief Valve ........................................................86
How to Set Up the Directional Valve Linkage.................................................87
Section 4 Fault Codes.........................................................................................................89
Introduction ..........................................................................................................89
Control System Fault Codes.............................................................................90
How to Retrieve Control System Fault Codes................................................90
Control System Fault Codes...........................................................................91
Fault Code Display - Deutz and Perkins Models............................................. 94
How to Retrieve Active Engine Fault Codes Deutz D 2.9 L4 and Perkins
404F-22 Models......................................................................................94
Fault Code Display - Flashing and Solid LED's - Deutz D 2.9 L4 and Perkins
404F-22 Models......................................................................................95
Soft Key Functions and Icons - Deutz D 2.9 L4 and Perkins 404F-22 Models
................................................................................................................96
Main Menu Structure - Deutz D 2.9 L4 Models ..............................................97
Main Menu Structure - Perkins 404F-22 Models............................................98
Deutz D 2.9 L4 Engine Fault Codes..................................................................99
Perkins 404F-22 Engine Fault Codes.............................................................110

March 2018
Table of Contents
Part No. 1287339GT S-80 • S-85 • S-80X xi
Section 5 Schematics .......................................................................................................112
Introduction.........................................................................................................112
Electrical Symbol Legend...................................................................................113
Hydraulic Symbols Legend ................................................................................114
Relay and Fuse Panel Legend - Deutz TD2011L04i .........................................115
Relay and Fuse Panel Legend - Deutz TD2.9 L4..............................................115
Engine Relay Layout - Perkins 404D-22T..........................................................116
Relay and Fuse Panel Legend - Perkins 804D-33.............................................117
Engine Relay Layout - GM 3.0L.........................................................................118
Connector Pin Legends......................................................................................119
S-80X Ground Control Box Wiring Diagram.......................................................124
Deutz TD2.9 L4 Engine Harness .......................................................................125
Electrical Schematics, S-80X – ANSI and CSA Models................................127
Electrical Schematic, S-80X - Deutz TD2.9 L4 Models (ANSI / CSA)..........128
Ground Control Box, S-80X - Deutz TD2.9 L4 Models (ANSI / CSA)...........132
Platform Control Box, S-80X - Deutz TD2.9 L4 Models (ANSI / CSA) .........133
Electrical Schematic, S-80X - Deutz TD2011L04i Models (ANSI / CSA).....136
Ground Control Box, S-80X - Deutz TD2011L04i Models (ANSI / CSA)......140
Platform Control Box, S-80X - Deutz TD2011L04i Models (ANSI / CSA) ....141
Electrical Schematic, S-80X - Perkins 404D-22T Models (ANSI / CSA)......144
Ground Control Box, S-80X - Perkins 404D-22T Models (ANSI / CSA).......148
Platform Control Box, S-80X - Perkins 404D-22T Models (ANSI / CSA) .....149
Electrical Schematic, S-80X - GM 3.0L Models (ANSI / CSA) .....................152
Ground Control Box, S-80X - GM 3.0L Models (ANSI / CSA)......................156
Platform Control Box, S-80X - GM 3.0L Models (ANSI / CSA).....................157

March 2018
Table of Contents
xii S-80 • S-85 • S-80X Part No. 1287339GT
Electrical Schematics, S-80, S-85 – ANSI and CSA Models ........................159
Electrical Schematic, S-80 • S-85 - Deutz TD2.9 L4 Models (ANSI / CSA) .160
Ground Control Box, S-80 • S-85 - Deutz TD2.9 L4 Models (ANSI / CSA)..164
Platform Control Box, S-80 • S-85 - Deutz TD2.9 L4 Models (ANSI / CSA) 165
Electrical Schematic, S-80 • S-85 - Deutz TD2011L04i Models (ANSI / CSA)
..............................................................................................................168
Ground Control Box, S-80 • S-85 - Deutz TD2011L04i Models (ANSI / CSA)
..............................................................................................................172
Platform Control Box, S-80 • S-85 - Deutz TD2011L04i Models (ANSI / CSA)
..............................................................................................................173
Electrical Schematic, S-80 • S-85 - Perkins 404D-22T Models (ANSI / CSA)
..............................................................................................................176
Ground Control Box, S-80 • S-85 - Perkins 404D-22T Models (ANSI / CSA)
..............................................................................................................180
Platform Control Box, S-80 • S-85 - Perkins 404D-22T Models (ANSI / CSA)
..............................................................................................................181
Electrical Schematic, S-80 • S-85 - GM 3.0L Models (ANSI / CSA).............184
Ground Control Box, S-80 • S-85 - GM 3.0L Models (ANSI / CSA) .............188
Platform Control Box, S-80 • S-85 - GM 3.0L Models (ANSI / CSA)............189
Electrical Schematics, S-80, S-85 – CE Models............................................191
Electrical Schematic, S-80 • S-85 - Deutz TD2.9 L4 Models (CE)...............192
Ground Control Box, S-80 • S-85 - Deutz TD2.9 L4 Models (CE)................196
Platform Control Box, S-80 • S-85 - Deutz TD2.9 L4 Models (CE) ..............197
Electrical Schematic, S-80 • S-85 - Deutz TD2011L04i Models (CE) ..........200
Ground Control Box, S-80 • S-85 - Deutz TD2011L04i Models (CE)...........204
Platform Control Box, S-80 • S-85 - Deutz TD2011L04i Models (CE)..........205
Electrical Schematic, S-80 • S-85 - Perkins 404TD-22 Models (CE) ...........208
Ground Control Box, S-80 • S-85 - Perkins 404TD-22 Models (CE)............212
Platform Control Box, S-80 • S-85 - Perkins 404TD-22 Models (CE)...........213
Electrical Schematic, S-80 • S-85 - GM 3.0L Models (CE)...........................216
Ground Control Box, S-80 • S-85 - GM 3.0L Models (CE)...........................220
Platform Control Box, S-80 • S-85 - GM 3.0L Models (CE)..........................221

March 2018
Table of Contents
Part No. 1287339GT S-80 • S-85 • S-80X xiii
Electrical Schematics, S-80, S-85 – AS Models ............................................223
Electrical Schematic, S-80 • S-85 - Deutz TD2011L04i Models (AS)...........224
Ground Control Box, S-80 • S-85 - Deutz TD2011L04i Models (AS) ...........228
Platform Control Box, S-80 • S-85 - Deutz TD2011L04i Models (AS)..........229
Electrical Schematic, S-80 • S-85 - Perkins 404TD-22 Models (AS)............232
Ground Control Box, S-80 • S-85 - Perkins 404TD-22 Models (AS) ............236
Platform Control Box, S-80 • S-85 - Perkins 404TD-22 Models (AS)...........237
Electrical Schematic, S-80 • S-85 - GM 3.0L Models (AS)...........................240
Ground Control Box, S-80 • S-85 - GM 3.0L Models (AS)............................244
Platform Control Box, S-80 • S-85 - GM 3.0L Models (AS) ..........................245
Schematics - Options.......................................................................................247
GM 3.0L Options Schematic.........................................................................248
Deutz and Perkins Options Schematic .........................................................249
Platform Level Cutout, CTE Option...............................................................252
12 kW Hydraulic Generator Wiring Diagram.................................................253
12 kW Hydraulic Generator Electrical Schematic.........................................256
Belt Driven Generator Option........................................................................257
Hydraulic Schematics......................................................................................259
Hydraulic Schematic, 2WD Models...............................................................260
Hydraulic Schematic, 4WD Models...............................................................261

March 2018 Service and Repair Manual
Specifications
Part No. 1287339GT S-80 • S-85 • S-80X 1
Section 2 Speci ficati ons
Machine Specifications
Tires and wheels
Rough Terrain and Non Marking
Tire size 18-625 FF
Tire ply rating 16 ply
Overall tire diameter 40.7 in
103.3 cm
Tire pressure Foam filled
Wheel diameter 24.5 in
62.2 cm
Wheel width 15 in
38.1 cm
Tire weight, new foam filled
(minimum) 622 lbs
282 kg
Tires and wheels High Flotation
Tire size 41/18LLx22.5
Tire ply rating 14 ply
Tire pressure 70 psi
4.8 bar
Wheel diameter 22.5 in
57 cm
Wheel width 14 in
35.6 cm
Lugs and Lug Nut Torque
Wheel lugs 11 @ 3/4 - 16
Lug nut torque, dry 420 ft-lbs
569 Nm
Lug nut torque, lubricated 320 ft-lbs
434 Nm
Fluid capacities
Fuel tank,
Deutz and Perkins models
35 gallons
132.5 liters
Fuel tank,
Continental model
30 gallons
113.5 liters
LPG tank
33.5 lbs
15.2 kg
Hydraulic tank
40 gallons
151.4 liters
Hydraulic system (including tank)
50 gallons
189.3 liters
Turntable rotation drive hub
(single fill port) 40 fl oz
1183 cc
Turntable rotation drive hub
(dual fill port) 43 fl oz
1262 cc
Drive hubs
four wheel drive
30.5 fl oz
902 cc
Drive hubs
two wheel drive 23 fl oz
680 cc
Drive hub oil type: SAE 90 multipurpose hypoid
gear oil API service classification GL5

Service and Repair Manual March 2018
Specifications
2 S-80 • S-85 • S-80X Part No. 1287339GT
Performance Specifications
Drive speed, maximum
Stowed position,
RT tires 40 ft / 7.9 - 8.5 sec
12.2 m / 7.9 - 8.5 sec
Stowed position,
High Flotation tires 40 ft / 11 - 13 sec
12.2 m / 11 - 13 sec
Raised or Extended 40 ft / 40 - 45 sec
12.2 m / 40 -
45 sec
Braking distance, maximum
High range on paved surface 6 ft / 1.8 m
Gradeability
Refer to Operator's Manual
Boom function speeds, maximum from platform
controls
Jib Boom up (S-85) 25 - 35 sec
Jib Boom down (S-85) 15 - 25 sec
Boom up (ANSI, CSA, models) 57 - 65 sec
Boom up (CE, AS models) 75 - 83 sec
Boom down (ANSI, CSA, models) 61 - 69 sec
Boom down (CE, AS models) 75 - 83 sec
Boom extend 59 - 67 sec
Boom retract 57 - 65 sec
Turntable rotate, (360°) fully stowed 95 - 103 sec
Turntable rotate, (360°) boom raised
or extended 210 - 250 sec
Platform rotate, 160° 8 - 12 sec
Platform level (10° range of motion)
ANSI, CSA 3 - 5 sec
Platform level (10° range of motion)
CE, AS 20 - 22 sec
For operational specifications, refer to the
Operator's Manual.
Hydraulic Oil Specifications
Hydraulic Fluid Specifications
Genie specifications require hydraulic oils which are
designed to give maximum protection to hydraulic
systems, have the ability to perform over a wide
temperature range, and the viscosity index should
exceed 140. They should provide excellent antiwear,
oxidation prevention, corrosion inhibition, seal
conditioning, and foam and aeration suppression
properties.
Cleanliness level,
minimum ISO 15/13
Water content,
maximum 250 ppm
Recommended Hydraulic Fluid
Hydraulic oil type Chevron Rando HD Premium
Viscosity grade 32
Viscosity index 200
Optional Hydraulic Fluids
Mineral based Shell Tellus S2 V 32
Shell Tellus S2 V 46
Shell Tellus S4 VX 32 Shell
Shell Donax TG (Dexron III)
Chevron 5606A
Biodegradable Petro Canada Environ MV 46
Fire resistant UCON Hydrolube HP-5046
Note: Genie specifications require additional
equipment and special installation instructions for
the approved optional fluids. Consult Genie Product
Support before use.
Optional fluids may not have the
same hydraulic lifespan and
may result in component
damage.
Note: Extended machine operation can cause the
hydraulic fluid temperature to increase beyond it's
maximum allowable range. If the hydraulic fluid
temperature consistently exceeds 200°F / 90°C an
optional oil cooler may be required.

March 2018 Service and Repair Manual
Specifications
Part No. 1287339GT S-80 • S-85 • S-80X 3
Do not top off with incompatible
hydraulic fluids. Hydraulic fluids
may be incompatible due to the
differences in base additive
chemistry. When incompatible
fluids are mixed, insoluble
materials may form and deposit
in the hydraulic system,
plugging hydraulic lines, filters,
control valve
s and may result in
component damage.
Note: Do not operate the machine when the
ambient air temperature is consistently above
120°F / 49°C.
Hydraulic Fluid Temperature
Range
Ambient air temperature
1 Chevron hydraulic oil 5606A
2 Petro-Canada Environ MV 46
3 UCON Hydrolube HP-5046D
4 Chevron Rando HD premium oil MV
Chevron Rando HD Premium Oil
MV Fluid Properties
ISO Grade
32
Viscosity index
200
Kinematic Viscosity
cSt @ 200°F / 100°C
cSt @ 104°F / 40°C
7.5
33.5
Brookfield Viscosity
cP @ -4°F / -20°C
cP @ -22°F / -30°C
1040
3310
Flash point
375°F / 190°C
Pour point -58°F / -
50°C
Maximum continuous operating
temperature
171°F / 77°C
Note: A hydraulic oil heating system is
recommended when the ambient temperature is
consistently below 0°F / -18°C.
Note: Do not operate the machine when the
ambient temperature is below -20°F / -29°C with
Rando HD Premium MV.

Service and Repair Manual March 2018
Specifications
4 S-80 • S-85 • S-80X Part No. 1287339GT
Chevron 5606A Hydraulic Oil
Fluid Properties
ISO Grade 15
Viscosity index 300
Kinematic Viscosity
cSt @ 200°F / 100°C
cSt @ 104°F / 40°C
cSt @ -40°F / -40°C
5.5
15.0
510
Flash point 180°F / 82°C
Pour point -81°F / -63°C
Maximum continuous operating
temperature 124°F / 51°C
Note: Use of Chevron 5606A hydraulic fluid, or
equivalent, is required when ambient temperatures
are consistently below 0°F / -17°C unless an oil
heating system is used.
Continued use of Chevron
5606A hydraulic fluid, or
equivalent, when ambient
temperatures are consistently
above 32°F / 0°C may result in
component damage
Petro-Canada Environ MV 46
Fluid Properties
ISO Grade 46
Viscosity index 154
Kinematic Viscosity
cSt @ 200°F / 100°C
cSt @ 104°F / 40°C
8.0
44.4
Flash point 482°F / 250°C
Pour point -49°F / -45°C
Maximum continuous operating
temperature 180°F / 82°C
Shell Tellus S4 VX Fluid
Properties
ISO Grade 32
Viscosity index 300
Kinematic Viscosity
cSt @ 200°F / 100°C
cSt @ 104°F / 40°C
9
33.8
Brookfield Viscosity
cSt @ -4°F / -20°C
cSt @ -13°F / -25°C
cSt @ -40°F / -40°C
481
702.4
2624
Flash point >100
Pour point -76°F / -60°C
Maximum continuous operating
temperature 103°F / 75°C

March 2018 Service and Repair Manual
Specifications
Part No. 1287339GT S-80 • S-85 • S-80X 5
UCON Hydrolube HP-5046 Fluid
Properties
ISO Grade 46
Viscosity index 192
Kinematic Viscosity
cSt @ 149°F / 65°C
cSt @ 104°F / 40°C
cSt @ 0°F / -18°C
22
46
1300
Flash point None
Pour point -81°F / -63°C
Maximum continuous operating
temperature 189°F / 87°C
Hydraulic Component Specifications
Drive Pump
Type: bi-directional variable displacement piston pump
Displacement per revolution
0 to 2.8 cu in
0 to 46 cc
Flow rate @ 2300 rpm
30.3 gpm
114.7 L/min
Drive pressure, maximum
3750 psi
259 bar
Charge Pump
Type
gerotor
Displacement per revolution
0.85 cu in
13.9 cc
Flow rate @ 2300 rpm
9 gpm
34 L/min
Charge pressure @ 2300 rpm
Neutral position
310 psi
21.4 bar
Function pump
Type: variable displacement piston pump
Displacement per revolution
0 to 2.3 cu in
0 to 38 cc
Flow rate @ 2300 rpm
0 to 23 gpm
0 to 87 L/min
Pressure, maximum
2900 psi
200 bar
Pressure compensator
2900 psi
200 bar
Standby pressure 250 psi
17.3 bar
Auxiliary Pump
Type: fixed displacement gear pump
Displacement per revolution
0.15 cu in
2.47 cc

Service and Repair Manual March 2018
Specifications
6 S-80 • S-85 • S-80X Part No. 1287339GT
Function manifold
System relief valve pressure,
maximum 3200 psi
221 bar
Primary boom extend relief pressure
(measured at PTEST port) 2400 psi
165 bar
Platform Manifold and Oscillate Valve
Platform level flow regulator
Platform rotate flow regulator
0.6 gpm
2.3 L/min
0.3 gpm
1.1 L/min
Oscillate relief pressure 950 psi
65.5 bar
Traction Manifold
Hot oil relief pressure 280 psi
19.3 bar
Brakes
Brake release pressure,
Wheel drive hubs 240 psi
16.5 bar
Drive Motors
Displacement per revolution
high speed: 0.9 cu in
14.7 cc
Displacement per revolution
low speed 2.7 cu in
45 cc
Hydraulic Filters
High pressure filter: Beta 3 ≥200
High pressure filter bypass pressure 102 psi
7 bar
Medium pressure filter Beta 3 ≥200
Medium pressure filter bypass
pressure 51 psi
3.5 bar
Hydraulic tank return filter
10 micron with
25 psi / 1.7 bar
bypass
Drive motor case drain return filter Beta 10 ≥2
Manifold Component
Specifications
Plug torque
SAE No. 2 36 in-lbs / 4 Nm
SAE No. 4 10 ft-lbs / 13 Nm
SAE No. 6 14 ft-lbs / 19 Nm
SAE No. 8 38 ft-lbs / 51 Nm
SAE No. 10 41 ft-lbs / 55 Nm
SAE No. 12 56 ft-lbs / 76 Nm
