TERMA KTX 1 User manual

User Manual — Electric heang elements of the KTX series32
User Manual
Our products have been designed and manufactured in such a way to
ensure that all quality, funconality and aesthec requirements are met.
We would like to congratulate you on the purchase of this great product
and wish you a pleasant experience with it.

User Manual — Electric heang elements of the KTX series 33
Electric radiator
Guide to safe installaon and use.
1. Do not install the heater under an electrical socket point.
2. Your electric heater should be lled with a carefully measured amount
of liquid. In the case of loss of heang medium, or in any other case
which demands its supplementaon, contact your supplier.
3. The device is not equipped with an external temperature controller*.
Do not use the device in a small room if unsupervised disabled or in-
capacitated individuals are inside it. Only use the device if those in-
dividuals are under constant supervision.
*Does not apply to selected models. Ask your supplier for details.

User Manual — Electric heang elements of the KTX series34
4. Electric heater is not a toy. Children under the age of 3 should not
be allowed within close proximity of the device without the super-
vision of an adult.
Children aged 3 to 8 should only be allowed to operate the heater
when it has been properly installed and connected. The child must
be under adult supervision or have been trained to safely operate
the device while understanding the risks.
5. Note: Some parts of the radiator can be very hot and can cause
burns. Pay special aenon to the presence of children or people
with disabilies.
6. If the device is used as a clothes and towel dryer, ensure that the
fabrics drying on it have only been washed in water, avoiding con-
tact with any harsh chemicals.

User Manual — Electric heang elements of the KTX series 35
7. To ensure the safety of very small children, install the electric dryer
so that the lowest tube is at least 600 mm above the oor.
8. The device should only be installed by a qualied installer in accord-
ance with the applicable regulaons regarding safety and all other
regulaons.
9. All installaons to which the device is connected should comply with
regulaons applicable in the country of installaon and use.
10. Extension leads or electric plug adapters should not be used in order
to supply power to the heater.
11. The electric installaon to which the heater is connected should have
the right current dierenal and overcurrent relay (R.C.D.) of 30 mA.
With the permanent installaon (cable connecon without plug) it is
also mandatory to have an omni-pole cut-out for disconnecng the
device on all poles, by points of contact with the clearance of 3 mm.

User Manual — Electric heang elements of the KTX series36
12. The device version labelled PB or MS can be installed in bathrooms
in zone 1, as dened by applicable law, subject to any addional reg-
ulaons concerning electrical installaons in wet areas. Other ver-
sions of the device can be installed in Zone 2 or beyond.
13. The device is recommended for use solely as described in the manual.
14. Ensure that the heater has been installed on a wall in accordance
with its installaon manual.
15. Please forward this instrucon manual to the end user.

User Manual — Electric heang elements of the KTX series 37
Zone 1
Zone 2

User Manual — Electric heang elements of the KTX series38
Electric Heang Element
Safety requirements — installaon
1. Fing and connecon of the heang element should only be per-
formed by a qualied installer.
2. Connect the unit to a sound electrical installaon (see the rangs on
the heater).
3. Switching on the heang element in the open air to test the device
is permied for a maximum of 3 seconds.
4. Never test a heang element that is already installed. Do not turn
the heang element on in an empty radiator!
5. Ensure that the power cord does not touch the hot parts of the heat-
ing element or radiator.

User Manual — Electric heang elements of the KTX series 39
6. Before installing or removing the device, make sure it is disconnect-
ed from the power source.
7. Do not open the device — any interference with internal compo-
nents will invalidate the warranty.
8. The heang element’s power output should not exceed the radiators
power output for the parameters 75/65/20° C.
9. The pressure in the radiator must not exceed 1 MPa (10 bar). Ensure
that an air cushion is preserved in electric radiators. In central heat-
ing systems, leave one valve open to prevent pressure build up due
to the thermal expansion of the liquid.
10. The device is intended for home use only.
11. Fing and Installaon of the device must be carried out in accord-
ance with all local regulaons for electrical safety, including installa-

User Manual — Electric heang elements of the KTX series40
on within permissible locaons only. Observe bathroom electrical
zone regulaons.
Safety requirements — use
1. The heang element must be fully submerged in the heang liquid
during its operaon.
2. Regularly check the device for damage to ensure it is safe to use.
3. If the power cord is damaged the device should not be used. Unplug
the device and contact the manufacturer or distributor.
4. Do not allow ooding into the heang element casing.
5. Do not use the heang element in heang systems where the water
temperature exceeds 82° C.

User Manual — Electric heang elements of the KTX series 41
6. The heang element and radiator can heat up to high temperatures.
Please be cauous — avoid direct contact with the hot parts of the
equipment.
7. Do not open the heang element casing.
8. When operang the heang element in a radiator connected to a cen-
tral heang system, always leave one of the valves open.
9. Ensure that minors aged 8 and above or those with a physical or men-
tal disability are supervised if operang the device.
10. The device is not a toy. Keep it out of the reach of children.
11. The device must be disconnected from the mains during cleaning
and maintenance.
12. Cleaning of the equipment by children under 8 years of age is only
permied under appropriate supervision.
