TerraKing Material FS2 User manual

Fill Sensor
Kit Includes
Description Qty.
Fill Sensor 1
Mounting Plate 1
Screw, Sheet Metal 2
Screw, Plastic 2
USB Cable 1
Material Collection Fill Sensor
Universal fill level Sensor that attaches any hopper bagger or collection system.
Our Material Collection Fill Sensor technology measures the airspace capacitance of your hopper to monitor material
ll level. Get alerted before you over ll and optimize the efciency of your leaf pick up. Don’t let wet grass plug your
chute and slow you down. Never overload your material collection system again!
Key Features
• Sensor alerts when your collection system is full.
• Light and Compact
• Adjustable Sensitivity levels.
• Rechargeable battery.
WEEE Notice
This symbol is only valid in the European Union (EU). If you wish
to discard this product please contact your local authorities or
dealer and ask for the correct method of disposal.
WARNING
DO NOT INGEST BATTERY, CHEMICAL BURN HAZARD
This product contains a lithium-ion/polymer cell battery. Keep
new and used batteries away from children.
Prevention of hearing loss
Permanent hearing loss may occur if product is used for
prolonged periods of time without hearing protection. To
prevent possible hearing damage, wear appropriate hearing
protection while using the product.
Find a complete manual online at terraking.com.
Limited Warranty
TerraKing’s products are guaranteed free from defects in
material and/or workmanship and to perform as advertised
when properly assembled, installed, used, and maintained in
accordance with written instructions. Failure to adhere to this
will void the warranty. TerraKing will not be responsible for labor,
loss, or consequential damage of any kind or character caused
by defective parts, or for charges incurred in the replacement or
repair of defective parts.
Warranty Period
The TerraKing Fill Sensor is warranted for a period of 1 (one)
year after the purchase date for residential use, and 6 (six)
months after the purchase date for commercial use. This
product is warranted by TerraKing to the original purchaser/
customer against defects in material and workmanship under
normal operating conditions.

Quick Start Guide Choose Mounting Location Mount Fill Sensor
Attach the Mounting Plate Mounting Template
Removable Mounting Plate
Status Lights
Power Button
Speaker
Plastic Hooper
• Attach the mounting plate with self drilling screws.
Metal Hopper
• Using the included mounting template drill two 1/8 in holes and
remove center square.
• Attach the mounting plate with sheet metal screws.
• Match the screws in the Sensor with the slots in the
mounting plate and rotate counter clockwise to lock
the Sensor to the mounting plate.
• Turn Sensor on after it is mounted to properly calibrate.
Indicates Battery Life and
Sensitivity Level
Find optimal mounting location on attachment.
Tips to determine mounting location.
• Material must fall against wall where Sensor is mounted.
• Near last location of where hopper lls.
• No metals between Sensor and material.
• Near ll tube.
•
Sensor must be charged prior to use to activate.
Scan Mode : Sensor is searching for material to indicate hopper is full. Status lights will display the chase sequence.
Alarm Mode : Buzzer will alarm, status lights will blink, buzzer will chirp every 15 seconds until hopper is emptied.
Sleep Mode : Sensor will begin to sleep after a period of inactivity. Sensor will awake upon movement.
Sensitivity Level : Press the power button multiple times to cycle through the sensitivity levels. Level 1 for wet grass, level 5 for dry leaves.
Power On/Off : Press the power button until status lights turn on. Press and hold to turn off.
Charging : Charge using included USB cable + AC adapter (Not included). Status lights indicate battery charge level.
Low Battery : The buzzer will chirp twice every minute indicating the battery is low.
Cut
Cut
Cut Cut
Dill 1/8 in
hole
Dill 1/8 in
hole
4
1
2
3
2 in square must be
removed from metal
hopper.
Drill 1/8 in
hole
Drill 1/8 in
hole
