Tescom TC-5972DP User manual

TC-5972DP Pneumatic Shield Box
User Manual
R20191111

Copyright©2019 TESCOM CO.,LTD. ALL RIGHTS RESERVED
Address | (10442) #927 Unitechvil 142, Ilsan-ro, Ilsandong-gu, Goyang-si, Gyeonggi-do
TEL | [phone]
HOMEPAGE | www.tescom.co.kr

Table of Contents
iii
Table of Contents
Revision History
WARRANTY
Safety Considerations
Safety Symbols and Terms
PART 1. Getting Started
1. Introduction and Specifications
1.1 Introduction
1.2 Specifications
1.3 Initial Inspection
1.4 Operating Environment
1.5 Optional Parts Check
1.6 TESCOM Sales and Service Office
PART 2. Hardware Description
2. Hardware Overview
2.1 Front
2.2 Rear
2.3 Inside
2.4 Control Box
2.5 Dimensions
3. Optional Panels & Fixture
3.1 I/O Interface Panels
3.2 Fixtures
PART 3. Putting into Operation
4. Setup and Operation
4.1 Exterior and Accessory Inspection
4.2 Connecting & Setting Up
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
. . . . . . . . . . . . . . . . . . . . . . . . . . 5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
. . . . . . . . . . . . . . . . . . . . . . . . . . 19
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

iv
4.3 Shield Box Operation with Fixture
4.4 Shield Box Operation without Fixture
5. Remote Operation Using RS-232C
5.1 RS-232C Cable Connection
5.2 RS-232C Port Setting
5.3 RS-232C Command Protocol
5.4 Control with Terminal Application on PC
5.5 RS-232C Command List
5.6 RS-232C Commands in Detail
PART 4. Maintenance
6. Maintenance
6.1 Maintenance
6.2 Performance Test
7. Expendables and Accessories
7.1 Expendables and Accessories
8. Check List for Common Problems
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Revision History
v
Revision Record
Revision Description Date
v1.0 Initial Draft 2019-11-06
v1.1 First Release 2019-11-12

WARRANTY
vi
TESCOM guarantees that this product will be free from defects in materials and workmanship for one
year from the date of shipment. During the warranty period, TESCOM will, at its discretion, either repair
or replace defective products.
For the warranty service, customer must notify TESCOM of the defect before the expiration of the
warranty period and make suitable arrangements for the performance of service. Customer shall be
responsible for packaging and shipping the defective product to TESCOM or to a service center
designated by TESCOM. Customer shall pay for shipping charges as well as any other charges incurred
outside of Korea. TESCOM shall pay shipping charge to return the product to the customer.
This warranty does not apply to Expendables and Accessories and any failure or damage caused by
improper use or unauthorized service. In such cases, TESCOM may refuse to offer any service under the
warranty.
LIMITATION OF WARRANTY
The foregoing warranty shall not apply to defects resulted from software (user interface) supplied by the
customer or any third party, unauthorized modification or misuse, accident or abnormal condition of
operation. Also, Tescom does NOT warrant certain parts which are considered expendable such as
gaskets, gas springs, handle assemblies, accessories, antennas, I/O interfaces, modules and fixtures.
TESCOM's responsibility to repair or replace defective products is the sole and exclusive remedy provided
to the customer for breach of this warranty. TESCOM will not be liable for any indirect, extraordinary,
incidental, or consequential damages, despite any advance notice of the possibility of such damages.

Safety Considerations
vii
Review the following safety precautions to avoid personal injury, damage to this product, or damage to
any product connected.
Do not disassemble any part unless listed replaceable in this manual
Do not operate in wet/damp conditions
To avoid injury or fire hazard, do not operate this product in wet or damp conditions.
Do not operate in explosive atmosphere
To avoid injury or fire hazard, do not operate this product in an explosive atmosphere.
Provide proper ventilation
To prevent product overheating, provide proper ventilation.
Do not operate with suspected failures
If there is any damage to this product, have it inspected by qualified service personnel
Environmental Conditions
Refrain from using this equipment in a place subject to intense vibration, direct sunlight, or uneven
ground. Also, use it where the temperature is between 0 °C to 50 °C and relative humidity is less than
85%.

Safety Symbols and Terms
viii
Various symbols are used in this manual and on the product itself to ensure correct usage, to prevent
danger to the user and others, and to prevent property damage. The meanings of these symbols are
described below. It is important that you read these descriptions thoroughly and fully understand its
context.
Safety Terms
WARNING: Identifies conditions or practices that could result in injury or loss of life.
CAUTION: Identifies conditions or practices that could result in damage to the product or other property.
Symbols: The following symbols may appear in this manual or on the product.
Symbol Meaning
 Crush hazard
Moving part can cause serious injury. Must not operate Shield Box when
unauthorized person is in proximity.
Symbol Meaning
Indicates a potentially hazardous situation which,if not avoided, could result in
serious injury and/or equipment damage.
Indicates a potentially hazardous situation which, if not avoided, may result in a
minor or moderate injury and/or equipment damage. It may also be used to
alert against unsafe practices.
Indicates necessary information or useful information for operation and
maintenance.

PART 1.
1
Getting Started

1. Introduction and Specifications
Introduction
2
1.1 Introduction
Shield Box is an equipment that shields wireless products from RF interference which flows in by
radiation or through I/O cables while running tests.
Shield Box is highly effective in shielding as well as being small and sturdy. Therefore, it offers efficient
and economical testing solution for mass production, service, and development.
Key Features
●High RF Shielding
●Pneumatic control of lid open-close and diverse fixture motions
●EMI filters on all Data and DC lines
●Easily customizable to meet various test needs
●Red and Green LED’s for Pass/Fail indication
●RS-232C Remote Control
●High performance absorber for radiation testing
1.2 Specifications
Mechanical Specifications
RF Connectors without I/O Interface Panel Four(4) N(f) outside and SMA(f) inside
Input Voltage 24 VDC
Power Consumption Max 1.5 W
Remote Control RS-232C, 3 wire, DB9(s)
Air Connector Main connector 6 mm OD hose, one-touch push-on fitting
Fixture control connector 4 mm OD hose, one-touch push-on fitting
Input air pressure 5 to 10 bar

Initial Inspection
3
Dimensions Inside 445(W) x 450(D) x 338(H) mm, 208(D) mm top side
Outside 582(W) x 661(D) x 451(H) mm, lid closed, 695(H) mm, lid open
Door 418(W) x 358(D) x 280(H) mm
Weight Approx. 32 kg
*Packing Size 850(W) x 720(D) x 590(H) mm
Weight Approx. 42 kg
*The size and/or weight of packing may vary depending on how the product is packed.
Typical RF Shielding
●The shielding effectiveness below is measured with blank panels; other I/O interface panels may
result in different shielding effectiveness of the shield box.
Frequency Shielding effectiveness (dB)
100 to 2000 MHz > 70 dB
2000 to 3000 MHz > 70 dB
3000 to 6000 MHz > 60 dB
Absorber Reflectivity
●The refelectivity below is verified by measuring signal strength with vector network analyzer after
reflecting it on the absorber.
Frequency Reflectivity (dB)
500 to 2000 MHz 15 dB (Typ.)
2000 to 6000 MHz 20 dB (Typ.)
1.3 Initial Inspection
When Shield Box is delivered, inspect the package and its content as follows:
1Check for any damage that could have occurred during the shipment.
2Verify that you have received the accessories supplied with the Shield Box and its options, which
are listed in 4.1 Exterior and Accessory Inspection

4
Operating Environment
3In case of any abnormality, do not install or operate the product for your own safety. Please
contact TESCOM immediately.
1.4 Operating Environment
Avoid locations with severe vibration, chance of explosion, or direct sunlight. Set Shield Box in a place
at 5 °C ~ 40 °C with humidity of less than 85%.
If Shield Box is not supposed to be used for a long time, securely pack it and store in a dry place at
room temperature.
1.5 Optional Parts Check
Referring to 3. Optional Panels & Fixture , check optional panels and accessories whether they are in
place as you ordered.
1.6 TESCOM Sales and Service Office
If you have difficulty with the product, call or write to our Technical Support specialists at:
TESCOM Company Limited # 927 Unitechvil, 142, Ilsan-ro, Ilsandong-gu, Goyang-si,
Gyunggi-do, Korea [ZIP 10442]
TEL.: [phone]
FAX: [phone]
Email: [email protected]
Website: http://www.tescom.co.kr

PART 2.
5
Hardware Description

2. Hardware Overview
Front
6
2.1 Front
Figure 2-1 TC-5972DP Front Components

Rear
7
Table 2-1 TC-5972DP Front Components
No. Description No. Description
1Lid handle 9Air cylinder
2Lid 10 Body handle
3Hinge 11 Remote switch connector
4RF connector (N(f) outside and SMA(f) inside) 12 Fixture operation button
5Ventilation holes 13 PASS/FAIL LED
6Lid safety guide 14 Power switch
7Lid-open sensor (JP21) 15 Remote Switch
8Lid-close sensor (JP22)
2.2 Rear
Figure 2-2 TC-5972DP Rear Components
Table 2-2 TC-5972DP Rear Components
No. Description No. Description
1Rear handle 4RS-232C Connector
2I/O interface panel 5Air inlet
3RF connector (N(f) outside and SMA(f) inside) 6Power supply

8
Inside
2.3 Inside
Figure 2-3 TC-5972DP Control Box Connection
Table 2-3 TC-5972DP Fixture Air Ports and Sensor Connector
No. Description
1Probe UP air port (Ø4) , speed control function excluded
2Probe DOWN air port (Ø4), speed control function excluded
3Handler IN air port (Ø4), speed control function excluded
4Handler OUT air port (Ø4), speed control function excluded
5Sensor connector DB9 100 pF Pi Filter for sensor cable connection

Control Box
9
Sensor Connector Pin Map
Figure 2-4 TC-5972DP Inside D-SUB 9P (Female) Connector Pin Map
Table 2-4 TC-5972DP Inside D-SUB 9P (Female) Connector Pin Map
Pin Number (Female) Function
1Probe Sensor Signal
2Probe Sensor GND
4Handler Sensor Signal
5Handler Sensor GND
2.4 Control Box

10
Control Box
Figure 2-5 5972DP CPU Board
Table 2-5 TC-5972DP CPU Board Connection
No. Function Connector Description
1RS-232C Communication JP2 RS-232C connector
2Power LED JP3 Power LED connector (remote switch)
3Power Supply JP1 +24V DC input connector
4Pass/Fail LED JP15 Fail LED connector
5JP14 Pass LED connector
6JP13 Fail LED connector (remote switch)
7JP12 Pass LED connector (remote switch)
8Solenoid Valves JP11 Solenoid valve connector for Handler
9JP10 Solenoid valve connector for Probe
10 JP9 Solenoid valve connector for lid
JP8 Solenoid valve connector for lid

Dimensions
11
No. Function Connector Description
11 Sensors JP22 Lid-close detection sensor connector
12 JP21 Lid-open detection sensor connector
13 JP7 Handler-inward detection sensor connector
14 JP6 Probe-downward detection sensor connector
15 Operation Buttons JP4 Gray button connector (remote switch)
16 JP5 White button connector (remote switch)
17 JP16 Fixture operation button connector
2.5 Dimensions
2.5.1 Inner Dimensions

12
Dimensions
2.5.2 Outer Dimensions
