Tesla 32S357SHS User manual

ENG
AL
BiH/CG
HR
SLO
SRB
MK
OPERATING INSTRUCTION
Please read these instructions before operating
your set and retain them for future reference.
UDHËZIM PËR PËR
Ju lutemi lexonie këtë udhëzim para përdorimit të
pajisjë suaj dhe ruajeni për nevoja plotësuese eventuale.
UPUTSTVO ZA UPOTREBU
Prije upotrebe uređaja pročitati ova uputstva
i zadržati ih radi kasnijih referenci.
UPUTE ZA KORIŠTENJE
Prije korištenja uređaja pažljivo pročitati
upute i sačuvati ih za buduću upotrebu.
NAVODILA ZA UPORABO
Pred uporabo pozorno preberite navodila
in jih shranite za morebitno uporabo v prihodnosti.
UPUTSTVO ZA UPOTREBU
Pre upotrebe uređaja pročitati ova uputstva
i zadržati ih radi kasnijih referenci.
  
        
    .
SERIES 332S357SHS
40S357SFS
43S357SFS
49S357SFS
55S357SFS

3
ENG
Note
1. The graphics in this manual are only for reference.
2. Your TV’s OSD may be slightly different with that shown in this manual.
3. The information in this document is subject to change without notice.
The manufacturer accepts no liability for damage resulting directly or indirectly from faults,
incompleteness or discrepancies between the user manual and the product described.
4. In dry environment due to static electricity, the product may be restart and return to the
main OSD interface, USB player interface or the previous source mode, please continue to
operate the TV as your will.
Contents
WARNINGS AND PRECAUTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
PANEL BUTTONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
TERMINALS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
REMOTE CONTROL FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
PERSONAL VIDEO RECORDING (REC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
ELECTRONIC PROGRAMME GUIDE (EPG) . . . . . . . . . . . . . . . . . . . . . . . . . 13
INITIAL SETUP & HOME FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
MENU CONTROL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Menu Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Advanced. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
USB CONTROL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
USB Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Reminder When Using the USB Player . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Movie Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Music Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Photo Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
TROUBLESHOOTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
SPECIFICATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

4
ENG
WARNINGS AND PRECAUTIONS
Read all of the instruction before operating the set. Keep the instruction for later use.
• Read these instructions – All the safety and operating instructions should be read before this
product is operated.
• Keep these instructions – The safety and operating instructions should be retained for future
reference.
• Read all warnings – All warnings on the appliance and in the operating instructions should
be adhered to.
• Follow all instructions – All operating and use instructions should be followed.
• Do not use this apparatus near water – The appliance should not be used near water or
moisture – for example, in a wet basement or near a swimming pool, and the like.
• Clean only with dry cloth.
• Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
• Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
• Do not defeat the safety purpose of the polarized or grounding plug. A polarized plug
has two blades with one wider than the other. A grounding plug has two blades and a
third grounding prong. The wide blade or the third prong is provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
• Protect the power cord from being walked on or pinched particularly at the plugs,
convenience receptacles, and at the point where they exit from the apparatus.
• Only use attachments/accessories specified by the manufacturer.
• Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer,
or sold with the apparatus. When a cart or rack is used, use caution when moving the
cart/apparatus combination to avoid injury from tip-over.
• Unplug the apparatus during lightning storms or when unused for long periods of time.
• Refer all servicing to qualified personnel. Servicing is required when the apparatus has
been damaged in any way, such as power supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
• CAUTION: These servicing instructions are for use by qualified service personnel only.
To reduce the risk of electric shock, do not perform any servicing that contained in the
operating instructions unless you are qualified to do so.
• Do not install this equipment in a confined or building-in space such as a book case or
similar unit, and remain a well ventilation conditions at open site. The ventilation should not
be impeded by covering the ventilation openings with items such as newspaper, table-
cloths, curtains etc.
• Hot Danger. Please don’t touch the area because a hot danger may exit.
• Caution – To prevent electric shock hazard, replace grille.
• Please refer the information on exterior bottom enclosure for electrical and safety
information before installing or operating the apparatus.
• To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
Important Safety Instructions

5
ENG
• The apparatus shall not be exposed to dripping or splashing and that no objects filled with
liquids, such as vases, shall be placed on the apparatus.
• For the terminals marked with symbol of “ ” may be of sufficient magnitude to constitute a
risk of electric shock. The external wiring connected to the terminals requires installation by
an instructed person or the used of ready-made leads or cords.
• To prevent injury, this apparatus must be securely attached to the floor/wall in accordance
with the installation instructions.
• Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type.
• The battery (battery or batteries or battery pack) shall not be exposed to excessive heat such
as sunshine, fire or the like.
• Listening to music at high volume levels and for extended durations can damage one’s
hearing. In order to reduce the risk of damage to hearing, one should lower the volume to a
safe, comfortable level, and reduce the amount of time listening at high levels.
• Headsets should comply with EN 50332-2 requirements (Only for German).
• The mains plug/appliance coupler/direct plug-in adapter is used as disconnect device, the
disconnect device shall remain readily operable.
• When not in use and during movement, please take care of the power cordset, e.g. tie up
the power cordset with cable tie or something like that. It shall be free from sharp edges
and the like that can cause abrasion of the power cordset. When put into use again, please
make sure the power cordset being not damaged, If any damages found, please look for
the service person to replace the power cordset specified by the manufacturer or have the
same characteristics as the original one.
• Attention should be drawn to environmental aspects of battery disposal. Use of the
apparatus in moderate climates.
• Protective earthing terminal.The apparatus should be connected to a mains socket
outlet with a protective earthing connection.
•
No naked flame sources, such as lighted candles, should be placed on the apparatus.
To prevent the spread of fire, keep candles or other open flames away from the
apparatus at all times.
• Means that the equipment is a Class II or double insulated electrical appliance. It has
been designed in such a way that it does not require a safety connection to electrical
earth.
• Using cabinets or stands recommended by the manufacturer of the television.
• Only using furniture that can safely support the television.
• Ensuring the television is not overhanging the edge of the supporting furniture.
• Not placing the television on tall furniture(for example, cupboards or bookcases) without
anchoring both the furniture and the television to a suitable support.
• Not standing the television on cloth or other materials placed between the television and
supporting furniture.
• Educating children about the dangers of climbing on furniture to reach the television or its
controls.
• The apparatus should be provided with a restraining device such as a fixing point to facilitate
restraining the apparatus from toppling forward.

6
ENG
• Install Display on solid horizontal surface such as a table or desk. For ventilation, leave a
space of at least 10cm free all around the set.To prevent any fault and unsafe situations,
please do not place any objects on top of the set. This apparatus can be used in tropical
and/or moderate climates.
WARNING
Do not ingest the battery, Chemical Burn Hazard
(The remote control supplied with) This product contains a coin/button cell battery. If the
coin/button cell battery is swallowed, it can cause severe Internal burns in just 2 hours and
can lead to death.
Keep new and used batteries away from children. If the battery compartment does not
close securely, stop using the product and keep it away from children.
If you think batteries might have been swallowed or placed inside any part of the body,
seek immediate medical attention.
• Do not install this equipment in a confined space such as a bookcase or similar unit.
• Do not use the set near damp and cold areas, protect the set from overheating.
• Keep away from direct sunlight.
• Do not use the set near dust place.
• Do not attach candle to accessible opening area, to avoid flammable foreign material from
entering the TV.
Correct Disposal of this product. This marking indicates that this product should not be
disposed with other household wastes throughout the EU. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, recycle it responsibly to
promote the sustainable reuse of material resources. To return your used device, please use
the return and collection systems or contact the retailer where the product was purchased.
They can take this product for environmental safe recycling.
WEEE Directive
Positioning of the TV Set
Warning for Apparatus containing COIN / BUTTONCELL BATTERIES
Operating Environment

7
ENG
• Use the remote control by pointing it towards the remote sensor. The items between the
remote control and the remote sensor will interfere the normal operation.
• Do not make remote control vibrate violently. Also, do not splash liquid on the remote
control, also do not put the remote control in high humidity place.
• Do not place remote control under direct sunlight which will cause deformation of the unit
by heat.
• When the remote sensor is under direct sunlight or strong lighting, the remote control will
do not work. If so please change the lighting or TV’s position, or operate the remote control
closer to the remote sensor.
Precautions for Using Remote Control
Improper using of the battery will cause leakage. So please do as the following methods
and use carefully.
1. Please note the batteries polarity, to avoid short circuit.
2. When the battery’s voltage is insufficient which affect the use range, you should replace
new battery. Remove the batteries from the remote control unit if you do not intend to use
it for a long time.
3. Do not use different types of batteries (for example, Manganese and Alkaline batteries)
together.
4. Do not put the battery into fire, and charge or decompose the battery.
5. Please dispose batteries abide by relevant environmental protection regulation.
WARNING: The batteries (battery pack or batteries installed) shall not be exposed to excessive
heat such as sunshine, fire or the like.
Precautions for Using Battery
Place two AAA size batteries in the remote controls battery
compartment, making sure to match the polarity markings inside the
compartment.
Note: The images are intended for reference only. Actual items may
differ.
Remote Control Battery Replacement

8
ENG
PANEL BUTTONS
Note: The images are intended for reference only.
Bottom view
Power Indicator /
Remote Sensor
Speakers
Press middle button:
1. In standby mode, press it to turn on the TV;
2. Without OSD, press it to access source menu; press and hold for 5 seconds to turn the TV
to standby;
3. With OSD, short press it to confirm a selection; long press it to return or exit a menu /
submenu.
Push left: decrease volume or go to left.
Push right: increase volume or go to right.
Push forward: channel up or go to above.
Push backward: channel down or go to below.

9
ENG
TERMINALS
Note: The images are intended for reference only.
1. S/PDIF OUT: Use a digital optical cable to connect your TV to a compatible audio receiver.
2. USB: USB port.
3. HDMI: Connect HDMI input signal from signal source such as DVD, HDMI3 port supports
MHL and ARC function.
4. PC IN: Connect a PC to the TV by using a VGA cable.
5. PC AUDIO IN: Audio input for PC and Audio input for HDMI when the signal is DVI timing.
6. ANTENNA IN: Connect a coaxial cable to receive signal from the antenna, cable or
satellite.
7. AV IN: Connect VIDEO input signal from signal source such as DVD.
8. EARPHONE: Audio output, speakers will be muted when earphone is plugged when
select headphone.
9. PCMCIA: PCMCIA port.
10. LAN: Ethernet RJ45 Terminal.

10
ENG
REMOTE CONTROL FUNCTIONS
Remote Control
1. POWER ( ) Press to turn the TV on or to put it
in standby.
2. MUTE ( ) Press to mute or restore the
volume.
3. Numeric buttons Choose channel directly.
4. CHN LIST Press to enter the channel list.
5. RETURN (BACK) Press to go back to a
previously viewed channel.
6. MENU Enter the menu options.
7. SOURCE Select the input source mode.
8. Up/Down/Left/Right (///)
Navigate through the menu.
9. OK Confirm the selection.
10. HOME Press this button will access the
home page, you can use the smart features,
settings and media player etc.
11. EXIT Exit the current menu.
12. YouTube Access the YouTube.
13. INFO Display information about current source.
14. Volume Up/Down (VOL+/VOL-)
Adjust the volume level.
15. Program Up/Down (PR+/PR-)
Change programs up or down.
16. EPG Press to display the current EPG
information in DTV mode.
17. Record (REC) Press to record the current
programme (available in DTV mode only).
18. NICAM Press to select desired sound output
depending on the broadcasting channel.
19. AD (Audio Description)
Press to turn on audio description. Narrator will
describe to blind or visually impaired viewers
what is happening on the screen. Press again
to turn this function off (available in DTV mode
only).

11
ENG
20. FAV. (Favorite Channel)
Press to view your assigned favourite channels.
Press Up/Down buttons to move through your
assigned favourite channels. Press OK to confirm.
21. QUICK Access the quick menu.
22. Color buttons Press to execute the fast-link
function in TV or DTV mode.
23. USB Play Control Buttons
Play & Pause ( )
Press to pause playback, then press again to
continue playback.
Stop ( )
Press to stop playback.
Fast Backward Button ( )
Press to fast reverse.
Fast Forward ( )
Press to fast forward.
TELETEXT BUTTONS
TEXT Press to enter or exit the teletext menu.
SIZE Enlarge the teletext display: Press this
button once to enlarge upper half of the screen.
Press this button again to enlarge lower half of
the screen. Press this button again to return to
normal screen size.
HOLD
Press to hold the teletext page on screen without
update and changes. Press again to release the
hold state.
SUB-PAGE
Press this button to enter or exit subpage mode (if
subpage is available). Press Red / Green button to
select the desired subpage.
INDEX Press this button to display index page.
REVEAL
Press this button to display concealed information,
such as solutions to riddles or puzzles. Press gain
to remove the information from the display.
MIX
Press this button to superimpose the teletext
over the TV programme. Press again to return to
normal teletext
CANCEL
Press this button to temporarily return to TV
programme while searching for a Teletext page.
When the search is done, the page number will
be displayed on the upper left of the screen.
Press again to return to the Teletext page.
21
20
22
23
24

12
ENG
PERSONAL VIDEO RECORDING (REC)
Instant one-touch recording and playback
Timeshift
IMPORTANT NOTE:
In DTV mode and with a USB device properly plugged in, you can record the channel you are
watching and view at a later, more convenient time. Use it to record a program when your
viewing is interrupted or delayed.
1. Please insert an external high-speed storage devices into the appropriate USB port at the
back of the TV, and make sure the device has enough free space.
2. Before the recording, suggest to format your USB device to ensure the operating speed. In
Option menu, select “REC File System” to format the USB device.
3. During the recording, do not change channels or operate another function.
4. If the signal is interrupted or removed, the recording will stop until the signal is established.
This may cause you to lose program content.
5. Please do not turn the TV OFF during recording. This will make the TV exit the REC and
turn to standby.
6. The file recorded can only be used in this TV, any copy communication is strictly prohibited.
7. Use high-quality mobile device to record HD programs, otherwise the videos will be
jammed during the playback.
8. Back up all of the data in the USB storage device in case data was lost due to an
unexpected accident. We do not assume any liability for the losses by misuse or
malfunction. Data backup is consumer’s responsibility.
9. Only in DVB-T/T2 &DVB-C input source, record files can be played from REC_LIST.
Press REC button to start the recording, at the same time below control bar will show at the
bottom of the screen.
Time-shift is the recording of television programs to a storage medium (such as your USB
device) for viewing at a later, more convenient time. Use it to record a program when your
viewing is interrupted or delayed. If you want to leave a while and watch the program
without missing the contents, you can press button to stop the program, and press
button again to start watching when you come back.
• Want to watch the recorded video while recording the program, press left direction button
to select and press OK button, the recorded video will start playing.
Select or can fast backward or fast forward the playing.
• If want to stop and exit the recording, select and press OK button.

13
ENG
Note:
1. Before time-shift, you’d better format the USB device to ensure the enough space for
recording.
2. You can also set the preset time of recording in EPG function (Refer to next page).
EPG stands for Digital Electronic Programme Guide. It is supplied by the programme providers
and offers information about the programmes to be broadcast. You can access it in digital
mode by pressing the EPG button on the remote control.
1. Press the EPG button to enter the EPG interface. Current date and time will be displayed
on the second bar from the top. On the list below, the channel you are currently watching
will be highlighted.
2. To check programmes to be broadcast in future, scroll up using the button to the date
field. Use the button to select the date you want to check.
3. Press the button to scroll up to the top bar in the display, then press the button to
select “Time”, you can check the program list of a channel of someday.
Schedule
Press the yellow button to display the
recording schedule list. You can delete an
appointment by press the red button.
Reminder
Press the blue button to display a reminder
menu. You can set up the remind time and
repeat mode.
Recorder
Press the RED button to display the schedule
setting menu. By using navigation buttons, set
the schedule time by highlight the number of
year, month, day, hour or minute and press
OK button, then use up and down buttons
to adjust the number. Using same method to
set up the repeat mode, and then select
SAVE” button to save the setting.
Info
Press the GREEN button to show information
about the selected program.
ELECTRONIC PROGRAMME GUIDE (EPG)

14
ENG
INITIAL SETUP & HOME FEATURES
Initial setup
The first time you power on the TV, there will show a setup wizard, press ENTER button to
start and finish following steps:
Step 1 Select the OSD language as you need;
Step 2 Select the environment between “HOME” and “STORE”;
Step 3 Select the country;
Step 4 Set up the TV clock (time setting), default is “Auto Sync”;
Step 5 Read the legal statements;
Step 6 Set up the network configuration;
Step 7 Start auto tuning to search for programs, when finished, the programs will be
stored into memories and the initial setup will be completed.
NOTE: Before power on the TV, you need to connect the TV signal cable to the tuner
terminal well on the back of the TV.
Home
Press Home button to access the home page. Use navigation and OK buttons to select
and access a shortcut.
Mirashare (May not be available on some models)
Without a data cable, open the Wi-Fi button on your mobile phone, then select “Mirashare”
on the home screen after pressing HOME button, contents on your mobile phone will be
shared to the TV, you can enjoy the big screen viewing experience.
STEPS:
1. Open the miracast function of your mobile phone;
2. Find the TV name on the mobile phone and select it, the TV will pop out a dialog, accept
it to connect Mirashare function, the contents on your mobile phone will be played on the
TV.
Note: For some models, after selecting the TV name, the mobile phone and the TV can
connect automatically.
Source
Select input source.
Network Applications
Such social applications as Facebook / YouTube / Twitter are provided for you.
For example, select the Facebook icon on the home page, press OK can access.
TV Browser
Select the TV Browser icon on the home page and press OK to access the internet surfing.
Features include speed dial and bookmarks etc.
Note:
1. The browser may not support some web pages or videos due to network failure,
difference of regions or service interruption, which has nothing to do with the TV.
2. If the current page is still not fully opened (progress bar is not completed), other page is
selected directly, the previous page won’t be saved in history.

15
ENG
Media Player
Connect a USB device to the TV and select the Media Player on the home page, you can play a
video/music/photo file in your USB on the TV.
Opera TV
It is an on-line application store made for TV. Open it you can experience various types
of apps, such as News & Weather, Nature & Travel, Kids, Lifestyle, Sports, Music, Live TV &
Video, Games, Movies & TV etc.
Home Media (May not be available)
Sharing videos, music and pictures in your mobile phone or PC to the TV, you need to connect
the TV and your device to the same network.
Note 1 Some of the applications on the home page may not be available on some models,
and this manual doesn’t include the operation instructions of all applications on the home
screen.
Note 2 If service providers upgrade or modify their servers, applications such as YouTube and
Facebook may not function on this Television.
Note 3 Your remote control may not be compatible well with some network applications or fail
due to service interruption, that has nothing to do with this TV.
Note 4
Network application contents and services are controlled by network application
providers by means of networks and transmission facilities, which are subject to
alteration, suspension, removal, termination or interruption, or invalid access at any
time without further notice in that the manufacturer is unable to control or to be
informed of the aforesaid change. The manufacturer makes a further declaration that it
disclaims any responsibility or liability arising from customer’s failure to use the
network application contents and services caused by, including but not limited to,
failure of network connection or communication lines, technological updates, or the
alteration, suspension, interruption, termination, disabling, or removal of any contents
or services by the network application providers etc.
Setting > Network > Wireless Connection/ Wired Connection
Wireless Connection
1. Select “Wireless Connection” and press OK button, and then set “WLAN Switch” on;
2. Wait a few seconds, the wi-Fi spots will be shown on the list, select and press OK button to
open the interface of inputting password.
3. Use navigation buttons to input the password, when finished, press the green button on
the remote control to start the connection.
Wired Connection
1. Connect the network cable to the LAN port at the back of the TV;
2. Access main menu and select network sub-menu.
3. Select “Wired Connection”, and then select “Auto Input”, wait a few seconds, the network
configuration will be finished successfully.
Note: Before getting started, make sure that your router is working well.

16
ENG
MENU CONTROL
Menu Operation
Press “MENU” key to enter the main menu .
Press the [] / [ ] key to select a menu.
Press the [] / [] key to select a menu.
Press “OK” key to enter the item.
Press “MENU” key to exit the item.
Note: The below menu options are under TV sources.
Picture Mode: Select the appropriate picture mode for different purposes.
Backlight: Adjust backlight parameter of the TV.
Color Temperature: Select the overall color tone of the picture.
Dynamic Noise Reduction: Choose between Off, Low, Middle and Strong.
MPEG Noise Reduction: Choose between Off, Low, Middle and Strong.
Aspect Ratio: Select the appropriate display mode for different purposes. Some options
may not be available under some sources and video content.
Dynamic Contrast: Set to On or Off as desired.
Picture Sensor: This feature adjusts the screen brightness automatically when the
brightness of the image changes. If the image is at night, the screen will turn darker
automatically; if the image is at daytime, the screen will turn brighter automatically.
Film Mode: Set to On or Off as desired.
Picture Reset: Reset the picture settings to default values.
Sound
Sound Mode Setting: Choose between Standard, Music, Movie, Sport, User.
Balance: Control the sound balance between the right and left speaker.
Auto Volume: Choose between On and Off.
Surround Sound: Turn virtual surround sound mode On or Off.
Analog Audio Output: This feature is used for selection of Headphone and Line Out.
Plug in a headphone to the headphone terminal of the TV, and you can listening through
the headphone.
Digital Audio Output: This feature is used for selection of Auto and PCM. When connect
a digital audio amplifier to the digital audio out terminal of the TV, select this feature from
SOUND menu and then select the audio output mode.
Audio HDMI: Select the HDMI audio mode, options include: Auto, Digital and Analog.
Audio Description (May not be available): Turn on or turn off the Audio description.
When turn on the audio description, a narrator will describe what is happening on the
screen for blind or visually impaired viewers.
Sound Reset: Reset the sound settings to default values.

17
ENG
Installation
Program Edit
Edit the programs. You can press colored buttons on the remote control to skip programs,
delete programs , and add programs to the favorite list by pressing FAV button.
5V Antenna Power
This option is only available in DVB-T/T2 source, select On to supply power for the TV’s
antenna; Select Off to turn off this function.
CI Information (Only available in DTV mode)
Enables the user to select from the CAM-provided menu. Select the CI menu based on the
menu PC Card.
Signal Information
Showing the information of current DTV channel.
Auto Tuning
Select corresponding source from the source list before starting the auto tuning.
• DVB-S/S2 Auto Tuning
Satellite Dish Settings (Step 1-3, refer to Fig1 and Fig2)
A set of satellite dish settings must be configured for each wanted satellite before
performing a channel scan.
Satellite - Select the satellite for this TV.
Long Cable - Increase LNB power.
LNB Type - Make sure the LNB type is corresponding to your dish.
LNB Power - Enable or disable the power supply for the LNB.
22KHz - Select the 22KHz to set 22K switch to ON/OFF. The auto mode is used to switch
22KHz on or off depending on the LNB type.
DiSEqC1.0/1.1 - Select the DiSEqC mode for the selected LNB.
Unicable/IF Freq/ Set Position - Setting the unicable parameter depend on your disk.
Fig. 1

18
ENG
Step 1 Press MENU button and select INSTALLATION menu. Select DVB-S/S2 auto
tuning and press OK button, the screen will show as Fig1, and the default satellite will
be highlighted.
Step 2 Press OK button to confirm the selected satellite.
Step 3 Press button to switch to LNB setting, press button to highlight LNB Type
and press OK button to set up this parameter.
Step 4 Check if the 22KHz Tone, DiSEqC1.0/1.1 is corresponding to the selected
satellite, if not, highlight and press OK button to set up the right parameter. (Refer to Fig 2)
After the above steps are finished, press the blue button to search for channels.
• DVB-T/T2 or DVB-C or ATV Auto Tuning
Select DVB-T/T2 (or DVB-C/ ATV) Auto Tuning to search the programs automatically Before
searching, you may need to select the country or set up the scan menu. If you want to stop
the auto search, press MENU or EXIT button, a exiting dialog is popped out.
• Press to confirm exit.
• Press to continue searching.
DVB-T/T2 or DVB-C Manual Tuning
Search and store programs manually, first select the corresponding source before starting
search.
1. In Installation menu, select DVB-T/T2 (or DVB-C) manual tuning and press OK to access
the searching interface, first select the country.
2. Second press or to set up relevant parameters such as scan mode, scan scope etc.,
and then select Search and press or to start the search.
3. The search stops when a program is found and this program will be stored in the current
channel position. If you want to stop the search, press MENU button.
Fig. 2

19
ENG
ATV Manual Tuning
In ATV mode, select ATV Manual Tuning and press OK button to access.
1. Use direction buttons to highlight and set up Storage To 1 (maybe other number), Color
System, Sound System and Current Channel. Then select search and press or to start
the search.
•Pressfor the unit to search towards higher frequency;
•Pressfor the unit to search towards lower frequency;
2. When a program is found, press the red button to stored it at the current channel position.
If you want to stop the search, press MENU button.
• Fine-Tune
Use to make small adjustments to tuning of an individual channel. Fine-tune is not
necessary under normal conditions. However, in area of inferior broadcast conditions
where adjustments is necessary for a better picture and sound, use fine-tune.
1. Select a channel that you want to fine tune.
2. In Installation menu, select ATV Manual Tuning and press to highlight Fine-Tune.
3. Press or to fine tune until the best possible picture and sound are obtained.
Setup
OSD Language: Select your desired OSD language.
Audio Language: Set the primary or secondary digital audio language corresponding
to the signal.
Subtitle Language: Select the subtitle language.
Hearing Impaired: This feature is helping hearing-impaired users to understand the
programs by showing the relevant graphic information (similar to subtitle but not subtitle)
on the screen. You need to turn on the switch before using this feature.
Teletext Language: Select the teletext language as your desire.
REC File System: Personal Video Record setting. If you want to use this function, you
must receive a digital program and plug a USB disk.
Note:
Suggest to use a high speed mobile hard disk, or your TV may get stuck when using
the REC and time shift function.
HDMI CEC: Link and control both the TV and its external devices by connecting the
external device to the HDMI port of the TV.
HDMI CEC - Turn on or off HDMI CEC function.
Auto Standby - Turn the TV to standby automatically.
Device List - When HDMI CEC is on, you check the device list of connecting to the TV.
Location: Select the location mode of playing at home or at store, when select “Store”,
you can turn on the sticker demo.
Presentation: Turn on or turn off the sticker demo and USB demo.
USB demo:
1. Required settings: Add “AutoDemo.txt” txt file at the root directory of a USB device,and
then write the route of videos need to be played on the TV, each route needs a line break.
2. When “USB Demo” is set up as “On”, the TV will automatically play the videos in the
“AutoDemo.txt”, after played all videos, TV will go back to play the previous watching
program. After five mintues, the TV will cycle playing wrote videos and program.
3. The route should be wrote in English or numbers, otherwise the TV can’t identify it.

20
ENG
Software Update:
1. Software update (USB)
Firstly download and save the upgrading software into a USB device, secondly connect the
USB device to a TV USB port, thirdly access “Setup” menu and select “Software update”, then
select “Software update (USB)” to start the upgrading process. When finished, the TV will
restart automatically.
NOTE: Do not power off the TV during the software upgrading process, otherwise the TV
may not work, and the customer should be responsible.
2. Software Update (Network)
Connect the TV to the internet and you can upgrade the TV system or a network application
on the TV.
NOTE: “Network Upgrade” may not be available for some regions.
3. Software Update (OAD) (Only for some regions and only available in DVB-T mode)
Select it to update the TV system software over the air.
Advanced Option: Set up “Fast Boot” and “Wake on Network” function.
Blue Screen: When Blue Screen is set to On, the screen will turn blue and the sound will
be muted when there is no signal received.
User Reset: Reset the menu settings to default values.
Legal Statements: Relevant legal statements.
Time
Clock: Set up the TV clock, time zone and summer time.
Clock mode - Options include Auto and Manual. When select “Auto”, the TV clock
will synchronize with the real time digital TV signal. When select “Manual”, you
need to manually set up the clock time, including setting up the number of year,
month, date, hour and minute.
Time zone - Select the time zone according to your location.
Summer time (Daylight saving time)- You can turn on or turn off this function.
Off Timer: The feature allows you to set the TV to turn off automatically at a regular time.
On Timer: The feature allows you to set the TV to turn on automatically to a preset input
or volume.
Sleep Timer: Set the automatic off time of the TV.
Automatic Power down: Set up the time to automatically turn off the TV on condition
that there is no operation.
Continuous viewing timer: To prevent watching TV continuously for long periods of
time, you can set a message to appear that suggests that the viewer takes a break. This
is especially useful for preventing children from watching TV for long periods of time.
From TIME menu select Continuous Viewing Timer and set the time. When the set time
has passed, a message suggesting the viewer takes a break appears. Press OK or EXIT to
clear the message.
