TEUCER LR-4RGB User manual
The LR-4RGB/4RGBW remote enables one to control up to 4
zones of RGBW LED strips.
Featuring a touch colour wheel which oers smooth and
connuous colour changing opons and enables creaon of
colourful stac and dynamic eects. Users can switch on or
o all individual RGBW colours.
Product ImageProduct Descripon
Technical Specicaon
Brighter for longer
CONTROLLER AND RECEIVER
www.teucerled.co.uk
Controller
Order Code LR-4RGB/4RGBW
Type RF Remote
Input Voltage 3VDC
Operaon Frequency 2.4GHz
Dimension 58.5x107x9mm (WxLxH)
Power baery CR2032
Receiver
Order Code R4C
Type RF receiver
Input Voltage 12-36VDC
Current 4x5A
Output 4X(60-180)W
Note Constant voltage
Dimension 45x175x27mm (WxLxH)
• Easy control of RGBW LED strips.
• Single zone, two, three and four zone control.
• 2.4GHz wireless technology, remote distance of up to
30m.
• Operates with an LED indicator light for ease of use.
• Each remote can control one or more receivers.
• Control each zone separately or simultaneously
• PWM dimming enables icker-less dimming
Features
RF technology allows for greater exibility when it comes to
controlling simple or complex lighng installaons without
the need of addional cabling.
There are some limitaons where installaons have the
receivers enclosed in electrical boxes or hidden away in a
ceiling , reducing the RF signal strength and therefore the
communicaon range.
In order to overcome these RF Signal restricons we sug-
gest the following when synchronising our RF controllers
and receivers:
• Keep the distance within 10 meters from the controller
to the receiver. The remote can operate up to 30mtrs if
signal is uninterrupted by obstacles.
• When expanding your lighng, always try and use a
signal repeater (PR-RGB), where possible.
• If your installaon requires several RF receivers, ensure
the “master” receiver is posioned in the middle.
Recommendaon
LR-4RGB/4RGBW and R4C
4 zones RF controller and 4 zones receiver for RGBW LED strip
Receiver wiring diagram
Controller layout
Brighter for longer
CONTROLLER AND RECEIVER
www.teucerled.co.uk
R4C
RGBW LED strip
Power supply
+
R
G
B
W
1234
colour wheel
Decrease brightness Increase brightness
Play mode
Zones
White
LR-4RGB/4RGBW and R4C
4 zones RF controller and 4 zones receiver for RGBW LED strip
Synchronising the remote to receiver
Brighter for longer
CONTROLLER AND RECEIVER
www.teucerled.co.uk
1) Ensure the receiver has power. Press the match buon on the receiver. Indicator will start ashing.
4) To restore to factory default sengs and delete the allocated con-
troller, press and hold the match buon longer than 5 seconds.
2) Choose the zone on the remote to allocate the receiver within 5 seconds aer pressing the match buon.
The indicator will stop ashing, and the controller will be synchronised.
Match bu�on
R4C
Press the zone
you wish to allocate
1234
Troubleshoot
Problem Cause Correcve
No light • No power.
• Wrong connecon or unsecure connec-
on.
• Check the power.
• Check the connecon.
Wrong Colour • Wrong connecon of RGBW wires. • Re trace and reconnect
RGBW wires.
Uneven intensity be-
tween front and rear of
the strip, with voltage
drop
• Output cable is too long.
• Cable diameter is too small.
• Overload beyond driver capability.
• Overload beyond receiver capability.
• Reduce cable or loop sup-
ply.
• Change to a thicker cable.
• Replace with a suitable
higher power driver.
• Add a power repeater.
No response
from the remote
• The baery has no power.
• Beyond controllable distance.
• The controller isn’t synchronised with the
remote.
• Replace baery.
• Reduce remote to receiver
distance.
• Re-sync the remote.
3) Repeat the process to allocate zones for all receivers.
LR-4RGB/4RGBW and R4C
4 zones RF controller and 4 zones receiver for RGBW LED strip
Teucer (UK) Ltd
Head oce
Bedford House, Fulham Green, Fulham High Street,
London, SW6 3JW, UK
Tel: +44 (0)20 7350 4429
Fax: +44(0)20 7228 4647
www.teucerled.co.uk
sales@teucer.eu
Logiscs Centre
Trident Court,
1 Oakcro Road,
Chessington,
Surrey, KT9 1BD, London, UK
Tel: +44(0)20 7350 4429, extension: 401
warehouse@teucer.eu
Controlling your LED strip
Brighter for longer
CONTROLLER AND RECEIVER
www.teucerled.co.uk
Warranty
• Products must be installed and serviced by qualied
electrician.
• Please ensure the receiver is mounted in a water proof
enclosure if installed in an outdoor environment,
avoiding metallic enclosures.
• Always ensure products are mounted in areas with
adequate venlaon to avoid overheang.
• Please ensure outputs of any power suppliers used in
conjucon with this product comply with its working
voltage.
• Never install product whilst connected to power and
double check connecons before switching on to
avoid short circuits.
Safety
Should this product fail during the 3 year warranty
period it will be replaced free of charge, subject to the
correct installaon of the original product in accordance
with applicable and appropriate electrical codes and
instrucons provided by Teucer, as well as subsequent
return of the faulty unit. Teucer does not accept
responsibility for any installaon costs associated with
the replacement of this product and Teucer reserves the
right to alter specicaons without prior noce. Teucer
can oer 5 year warranty upon request. For further
informaon, please see our Terms and Condions.
www.teucerled.co.uk/terms-and-condions/
• Choose the zone(s) you
wish to control.
• To change the colour, use
the touch sensive colour
wheel.
• To adjust the brightness,
press the buons to in-
crease / decrease bright-
ness.
1234
Touch sensi�ve
colour wheel ON/OFF
Decrease brightness Increase brightness
Play mode
Zones
Scene save / recall
White
• There are several dynamic modes, press the play mode buon to browse thorugh modes. To
choose the mode, press and hold play mode for 2 seconds.
• There are 10 speeds for the play modes. Press the speed buon to browse through the speed
levels.
• Press and hold the speed buon to go to the highest speed level.
• To save your favourite setup, press and hold scene buons.
• To recall saved setup, press scene buon.
LR-4RGB/4RGBW and R4C
4 zones RF controller and 4 zones receiver for RGBW LED strip
